M.Sc. in Meteorology Synoptic Meteorology [MAPH P312] Prof Peter Lynch Second Semester, 20042005 Seminar Room Dept. of Maths. Physics, UCD, Belfield. Part 8 The Quasigeostrophic System These lectures follow closely the text of Holton


slide-1
SLIDE 1

M.Sc. in Meteorology Synoptic Meteorology

[MAPH P312]

Prof Peter Lynch

Second Semester, 2004–2005 Seminar Room

  • Dept. of Maths. Physics, UCD, Belfield.
slide-2
SLIDE 2

Part 8 The Quasigeostrophic System

These lectures follow closely the text of Holton (Chapter 6).

2

slide-3
SLIDE 3

The Quasi-Geostrophic Equations

3

slide-4
SLIDE 4

The Quasi-Geostrophic Equations

We will derive a system of equations suitable for qualitative analysis of mid-latitude weather systems.

3

slide-5
SLIDE 5

The Quasi-Geostrophic Equations

We will derive a system of equations suitable for qualitative analysis of mid-latitude weather systems. We will assume that the motion is hydrostatically balanced and approximately in geostrophic balance.

3

slide-6
SLIDE 6

The Quasi-Geostrophic Equations

We will derive a system of equations suitable for qualitative analysis of mid-latitude weather systems. We will assume that the motion is hydrostatically balanced and approximately in geostrophic balance.

In that case, the three-dimensional flow is de- termined by the pressure field.

3

slide-7
SLIDE 7

The Quasi-Geostrophic Equations

We will derive a system of equations suitable for qualitative analysis of mid-latitude weather systems. We will assume that the motion is hydrostatically balanced and approximately in geostrophic balance.

In that case, the three-dimensional flow is de- termined by the pressure field.

Since meteorological measurements are generally referred to constant pressure surfaces and since the equations are simpler in pressure coordinates than in height coordinates, we will use pressure as the vertical variable.

3

slide-8
SLIDE 8

The Quasi-Geostrophic Equations

We will derive a system of equations suitable for qualitative analysis of mid-latitude weather systems. We will assume that the motion is hydrostatically balanced and approximately in geostrophic balance.

In that case, the three-dimensional flow is de- termined by the pressure field.

Since meteorological measurements are generally referred to constant pressure surfaces and since the equations are simpler in pressure coordinates than in height coordinates, we will use pressure as the vertical variable.

In that case, the three-dimensional flow is de- termined by the geopotential field.

3

slide-9
SLIDE 9

The Primitive Equations

4

slide-10
SLIDE 10

The Primitive Equations

The dynamical equations in pressure coordinates are

dV dt + fk × V + ∇Φ = 0 ∂Φ ∂p = −RT p ∇·V + ∂ω ∂p = 0 ∂ ∂t + V · ∇

  • T − Sω =

˙ Q cp

4

slide-11
SLIDE 11

The Primitive Equations

The dynamical equations in pressure coordinates are

dV dt + fk × V + ∇Φ = 0 ∂Φ ∂p = −RT p ∇·V + ∂ω ∂p = 0 ∂ ∂t + V · ∇

  • T − Sω =

˙ Q cp

Here the total time derivative is d dt = ∂ ∂t + (V · ∇)p + ω ∂ ∂p

4

slide-12
SLIDE 12

Notation:

5

slide-13
SLIDE 13

Notation: The vertical velocity is ω = dp/dt,

5

slide-14
SLIDE 14

Notation: The vertical velocity is ω = dp/dt, S = −T∂ ln θ/∂p is the static stability parameter The typical scale of S is about 5 × 10−4 K Pa−1 in mid-troposphere).

5

slide-15
SLIDE 15

Notation: The vertical velocity is ω = dp/dt, S = −T∂ ln θ/∂p is the static stability parameter The typical scale of S is about 5 × 10−4 K Pa−1 in mid-troposphere). The primitive equations will now be simplified based on the assumption that the flow is close to geostrophic balance and the vertical velocity is much smaller than the horizontal.

5

slide-16
SLIDE 16

The Momentum Equation

6

slide-17
SLIDE 17

The Momentum Equation

We first partition the horizontal component of the wind into geostrophic and ageostrophic parts

V = Vg + Va

with the geostrophic wind defined by Vg = 1 f0 k × ∇Φ

6

slide-18
SLIDE 18

The Momentum Equation

We first partition the horizontal component of the wind into geostrophic and ageostrophic parts

V = Vg + Va

with the geostrophic wind defined by Vg = 1 f0 k × ∇Φ In component form this is ug = − 1 f0 ∂Φ ∂y , vg = + 1 f0 ∂Φ ∂x .

6

slide-19
SLIDE 19

The Momentum Equation

We first partition the horizontal component of the wind into geostrophic and ageostrophic parts

V = Vg + Va

with the geostrophic wind defined by Vg = 1 f0 k × ∇Φ In component form this is ug = − 1 f0 ∂Φ ∂y , vg = + 1 f0 ∂Φ ∂x . We take a constant “central” value f0 of the Coriolis param- eter here. This is consistent with the assumption that the horizontal scale L of the motion is small compared to the Earth’s radius, L ≪ a.

6

slide-20
SLIDE 20

We note also that the geostrophic divergence vasnishes: δg = ∇·Vg = ∂ ∂x

  • − 1

f0 ∂Φ ∂y

  • + ∂

∂y 1 f0 ∂Φ ∂x

  • = 0

7

slide-21
SLIDE 21

We note also that the geostrophic divergence vasnishes: δg = ∇·Vg = ∂ ∂x

  • − 1

f0 ∂Φ ∂y

  • + ∂

∂y 1 f0 ∂Φ ∂x

  • = 0

The continuity equation may now be written ∇·Va + ∂ω ∂p = 0 This implies that ω is determined by the ageostrophic com- ponent of the wind.

7

slide-22
SLIDE 22

We note also that the geostrophic divergence vasnishes: δg = ∇·Vg = ∂ ∂x

  • − 1

f0 ∂Φ ∂y

  • + ∂

∂y 1 f0 ∂Φ ∂x

  • = 0

The continuity equation may now be written ∇·Va + ∂ω ∂p = 0 This implies that ω is determined by the ageostrophic com- ponent of the wind. The geostrophic vorticity is given by ζg = k · ∇×Vg = ∂ ∂x 1 f0 ∂Φ ∂x

  • − ∂

∂y

  • − 1

f0 ∂Φ ∂y

  • = 1

f0 ∇2Φ so that ζg is determined once Φ is given.

7

slide-23
SLIDE 23

We note also that the geostrophic divergence vasnishes: δg = ∇·Vg = ∂ ∂x

  • − 1

f0 ∂Φ ∂y

  • + ∂

∂y 1 f0 ∂Φ ∂x

  • = 0

The continuity equation may now be written ∇·Va + ∂ω ∂p = 0 This implies that ω is determined by the ageostrophic com- ponent of the wind. The geostrophic vorticity is given by ζg = k · ∇×Vg = ∂ ∂x 1 f0 ∂Φ ∂x

  • − ∂

∂y

  • − 1

f0 ∂Φ ∂y

  • = 1

f0 ∇2Φ so that ζg is determined once Φ is given. Moreover, if ζg is given, the Poisson equation ∇2Φ = f0ζg may be solved for the geopotential. Then Vg follows imme- diately.

7

slide-24
SLIDE 24

Scale Analysis

8

slide-25
SLIDE 25

Scale Analysis

We can introduce characteristic scales for the motion. Thus, L is the typical horizontal scale, H the vertical scale and T = L/V the advective time scale.

8

slide-26
SLIDE 26

Scale Analysis

We can introduce characteristic scales for the motion. Thus, L is the typical horizontal scale, H the vertical scale and T = L/V the advective time scale. Then the size of the advection relative to the Coriolis term is V · ∇V fk × V ∼ V f0L ≡ Ro where Ro is the Rossby Number.

8

slide-27
SLIDE 27

Scale Analysis

We can introduce characteristic scales for the motion. Thus, L is the typical horizontal scale, H the vertical scale and T = L/V the advective time scale. Then the size of the advection relative to the Coriolis term is V · ∇V fk × V ∼ V f0L ≡ Ro where Ro is the Rossby Number. For the systems of interest |Va| ≪ |Vg| or, more specifically, |Va| |Vg| ∼ Ro

8

slide-28
SLIDE 28

Scale Analysis

We can introduce characteristic scales for the motion. Thus, L is the typical horizontal scale, H the vertical scale and T = L/V the advective time scale. Then the size of the advection relative to the Coriolis term is V · ∇V fk × V ∼ V f0L ≡ Ro where Ro is the Rossby Number. For the systems of interest |Va| ≪ |Vg| or, more specifically, |Va| |Vg| ∼ Ro We can then replace the velocity by its geostrophic com- ponent, and ignore the vertical advection in the total time derivative: dV dt ≈ d dt

  • g

Vg = ∂ ∂t + Vg·∇

  • Vg

8

slide-29
SLIDE 29

Exercise: Using the vector relationship k · ∇ × V = ∇ · V × k and the def- inition Vg = (1/f0)k × ∇Φ, derive the above expression for the geostrophic vorticity.

⋆ ⋆ ⋆

9

slide-30
SLIDE 30

Exercise: Using the vector relationship k · ∇ × V = ∇ · V × k and the def- inition Vg = (1/f0)k × ∇Φ, derive the above expression for the geostrophic vorticity.

⋆ ⋆ ⋆ We wish to retain the variation of the Coriolis parameter with latitude y = a(φ − φ0) as it has important dynamical consequences.

9

slide-31
SLIDE 31

Exercise: Using the vector relationship k · ∇ × V = ∇ · V × k and the def- inition Vg = (1/f0)k × ∇Φ, derive the above expression for the geostrophic vorticity.

⋆ ⋆ ⋆ We wish to retain the variation of the Coriolis parameter with latitude y = a(φ − φ0) as it has important dynamical consequences. Expanding in a Taylor series, we write the first two terms f = f0 + βy where β = (d f/dy)0 = 2Ω cos φ0/a with y = 0 at φ = φ0.

9

slide-32
SLIDE 32

Exercise: Using the vector relationship k · ∇ × V = ∇ · V × k and the def- inition Vg = (1/f0)k × ∇Φ, derive the above expression for the geostrophic vorticity.

⋆ ⋆ ⋆ We wish to retain the variation of the Coriolis parameter with latitude y = a(φ − φ0) as it has important dynamical consequences. Expanding in a Taylor series, we write the first two terms f = f0 + βy where β = (d f/dy)0 = 2Ω cos φ0/a with y = 0 at φ = φ0. This is the mid-latitude β-plane approximation.

9

slide-33
SLIDE 33

Exercise: Using the vector relationship k · ∇ × V = ∇ · V × k and the def- inition Vg = (1/f0)k × ∇Φ, derive the above expression for the geostrophic vorticity.

⋆ ⋆ ⋆ We wish to retain the variation of the Coriolis parameter with latitude y = a(φ − φ0) as it has important dynamical consequences. Expanding in a Taylor series, we write the first two terms f = f0 + βy where β = (d f/dy)0 = 2Ω cos φ0/a with y = 0 at φ = φ0. This is the mid-latitude β-plane approximation. The ratio of the two terms is βy f0 ∼ cos φ0L sin φ0a ∼ L a ∼ Ro ≪ 1

9

slide-34
SLIDE 34

We now consider the Coriolis and pressure gradient terms fk × V + ∇Φ The term omitted is O(Ro).

10

slide-35
SLIDE 35

We now consider the Coriolis and pressure gradient terms fk × V + ∇Φ The term omitted is O(Ro). Expanding in geostrophic and ageostrophic parts, we get fk × V + ∇Φ = (f0 + βy)k × (Vg + Va) − f0k × Vg ≈ f0k × Va + βy k × Vg

10

slide-36
SLIDE 36

We now consider the Coriolis and pressure gradient terms fk × V + ∇Φ The term omitted is O(Ro). Expanding in geostrophic and ageostrophic parts, we get fk × V + ∇Φ = (f0 + βy)k × (Vg + Va) − f0k × Vg ≈ f0k × Va + βy k × Vg The horizontal momentum equation may now be written

d dt

  • g

Vg + f0k × Va + βyk × Vg = 0

10

slide-37
SLIDE 37

We now consider the Coriolis and pressure gradient terms fk × V + ∇Φ The term omitted is O(Ro). Expanding in geostrophic and ageostrophic parts, we get fk × V + ∇Φ = (f0 + βy)k × (Vg + Va) − f0k × Vg ≈ f0k × Va + βy k × Vg The horizontal momentum equation may now be written

d dt

  • g

Vg + f0k × Va + βyk × Vg = 0

All the terms here are O(Ro) and neglected terms are O(Ro2).

10

slide-38
SLIDE 38

The Thermodynamic Equation

11

slide-39
SLIDE 39

The Thermodynamic Equation

Recall that the vertical advection of temperature is included in the Sω term (Holton, Eq. (3.6), p. 59).

11

slide-40
SLIDE 40

The Thermodynamic Equation

Recall that the vertical advection of temperature is included in the Sω term (Holton, Eq. (3.6), p. 59). We can use the geostrophic wind in the expression for hor- izontal advection.

11

slide-41
SLIDE 41

The Thermodynamic Equation

Recall that the vertical advection of temperature is included in the Sω term (Holton, Eq. (3.6), p. 59). We can use the geostrophic wind in the expression for hor- izontal advection. Moreover, we separate the temperature field into a basic part varying only in the vertical and a part depending on all coordinates and time: T = T0(p) + T ′(x, y, p, t)

11

slide-42
SLIDE 42

The Thermodynamic Equation

Recall that the vertical advection of temperature is included in the Sω term (Holton, Eq. (3.6), p. 59). We can use the geostrophic wind in the expression for hor- izontal advection. Moreover, we separate the temperature field into a basic part varying only in the vertical and a part depending on all coordinates and time: T = T0(p) + T ′(x, y, p, t) We can replace T by T0 and θ by θ0 in evaluating the static stability: S ≡ −T ∂ ln θ ∂p , S0 ≡ −T0 d ln θ0 dp , S ≈ S0

11

slide-43
SLIDE 43

The Thermodynamic Equation

Recall that the vertical advection of temperature is included in the Sω term (Holton, Eq. (3.6), p. 59). We can use the geostrophic wind in the expression for hor- izontal advection. Moreover, we separate the temperature field into a basic part varying only in the vertical and a part depending on all coordinates and time: T = T0(p) + T ′(x, y, p, t) We can replace T by T0 and θ by θ0 in evaluating the static stability: S ≡ −T ∂ ln θ ∂p , S0 ≡ −T0 d ln θ0 dp , S ≈ S0 Note that S0 depends only on pressure p.

11

slide-44
SLIDE 44

The temperature may be given in terms of the geopotential by means of the hydrostatic equation ∂Φ ∂p = −1 ρ = −RT p

12

slide-45
SLIDE 45

The temperature may be given in terms of the geopotential by means of the hydrostatic equation ∂Φ ∂p = −1 ρ = −RT p Then the thermodynamic equation becomes ∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p where κ = R/cp and σ is another measure of static stability: σ ≡ R p S0 = −RT0 p d ln θ0 dp

12

slide-46
SLIDE 46

The temperature may be given in terms of the geopotential by means of the hydrostatic equation ∂Φ ∂p = −1 ρ = −RT p Then the thermodynamic equation becomes ∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p where κ = R/cp and σ is another measure of static stability: σ ≡ R p S0 = −RT0 p d ln θ0 dp The scale of σ in the mid-troposphere is ∼ 2.5×10−6 m2Pa−2s−2.

12

slide-47
SLIDE 47

The temperature may be given in terms of the geopotential by means of the hydrostatic equation ∂Φ ∂p = −1 ρ = −RT p Then the thermodynamic equation becomes ∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p where κ = R/cp and σ is another measure of static stability: σ ≡ R p S0 = −RT0 p d ln θ0 dp The scale of σ in the mid-troposphere is ∼ 2.5×10−6 m2Pa−2s−2. Although σ varies with height, we will assume that it is a

  • constant. This simplifies the analysis.

12

slide-48
SLIDE 48

The Quasigeostrophic Equations

13

slide-49
SLIDE 49

The Quasigeostrophic Equations

The complete system of Quasigeostrophic Equations is: ∂ ∂t + Vg · ∇

  • Vg + f0k × Va + βyk × Vg = 0

∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p ∇·Va + ∂ω ∂p = 0 Vg = 1 f0 k × ∇Φ

13

slide-50
SLIDE 50

The Quasigeostrophic Equations

The complete system of Quasigeostrophic Equations is: ∂ ∂t + Vg · ∇

  • Vg + f0k × Va + βyk × Vg = 0

∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p ∇·Va + ∂ω ∂p = 0 Vg = 1 f0 k × ∇Φ These 4 equations (6 scalar equations) form a complete sys- tem for the variables Φ, Vg, Va and ω (6 scalar variables).

13

slide-51
SLIDE 51

The Quasigeostrophic Equations

The complete system of Quasigeostrophic Equations is: ∂ ∂t + Vg · ∇

  • Vg + f0k × Va + βyk × Vg = 0

∂ ∂t + Vg · ∇ ∂Φ ∂p

  • + σω = −κ ˙

Q p ∇·Va + ∂ω ∂p = 0 Vg = 1 f0 k × ∇Φ These 4 equations (6 scalar equations) form a complete sys- tem for the variables Φ, Vg, Va and ω (6 scalar variables). However, they are not in a form convenient for prediction. For this purpose, we derive an equation for the geostrophic vorticity.

13
