Lucia Gardini LOT/2019 LENS Fluorescence microscopy Single-molecule fluorescence microscopy Information on distributions and time trajectories that would otherwise be hidden Identify and compare sub-populations Probe biological
SLIDE 2
SLIDE 3
Fluorescence microscopy
SLIDE 4
SLIDE 5
Single-molecule fluorescence microscopy
ONE MOLECULE AT A TIME
Information on distributions and time trajectories that would otherwise be hidden Identify and compare sub-populations Probe biological macromolecules and provide informations on their structure and function In vitro and in vivo
SLIDE 6
NA n D d
S
2 sin 2 22 . 1
2
= =
PSF and image resolution
Abbe formula (x, y) Abbre forluma (z) 2/NA2 Radius of x,y PSF Axial amplitude of the PSF
SLIDE 7
d d = /2NA
Rayleigh criterion
Lateral resolution ~ 250 nm Axial resolution = 2/NA2 ~ 500nm
Image resolution
SLIDE 8
~ 250 nm
Overcoming the diffraction limit
SLIDE 9
x y x centre y centre
Localized point
Fluorescence Imaging with One Nanometer Accuracy FIONA
Thompson et al. Biophys.J. 2002
SLIDE 10
Fluorescence Imaging with One Nanometer Accuracy FIONA
Thompson et al. Biophys.J. 2002
b N
?
High quantum yield fluo probes High NA aperture
- bjectives (1.45)
High sensitivity CCD cameras such as EMCCD
SLIDE 11
Yildiz et al. Science 2003
High quantum yield fluo probes High NA aperture
- bjectives (1.45)
High sensitivity CCD cameras such as EMCCD
SLIDE 12
LOCALIZATION ON SURFACES:TIRF MICROSCOPY
100 nm depth in the sample Small volume excited High S/N
100 nm
TOTAL INTERNAL REFLECTION MICROSCOPY (proximity to the membrane)
b
SLIDE 13
LOCALIZATION ON SURFACES:TIRF MICROSCOPY
INCLINED ILLUMINATION HILO (Highly inclined and Laminated Optical sheet)
THE ILLUMINATION BEAM ALWAYS PASSES THROUGH THE CENTER OF THE SPECIMEN PLANE ALLOWING OPTICAL SECTIONING 8 FOLD HIGHER SIGNAL/BACKGROUND COMPARED TO TRADITIONAL WIDEFIELD MICROSOCPY
b
SLIDE 14
Yildiz et al. Science 300:2061, 2003
Application in vitro: myosin V walks hand over hand
Accuracy: 1.5 nm. Time resolution: 0.5 s 10^4 photons collected
SLIDE 15
Singel Molecule FRET (Forster Resonance Energy Transfer)
Distanze tipiche tra 30 e 80 Å
SLIDE 16
R = dist.donor/acc R0 = dist.caratteristica (50% di en. trasferita) Es.Cy3/Cy5 R0= 60 Å (6 nm)
SLIDE 17
Probing conformational changes and displacements
SLIDE 18
Lucia Gardini 09/04/2019 LENS
SLIDE 19
NOBEL PRIZE IN CHEMISTRY 2014
Xiaowei Zhuang BREACKTHROUGH PRIZE 2019
Single molecule localization microscopy: SUPER-RESOLUTION MICROSCOPY
SLIDE 20
The principle of PALM and STORM
SLIDE 21
The principle of PALM and STORM
SLIDE 22
FIONA
The principle of PALM and STORM
SLIDE 23
The principle of PALM and STORM
SLIDE 24
The principle of PALM and STORM
SLIDE 25
The principle of PALM and STORM
SLIDE 26
The principle of PALM and STORM
SLIDE 27
The principle of PALM and STORM
SLIDE 28
The principle of PALM and STORM
SLIDE 29
The principle of PALM and STORM
SLIDE 30
The principle of PALM and STORM
SLIDE 31
The principle of PALM and STORM
SLIDE 32
Activation Imaging laser (657 nm) Activation laser (532 nm) Cy3 Cy5 Cy3 Cy5 Cy3 Cy5
20 15 10 5
Activation laser pulses Cy5 fluorescence Time (s)
Activator Reporter 6000 photons
STORM - Photo-switchable Probes
More colors
SLIDE 33
Direct STORM
Dempsey G.T. et al Nat. Methods 2011
SLIDE 34
5 μm B-SC-1 cell, Microtubules stained with anti-β tubulin Cy3 / Alexa 647 secondary antibody
SLIDE 35
5 μm
Bates et al, Science 317, 1749 – 1753 (2007)
106 molecules, 2-30 min
SLIDE 36
500 nm
5 μm
SLIDE 37
5 μm █ Cy3 / Alexa 647: Clathrin █ Cy2 / Alexa 647: Microtubule
Bates et al, Science 317, 1749 – 1753 (2007)
SLIDE 38
1 μm
SLIDE 39
200 nm
Avg = 172 nm
SLIDE 40
3D via astigmatic detection
SLIDE 41
10 nm lateral 20 nm axial
