Municipally-Initiated Zoning By-law & Official Plan Amendments for parts of the Elgin, Central and Memorial neighbourhoods in Bowmanville COPA2019-0002 & ZBA2019-0019 Public Meeting: January 13 th 2020 Planning Services Department
Public Meeting: January 13th 2020
Planning Services Department
April 11
Notice of Project Commencement
May 11
Walking Tour
May 11 – 31
Online Survey Self-Guided Walking Tour
May 30
Character Workshop
September 12
Options & Analysis Workshop
December 4
Notice of Project Completion
Illustration of Current Zoning Provisions Illustration of Proposed Zoning Provisions
R1 Zone Regulation Current 84-63 Provision Proposed Character Overlay Regulations Front Yard (minimum) 6m to private garage or carport and 4.5m to dwelling The dwelling shall be within 1.0m of the established building line; 6.0m (min.) to attached garage or carport Exterior Side Yard (minimum) 6m Interior Side Yard (minimum) a) With an attached garage or carport b) Without an attached garage a) Single/Semi/Duplex = 1.2m b) Single = 4.5m on one side, 1.2m on the
Semi/Duplex = 3.0m a) 1.2m for the first storey, plus an additional 0.6m for each additional full storey above the first storey b) 1.2m for the first storey plus an additional 0.6m for each additional full storey above the first storey on one side and 3.0m on the other side
R1 Zone Regulation Current 84-63 Provision Proposed Character Overlay Regulations Lot Coverage (maximum) i) Single detached dwelling = 40 percent ii) Semi-detached and duplex dwelling = 45 percent i) For dwellings 1.5 storeys or less = 35 percent ii) For dwellings greater than 1.5 storeys = 30 percent Landscaped Open Space (minimum) 30 percent i) Overall = 40 percent ii) Front Yard = 50 percent, which shall not include hard surfaced areas such as driveways, aisles, parking areas, interlocking stone and walkways
R1 Zone Regulation Current 84-63 Provision Proposed Character Overlay Regulations Building Height (maximum) 10.5m 8.5m in Area 1 and 9.0m in Areas 2 and 3 Special Regulations i) Private garages and carports may extend a maximum of 3.0m in front of the dwelling unit. This provision shall apply to all lots registered after June 30, 2000. i) A private garage, attached garage or carport may not extend in front of the dwelling unit ii) Where an attached garage faces a street, the maximum permitted outside width of the garage shall be 25 percent of the total frontage of the lot for single detached dwellings and 35 percent of the lot for semi-detached dwellings iii) An attached garage or carport shall be setback a minimum of 1.0 metres from the front or exterior side wall of the dwelling
Street Local Corridor and established neighbourhoods
principal dwellings
Illustrative Guide
to the established neighbourhood;
neighbourhood with proportional rear yard space and appropriate landscaping that enhances the adjacent established neighbourhood context;
architectural form, and materiality; and
screening from the adjacent neighbourhood to reduce impacts.
2nd front door to apartment-in-house 1 front door – shared entrance to basement apartment
Council consideration
Planning Services Department
www.Clarington.net/ncs
