Modal µ-Calculus and Alternating Tree Automata

Seminar “Automata, Logics, and Infinite Games”

Patrick Bahr s0404888@inf.tu-dresden.de

Dresden, February 1, 2008

Outline

Modal µ-Calculus Introduction Syntax Semantics Auxiliary Notions Translation into Alternating Tree Automata [Alternating Tree Automata] Construction of Equivalent Alternating Tree Automata Model-Checking and Satisfiability Conclusion

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 2 of 28

Outline

Modal µ-Calculus Introduction Syntax Semantics Auxiliary Notions Translation into Alternating Tree Automata [Alternating Tree Automata] Construction of Equivalent Alternating Tree Automata Model-Checking and Satisfiability Conclusion

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 3 of 28

01 Introduction to µ-Calculus

• introduced in the context of systems verification
• basic modal language (i.e. Boolean connectives plus modal connectives)
• interpret Boolean and modal connectives as set-theoretic operations
• additional connectives to define fixed points
• great expressive power
• includes many temporal logics e.g. CTL* and PDL
• computationally “well-behaved”

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 4 of 28

01 Syntax of the µ-Calculus Lµ

• In the following we fix a set of atomic propositions P.

Definition (Lµ formulae)

The set of formulae of the modal µ-calculus, denoted by Lµ is defined by the following grammar: ϕ, ψ ::= ⊥ | ⊤ | p | ¬ϕ | ϕ ∧ ψ | ϕ ∨ ψ | ϕ | ♦ϕ | µp.ϕp | νp.ϕp

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 5 of 28

01 Syntax of the µ-Calculus Lµ

• In the following we fix a set of atomic propositions P.

Definition (Lµ formulae)

The set of formulae of the modal µ-calculus, denoted by Lµ is defined by the following grammar: ϕ, ψ ::= ⊥ | ⊤ | p | ¬ϕ | ϕ ∧ ψ | ϕ ∨ ψ | ϕ | ♦ϕ | µp.ϕp | νp.ϕp where p ∈ P and ϕp is restricted to only contain p in the scope of an even number

• f negation connectives “¬”.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 5 of 28

01 Example Lµ-Formulae

Example

ϕ1 = µp.¬(µp′.(¬q ∨ p′) ∨ ¬p) is well-formed

ϕ1 : µp ¬ µp′ ∨ ∨ ¬ ¬

• q

p′ p

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 6 of 28

01 Example Lµ-Formulae

Example

ϕ1 = µp.¬(µp′.(¬q ∨ p′) ∨ ¬p) is well-formed

ϕ1 : µp ¬ µp′ ∨ ∨ ¬ ¬

• q

p′ p

Example

ϕ2 = µp.¬(µp′.(¬q ∨ p′) ∨ (¬p ∧ p)) is not well-formed ϕ2 : µp ¬ µp′ ∨ ∨ ∧ ¬

• ¬

p q p′

• p

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 6 of 28

01 Example Lµ-Formulae

Example

ϕ1 = µp.¬(µp′.(¬q ∨ p′) ∨ ¬p) is well-formed

ϕ1 : µp ¬ µp′ ∨ ∨ ¬ ¬

• q

p′ p

Example

ϕ2 = µp.¬(µp′.(¬q ∨ p′) ∨ (¬p ∧ p)) is not well-formed ϕ2 : µp ¬ µp′ ∨ ∨ ∧ ¬

• ¬

p q p′

• p

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 6 of 28

01 Fixed Point Connectives bind Atomic Propositions

Definition (Free Occurrences of Atomic Propositions)

The set free(ϕ) of atomic propositions occurring freely in ϕ: free(⊤) = free(⊥) = ∅, free(p) = {p}, free(ϕ ∨ ψ) = free(ϕ ∧ ψ) = free(ϕ) ∪ free(ψ), free(¬ϕ) = free(ϕ) = free(♦ϕ) = free(ϕ), free(µp.ϕ) = free(νp.ϕ) = free(ϕ) \ {p}.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 7 of 28

01 Kripke Models

Definition (Kripke Models)

A Kripke model is a triple K = (W, R, λ) where

• W, the universe of K, is a set of worlds,
• R ⊆ W × W is an accessibility relation, and
• λ : P → 2W is a valuation of the atomic propositions.

For w ∈ W we will call (K, w) a pointed Kripke model.

Definition (Update of Kripke Models)

Let K = (W, R, λ) be a Kripke model.

• λ[p′ → W ′](p) =
• W ′

if p = p′ λ(p)

• therwise

for all p ∈ P.

• K[p′ → W ′] = (W, R, λ[p′ → W ′])

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 8 of 28

01 Semantics of the µ-Calculus

Definition (Semantics of µ-Calculus)

Let K = (W, R, λ) be a Kripke model. For every Lµ formula ϕ the set ϕK ⊆ W is defined as follows: ⊥K = ∅, ⊤K = W, pK = λ(p) for all p ∈ P, ¬ϕK = W \ ϕK, ϕ ∨ ψK = ϕK ∪ ψK, ϕ ∧ ψK = ϕK ∩ ψK, ϕK = {w ∈ W | wR ⊆ ϕK}, ♦ϕK = {w ∈ W | wR ∩ ϕK = ∅}, µp.ϕK = {W ′ ⊆ W | ϕK[p→W ′] ⊆ W ′}, νp.ϕK = {W ′ ⊆ W | ϕK[p→W ′] ⊇ W ′}.

• (K, w) |

= ϕ if w ∈ ϕK.

• ϕ ≡ ψ if for all pointed Kripke models (K, w) we have that (K, w) |

= ϕ iff (K, w) | = ψ.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 9 of 28

01 Semantics of Fixed Point Connectives in Detail

• Reconsider µp.ϕK =

{W ′ ⊆ W | ϕK[p→W ′] ⊆ W ′}.

• This implicitly refers to the function:

g : 2W → 2W , W ′ → ϕK[p→W ′]

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 10 of 28

01 Semantics of Fixed Point Connectives in Detail

• Reconsider µp.ϕK =

{W ′ ⊆ W | ϕK[p→W ′] ⊆ W ′}.

• This implicitly refers to the function:

g : 2W → 2W , W ′ → ϕK[p→W ′]

• Now µp.ϕK =

{W ′ ⊆ W | g(W ′) ⊆ W ′}

• Due to syntactic restriction w.r.t. bound propositions: g is monotone!
• µp.ϕK = least fixed point of g. [Knaster-Tarski-Theorem]

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 10 of 28

01 Semantics of Fixed Point Connectives in Detail

• Reconsider µp.ϕK =

{W ′ ⊆ W | ϕK[p→W ′] ⊆ W ′}.

• This implicitly refers to the function:

g : 2W → 2W , W ′ → ϕK[p→W ′]

• Now µp.ϕK =

{W ′ ⊆ W | g(W ′) ⊆ W ′}

• Due to syntactic restriction w.r.t. bound propositions: g is monotone!
• µp.ϕK = least fixed point of g. [Knaster-Tarski-Theorem]
• Dually νp.ϕK = greatest fixed point of g.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 10 of 28

01 Equivalences

Lemma (Equivalences)

Let ϕ, ψ ∈ Lµ and p, q ∈ P, s.t. q does not occur in ϕ. Then we have the following equivalences: (i) µp.ϕ ≡ µq.ϕ[p/q] (ii) νp.ϕ ≡ νq.ϕ[p/q], (iii) ¬¬ϕ ≡ ϕ, (iv) ϕ ∨ ψ ≡ ¬(¬ϕ ∧ ¬ψ), (v) ♦ϕ ≡ ¬¬ϕ, (vi) µp.ϕ ≡ ¬νp.¬ϕ[p/¬p].

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 11 of 28

01 Some Examples

Example

Consider ϕ1 = µp.p. (K, w) | = ϕ1 iff all paths in K starting in w are finite.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 12 of 28

01 Some Examples

Example

Consider ϕ1 = µp.p. (K, w) | = ϕ1 iff all paths in K starting in w are finite.

Example

Consider ϕ2 = µp. (ψ ∨ ♦p). (K, w) | = ϕ2 iff there is a world w′ in K in which ψ holds and which is reachable from w.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 12 of 28

01 Some Examples

Example

Consider ϕ1 = µp.p. (K, w) | = ϕ1 iff all paths in K starting in w are finite.

Example

Consider ϕ2 = µp. (ψ ∨ ♦p). (K, w) | = ϕ2 iff there is a world w′ in K in which ψ holds and which is reachable from w.

Example

Consider ϕ3 = νp.µq. ((ψ ∧ p) ∨ ♦q) (K, w) | = ϕ2 iff ψ holds infinitely often on a path starting in w.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 12 of 28

01 Some Examples

Example

Consider ϕ1 = µp.p. (K, w) | = ϕ1 iff all paths in K starting in w are finite.

Example

Consider ϕ2 = µp. (ψ ∨ ♦p). (K, w) | = ϕ2 iff there is a world w′ in K in which ψ holds and which is reachable from w.

Example

Consider ϕ3 = νp.µq. ((ψ ∧ p) ∨ ♦q) (K, w) | = ϕ2 iff ψ holds infinitely often on a path starting in w.

Intuitive Semantics of Fixed Point Connectives

• µ specifies properties of finite paths
• ν specifies properties of infinite paths

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 12 of 28

01 Normal Forms

Definitions

To make the translation into an alternating tree automaton easier, normal forms of Lµ formulae are considered.

Definition (Normal Forms)

Let ϕ ∈ Lµ. (i) ϕ is standardised apart if every atomic proposition in ϕ occurs either only free

• r is bound exactly once.

The subformula ηp.ψ uniquely determined by p will be denoted by ϕp. (ii) ϕ is in negation normal form if ¬ψ ≤ ϕ implies ψ ∈ P for every ψ ∈ Lµ. That is, the negation connective only occurs in front of atomic propositions. (iii) ϕ is in normal form if it is standardised apart and in negation normal form.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 13 of 28

01 Normal Forms

Notes

• For every formula ϕ there is an equivalent formula ϕ′ that is in normal form.
• |ϕ′| ≤ 2 · |ϕ|.
• Transformation to normal form takes linear time.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 14 of 28

01 Alternation Depth

Definition (Alternation Depth)

Let ϕ be an Lµ formula being standardised apart. The alternation depth of ϕ, denoted α(ϕ), is recursively defined as follows: α(⊥) = α(⊤) = α(p) = 0, α(ψ1 ∨ ψ2) = α(ψ1 ∧ ψ2) = max({α(ψ1), α(ψ2)}), α(¬ψ) = α(ψ) = α(♦ψ) = α(ψ), α(µp.ψ) = max({1, α(ψ)} ∪ {α(νq.ψ′) + 1 | νq.ψ′ ≤ ψ, p ∈ free(νq.ψ′)}), α(νp.ψ) = max({1, α(ψ)} ∪ {α(µq.ψ′) + 1 | µq.ψ′ ≤ ψ, p ∈ free(µq.ψ′)}).

Note

The alternation depth of all subformulae of an Lµ formula ϕ can be computed in O |ϕ|2 time.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 15 of 28

Outline

Modal µ-Calculus Introduction Syntax Semantics Auxiliary Notions Translation into Alternating Tree Automata [Alternating Tree Automata] Construction of Equivalent Alternating Tree Automata Model-Checking and Satisfiability Conclusion

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 16 of 28

02 Alternating Tree Automata

The Definition

Definition (Alternating Tree Automata)

An alternating tree automaton is a tuple A = (Q, qI, δ, Ω) where

• Q is a finite set of states of the automaton,
• qI ∈ Q is a state called initial state,
• δ : Q → TCQ is called transition function, and
• Ω : Q → ω is called priority function.

Skip alternating tree automata recap TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 17 of 28

02 Alternating Tree Automata

The Definition

Definition (Alternating Tree Automata)

An alternating tree automaton is a tuple A = (Q, qI, δ, Ω) where

• Q is a finite set of states of the automaton,
• qI ∈ Q is a state called initial state,
• δ : Q → TCQ is called transition function, and
• Ω : Q → ω is called priority function.

Definition (Transition Conditions)

Let Q be some set of states. The transition conditions TCQ over Q are defined as follows:

• 0, 1 ∈ TCQ,
• p, ¬p ∈ TCQ

for all p ∈ P,

• q, q, ♦q ∈ TCQ

for all q ∈ Q, and

• q1 ∨ q2, q1 ∧ q2 ∈ TCQ

for all q1, q2 ∈ Q.

Skip alternating tree automata recap TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 17 of 28

02 Alternating Tree Automata

Runs

Definition (Runs of Alternating Tree Automata)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton and (K, wI) a pointed Kripke model where K = (W, R, λ). A run of A on (K, w) is a (W × Q)-vertex-labelled tree R = (V, E, l) such that the root is labelled with (wI, qI) and for every vertex v with label (w, q) the following conditions are satisfied:

• δ(q) = 0.
• δ(q) = p

⇒ w ∈ λ(p)

• δ(q) = ¬p

⇒ w ∈ λ(p).

• δ(q) = q′

⇒ ∃v′ ∈ vE s.t l(v′) = (w, q′).

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 18 of 28

02 Alternating Tree Automata

Runs

Definition (Runs of Alternating Tree Automata)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton and (K, wI) a pointed Kripke model where K = (W, R, λ). A run of A on (K, w) is a (W × Q)-vertex-labelled tree R = (V, E, l) such that the root is labelled with (wI, qI) and for every vertex v with label (w, q) the following conditions are satisfied:

• δ(q) = 0.
• δ(q) = p

⇒ w ∈ λ(p)

• δ(q) = ¬p

⇒ w ∈ λ(p).

• δ(q) = q′

⇒ ∃v′ ∈ vE s.t l(v′) = (w, q′).

• δ(q) = ♦q′

⇒ ∃w′ ∈ wR ∃v′ ∈ vE having l(v′) = (q′, w′)

• δ(q) = q′

⇒ ∀w′ ∈ wR ∃v′ ∈ vE having l(v′) = (q′, w′)

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 18 of 28

02 Alternating Tree Automata

Runs

Definition (Runs of Alternating Tree Automata)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton and (K, wI) a pointed Kripke model where K = (W, R, λ). A run of A on (K, w) is a (W × Q)-vertex-labelled tree R = (V, E, l) such that the root is labelled with (wI, qI) and for every vertex v with label (w, q) the following conditions are satisfied:

• δ(q) = 0.
• δ(q) = p

⇒ w ∈ λ(p)

• δ(q) = ¬p

⇒ w ∈ λ(p).

• δ(q) = q′

⇒ ∃v′ ∈ vE s.t l(v′) = (w, q′).

• δ(q) = ♦q′

⇒ ∃w′ ∈ wR ∃v′ ∈ vE having l(v′) = (q′, w′)

• δ(q) = q′

⇒ ∀w′ ∈ wR ∃v′ ∈ vE having l(v′) = (q′, w′)

• δ(q) = q1 ∨ q2 ⇒ ∃v′ ∈ vE s.t. l(v′) = (w, q1) or l(v′) = (w, q2).
• δ(q) = q1 ∧ q2 ⇒ ∃v1, v2 ∈ vE s.t. l(v1) = (w, q1) and l(v2) = (w, q2).

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 18 of 28

02 Alternating Tree Automata

Acceptance

Definition (Acceptance)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton and R = (V, E, l) a run of it.

• Let π = v0v1 . . . be an infinite branch of R and l(π) = (w0, q0)(w1, q1) . . .

its labelling trace. π is accepting if max{Ω(q)|q occurs infinitely often in q0q1 . . . } is even.

• R is accepting if every infinite branch of R is accepting.

Definition (Language of Alternating Tree Automata)

Let A be an alternating tree automaton and (K, w) a pointed Kripke model. (K, w) is accepted by A if there is an accepting run of A on (K, w). The set of all pointed Kripke models of an alternating tree automaton A — denoted L(A) — is called the language of A.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 19 of 28

02 Alternating Tree Automata

Transition Graph & Index

Definition (Transition Graph)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton. The transition graph of A, denoted G(A), is the directed graph (V, E) where:

• V = Q
• E = {(q, q′)|q′ appears in the transition condition δ(q)}

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 20 of 28

02 Alternating Tree Automata

Transition Graph & Index

Definition (Transition Graph)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton. The transition graph of A, denoted G(A), is the directed graph (V, E) where:

• V = Q
• E = {(q, q′)|q′ appears in the transition condition δ(q)}

Definition (Index)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton and CA the set of all strongly connected components of G(A).

• For every C ∈ CA, mA

C denotes the number of different priorities of states

• ccurring in C, i.e.,

mA

C = |{Ω(q)|q ∈ C}|

• The index ind(A) of the automaton A is the maximum of all mA

C , i.e.,

ind(A) = max({mA

C |C ∈ CA} ∪ {0}) TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 20 of 28

02 Alternating Tree Automata

Complexity Results

Theorem (Word Problem Complexity)

Let A = (Q, qI, δ, Ω) be an alternating tree automaton with d different non-zero priorities and let (K, w) be a finite pointed Kripke model.

• There is an algorithm which computes in time

O

• d|Q|(|R| + 1)

|Q||W|

⌈d/2⌉

⌈d/2⌉

, and in space O (d|Q||W| log (|Q||W|)) . whether A accepts (K, w).

• The problem whether A accepts (K, w) is in UP ∩ co-UP.

Theorem (Emptiness Problem Complexity)

The emptiness problem of alternating tree automata is in Exptime.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 21 of 28

02 Translation into Alternating Tree Automaton

The Idea

• W.l.o.g. the input Lµ formula ϕ is in normal form.
• For every subformula ψ of ϕ there is a state ψ in the automaton.
• ϕ is the initial state.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 22 of 28

02 Translation into Alternating Tree Automaton

The Idea

• W.l.o.g. the input Lµ formula ϕ is in normal form.
• For every subformula ψ of ϕ there is a state ψ in the automaton.
• ϕ is the initial state.
• Boolean and modal connectives of Lµ are directly translated into the

respective connectives of transition conditions. (e.g. δ(ψ1 ∨ ψ2) = ψ1 ∨ ψ2)

• Unbound (“real”) atomic propositions and their negation are translated into

respective terminating transition conditions. (e.g. δ(¬p) = ¬p)

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 22 of 28

02 Translation into Alternating Tree Automaton

The Idea

• W.l.o.g. the input Lµ formula ϕ is in normal form.
• For every subformula ψ of ϕ there is a state ψ in the automaton.
• ϕ is the initial state.
• Boolean and modal connectives of Lµ are directly translated into the

respective connectives of transition conditions. (e.g. δ(ψ1 ∨ ψ2) = ψ1 ∨ ψ2)

• Unbound (“real”) atomic propositions and their negation are translated into

respective terminating transition conditions. (e.g. δ(¬p) = ¬p)

• For fixed point connectives loops are constructed by having a transition from

states p to ηp.ψ.

• Least and greatest fixed points are discriminated by appropriately choosing

the priority function.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 22 of 28

02 Translation into Alternating Tree Automaton

Formal Definition

Definition

Let ϕ be an Lµ formula in normal form. The alternating tree automaton corresponding to ϕ, denoted by A(ϕ) = (Q, q0, δ, Ω), is defined as follows:

• Q = {ψ | ψ ≤ ϕ},
• q0 = ϕ,
• δ : Q → TC Q is defined by:

δ(⊥) = 0, δ(⊤) = 1, δ(p) =

• p

if p ∈ free(ϕ), ϕp

• therwise,

δ(¬p) = ¬p, δ(ψ1 ∨ ψ2) = ψ1 ∨ ψ2, δ(ψ1 ∧ ψ2) = ψ1 ∧ ψ2, δ(ψ) = ψ, δ(♦ψ) = ♦ψ, δ(µp.ψ) = ψ, δ(νp.ψ) = ψ,

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 23 of 28

02 Translation into Alternating Tree Automaton

Formal Definition (cont.)

Definition (cont.)

• Ω : Q → ω is defined by:

Ω(ψ) =

  

smallest odd number ≥ α(ψ) − 1 if ψ = µp.ψ′, smallest even number ≥ α(ψ) − 1 if ψ = νp.ψ′,

• therwise.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 24 of 28

02 Translation into Alternating Tree Automaton

Formal Definition (cont.)

Definition (cont.)

• Ω : Q → ω is defined by:

Ω(ψ) =

  

smallest odd number ≥ α(ψ) − 1 if ψ = µp.ψ′, smallest even number ≥ α(ψ) − 1 if ψ = νp.ψ′,

• therwise.

Note

This construction takes O |ϕ|2 time and O (|ϕ|) space.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 24 of 28

02 Translation into Alternating Tree Automaton

Formal Definition (cont.)

Definition (cont.)

• Ω : Q → ω is defined by:

Ω(ψ) =

  

smallest odd number ≥ α(ψ) − 1 if ψ = µp.ψ′, smallest even number ≥ α(ψ) − 1 if ψ = νp.ψ′,

• therwise.

Note

This construction takes O |ϕ|2 time and O (|ϕ|) space.

Observation

(i) α(ϕ) = ind(A(ϕ)), (ii) ind(A(ϕ)) = “number of different non-zero priorities”, (iii) |QA(ϕ)| = |ϕ|S.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 24 of 28

02 Equivalence of ϕ and A(ϕ)

Theorem

Let ϕ be am Lµ formula in normal form. Then for every pointed Kripke model (K, w) the following holds: (K, w) | = ϕ iff (K, w) ∈ L(A(ϕ)).

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 25 of 28

02 Equivalence of ϕ and A(ϕ)

Theorem

Let ϕ be am Lµ formula in normal form. Then for every pointed Kripke model (K, w) the following holds: (K, w) | = ϕ iff (K, w) ∈ L(A(ϕ)).

Consequences

• The model-checking problem of the modal µ-calculus can be reduced to the

word problem of alternating tree automata.

• The satisfiability problem of the modal µ-calculus can be reduced to the

(non-)emptiness problem of alternating tree automata.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 25 of 28

02 Model-Checking and Satisfiability

Complexity Results

Corollary (Model-Checking Problem Complexity)

Let ϕ be an Lµ formula with α(ϕ) ≥ 2 and (K, w) a pointed Kripke model.

• Then solving the corresponding model-checking problem is bound in time by

O

• α(ϕ)|ϕ|(|R| + 1)

|ϕ||W|

⌈α(ϕ)/2⌉

⌈α(ϕ)/2⌉

, and in space by O (α(ϕ)|ϕ||W| log (|ϕ||W|)) .

• The model-checking problem for the modal µ-calculus is in UP ∩ co-UP.

Corollary (Satisfiability Problem Complexity)

The satisfiability problem for the modal µ-calculus is in Exptime.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 26 of 28

Outline

Modal µ-Calculus Introduction Syntax Semantics Auxiliary Notions Translation into Alternating Tree Automata [Alternating Tree Automata] Construction of Equivalent Alternating Tree Automata Model-Checking and Satisfiability Conclusion

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 27 of 28

03 Conclusion

• The modal µ-calculus is a powerful logic to describe properties of transition

systems (Kripke models).

• There is an effective construction of an equivalent alternating tree automaton

corresponding to an Lµ formula.

• Hence, model-checking and satisfiability of modal µ-calculus can be reduced

to word problem and emptiness problem of alternating tree automata.

• Significant quantities of the formula (“size”, alternation depth) are conveyed

to the equivalent automaton (state space, number of non-zero priorities).

• Hence, complexity results of alternating tree automaton are easily translated

to the modal µ-calculus.

• Considering a fixed Lµ formula the model-checking problem is polynomial in

the size of the state space of the transition system.

TU Dresden, February 1, 2008 µ-Calculus & Alternating Tree Automata slide 28 of 28
