LVD Product Introduction 2011 CONFIDENTIAL OUR CORE LVD, stands for Low Voltage Drive, is a compact drive designed for a variety of low voltage applications. POTENTIAL APPLICATIONS


slide-1
SLIDE 1
  • CONFIDENTIAL

LVD – Product Introduction

2011

slide-2
SLIDE 2
  • OUR CORE

LVD, stands for Low Voltage Drive, is a compact drive designed for a variety of low voltage applications.

slide-3
SLIDE 3
  • Industrial Automation

Positioning and indexing systems Material handling Educational tools such as robotics lab Conveyor systems Surveillance cameras Laboratory instrumentation and sequencing machines Semiconductor wafer handling processes Printing machines Medical solution for real time digital imaging system Automotive applications might include Seat adjustment Power steering Electronically adjustable shock absorbers

POTENTIAL APPLICATIONS

slide-4
SLIDE 4
  • SUCCESS STORY

Digital 3D in mouth imaging solutions - dental / orthodontic industry. Solution - LVD drive, with Portescap 12G88 motor, closes a position loop with trapezoidal motion profile for the Z axis which controls the camera’s zoom (1,000-2,000 units per year).

http://www.cadentinc.com

slide-5
SLIDE 5
  • WHY DID WE WIN

Complete axis solution Meeting costumers performance requirements Attractive prices Responsive application and integration team Strong cooperation between Servotronix and Portescap teams Servotronix and Portescap flexibility in achieving customer requirements

slide-6
SLIDE 6
  • LVD’S MAIN ADVANTAGES

FW flexibility addressing customers needs CE, UL(in process) and RoHS Regulation Wider power supply range Higher current output capability Selectable switching frequency High sample rate for all operation modes Impressive range and resolution of the analog input

slide-7
SLIDE 7
  • FEATURES

Mechanical

Very small and light weight 117 x 78 x 21 mm 250g

Electrical

Wide range allowed in the logic voltage as well as the bus voltage supply 10V – 36V logic power supply 12V – 48V bus voltage Output current up to 7Arms continuous and 12Arms peak.

slide-8
SLIDE 8
  • FEATURES

Motors

BLDC motors DC motors

Feedbacks

Incremental encoder + halls Supports with and without Index signal Supports differential and single ended encoder Supports encoder with and without halls Halls only*

* Halls only will be supported by demand.

slide-9
SLIDE 9
  • FEATURES

Motion and control

Switching frequencies supported:16kHz and 100kHz (for low inductance motors) Current, velocity and position control Absolute and incremental point to point motion Trapezoidal and S curve motion profile* Supports homing using Index signal Digital input Limit switches Combined

*S curve profile will be supported by demand.

slide-10
SLIDE 10
  • FEATURES

Protections

Short circuit Over current Programmable I²T protection mechanism Programmable bus over voltage level Programmable bus under voltage level Encoder disconnect Illegal Halls

slide-11
SLIDE 11
  • FEATURES

I/O

2 programmable differential analog inputs with +/-10V input range and 12 bit resolution 6 Opto-isolated programmable digital inputs 2 opto-isolated open collector digital

  • utput

One input for encoder strobe (fast capture of position) One opto-isolated external enable input signal with bypass though a switch in the drive address area

Communication

  • Serial communication RS232
  • CANOpen DS301,DSP402

User Interface

2 Leds indicators Bus Indicator Drive Status The Axis Manager GUI

slide-12
SLIDE 12
  • CONNECTORS

CAN Input and output RS232 I/O Halls Encoder Logic Supply Bus and Regen connection Motor Phases Address, Enable Bypass and CAN termination switches External Enable

slide-13
SLIDE 13
  • AXIS MANAGER

The Axis Manager is the LVD’s user friendly graphical management tool which allows the user to configure and control multiple drives using serial or CAN communication.

slide-14
SLIDE 14
  • AXIS MANAGER FEATURES

Axis manager features include:

Communication via RS232 or Can Easy to use motor feedback and profile configuration tools Comfortable drive monitoring tools Recorder Watch window Status tab Dedicated tuning windows for all control loops User friendly I/O configuration window

slide-15
SLIDE 15
  • CONFIDENTIAL

You are welcome to visit our website at www.Servotronix.com

slide-16
SLIDE 16
  • CONFIDENTIAL

THANK YOU ALL TODA RABA
