Microsoft Azure Backup echnologies wadew@biggreenit.com Manager Cloud T Wade Walker
T oday’s Agenda 11:40 – Who is Big Green IT? – Jonas Nordling 11:45 – Azure Backup – Wade Walker 12:10 – Azure Backup Demo – Ryan Starkweather 12:35 – Azure Site Recovery Overview – Wade Walker 12:50 – Q & A – Azure Next Steps – Wade Walker
Quote from StudioW ioWC • – “ I had no idea a our r transi ansition tion woul uld d be so s smooth! th! Big Green en IT was respon onsi sive e and d prompt pt eve very ste tep of the way. The nicest team I’ve ever worked with!” Head adquar quarter ered ed in Rocklin, klin, CA CA (Sacramen ramento) o) with h offices ices in San Diego go & Los Angeles eles • 2017 Sacramen amento o Busines ness Journal nal - #1 Fastest test Growing wing Co Compan any • 2017 & 2018 Sacramen amento o Busine ness Journa nal l - Best Place ace to to Work • Microso soft t Gold d Platform tform Partne ner • Microso soft t Tier er 1 Azure e and Office fice 365 M Mana naged ged Partne ner • Microso soft t Data a Ce Center er Optimization timization (DCO) O) Partner ner • Some of our Micr croso soft t Cloud oud Cli lient ents: s: • Summit it Fundi ding ng 1,20 200 users Rideou eout Healt lth 3,400 00 users – Red Hawk wk (Ranch cheria eria) 340 0 users Tremont t Lymon mon 220 20 users – Rego Consult ltin ing 150 0 users APM 1,400 00 users – In In-Shape ape Clubs bs 1,30 300 users ProS oSea earch Strateg egie ies 230 30 User ers – EJ Gallo lo 7,00 000 0 users Many y others in the 20-100 00 user r range ge –
https://azure.microsoft.com/en-us/global-infrastructure/regions/
https://aka.ms/AzureCompliance
How do I know my backup data in the cloud is safe from hackers?
Azure Backup Architecture - Components Azure Backup • Recovery Services Vaults (RSV) • Azure Recovery Services Agent (MARS) • Azure Backup Server (MABS) https://docs.microsoft.com/en-us/azure/backup/backup-introduction-to-azure-backup
Azure Virtual Windows Physical Server machine Windows or Linux Windows PC MARS Agent Windows 7+ Application Workload SQL, Exchange, etc. Azure Backup Windows Server VM Hyper-V or VMware Azure Backup Server Linux Server VM Or Data Protection Manager Hyper-V or VMware
Recovery Services Vaults • A Recovery Services vault is your storage account for backups • The data is typically copies of data, or configuration information for virtual machines (VMs), workloads, servers, or workstations under protection • Recovery Services vaults support System Center DPM, Windows Server, Azure Backup Server, etc. • Limits: 1,000 VMs per vault, 500 vaults per subscription per region, 2 PB per vault
Azure Backup (MARS) agent • An agent you deploy onto a target OS • Back up files and folders on physical or virtual OS (VMs can be on- premises or in Azure) • No separate backup server required • Limits: • Backup up to 3 times per day • Not application aware; file, folder, and volume-level restore only
Azure Backup Server (MABS) • Can be installed as a service on an existing server • Inherits much of the workload backup functionality from Data Protection Manager (DPM) except: • No tape support • No System Center license needed • Requires an Azure Subscription
Azure Backup Server (MABS) • Enhanced Capabilities: • Application-aware snapshots (VSS) • Full flexibility for when to take backups • Recovery granularity (all) • Back up and restore VMware and Hyper-V VMs • Linux support on Hyper-V and VMware VMs • Disk to Disk to Cloud • Full On-premise backup
Compone nent nt Benefits ts Limits What is pro rotec tected? Where re are re backup ups sto tored red? • Back up files and folders on • Backup up to 3 times per • Files • Recovery Services vault physical or virtual Windows day • Folders OS (VMs can be on- • Not application aware; file, premises or in Azure) folder, and volume-level Azure Backup up • No separate backup server restore only Agent nt (MARS) RS) required • No support for Linux • App aware snapshots (VSS) • Cannot back up Oracle • Files • Recovery Services vault • Full flexibility for when to workloads • Folders • Locally attached disk take backups • Always requires an active • Volumes • Recovery granularity (all) Azure subscription • VMs • Can use Recovery Services • No support for tape backup • Applications vault • Workloads • Linux support on Hyper-V and VMware VMs Azure Backup up • Back up and restore VMware Server r (MABS) VMs • Does not require a System Center license
Azure IaaS VM Backup • Built right into the portal – easy setup • Application-aware snapshots (VSS) • Native backups for Windows/Linux • No specific agent installation required • Fabric-level backup with no backup infrastructure needed • Limits • Backs up VMs once per day • Cannot back up on-premises infrastructure
Deployment Scenarios Can be deplo loyed yed Can be deplo loyed yed Target et Compon onent ent in Azure? e? on on-prem? em? Sto torag rage Azure Backup Yes Yes RSV (MARS) agent Azure Backup RSV Yes Yes Server Local Disk Azure IaaS VM Yes No RSV Backup
Multi-location deployment model Centralized Management and Reporting in the Azure Portal Main Datacenter Microsoft Azure Branch Offices Workloads SQL Exchange SharePoint File Server Server Physical Hosts Hyper-V VMware
NEW
Management Recovery Services iSCSI Target iSCSI Target iSCSI Initiator iSCSI Initiator
Azure Import Ship Service Backup data
Alert Pr Prote tect Recover ver Security PIN for multiple Portal based alerts for critical layers of authentication Store deleted data on cloud operations like re-encrypting for additional 14 days data using passphrase Support for Azure Disk Encryption (ADE) VMs Recover using alternate server Email notifications for operations in case original server is impacting availability of backup Hybrid Backup encryption unavailable data like delete backups and Storage side encryption (SSE) RBAC for restricted access to key operations
View All
No infrastructure Enterprise Wide Custom Queries (KQL) ITSM Integration
No infrastructure Enterprise Wide Custom Reports Access Control
Instance < or = 50 GB $5 + storage consumed Instance is > 50 but < or = 500 GB $10 + storage consumed Instance > 500 GB $10 for each 500 GB increment + Azure Backup storage consumed
Azure Backup Sample Diagram Windows Physical Server MARS Agent Replicas Azure VM for Test/Dev Linux Server VM US East Region SQL Workload SQL MySQL Workload Recovery Services Vault Application Server VM Web Server VM Azure Backup Domain Controller VM Server Azure Backup Replicas Solution Directory Server VM US West Region Azure Management Portal File Server VM Vmware Environment Local Azure
Hyper-V Azure Site Server Recovery Microsoft Azure Data Channel Source: Hyper-V Public Internet or ExpressRoute with Public Peering Microso soft t Azure e Recover very Servi vice ces Ag Agent t Documentation: https://aka.ms/asr_hyperv Videos: https://aka.ms/asr_videos
Config Server Process Server Azure Site Recovery Microsoft Azure Data Channel Source: VMware, AWS & Physical Servers Public Internet or ExpressRoute with Public Peering Process ess Server ver Config igur urat ation ion Server ver Mobility Mo ity Service vice Documentation: http://aka.ms/asr_vmware Videos: https://aka.ms/asr_videos
Azure Site Recovery to customer owned $16/month per protected instance sites Azure Site Recovery to Azure $25/month per protected instance Site Recovery Every instance is free for the first 31 days
Azure Site Recovery Sample Diagram Recovery Services Vault Replicas Windows Server VM Windows Physical Server MARS Agent Linux Server VM Linux Server VM SQL Workload US West Region SQL SQL Workload SQL MySQL Workload Azure Site MySQL Workload Recovery Application Server VM Replicas Azure Management Portal US East Region Application Server VM Web Server VM Web Server VM Domain Controller VM Azure Site Domain Controller VM Recovery Process Directory Server VM Server Directory Server VM PowerBI Reports File Server VM Azure Management & Reporting Azure Recovery Environment File Server VM Vmware Environment Local Azure Internet Traffic Manager
Microsoft Licensing Options • Bundles vs. A la Carte - Mix and match! • Enterprise vs. Business Bundles • Open Volume • Enterprise Agreements (EAs) • Migrate SA Benefits from EA to MPSA • Non-Profit • Government/Education • Cloud Service Provider (CSP) Big Green Bi en IT can n handle dle ALL LL of yo your Micr icroso osoft t Licensi icensing! ng!
• LinkedIn: https://www.linkedin.com/in/wade- walker-a830781/ • Twitter: @coachwade • Big Green IT Backup Assessment Qu Ques estio tions? ns? • Microsoft Licensing • IAMCP (International Association of Microsoft Channel Partners)
