Modeling and Analysis of Signal Estimation for Stepper Motor Control Dan Simon Cleveland State University October 8, 2003 Outline Problem statement Simplorer and Matlab Optimal signal estimation Postprocessing


slide-1
SLIDE 1

Modeling and Analysis of Signal Estimation for Stepper Motor Control

Dan Simon Cleveland State University October 8, 2003

slide-2
SLIDE 2

Outline

  • Problem statement
  • Simplorer and Matlab
  • Optimal signal estimation
  • Postprocessing
  • Simulation results
  • Conclusion
slide-3
SLIDE 3

Problem statement

  • Speed control for PM DC motor
  • Aerospace applications

– Flywheel energy storage – Flight control trim surfaces – Hydraulics – Fans – Thrust vector control – Fuel pumps

slide-4
SLIDE 4

Problem statement

DC Machine Permanent Excitation

J T J kI L k L RI L V I

L /

/ / / / − = − − = ω ω

  • I = armature current

V = armature voltage L = inductance R = resistance k = motor constant ω = rotor speed θ = rotor angle J = moment of inertia TL = load torque

slide-5
SLIDE 5

State assignment:

  • x1 = I
  • x2 = ω
  • x3 = θ
  • x4 = TL / J

Measurements:

  • y = current (and possibly position)

Problem statement

slide-6
SLIDE 6

Problem statement

Estimate velocity x2

noise 1 1 y noise / 1 1 1 / / / +       = +             +             − − − = x V L x J k L k L R x

slide-7
SLIDE 7

Simplorer and Matlab

  • Simplorer

– Circuit element models – Electric machine models – Data analysis tools – Interfaces with Matlab / Simulink

slide-8
SLIDE 8

Simplorer and Matlab

  • Matlab

– Powerful math and matrix capabilities

  • Co-Simulation

– Link Simplorer and Matlab – Plot and analyze data in either environment

slide-9
SLIDE 9

Simplorer and Matlab

  • Use the SiM2SiM tool in

Add Ons / interfaces6

  • Begin the simulation in Simulink
slide-10
SLIDE 10

Simplorer and Matlab

Define Simplorer inputs and outputs in the property dialog of the SiM2SiM component Simplorer ↔ Simulink

slide-11
SLIDE 11

Simplorer and Matlab

  • Use the S-function property dialog in Matlab

to link Simplorer / Matlab signals

slide-12
SLIDE 12

Simplorer and Matlab

  • Begin the simulation in Matlab
  • Couple Simplorer’s and Matlab’s strengths

– Simplorer: power electronics, electromechanics, data analysis, state diagrams – Matlab: matrix algebra, toolboxes

  • Data analysis / viewing can be done in

either Simplorer or Matlab

slide-13
SLIDE 13

Optimal signal estimation

Given a linear system:

Dv Cx y w B u B Ax x

w u

+ = + + =

  • x = state

y = measurement u = control input w, v = noise Find the best estimate for the state x

slide-14
SLIDE 14

Optimal signal estimation

Suppose w ~ N(0, Q) and v ~ N(0, R). The Kalman filter solves the problem

{ }

) ˆ ( ˆ ˆ ) ˆ ( ) ˆ ( min

1 1

x C y K x A x D R D PC K KCP QB B PA AP P dt x x x x E

T T T w w T T

− + = = − + + = − −

− − −

slide-15
SLIDE 15

Optimal signal estimation

The H∞ filter solves the problem

θ 1 ) ( ˆ ) ( ˆ

2 2 2 2

1 1 1

< + + − −

∫ ∫ ∫

− − −

dt v dt w x x dt x x

R Q P S

This is a game theory approach. Nature tries to maximize the estimation error. The engineer tries to minimize the error.

Dv Cx y w B u B Ax x

w u

+ = + + =

slide-16
SLIDE 16

Optimal signal estimation

Rewrite the previous equation:

J J dt v w dt x x x x

x v w x R Q S P ) ( , , ˆ 2 2 2 2

max min 1 ˆ ) ( ˆ ) ( 1

1 1 1

< < + − − + − −

∫ ∫

− − −

θ θ

Game theory: nature tries to maximize J and the engineer tries to minimize J

slide-17
SLIDE 17

Optimal signal estimation

The H∞ filter is given as follows:

) ˆ ( ˆ ˆ

1 1

x C y K x A x D R D PC K PSP KCP QB B PA AP P

T T T w w T

− + = = + − + + =

− − −

  • θ

Note this is identical to the Kalman filter except for an extra term in the Riccati equation.

slide-18
SLIDE 18

Optimal signal estimation

  • The Kalman filter is a least-mean-squares

estimator

  • The H∞ filter is a worst-case estimator
  • The Kalman filter is often made more

robust by artificially increasing P

  • The H∞ filter shows exactly how to

increase P in order to add robustness PSP KCP QB B PA AP P

T w w T

θ + − + + =

slide-19
SLIDE 19
  • Steady state:

Optimal signal estimation

) ˆ ( ˆ ˆ

1 1

x C y K x A x D R D PC K PSP KCP QB B PA AP P

T T T w w T

− + = = = + − + + =

− − −

  • θ
  • This is an Algebraic Riccati Equation
  • Real time computational savings

Jacopo Riccati 1676-1754

slide-20
SLIDE 20

Postprocessing

Transfer Matlab data to Simplorer for plotting and analysis

slide-21
SLIDE 21

Postprocessing

  • Start the Matlab postprocessor interface

before starting the co-simulation

  • After running the co-simulation, the Day

postprocessor can exchange data with Matlab

slide-22
SLIDE 22

Postprocessing

Drag data between Day and Matlab

Matlab commands Matlab output Matlab variables

slide-23
SLIDE 23

Postprocessing

  • Day cannot handle arrays with more than

two dimensions – use Matlab’s “squeeze” command

  • Make sure Matlab data is not longer than

Simplorer’s time array

slide-24
SLIDE 24

Postprocessing

Simplorer data Matlab data

slide-25
SLIDE 25

Postprocessing

Analysis Characteristics to view statistical information

Select the desired

  • utput variable

Export to table

slide-26
SLIDE 26

Simulation results

motor parameters measurements control input Ouput from Matlab

slide-27
SLIDE 27

Simulation results

equations ˆ and implement x P

  • motor

PI Controller

slide-28
SLIDE 28

Simulation parameters:

  • 1.2 ohms, 9.5 mH, 0.544 Vs, 0.004 kg⋅m2
  • Initial speed = 0

cmd speed = 1000 RPM

  • External load torque

changes from 0 to 0.1

  • Measurement errors

0.1 A, 0.1 rad (1 σ)

Simulation results

slide-29
SLIDE 29

Simulation results

slide-30
SLIDE 30

Steady state parameters:

  • Initial speed = 1000

commanded speed = 1000 RPM

  • External load torque = 0
  • Measurement error = 0.1 A, 0.1 rad (1 σ)

Simulation results

slide-31
SLIDE 31

Simulation results

slide-32
SLIDE 32

Simulation results

slide-33
SLIDE 33

Simulation results

0.058 0.035 L = 2 L 938 941 k = 2 k 0.082 0.078 J = 2 J 0.120 0.122 R = 2 R 828 834 k = k / 2 0.060 0.060 J = 0.6 J 0.056 0.032 L = L / 2 0.106 0.102 R = R / 2 0.057 0.033 Nominal H∞ filter Kalman filter

RMS Estimation Errors (RPM) current and position measurements

slide-34
SLIDE 34

Simulation results

Now suppose we measure winding current but not rotor position. Can we still get a good estimate of motor velocity? [ ]

sigma)

  • ne

amps, (0.1 noise 1 y noise / 1 1 1 / / / + = +             +             − − − = x V L x J k L k L R x

slide-35
SLIDE 35

Simulation results

0.038 0.036 L = 2 L 959 959 k = 2 k 0.081 0.081 J = 2 J 0.154 0.154 R = 2 R 939 941 k = k / 2 0.060 0.060 J = 0.6 J 0.036 0.034 L = L / 2 0.102 0.102 R = R / 2 0.036 0.034 Nominal H∞ filter Kalman filter

RMS Estimation Errors (RPM) current measurement only

slide-36
SLIDE 36

Conclusion

  • Motor state estimation is required for

motor control

  • Kalman filtering and H∞ filtering can be

used for motor state estimation

  • Steady state filtering saves time
  • Simplorer / Matlab co-simulation
  • Estimate motor parameters R, L, J, k
