  1. Magnetic-inductive flow meter MP603 Justing s.r.o. Nám. Dr. A. Schweitzera 180 EU / SK - 916 01 Stará Turá

  2. MP603 // Purpose EC Type-examination Certificate No. SK 08-MI001-SMU001 for measuring of electro-conductive liquids for chemical aggressive substances (acids, plains,...) for eatables (milk, beer, wine, yoghurt, jam, water) for bilge water (sewage disposal works) flow sensors in the food industry can be cleaned as standard pipings 2

  3. MP 603 // Advantages high protection IP65, aluminium case of the evaluation unit new input amplifier with high resistance against disturbing impacts precise micro-controller with two 24-bit A/D encoders (ADuC845) built-in voltaic detached output (set as a frequency or pulse output) built-in voltaic detached input possibility to simultaneously connect 3 additional modules: analog input module 4 - 20 mA, for measuring temperature, pressure, density,... voltaic detached analog output module 4 - 20 mA or 0 - 20 mA voltaic detached serial interface module RS485 (on demand: M-BUS, RS232, radio, USB...) software options: user zero-fill counter of passed (flown) volume passed (flown) volume counter under and over a par limit 3

  4. MP603 // Specifications Environment temperature MP603: 0°C - 55°C (MP603Z: -25°C - 50°C) Protection IP 65 Display 16-digits LCD Storing period for measured data min. 10 years 230 V - 15%, +10%; 50 Hz ± 2% Feeding MP603: 10 VA (MP603Z: 25 VA) resistance: E2 class - industrial environment Electro-magnetic environment radiation: E1 class - domiciliary, light industry MP603: B class - static units installed indoors Climatic and mechanic environment MP603Z: C class - static units installed outdoors Mechanical environment M1 - spaces with vibrations and shakings of low intensity Dimensions of evaluation electronics 180 x 170 x 90 mm Weight of evaluation electronics 4 kg Max. temperature of medium - PTFE (teflon) coating 160 °C Max. temperature of medium - rubber coating 60 °C Required medium conductibility min. 20 ! S/cm Min. linear piping lengths 5 DN in front of the sensor, 3DN behind the sensor 4

  5. MP603 // Flow ranges - water DN (mm) 10 15 20 25 32 40 50 Overload flow Q4 3,13 7,88 12,5 20 31,25 50 78,75 (m 3 /h) Nominal flow Q3 2,5 6,3 10 16 25 40 63 (m 3 /h) Transitional flow Q2 0,08 0,20 0,32 0,51 0,80 1,28 2,02 (m 3 /h) Minimal flow Q1 0,05 0,13 0,20 0,32 0,50 0,80 1,26 (m 3 /h) Range Q3 : Q1 50 50 50 50 50 50 50 DN (mm) 65 80 100 150 200 250 300 Overload flow Q4 125 200 312,5 787,5 1 250 2 000 3 125 (m 3 /h) Nominal flow Q3 100 160 250 630 1 000 1 600 2 500 (m 3 /h) Transitional flow Q2 3,20 5,12 8,00 20,16 32,00 51,20 80,00 (m 3 /h) Minimal flow Q1 2,00 3,20 5,00 12,60 20,00 32,00 50,00 (m 3 /h) Range Q3 : Q1 50 50 50 50 50 50 50 5

  6. MP603 // Accuracy - water Max. uncertainty Q 1 ! Q < Q 2 Q 2 ! Q < Q 4 cold water t ! 30°C max ± 5%; typical ± 2% max ± 2%; typical ± 1% warm water t > 30°C max ± 5%; typical ± 3% max ± 3%; typical ± 1,5% 6

  7. MP603 // Dimensions DN (mm) 10 15 20 25 32 40 50 Length (winding) 130 / 3/4” 130 / 3/4” 190 / 1” 190 / 5/4” 190 / 6/4” 200 / 2” - (mm / thread) Length (flanged) 130 130 190 190 190 200 200 (mm) Flange diameter 95 95 105 115 140 150 165 for PN16 (mm) Flange diameter 95 95 105 115 140 150 165 for PN40 (mm) Approx. weight (kg) 4,5 5 6 7 8 9 10 DN (mm) 65 80 100 150 200 250 300 Length (winding) - - - - - - - (mm / thread) Length (flanged) 200 225 250 300 350 450 500 (mm) Flange diameter 180 200 220 285 340 405 460 for PN16 (mm) Flange diameter 180 200 235 300 375 450 515 for PN40 (mm) Approx. weight (kg) 12,5 15 17 28 44 50 55 7

  8. Other products from JUSTING h / m l 0 0 0 . 0 3 - 3 g n r i u s s a e e m s Ultrasonic heat meters a e g t d a r n u a c s c d A i u q i l r o f Domestic water meter chambers Equipment for drinking water Pressure gauges and thermometers Water meters and compact heat meters 9

  9. Thank you for your attention... 10
