SLIDE 1
Materials & Shading
CPSC 453 – Fall 2018 Sonny Chan
Materials
Rendered by Unreal Engine
Materials & Shading CPSC 453 Fall 2018 Sonny Chan Materials - - PowerPoint PPT Presentation
Materials & Shading CPSC 453 Fall 2018 Sonny Chan Materials - - PowerPoint PPT Presentation
Materials & Shading CPSC 453 Fall 2018 Sonny Chan Materials Rendered by Unreal Engine The appearance of a material is determined by the manner in which light is reflected from it, or transmitted through it. What is the most basic
SLIDE 2
SLIDE 3
The appearance of a material is determined by the manner in which light is reflected from it, or transmitted through it.
SLIDE 4
What is the most basic
material property?
SLIDE 5
Colour: Spectral Reflectance Curves
[from scratchapixel.com]
SLIDE 6
But not the only factor!
RenderMan PxrLM
SLIDE 7
Let’s take a look at some
real world materials
SLIDE 8
Hand with Reflecting Sphere (Self-Portrait)
M.C. Escher, 1935
SLIDE 9
Ideal Specular Reflections
r = d − 2(d · ˆ n)ˆ n Trace another ray, as if you were looking from underneath.
SLIDE 10
Real surfaces are not perfectly specular!
SLIDE 11
Real surfaces are not perfectly specular!
SLIDE 12
Mixed Specular Reflections
r = d − 2(d · ˆ n)ˆ n Add fraction of ray’s light with to surface material colour.
SLIDE 13
But wait a minute…
What’s the difference? dielectric (non-conductor) metallic (conductor)
SLIDE 14
Metallic Specular Reflections
r = d − 2(d · ˆ n)ˆ n Multiply reflected ray’s light with the surface material colour.
SLIDE 15
A Glass Marble
What do we do with this material?
SLIDE 16
Snell’s Law
- Ratio of sines of angles is
equal to ratio of velocities:
sin θ sin φ = v vt = nt n
SLIDE 17
SLIDE 18
n Material 1.0001 air 1.333 water 1.47
- live oil
1.52 crown glass 1.62 flint glass 2.15 cubic zirconia 2.42 diamond
Index of Refraction
- f some common materials
SLIDE 19
Ray Tracing Refraction
n sin θ = nt sin φ cos2 φ = 1 − n2(1 − cos2 θ) n2
t
t = n(d + ˆ n cos θ) nt − ˆ n cos φ
SLIDE 20
A Diffuse Reflector
M.C. Escher, 1946
SLIDE 21
Three Spheres II
M.C. Escher, 1946
SLIDE 22
Properties of Diffuse Reflectors
SLIDE 23
SLIDE 24
Diffuse Reflection
- Brightness dependent
- nly on the direction of
incident light
- View direction has no
effect on appearance
- Lambert’s cosine law:
c ∝ ˆ n ·ˆ l c = crcl max(0, ˆ n ·ˆ l)
SLIDE 25
Specular Highlights
A Heuristic Approximation
SLIDE 26
Moonlight Reflection
What do you see in this picture?
SLIDE 27
Plastic, Magnified
[image from gelsight.com]
SLIDE 28
Microfacet Geometry Model
[images from Real-Time Rendering, A K Peters, 2008]
SLIDE 29
Phong Lighting Model
r = −l + 2(l · ˆ n)ˆ n c = cl max(0, ˆ e · ˆ r)p
SLIDE 30
Blinn-Phong Lighting Model
ˆ h = e + l ||e + l|| c = cl max(0, ˆ h · ˆ n)p
SLIDE 31
The Phong Exponent
y = cosp θ
p = 1 p = 64
SLIDE 32
Phong Highlights
SLIDE 33
Summary: Types of Surface Reflectance
- Ideal specular (mirror)
- reflection law
- Ideal diffuse (matte)
- Lambert’s law
- Specular (glossy)
- directional diffuse
SLIDE 34
What about
ambient light?
SLIDE 35
Indirect Lighting
Material reflection works both ways!
SLIDE 36
Global Illumination
direct indirect combined Global illumination is really hard and expensive to compute!
SLIDE 37
Ambient Light
Approximated by a constant light source that represents the average indirect light energy in the scene.
c = crca
SLIDE 38
Our final heuristic shading equation…
- with ambient, diffuse, and specular terms:
- cr is reflectance (diffuse) colour of material
- cp is specular colour of material
- p is Phong exponent, or shininess of material
- cl is light source intensity (colour)
- ca is ambient light intensity (colour)
c = cr ⇣ ca + cl max(0, ˆ n ·ˆ l) ⌘ + cl cp ⇣ ˆ h · ˆ n ⌘p
SLIDE 39
Things to Remember
- The appearance of a material is determined by the
manner in which light is reflected from it
- The Phong lighting equation approximates material
colour, diffuse and specular reflection, and ambient light
- Ideal specular reflection and refraction are relatively easy
to achieve with ray tracing
