Michael Homer

Programming Languages

2

Research focus

• Making programming more

accessible to non-programmers.

• Making (sub-)language creation

more available to programmers

• Packaging

3

Enabling embedded domain-specific languages We want to let a programmer write a library that

• extends the language,
• restricts the language,
• or some combination of the two.

Graceful Dialects. Homer et al. ECOOP’14.

4

Extending the language

aDSL ModuleX

dialect "aDSL" ... ... use {x} on(arg) ...

dslhlpr aDSL

dialect "dslhlpr" ... method use(arg1)

• n(arg2) {

...

}

5

Restricting the language

6

Turtle graphics

import "turtle" as turtle def red = turtle .red ... var lineWidth := 1 var lineColour := black method forward(dist) { turtle .move(dist, lineColour, lineWidth)

}

method turnRight(ang) { turtle .turnRight(ang)

}

... method repeat(n)times(blk) { var counter := 1 while {counter <= n} do { blk.apply counter := counter + 1

} }

method atModuleEnd(mod) { turtle . start

}

7

Helping to write restrictive dialects

method checker(ast) { // Loop over every node and examine it for (ast.nodes) do { n −> for (rules) do { r −> ... } }

}

method rule(block) { rules.push(block)

}

method when(pred : UnaryPredicate) error(msg : String) { rule { node −> def matches = pred.match(node) if (matches.andAlso {matches.result}) then { fail(msg) }

} }

8

Enforcing nominal types

rule { req : QualifiedRequest −> def rType = typeOf(req.receiver) match (rType) case { r : Brand −> ... }

}

rule { decl : Let −> def eType = typeOf(decl.value) if (BrandType.match(eType)) then { eType.name := decl.name.value

} }

209 LOC total

Brand Objects for Nominal Typing. Jones, Homer, and Noble. ECOOP’15.

9

GrAPL

dialect "grapl" N ← [1, 2, 3, 4] print (N) // Prints [1, 2, 3, 4] print (N + 2) // Prints [3, 4, 5, 6] print (+/N) // Prints 10 // Standard Lotto example. print (L[ |

(L ← (n 6 ? 40))])

// Calculate primes up to 20. print ((P ← (n 1 ↓ ι20))/(P∈(P◦·∗P)))

10

Combining tiled and textual programming

Combining Tiled and Textual Views of Code. Homer and Noble. VISSOFT’14. 11

Tiled Grace

http://ecs.vuw.ac.nz/˜mwh/minigrace/tiled/

Combining Tiled and Textual Views of Code. Homer and Noble. VISSOFT’14.

12

Switching views

• Median participant switched 6 times.
• 75% switched at least 4 times.
• Half of participants spent between 24% and 52% of their time in

text view.

2 4 6 5 10 15 20

Total number of switches of view count

13

Error reporting

“The way of showing errors was amazingly helpful.” “It also gave specific detail about the error.” “Error finding and handling looks great, is very easy and straightforward.”

5 10 1 Agree 2 3 4 Neutral 5 6 7 Disagree

Finding errors in the code was easy count

Finding errors in the code was easy 1 Agree 2 3 4 Neutral 5 6 7 Disagree

14

Engagement

0:15 0:30 0:45 1:00 1:30 2:00 2:30 3:00 3:30 4:00 4:30 5:00 6:00 7:00 8:00 9:00 10:00 11:00 12:00 13:00 14:00 10 20 30

count Time spent unprompted on Task 5 (minutes)

More or less time than this Less More

70% used system when they didn’t have to.

15

Engagement

0% 10% 20% 30% 40% 1 Agree 2 3 4 Neutral 5 6 7 Disagree

The system was fun to use Percentage choosing each option

How many technologies used Ten or fewer More than ten

16

Ongoing

• Gradual typing
• Concatenative programming
• Package management
• Object inheritance

17

Outlook

18

References

• Graceful Dialects. European Conference on Object-Oriented Programming

(ECOOP), 2014. Michael Homer, Timothy Jones, James Noble, Kim B. Bruce, and Andrew P . Black.

• Brand Objects for Nominal Typing. European Conference on Object-Oriented

Programming (ECOOP), 2015. Timothy Jones, Michael Homer, and James Noble.

• From APIs to Languages: Generalising Method Names. Dynamic Language

Symposium (DLS), 2015. Michael Homer, Timothy Jones, and James Noble.

• Patterns as Objects in Grace. Dynamic Language Symposium (DLS), 2012.

Michael Homer, James Noble, Kim B. Bruce, Andrew P . Black, and David J. Pearce.

• Combining Tiled and Textual Views of Code. IEEE Working Conference on

Software Visualisation (VISSOFT), 2014. Michael Homer and James Noble.

• A Tile-based Editor for a Textual Programming Language. IEEE Working

Conference on Software Visualisation (VISSOFT), 2013. Michael Homer and James Noble.

19

Michael Homer

Multi-part method names

method check(x) between(low) and(high) { return (x >= low) && (x <= high)

}

if (x < y) then { print "less"

} else {

print "Not less"

}

21

Repeated parts

+ before a part means it can appear more than once. method a(x) +b(y) { ... }

accepts requests

a(1) b(2) a(1) b(2) b(3) a(1) b(2) b(3) b(4) ...

∗ means zero or more times.

22

Parameter binding

Parameters in repeated parts are bound as sequences.

method a(w) +b(x, y) c(z) { // x and y are sequences here for (x) do { xv −> print(xv) } // w and z are not print (w)

}

23

Optional parts

? before a part means it is optional. method a(x) ?b(y) { ... }

accepts requests

a(1) a(1) b(2)

Parameters are also bound as trivial sequences. 24

Grouping parts

Parentheses around parts create a group for other modifiers.

method a(x) ?(b(y) c(z)) { ... }

accepts requests

a(1) a(1) b(2) c(3)

but not

a(1) b(2) a(1) c(3)

25

Alternations

| inside a group creates an alternation.

method a(x) (b(y) | c(z)) { ... }

accepts requests

a(1) b(2) a(1) c(3)

26

Prefixes

Methods are uniquely identified by their prefix of required parts.

Declaration Prefix 1

a(x) b(y) c(z)

a b c 2

a(x) b(y) ?c(z)

a b 3

a(x) ?b(y) c(z)

a 4

a(x) +b(y) c(z)

a b

Shortest prefix used: there is at most one method in an object that could be selected to respond to any given request.

27

Greedy matching

Match request and declaration parts left to right, committing to potential matches eagerly. Greedy matching of parts allows concrete error messages: Error: expected to see part "finally" but saw part "else" instead. 28

Uncallable methods

method a(x) ∗b(y) b(z) {}

There is never a b left for the last part to match. However, the requests presumably intended are accepted by:

method a(x) +b(y) {}

29

match case... method match(target) +case(cases) { for (cases) do { case −> def mr = case.match(target) if (mr) then { return mr.result

} }

fail "Match was not exhaustive"

}

30

Control structures

method if(bool) then(blk) +( elseif (conds) then(blks)) ?else(elseblk) { ... } method try(blk) ∗catch(catchblk) ? finally ( finallyblk ) { ... }

31

Testing DSL

method feature(name) ?background( initialisation ) +(scenario(desc) ?(Given(context) ∗And(contexts)) When(event) Then(expr) ShouldBe(val)

∗(And(exprs) ShouldBe(vals)))

Based on http://cucumber.io/’s testing language 32

Creating a button

Declarative construction of a button:

gtk.button { document.save } label "Save" image(icons.floppy disk) position(gtk. position . right ) relief (gtk. relief .none)

Well-formedness of method name guarantees semantic validity. 33

Embedded DSL: Query language

from(students) Where { s −> s.enrolledIn "COMP231" } Where { s −> s.age > 25 } OrderBy { s −> s.gpa } ThenBy { s −> s.age } ThenBy { s −> s.id } Select { s −> s.name }

from s in students where s.enrolledIn("COMP231") where s.age > 25

• rderby s.gpa, s.age, s.id

select s.name 34

selectProjection .do { p −> return data.select(p)

}

thenBys.do { ifPresent −> for (ifPresent) do { t −> data := data.thenBy(t)

} }

35

Library initialisation

method button(handler : Block) ( ( label( text : String) | mnemonic(mt : String)) ?(image(textImage : Image) ?position(imagePos:PositionType) )

| namedIcon(name : String, size : IconSize) | image(image : Image) | widget(w : Widget)

) ? relief ( style : ReliefStyle) ?alignment(xalign : Number, yalign : Number) { ... }

36

Greedy matching

To match request parts to declaration parts:

• 1. Match the prefix of both.

This is known to match exactly by the method resolution rules.

• 2. If the current request part is accepted by the current declaration

part, commit to it (bind the request arguments into the declaration parameters) and advance the request part. If the declaration part is a group, it matches if the prefix of the group matches the request starting at this point. (a) If the declaration part is not a + or ∗, advance the declaration part. Go to 2 37

• 3. If the current request part is not accepted by the current

declaration part: (a) If the current declaration part is a ∗ or ?, advance the declaration part and go to 2. (b) If the current declaration part is a + that has already consumed at least one request part, advance the declaration part and go to 2. (c) Otherwise, report an error “expected part X, saw part Y”.

• 4. If there are no more declaration parts and there are remaining

request parts, report an error.

• 5. If there are no more request parts, and any remaining declaration

part is not optional, report an error. 38

Enabling embedded domain-specific languages We want to let a programmer write a library that

• extends the language,
• restricts the language,
• or some combination of the two.

Graceful Dialects. Homer et al. ECOOP’14.

39

Extending the language

aDSL ModuleX

dialect "aDSL" ... ... use {x} on(arg) ...

dslhlpr aDSL

dialect "dslhlpr" ... method use(arg1)

• n(arg2) {

...

}

40

Restricting the language

41

Pattern matching

match(node) case { v : VarDeclaration | TypeDeclaration

−> ... }

Destructuring:

case { w : WhileDo(condition, body)

−> if (condition == ...) then {

...

} }

Patterns as Objects in Grace. Homer et al. DLS’12.

42

Building a type checker

rule { req : Request −> match(typeOf(req.in).getMethod(req.name)) case { : NoSuchMethod −> fail "no such method" } case { mt : MethodType −> for (mt.signature) and(req.with) do { s, w −> for (s.params) and(w.args) do { p, a −> if (!typeOf(a).isSubtypeOf(p.decType)) then { fail "argument does not satisfy parameter type" }

} }

return mt.returnType // Type of expression

} }

Brand Objects for Nominal Typing. Jones, Homer, and Noble. ECOOP’15.

43
