More Trike, More Fun 2 Person Surrey Bike (MS-2) Technical Data Components Overall width 105 cm Frame Reinforced steel Overall height 185 cm Paint Powder coat Motorcycle tire, 2.25-16 front/2.5- Overall length 180 cm Tire 18 rear 59.5 cm

SLIDE 1

More Trike, More Fun

SLIDE 2

SLIDE 3

SLIDE 4

SLIDE 5

SLIDE 6

SLIDE 7

SLIDE 8

SLIDE 9

SLIDE 10

SLIDE 11

SLIDE 12

SLIDE 13

SLIDE 14

SLIDE 15

SLIDE 16

2 Person Surrey Bike (MS-2) Technical Data Components Overall width 105 cm Frame Reinforced steel Overall height 185 cm Paint Powder coat Overall length 180 cm Tire Motorcycle tire, 2.25-16 front/2.5- 18 rear Track width 59.5 cm front/78.5 cm rear Rim Motorcycle steel rim Wheel base 130 cm Brake Dual rear drum brakes Ground clearance 28 cm Seat Faux leather Seat height 78.5 cm Steering wheel Dual steering wheels (right side inoperable) Seat width 104.5 cm Floorboard Aluminum alloy Seat depth 34.5 cm Pedal Aluminum alloy Turning circle 3.1 m Headlamp Dual Headlamps Net weight 98 kg Awning Waterproof canvas Gross weight 122 kg Stainless steel features Fenders, bumpers, uprights, brake lever Carton size 184 x 102 x 62 cm Option (MS-2E) Wheel size 17" front/19" rear Motor 60v 1500w rear hub motor

Max. load

250 kg Battery 60v 32Ah lead acid battery Display LCD display Pedal assist Cadence sensor

SLIDE 17

4 Person Surrey Bike (MS-4) Technical Data Components Overall width 105 cm Frame Reinforced steel Overall height 190 cm Paint Powder coat Overall length 260 cm Tire Motorcycle tire, 2.25-16 front/2.5- 18 rear Track width 59.5 cm front/78.5 cm rear Rim Motorcycle steel rim Wheel base 203.5 cm Brake Dual rear drum brakes Ground clearance 28 cm Seat Faux leather Seat height 78.5 cm Steering wheel Dual steering wheels (right side inoperable) Seat width 104.5 cm Floorboard Aluminum alloy Seat depth 34.5 cm Pedal Aluminum alloy Turning circle 3.1 m Headlamp Dual Headlamps Net weight 128 kg Awning Waterproof canvas Gross weight 157 kg Stainless steel features Fenders, bumpers, uprights, brake lever Carton size 264 x 102 x 62cm Option (MS-4E) Wheel size 17" front/19" rear Motor 60v 1500w rear hub motor

Max. load

450 kg Battery 60v 32Ah lead acid battery Display LCD display Pedal assist Cadence sensor

SLIDE 18

6 Person Surrey Bike (MS-6) Technical Data Components Overall width 105 cm Frame Reinforced steel Overall height 190 cm Paint Powder coat Overall length 355 cm Tire Motorcycle tire, 2.25-16 front/2.5- 18 rear Track width 59.5 cm front/78.5 cm rear Rim Motorcycle steel rim Wheel base 309.3 cm Brake Dual rear drum brakes Ground clearance 28 cm Seat Faux leather Seat height 78.5 cm Steering wheel Dual steering wheels (right side inoperable) Seat width 104.5 cm Floorboard Aluminum alloy Seat depth 34.5 cm Pedal Aluminum alloy Turning circle 3.1 m Headlamp Dual Headlamps Net weight 148 kg Awning Waterproof canvas Gross weight 177 kg Stainless steel features Fenders, bumpers, uprights, brake lever Carton size 355 x 105 x 62cm Option (MS-4E) Wheel size 17" front/19" rear Motor 60v 1500w rear hub motor

Max. load

900 kg Battery 60v 32Ah lead acid battery Display LCD display Pedal assist Cadence sensor
