S ERVICIOS A LA N AVEGACIN EN EL E SPACIO A REO M EXICANO MEXICO ADS-B PROJECT PREVIEW Syllabus SENEAM Previous SENEAM ADS-B Program SENEAM-FAA ADS-B Program SENEAM ADS-B Schedule SENEAM ADS-B 2014-2018 1 2 3 4 5 2 Syllabus:

slide-1
SLIDE 1

SERVICIOS A LA NAVEGACIÓN EN EL ESPACIO AÉREO MEXICANO MEXICO ADS-B PROJECT PREVIEW

slide-2
SLIDE 2

2

Syllabus 1 2 3 4 5

SENEAM

Previous SENEAM ADS-B Program SENEAM-FAA ADS-B Program SENEAM ADS-B Schedule SENEAM ADS-B 2014-2018

slide-3
SLIDE 3

3

Syllabus: 6 7

SENEAM

SENEAM ADS-B Sites. ADS-B Track Symbols. Mexico´s ATM System.

slide-4
SLIDE 4

1

Previous

SENEAM

slide-5
SLIDE 5

5

1

PREVIOUS

Mexico as member of ICAO and in accordance with the 2013 – 2016

  • Activities. Plan of the Regional Technical Cooperation Project for the Caribbean

Region – implementation of the Performance Based Air Navigation Systems for the CAR Region, have designed an implementation plan to install a first set of 10 ADS-B radio stations on strategic sites, to feed with ADS-B data meet DO-260 and DO- 260A and Asterix Cat 21 forward to four ATM systems in FDRG through

  • ur country.

The four ATM systems are being updated for accepting and processing ADS-B data and fusing them with ATC radar sensors. The implementation plan, obeys the need of increasing safety and efficiency of air / ground operations, mainly about surveillance, separation, coverage redundancy and getting surveillance data in non radar areas.

slide-6
SLIDE 6

6

1

PREVIOUS

Also, in parallel, SENEAM is working together with FAA to develop and deploy of Automatic Dependent Surveillance – Broadcast (ADS-B) as a means of providing satellite based surveillance for air traffic control (ATC) systems that serve the Gulf of Mexico region. New ADS-B services will be beneficial to both parties in areas where radar coverage may be nonexistent or can be enhanced by ADS-B sensors.

slide-7
SLIDE 7

7

1

PREVIOUS

The joint use of ADS-B will enhance the development and performance of air traffic control and pilot applications. Safety levels, efficiency, and capacity will also be enhanced by providing new and expanded surveillance coverage for the airspace in the United States and Mexico.

slide-8
SLIDE 8

2

SENEAM ADS-B Program

SENEAM

slide-9
SLIDE 9

9

2

SENEAM ADS-B Program

Up to date, SENEAM has installed 10 ADS-B stations at the following sites:

  • 5 in Mexico’s City Valley (Toluca’s Airport, Cerro Peñon, Cerro

Catedral, Cerro Gordo & Mexico’s ATC TWR Control)

  • 1 in Radar Station of Cerro Los Gallos, Aguascalientes (LGS), at

Central of Mexico

  • 1 in Southeast of Mexico at Ciudad del Carmen (CME)
  • 2 in Northeast of Mexico at Monterrey´s Terminal Airport (MTY) &

in Radar station of Cerro de Potosi (CPT)

  • 1 in Radar station of Puerto Peñasco Sonora (PPE), at the Northwest
  • f México
slide-10
SLIDE 10

10

2

SENEAM ADS-B Program

SENEAM is also executing a software updating all four main ATM systems based on each ACC: Mérida: The ATM system has been updated since Dec 4 2013, full ADS-B capable. One ADS-B station at Ciudad del Carmen, Campeche is on test process. México: Five ADS-B stations are working and on test process Data gathering is taking place to begin the evaluation for data integration

  • n ATM systems (Radars and ADS-B sensors).

Monterrey & Mazatlán: ADS-B software (MEDISIS), is on Test & Evaluation platform. FAA ADS-B stations on Tampico, Mérida and Cancún will be installed on 2015 and will be operative until 2016.

slide-11
SLIDE 11

11

2

Coverage of SENEAM ADS-B 2015

SENEAM ADS-B Program

PPE MTY CPT MEX CME LGS

slide-12
SLIDE 12

12

Needs to be covered

  • Surveillance of México Valley
  • Air Traffic Control of Mexico City Airport Terminal Area
  • Air Traffic Control of Helicopters flying over Mexico Valley
  • Air Traffic Control of Monterrey Airport Terminal Area
  • Surveillance redundancy on Puerto Peñasco station
  • Air Traffic Control Area of Merida
  • Surveillance of Helicopters flying from/to Oil Platform on Gulf of

México

2

SENEAM ADS-B Program

slide-13
SLIDE 13

3

SENEAM-FAA ADS-B Program

SENEAM

slide-14
SLIDE 14

14

3

SENEAM-FAA ADS-B Program

FAA-SENEAM Agreement ADS-B Stations

FAA-SENEAM Agreement considers the installation of ADS-B stations at:

  • Tampico
  • Mérida
  • Cancún
slide-15
SLIDE 15

15

3

SENEAM-FAA ADS-B Program

FAA ADS-B current coverage on GOM

slide-16
SLIDE 16

16

3

SENEAM-FAA ADS-B Program

FAA-SENEAM ADS-B forecasted coverage

slide-17
SLIDE 17

17

Coverage of SENEAM-FAA ADS-B 2015

3

SENEAM-FAA ADS-B Program

PPE MTY CPT MEX CME TAM MID CUN LGS

slide-18
SLIDE 18

18

Needs to be covered

  • Air Traffic Control Area of Merida, Cancún
  • Complete surveillance of Helicopters flying from/to Oil Platform on

Gulf of México

  • Sharing data with FAA to have complete surveillance of Gulf of

Mexico in order to enhance the Air Traffic Management beetwen FDRG of both countries.

3

SENEAM-FAA ADS-B Program

slide-19
SLIDE 19

4

SENEAM ADS-B Schedule

SENEAM

slide-20
SLIDE 20

20

Date Site ID May 2014 Cerro Gordo CGO May 2014 Cerro Peñón PEN May 2014 AICM MEX May 2014 Toluca TLC May 2014 Cerro Catedral CCD

SENEAM ADS-B Schedule

4

SENEAM ADS-B Schedule

PPE MTY CPT MEX CME TAM LGS

slide-21
SLIDE 21

21

ADS-B coverage area of all 5 selected ADS-B ground stations within Mexico Valley and Toluca Valley at 40000 ft AMSL for aircraft ADS-B transponders Tx power of 250 W

4

SENEAM ADS-B Schedule

Theoretical coverage on Mexico Valley

slide-22
SLIDE 22

22

4

SENEAM ADS-B Schedule

Date Site ID

  • Jan. 2015

Puerto Peñasco PPE

  • Jan. 2015

Monterrey MTY

  • Jan. 2015

Cerro Potosí CPT

  • Jan. 2015
  • Cd. Carmen

CME PPE MTY CPT MEX CME TAM LGS

  • Jan. 2015

Los Gallos LGS

slide-23
SLIDE 23

5

SENEAM ADS-B 2014-2018

SENEAM

slide-24
SLIDE 24

24

ADS-B 2014-2018

2014 2015 2016 2017 Total 2018 5 5 + 3 13 12

35+3

CGO, PEN, MEX, TLC, CCD PPE, MTY, CPT, CME, LGS TAM, CUN, MID TRC, CUU, SEU, ZIH, PVR, TGZ, ACA, MZT, CUL, SLP, BJX, GDL, SJD LAP, CAB, LPD, PTE, CCL, LRS, VER, VSA, ZIJ, HUA, TIJ, HMO

5

SENEAM ADS-B 2014-2018

slide-25
SLIDE 25

6

SENEAM ADS-B Sites.

SENEAM

slide-26
SLIDE 26

26

TWR MEX 6

SENEAM ADS-B Sites

slide-27
SLIDE 27

27

CERRO GORDO 6

SENEAM ADS-B Sites

slide-28
SLIDE 28

28

CERRO GORDO 6

SENEAM ADS-B Sites

slide-29
SLIDE 29

29

SENEAM ADS-B Sites

6

CERRO CATEDRAL, EDO. DE MEXICO

slide-30
SLIDE 30

30

SENEAM ADS-B Sites

6

PUERTO PEÑASCO, SONORA

slide-31
SLIDE 31

31

SENEAM ADS-B Sites

6

LOS GALLOS, AGUASCALIENTES

slide-32
SLIDE 32

32

SENEAM ADS-B Sites

6

MONTERREY, NUEVO LEON

slide-33
SLIDE 33

33

SENEAM ADS-B Sites

6

CIUDAD DEL CARMEN, CAMPECHE

slide-34
SLIDE 34

7

ADS-B Track Symbols

  • n ACC Mexico System

& ADS-B Labels from

  • ther sites.

SENEAM

slide-35
SLIDE 35

35

7

ADS-B Only (MEX)

slide-36
SLIDE 36

36

7

ADS-B + SSR (MEX)

slide-37
SLIDE 37

37

7

ADS-B + SSR + PSR (MEX)

slide-38
SLIDE 38

38

7

ADS-B LGS

slide-39
SLIDE 39

39

7

ADS-B PPE

slide-40
SLIDE 40

40

7

ADS-B CME

slide-41
SLIDE 41

SERVICIOS A LA NAVEGACIÓN EN EL ESPACIO AÉREO MEXICANO

MEXICO ADS-B PROJECT PREVIEW

THANK YOU !

Mexico City. April 27, 2015
