Mine Gold. Create Value.

March 2020 Quarterly Activities Report

Corporate Presentation

slide-2
SLIDE 2

1

Important Notices and Disclaimers

This presentation contains information about Resolute Mining Limited (Resolute or the Company) and its activities that is current as at the date of this presentation unless otherwise stated. The information in this presentation remains subject to change without notice. This presentation has been prepared by Resolute and no party other than Resolute has authorised or caused the issue, lodgement, submission, despatch or provision of this presentation. The information in this presentation is general in nature and does not purport to be complete. This presentation is not a prospectus, disclosure document or other offering document under Australian law or under the laws of any other jurisdiction. This presentation is provided for information purposes and does not constitute an offer, invitation, inducement or recommendation to subscribe for or purchase securities in Resolute in any jurisdiction. The information contained in this presentation has been prepared in good faith by Resolute, however no guarantee, representation or warranty expressed or implied is or will be made by any person (including Resolute and its affiliates and their directors, officers, employees, associates, advisers and agents) as to the accuracy, reliability, correctness, completeness or adequacy of any statements, estimates, options, conclusions or other information contained in this presentation. To the maximum extent permitted by law, Resolute and its affiliates and their directors, officers, employees, associates, advisers and agents each expressly disclaims any and all liability, including, without limitation, any liability arising out of fault

  • r negligence, for any loss or damage suffered by any person relating in any way to the use of or reliance on information contained in this presentation including, without limitation:
  • from representations or warranties or in relation to the accuracy or completeness of the information contained within this presentation;
  • from statements, opinions, forecasts, reports or other matters, express or implied, contained in, arising out of or derived from this presentation; or
  • for omissions from this presentation including, without limitation, any financial information, any estimates, forecasts, or projections and any other financial information derived therefrom.

This presentation does not constitute financial product advice, investment, legal, taxation or other advice and is not intended to be used or relied upon as the basis for making an investment decision. This presentation is not a recommendation to acquire Resolute securities and has been prepared without taking into account the investment objectives, taxation situation, financial situation or needs of individuals. Before making any investment decision in connection with any acquisition

  • f Resolute securities, prospective investors should consider the appropriateness of the information having regard to their own objectives, tax situation, financial situation and needs and seek financial, legal and taxation advice appropriate to

their jurisdiction. Past performance information given in this presentation is for illustrative purposes only and should not be relied upon as an indication of future performance. This presentation includes certain forward-looking statements, including statements regarding our intent, belief or current expectations with respect to Resolute’s business and operations, market conditions, results of operations and financial condition, and risk-management practices. Words such as ‘project’, ‘foresee’, ‘plan’, ‘expect’, ‘aim’, ‘intend’, ‘anticipate’, ‘believe’, ‘estimate’, ‘may’, ‘should’, ‘will’ and similar expressions are intended to identify forward-looking statements. Indications of, and guidance on, future earnings and financial position and performance are also forward-looking statements. Forward-looking statements are provided as a general guide only and should not be relied upon as an indication or guarantee of future performance. These statements are based upon a number of estimates and assumptions that, while considered reasonable by Resolute, are inherently subject to significant uncertainties and contingencies, many of which are outside the control of Resolute, involve known and unknown risks and uncertainties that could cause actual events or results to differ materially from estimated or anticipated events or results reflected in such forward looking statements on certain assumptions, which may prove to be incorrect. Actual results, performance, actions and developments of Resolute may differ materially from those expressed or implied by the forward-looking statements in this presentation. As an Australian company listed on the Australian Securities Exchange (ASX), Resolute is required to report Ore Reserves and Mineral Resources in Australia in accordance with the Australasian Code for Reporting of Exploration Results, Mineral Resources and Ore Reserves (JORC Code). Recipients should note that while Resolute’s Mineral Resource and Ore Reserve estimates comply with the JORC Code, they may not comply with relevant guidelines in other countries. For details of the Mineral Resources and Ore Reserves used in this presentation, please refer to ASX Announcement dated 18 February 2020 titled “Annual Ore Reserve and Mineral Resource Statement as at 31 December 2019”,The Company is not aware of any new information or data that materially affects the Mineral Resources and Ore Reserves as reported in this ASX Announcement and confirms that all material assumptions and technical parameters underpinning this plan continue to apply and have not materially changed. The form and context in which the Competent Persons’ findings are presented have not been materially modified. All in Sustaining Cost (AISC) per ounce of gold produced are calculated in accordance with World Gold Council guidelines. These measures are included to assist investors to better understand the performance of the business. Cash cost per

  • unce of gold produced and AISC are non‐International Financial Reporting Standards financial information

An investment in Resolute is subject to known and unknown risks, some of which are beyond the control of Resolute, including possible loss of income and principal invested. Resolute does not guarantee any particular rate of return or the performance of Resolute, nor does it guarantee any particular tax treatment. Investors should have regard (amongst other things) to the risk factors outlined in this Presentation when making their investment decision. See the “Key Risks" section of this presentation for certain risks relating to an investment in Resolute. All dollar values are in United States dollars ($ or USD) unless otherwise stated. This presentation includes pro-forma financial information which is provided for illustrative purposes only and is not represented as being indicative of Resolute (or anyone else's) views on Resolute's future financial position or performance. A number of figures, amounts, percentages, estimates, calculations of value and fractions in this presentation are subject to the effect of rounding. Accordingly, the actual calculation of these figures may differ from the figures set out in this presentation.

slide-3
SLIDE 3

2

Mako

Senegal

Syama

Mali

Bibiani

Ghana

Ravenswood

Australia

Market Capitalisation

A$1.03Bn

£527m | US$659m

2020 Guidance

430,000oz at US$980/oz

AISC

Note: Market capitalisation as at 17 April 2020. Mineral Resources and Ore Reserves are as at 31 December 2019 and stated exclusive of Ravenswood. 2020 guidance has been updated to reflect the sale of Ravenswood which completed on 31 March 2020.

Strategic Review Ongoing

Mineral Resources

13.3Moz

Ore Reserves

4.7Moz

Sale Completed

  • n 31 March 2020
slide-4
SLIDE 4

3

March 2020 Quarterin Review

COVID-19 Response

  • Comprehensive companywide response implemented; US$1 million to support Mali Govt / Senegal Govt response
  • Mining and processing continuing as normal; no reported COVID-19 cases across sites or offices

Production and Sales

  • Gold poured of 110,763oz at an AISC of US$1,007/oz; Syama and Mako deliver 99,717oz at an AISC of US$918/oz
  • Gold sales of 102,008oz at an average realised gold price of US$1,407/oz

Development

  • Construction of new solar hybrid power station at Syama commenced
  • Tabakoroni Underground Mine Pre-Feasibility Study initiated following positive Concept Study outcomes

Exploration

  • Significant high-grade oxide gold intersections from drilling at Syama
  • Results support potential to extend the life of Syama’s oxide operation

Portfolio

  • Ravenswood sale completed on 31 March 2020; up to A$300 million in total proceeds realisable
  • Bibiani strategic review ongoing; targeting completion in H2 2020

Balance Sheet

  • Completed US$300 million senior debt refinancing and ~A$194 million equity raising; higher cost debt repaid
  • Cash and bullion of US$96 million; total borrowings of US$308 million; net debt of US$212 million

Photo: Tabakoroni Open Pit Mine

Note: A$25m of the A$194m equity raising proceeds being received during April 2020.
slide-5
SLIDE 5

4

Resolute’s COVID-19 Response

  • The health and safety of our people is a Resolute priority
  • Comprehensive companywide response to the coronavirus pandemic has been implemented
  • Keeping our mines running is important for employees, local communities, national economies
  • Resolute actions to ensure impact of COVID-19 mitigated across all aspects of operations
  • Gold production not affected - mining and processing continuing at Syama and Mako
  • No changes to FY20 production or cost guidance at Syama or Mako
  • Resolute has regional experience, secure supply lines, and robust relationships
  • Challenges presented by COVID-19 continue to change on a daily basis
  • Resolute will adapt to keep our people safe and keep our mines producing gold
  • US$1 million committed to support Mali and Senegal in their response efforts

Hand washing facilities, Syama Social distancing at the Mess, Mako

slide-6
SLIDE 6

5

Sustainability Update

Health and Safety

  • Improved safety performance: lower Total Record Injury Frequency

Rate relative to previous quarter; 1.60 at 31 March 2020 relative to 2.09 as at 31 December 2019

Photo: Market Gardens, Mako Gold Mine

Enhanced sustainability reporting provided in the 2019 Annual Report which was published during the March 2020 Quarter

Environment

  • Quarterly external environmental audit undertaken at Syama by the

National Directorate of Geology and Mines; with no significant non- compliance identified

  • Extensive environmental monitoring ongoing across Syama and

Mako operations with zero significant incidents reported Community

  • US$1 million in financial and medical supplies donated to Mali

and Senegal Governments to support response to COVID-19

  • Handwashing basins donated to local Bibiani community in Ghana
slide-7
SLIDE 7

6

Operational Performance

110,763oz

T

  • tal Gold Production

US$1,007/oz

All-In Sustaining Cost

Syama and Mako AISC: US$918/oz

102,008oz

T

  • tal Gold Sold

US$1,407/oz

Ave Price Received

6

March 2020 Quarter

Photo: Tabakoroni Open Pit Mine

slide-8
SLIDE 8

7

84,552 65,757 45,804 46,945 57,531 13,554 12,375 13,206 15,351 11,046 44,191 42,997 42,186 Mar 19 Qtr Jun 19 Qtr Sep 19 Qtr Dec 19 Qtr Mar 20 Qtr

Syama Ravenswood Mako

March 2020 Quarter Production of 110,763oz

2020 Production Guidance of 430,000oz

Multi-Asset Production Base

98,105oz 78,132oz 103,201oz 105,293oz 110,763oz

slide-9
SLIDE 9

8

598 790 1,523 2,157 1,083 1,335 1,642 1,422 1,087 1,537 716 658 694 Mar 19 Qtr Jun 19 Qtr Sep 19 Qtr Dec 19 Qtr Mar 20 Qtr

Syama Ravenswood Mako

March 2020 Quarter AISC of US$1,007/oz

2020 Cost Guidance of US$980/oz

AISC by Asset (US$/oz)

Note: (1) The abnormally high ASIC was the result of the Syama roaster shut down being offline for the majority of the December 2019 Quarter.

740 939 1,202 1,419 1,007 Group AISC

(1)
slide-10
SLIDE 10

9

Syama Gold Mine: Mali

March 2020 Quarter: 57,531oz at an AISC of US$1,083/oz 2020 Guidance: 260,000oz at an AISC of US$960/oz

9

Sulphide production up 54% on December 2019 Quarter; achieved recoveries of 75%; targeting 85% in H2 2020 Tabakoroni: promising oxide exploration results; PFS commenced on future underground mine Oxide circuit continues to deliver high recoveries; production up 10% on December 2019 Quarter

March 2020 Quarter Update

Substantial increase in mined and hauled tonnages from the Syama Underground Mine

Photo: Processing Plant, Syama Gold Mine

slide-11
SLIDE 11

10

Sulphide Operations

Improved tonnages and recoveries corresponded with higher quarterly output

Sulphide Production

  • 21,430oz at an AISC of US$1,637/oz
  • Increase of 54% on the December 2019 Quarter
  • Overall sulphide circuit recovery was 75.1%
  • Roaster performance remains a key area of focus with

incremental improvement expected during 2020

  • Recoveries expected to average 80% for the June 2020 Quarter
  • Target recoveries of 85% during H2 2020

Syama Underground Mine Performance

  • Substantial increase in mined and hauled tonnages
  • 519,898 tonnes of ore mined, 33% up on December 2019 Quarter
  • 186,807 tonnes mined in the month of March
  • 976,187 tonnes of ore blasted, 39% up on December 2019 Quarter
  • During 2020, the Syama Underground Mine will move from around

50% haulage of ore broken to over 80% Stockpiles

  • 517,000 tonnes at an average grade of 2.5g/t Au

200,000 400,000 600,000 800,000 1,000,000 Mar 19 Qtr Jun 19 Qtr Sep 19 Qtr Dec 19 Qtr Mar 20 Qtr Ore Tonnes Hauled Ore Tonnes Blasted

Syama Underground Mine Hauled and Blasted Ore Tonnages

slide-12
SLIDE 12

11

Sulphide Operations

Sulphide Circuit Flow Sheet: targeting 85% recoveries

CIL Tails Dam Float Tails Dam

Crushing Concentrate Thickener

Roaster

Air

Calcine Carbon-in- Leach (CIL)

Primary Mill Secondary Mills Flotation Feed Atmosphere Mill Feed Jaw Crusher Cone Crushers Cyanide Solution & Lime Slurry Overflow Gold Room

Concentrate directed to Pond when Roaster is
  • ff-line for
maintenance. Concentrate reclaimed when Mill is off-line for maintenance.

Float Tails Float Concentrate

CIL Tails Float CIL Tails

Gold Room

FT Leach assumed recovery is 35% Slight mass loss in roaster due to
  • xidation of
sulphur

Flotation Concentrator

Cyanide Solution & Lime Slurry

Milling Calcine

Comminution

Float Tails Leach

Leaching and Elution

slide-13
SLIDE 13

12

Oxide Operations

Low cost production from T abakoroni; satellite deposits to provide feed in H2 2020

Oxide Production

  • 36,101oz at an AISC of US$754/oz
  • Increase of 10% on the December 2019 Quarter
  • Recoveries strengthened as more oxidised

material from the Tabakoroni North Pits processed Future Oxide Production

  • Mining is expected to be completed at

Tabakoroni in May 2020

  • Cashew, Paysans, and Tellem satellite deposits

to provide additional oxide feed Stockpiles

  • Over 3 million tonnes at an average grade of

1.3g/t Au

  • Provides feed source through to 2022

Photo: Tabakoroni Open Pit MIne

slide-14
SLIDE 14

13

Syama Oxide Exploration

13

Near surface drilling programs at satellites are returning significant high-grade oxide gold intersections

Photo: Exploration Drilling at Tabakoroni

Tabakoroni area drillhole locations on geology and satellite imagery

slide-15
SLIDE 15

14

T abakoroni Underground Mine

14

Pre-Feasibility Study Commenced

  • Pre-Feasibility Study (PFS) initiated in the March

2020 Quarter following positive outcomes from internal Concept Study completed in 2019

  • The PFS is investigating various underground

mining methods and rates and will review suitable processing options maximising utilisation of the nearby Syama processing plant infrastructure

  • The PFS aims to sufficiently advance study work to

progress to full Feasibility Studies during the September 2020 Quarter

  • Early underground access works to commence

during the March 2021 Quarter, pending Board approval and environmental and social permitting

  • Deposit remains largely open both at depth and along

strike

slide-16
SLIDE 16

15

Syama Power Upgrade Project

15

Construction of new solar hybrid modular power underway

  • Early works comprising mobilisation of the earthworks contractor, bulk earthworks and relocation of existing hire power

units undertaken; detailed earthworks commenced

  • The new power station will deliver cost effective, environmentally friendly, capital efficient power and long-term electricity

cost savings of up to 40% while reducing carbon emissions by approximately 20%

Photo: Syama Solar Hybrid Power Plant Site

slide-17
SLIDE 17

16 16

March 2020 Quarter: 42,186oz at an AISC of US$694/oz FY20 Guidance: 160,000oz at an AISC of US$800/oz

Mako Gold Mine: Senegal

Consistent and reliable performance generating strong free cash flow Accelerating drilling activities to increase resource base in pursuit of mine life extension opportunities

March 2020 Quarter Update

Photo: Processing Plant, Mako Gold Mine

slide-18
SLIDE 18

17 17

Ravenswood Gold Mine: Australia

Sale successfully completed on 31 March 2020 All assets and associated liabilities transferred

17

Sale Proceeds

A$50m upfront cash and A$50m note earning a 6% annual coupon received Up to A$200 million in future proceeds contingent on gold price, production and EMR Capital’s investment outcome

Photo: Nolans Processing Plant, Ravenswood Gold Mine

slide-19
SLIDE 19

18 18

Bibiani Gold Mine: Ghana

Strategic review ongoing; targeting completion in H2 2020

18

Deliver value accretive outcome from strategic review

2020 Focus

Photo: Processing Plant, Bibiani Gold Mine

slide-20
SLIDE 20

19

Full Year Results Presentation: For the 12 months to 31 December 2019

19

Financial Performance

US$20m

Operating Cash Flow

US$96m

Cash and Bullion at 31 March

US$25m

Capital and Exploration Expenditure

US$212m

Net Debt at 31 March

March 2020 Quarter

Photo: Processing Plant, Syama Gold Mine

Note: Capital expenditure includes sustaining capital expenditure and Bibiani care and maintenance.
slide-21
SLIDE 21

20

Cash as at 31 Dec 2019 Operating Cash Flows Equity Raising Proceeds Net Borrowings Capital Expenditure Net Interest Expense Ravenswood Sale Proceeds Working Capital / Other Cash as at 31 Mar 2020 Bullion Cash and Bullion as at 31 Mar 2020

Cash Flow Analysis

(US$m)

87 20 (25) 110 (118) (10) 66 32 (30) 29 96

Note: numbers subject to rounding.
slide-22
SLIDE 22

21

Balance Sheet

New US$300 million flexible low cost senior debt facility secured

Overview

  • Higher cost US$130 million Toro Gold acquisition bridge facility and US$63 million Mako project loan repaid through a combination of low cost debt and

equity

  • Additional liquidity provided through new senior debt facility

Equity Raising

  • ~A$194 million equity raising comprising two-tranche placement and share purchase plan launched in January 2020(1); strongly supported by new and

existing investors Debt Refinancing

  • Existing US$195 million syndicated loan facility replaced with new flexible low cost US$300 million senior debt facility in March 2020 comprising:
  • US$150 million revolving credit facility (three-year term) currently drawn to US$105 million; and
  • US$150 million term loan facility (four-year term)
  • Strong support from banking syndicate including existing financiers, BNP Paribas, Citibank, Investec and Nedbank, and new syndicate participants,

ING Group and Société Générale Mako Royalty

  • Agreement with Taurus in January 2020 to buyout existing 1.1% royalty over Mako removes encumbrance and secures full benefit of Mako’s positive

cashflows for Resolute

Capital Structure Simplification

Note: (1) A$25m of the A$194m equity raising proceeds being received during April 2020.
slide-23
SLIDE 23

22

2020 Outlook and Focus Areas

22

2020 Guidance 430,000oz at an AISC of US$980/oz Syama Strengthening sulphide recoveries, Tabakoroni Underground PFS, oxide resource growth Balance Sheet Strengthen financial position with surplus cash to be used for deleveraging Mako Sustained high margin production; accelerated drilling to grow resource base and mine life Growth Evaluate accretive growth opportunities

Photo: Syama Underground Mine Decline Entry

slide-24
SLIDE 24

23

Resolute Portfolio

23

Syama

Syama Complex comprises the Syama Underground Mine, a world class, fully automated sublevel cave, and the Tabakoroni Open Pit Mine

Bibiani

Bibiani is a potential long life, high margin operation which offers significant

  • ptionality for Resolute; currently

subject to a strategic review

14years 8.3Moz

Mineral Resources

3.3Moz

Ore Reserves 2020 AISC

US$

960/oz

2020 Production

260

koz

Plant Capacity

Note: Mineral Resources are inclusive of Ore Reserves and is as at 31 December 2019. Production and AISC numbers are based on 2020 guidance except for Bibiani which is based on the Company’s latest study. Numbers subject to rounding.

Mine Life

4Mtpa 10years

Target AISC

US$

764/oz

Target Annual Production

100

koz

Plant Capacity Mine Life

3Mtpa

Mako

Mako is a high quality, low-cost producing asset with attractive scale, located in the stable, mining friendly jurisdiction of Senegal

7years 1.1Moz

Mineral Resources

0.7Moz

Ore Reserves 2020 AISC

US$

800/oz

2020 Production

160

koz

Plant Capacity Mine Life

2.3Mtpa 2.5Moz

Mineral Resources

0.7Moz

Ore Reserves

Ravenswood

A$100 million of upfront proceeds received (A$50 million cash and A$50 million notes with a 6% coupon); additional notes valued at up to A$200 million received

+10years 5.9Moz

Mineral Resources

2.7Moz

Ore Reserves 2020 AISC

US$

1,200/oz

Plant Capacity Mine Life

5Mtpa

2020 Production

80

koz SALE COMPLETED 31 MARCH 2020

slide-25
SLIDE 25

24

A$ £ US$ Share Price $0.95 £0.48 $0.64 Shares on Issue 1,095m Market Capitalisation $1,035m £527m $659m

Corporate Summary (ASX / LSE : RSG)

Capitalisation ASX Price Performance

Note: Market data as at 17 April 2020. Top 10 Shareholders as at 26 March 2020.

Top 10 Shareholders

1 ICM Limited 12.35% 2 Van Eck Associates Corporation 8.92% 3 L1 Capital 6.79% 4 The Vanguard Group 5.01% 5 Baker Steel Capital Manager 3.99% 6 QG Investments Africa 3.90% 7 Dimensional Fund Advisors 3.18% 8 BlackRock 3.07% 9 FMR 2.84% 10 Schroders 2.27%

FY20 Guidance Trading Statistics

430,000oz at US$980/oz AISC

L TM Average Daily Trading

Volume: 10.9m Value: A$13.6m

Volume Share Price

slide-26
SLIDE 26

25 25

Resolute is committed to the World Gold Council’s Responsible Gold Mining Principles

slide-27
SLIDE 27

Contacts

John Welborn | Managing Director & CEO Jeremy Meynert | General Manager –BD & IR

EMAIL | contact@rml.com.au PHONE | +61 8 9261 6100

Follow Us

WEB | www.rml.com.au
