Coastal winds over EBUS Mean Structure and Variability Ren D. Gareaud Geophysics Department, Universidad de Chile Center for Climate and Resilience Research Thanks to Jos Rutllant 1,2 , Ricardo Muoz 1 , David Rahn Outline Subtropical

slide-1
SLIDE 1

Coastal winds over EBUS Mean Structure and Variability

René D. Gareaud Geophysics Department, Universidad de Chile Center for Climate and Resilience Research

Thanks to José Rutllant1,2, Ricardo Muñoz1, David Rahn

slide-2
SLIDE 2

Outline

  • Subtropical anticyclones: Hadley + Mnts + Monsoons
  • Coastal jets (large-scale and local-scale mean structure)
  • Extra bonus….when upwelling is gone….
  • Coastal winds variability
slide-3
SLIDE 3

EBUS: Subtropical anticyclones, equatorward flow and cold SST

slide-4
SLIDE 4

General circulation in an aqua-planet

Perpetual Equinox

0° 45° NE trades SE trades ITCZ: Intertropical Convergence Zone

Surface wind (arrows) Precipitation (green shadow) But we want subtropical highs!

slide-5
SLIDE 5

0° 60°

General circulation in an aqua-planet

Perpetual Equinox

Jet stream (westerly flow) aloft (10-12 km): long term mean. Boundary between subtropical and extratropical air masses ITCZ Midlatitude precipitation maximum and westerly belt

slide-6
SLIDE 6

Zonal wind just upstream of the Andes (over the SE Pacific). Note that in winter the subtropical Jet (30ºS) impinges against the high Andes (not so much in summer).

Atmospheric flow – mountain interaction

slide-7
SLIDE 7

West East North

H = constant

South

5 km 12 km

Atmospheric flow – mountain interaction

slide-8
SLIDE 8

H = constant

Atmospheric flow – mountain interaction

slide-9
SLIDE 9

Austral winter: Mountain only run (no latent heating) is quite good in simulating the SEP anticyclone

w(700 hPa) Stream function at 900 hPa Full (heat+mnt)

  • Mnt. only

Anticyclone split Strong subsidence Rodwell and Hoskins 2001

slide-10
SLIDE 10

July 850 hPa winds CTRL NSAO CTRL NSAO

Atmospheric flow – mountain interaction

slide-11
SLIDE 11

Atmospheric flow – mountain interaction

Low cloud feedback Evaporative cooling

slide-12
SLIDE 12

Atmospheric flow – mountain interaction

Control noAndes

900 hPa wind & Temp Clouds: Control - noAndes

Warm air into MBL No Andes No clouds!

slide-13
SLIDE 13

Atmospheric flow – mountain interaction

No Andes No clouds!

slide-14
SLIDE 14

No Andes No clouds! Warm ocean…

SST and Sfc Wind: Control - No Andes Clouds & LTS Control - No Andes

slide-15
SLIDE 15

Zonal wind just upstream of the Andes (over the SE Pacific). Note that in winter the subtropical Jet (30ºS) impinges against the high Andes (not so much in summer).

Monsoonal (continental heating) influence

slide-16
SLIDE 16

w(700 hPa) Stream function at 900 hPa Full (heat+mnt)

  • Mnt. only

Subsidence in right place but only ¼ of the full value

Austral summer: Mountain only run not good in simulating the SEP anticyclone. Continental heating is essential.

Anticyclone split much weaker

slide-17
SLIDE 17

Efecto monsonal (Rodwell and Hoskins 2001)

  • Calentamiento diabático en zona de precipitación
  • Expansión del calentamiento por ondas de Kelvin/Rossby
  • Advección fría al Oeste del continente
  • Incremento de la subsidencia sobre Pacifico SE

Precipitation 200 hPa wind 500 hPa temperature 200 hPa wind Horizontal cold advection

slide-18
SLIDE 18

Efecto monsonal (Rodwell and Hoskins 2001)

200 hPa Hor Temp Adv SLP

Sobre el SEP el calentamiento diabático es levemente negativo por lo que advección horizontal fría es compensada por subsidencia (calentamiento adiabático). Notar qué lo contrario ocurre en el SACZ. Sobre la Amazonia el balance es entre ascenso y calentamiento diabatico.

slide-19
SLIDE 19

Subtropical Hig igh

SC SCu deck

SAM IT ITCZ

Key atmospheric features over the SEP

Coastal je jet Coastal Fog

slide-20
SLIDE 20

Zonal flow – Andes interaction Monsonal connection (austral summer only) Equatorward flow ↑ Low Trop. Stability Drying of MBL ↑ subsidence ↑ coastal upwelling ↑ Evaporative cooling ↑ Stratus clouds ↓Solar rad. at sfc ↑ MBL cooling ↓ SST (near shore and offshore) Oceanic transport

Svedrup balance

slide-21
SLIDE 21

Coastal Low Level Jets

NCEP-NCAR Reanalysis, 1000 hPa meridional (NS) winds, annual long term mean

slide-22
SLIDE 22

A A

Surface wind speed & coastal jets

Jet costero (máxima magnitud) a lo largo de la costa Variabilidad sinóptica y estacional dictada por (SLP) / y

slide-23
SLIDE 23

V

U  w

V

U  w

Along shore

V > 18 m/s

Simulated (MM5) structure of the coastal jet Cross shore

Garreaud & Muñoz 2006

slide-24
SLIDE 24

v u H d C fv x p y u v x u u t u  − +   =   +   +    1 v v H C fu y p y v v x v u t v

d

 − +   − =   +   +    1

2

1 v H C y p

d

=   − 

Garreaud & Muñoz 2006

Coastal jet dynamics

Along-shore pressure gradient  friction

slide-25
SLIDE 25

Goals of Fondecyt 1090492 (Garreaud, Muñoz, Rutllant)

Understand the alongshore structure of the MBL and its diurnal cycle

slide-26
SLIDE 26

Coastal jets intensify downstream of major capes. Upwelling maximum Cloud free

slide-27
SLIDE 27

QSCAT also reveals some meso-scale details and insights on the diurnal cycle

slide-28
SLIDE 28

Max Upwelling Min SST Expansion Fan?

SQ1-Climatological near-coastal wind maxima around 30°S:

Structure? Wind-SST feedback or expansion fan Effect?

  • Aircraft zonal coastal jet missions
  • Radiosonde from R/V
  • Modeling: control(?) + sens. runs

SST Front Coastal Jet Core: vp/y

74°W 72°W 70°W 30°S 28°S 32°S

slide-29
SLIDE 29

New Conceptual Model for Coastal Jet (30ºS)

Rahn & Garreaud 2012

slide-30
SLIDE 30

Synoptic variability during CUpEx: Local T(Ocean) & wind

R1 R2

slide-31
SLIDE 31

PGF

Synoptic variability during CUpEx

v v H C y p

d

 =   −

2

1 

slide-32
SLIDE 32

Synoptic variability during CUpEx: SSMI SST

High wind SST field [C] Low - High wind SST field [C]

slide-33
SLIDE 33
slide-34
SLIDE 34

U,V elsewhere (vectors) WS elsewhere (contour) Cloud elsewhere (colors)

U,V elsewhere (vectors) V elsewhere (contour) SST elsewhere (colors) Jet events associated with: Stronger anticyclone / Reduced Sc near the coast / Increased Sc off the coast / Sea surface cooling at and downstream the jet 1-Point correlation map. V(33S/73W) regresed upon

Synoptic variability of Coastal winds

slide-35
SLIDE 35

Composite upwelling events in near Concepción (37ºS, Chile)

Relaxation begins Upwelling begins

slide-36
SLIDE 36

Composite upwelling events in near Concepción (37ºS, Chile)

Relaxation begins Upwelling begins

slide-37
SLIDE 37

(a) 200 hPa height and OLR anomalies (15-30 January 2017) (b) Rainfall deciles January 2017

Coastal El Niño 2017

3 weeks with very weak westerlies impinging the Andes Garreaud 2017

slide-38
SLIDE 38

NW Peru storms, 03 March 2017 GPM radar 17 dBZ isosurface

Source: Harold Pierce, NASA GSFC

>200 fallecidos, 3.1 Bill US$

Coastal El Niño 2017

slide-39
SLIDE 39

The March 2015 Atacama Storm. Three days of intense rainfall triggered landslides and widespread flooding. More than 80 causalities and major damage to public and private infrastructure. Most acute impact during the event but many problems (e.g. public health) in subsequent months.

slide-40
SLIDE 40

Niño 1-2 SST SST anomaly 23 March 2015

COL Track

Plausible suspect: marked, sudden SST warming off South America (EN 2015) Destabilize the atmosphere and provide extra moisture

slide-41
SLIDE 41

Numerical experiment using RegCM (forced by ERA)

In a sensitivity run the SST was keep equal to the field at March 10 (prior to the warming) thus causing a sfc BC cooler than the control run

slide-42
SLIDE 42

RegCM simulated precipitation

CTR Sens Sens-CTR Sens/CTR %

slide-43
SLIDE 43

CTR PW (contours) and SENS-CTR PW (colors)
