Micromonitoring Comes of Age By John Barton , Ph.D., P.E. Joseph Kamalesh, M.S. Stantec Consulting Services, Inc. Overview Technology Research and Development Case Study Advantages Limitations Acknowledgements Seattle

slide-1
SLIDE 1

Micromonitoring Comes of Age

By John Barton, Ph.D., P.E. Joseph Kamalesh, M.S. Stantec Consulting Services, Inc.

slide-2
SLIDE 2

Overview

  • Technology
  • Research and Development
  • Case Study
  • Advantages
  • Limitations

Acknowledgements Seattle Public Utilities, Washington Clayton County Water Authority, Georgia City of Florence, Kentucky

slide-3
SLIDE 3

3

Technology

A new technique to cost-effectively isolate I/I. What is micromonitoring?

slide-4
SLIDE 4

4

What is a micromonitor?

Primary Flow

slide-5
SLIDE 5

WWTP

Regional Flow Monitoring

Regional Monitors (1 per 5 miles of pipe)

FLOW RAIN I/I

slide-6
SLIDE 6

6

Regional Flow Monitoring

Equipment: ADS, ISCO, HACH Cost: as much as $2,000 per month per site Range: Must be 2”+ of flow

6

slide-7
SLIDE 7

WWTP Regional Flow Monitor Distributed Micromonitors

Micromonitors - an SSES tool

slide-8
SLIDE 8

8

Flume Calibration

Research and Development

slide-9
SLIDE 9

9

Seattle Flume Calibration

slide-10
SLIDE 10

10

Seattle Flume Calibration

Supercritical Subcritical

slide-11
SLIDE 11

11

Supercritical Subcritical

Micromonitor Flow Characteristics

AV calculation Weir calculation

slide-12
SLIDE 12

12

Research and Development

Seattle

slide-13
SLIDE 13

13

CCWA Basin -071 Spring 2010 Regional Monitor -071

Case Study

slide-14
SLIDE 14

14

Micro Monitoring Schematic

Micromonitors upstream of -071 MM-06 MM-05 MM-04 MM-03 MM-02 MM-01

  • 071
slide-15
SLIDE 15

15

CCWA Basin 071

MM-06 MM-05 MM-04 MM-03 MM-02 MM-01

  • 071
slide-16
SLIDE 16

16

Regional Monitor -071

29,000 gal Feb 28th Storm

slide-17
SLIDE 17

17

MM-01

MM-01

slide-18
SLIDE 18

18

Micromonitor 01

~ 0 gal Feb 28th Storm

slide-19
SLIDE 19

19

MM-02

MM-02

slide-20
SLIDE 20

20

Micromonitor 02

~ 0 gal Feb 28th Storm

slide-21
SLIDE 21

21

MM-03

MM-03

slide-22
SLIDE 22

22

Micromonitor 03

~ 0 gal Feb 28th Storm

slide-23
SLIDE 23

23

MM-04

MM-04

slide-24
SLIDE 24

24

Micromonitor 04

9,000 gal Feb 28th Storm

slide-25
SLIDE 25

25

MM-05

MM-05

slide-26
SLIDE 26

26

Micromonitor 05

34,000 gal Feb 28th Storm

slide-27
SLIDE 27

27

Micro Monitoring Schematic

Layout of Micromonitors upstream of -071 MM-06 MM-05 MM-04 MM-03 MM-02 MM-01

  • 071
slide-28
SLIDE 28

28

MM-06

MM-06

slide-29
SLIDE 29

29

Micromonitor 06

36,000 gal Feb 28th Storm

slide-30
SLIDE 30

30

CCWA – Summary

INFLOW recorded at the downstream monitor (-071)

  • riginated in Sub-basin 6. (18% of the Basin)

82% reduction in SSES!!

slide-31
SLIDE 31

31

Micromonitoring Advantages

  • Significant I/I sources (the cost effective ones)
  • No CSE (one-man crew)
  • Quick Calibration
  • Rapid Deployment
  • Poor Quality sites
  • Low flow
  • Non-Invasive
slide-32
SLIDE 32

32

Micromonitoring Limitations

  • 8” pipes only
  • Lined pipes
  • Overestimates during surcharge and steep pipes
slide-33
SLIDE 33

33

Questions?
