SLIDE 1
LINGUISTIC PITCH IN DEPTH, PART I
YU / LAMONT FEBRUARY 6, 2018
LINGUIST 197M, SPRING 2018. CLASS 3.1
Work on the RQ linked from the course webpage!
2
LINGUISTIC PITCH IN DEPTH, PART I Work on the RQ linked from YU / - - PowerPoint PPT Presentation
LINGUISTIC PITCH IN DEPTH, PART I Work on the RQ linked from YU / - - PowerPoint PPT Presentation
LINGUIST 197M, SPRING 2018. CLASS 3.1 LINGUISTIC PITCH IN DEPTH, PART I Work on the RQ linked from YU / LAMONT the course webpage! FEBRUARY 6, 2018 2 WHAT IS FUNDAMENTAL FREQUENCY? LINGUIST 197M, SPRING 2018. CLASS 3.1 3 FREQUENCY OF THE
SLIDE 2
SLIDE 3
LINGUIST 197M, SPRING 2018. CLASS 3.1
FREQUENCY OF THE VOICE
3
The frequency of the voice is the rate of vocal fold vibration at that timepoint.
▸ Watch what happens to the vocal folds as you hear pitch
going up and down
▸ http://youtu.be/P2pLJfWUjc8?t=3m53s ▸ http://www.youtube.com/watch?v=9kHdhbEnhoA
SLIDE 4
4
SLIDE 5
5
SLIDE 6
LINGUIST 197M, SPRING 2018. CLASS 3.1
FREQUENCY OF SOUND WAVES (ACOUSTICS)
6
\
https://musiclab.chromeexperiments.com/Sound-Waves
SLIDE 7
LINGUIST 197M, SPRING 2018. CLASS 3.1
EXERCISE: DETERMINE PERIOD/FREQUENCY
7
▸ Let’s determine what the period and frequency of each
- f our generated sounds are from the waveform
SLIDE 8
8
SLIDE 9
9
COMPLEX WAVES (“TONE COMPLEXES”)
SLIDE 10
LINGUIST 197M, SPRING 2018. CLASS 3.1
EXERCISE: SOUND OF ADDING IN HARMONICS
10
https://soundphysics.ius.edu/?page_id=949
Can you adjust the amplitudes
- f the harmonics to get the
timbre to sound like some instrument you like?
SLIDE 11
LINGUIST 197M, SPRING 2018. CLASS 3.1
DEMO: COMPLEX WAVES
11
https://musiclab.chromeexperiments.com/Oscillators
SLIDE 12
LINGUIST 197M, SPRING 2018. CLASS 3.1
BUILDING UP A SQUARE WAVE WITH SINES
12
https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Synthesis_square.gif
SLIDE 13
LINGUIST 197M, SPRING 2018. CLASS 3.1
BUILDING UP A SQUARE WAVE
13
https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif
SLIDE 14
LINGUIST 197M, SPRING 2018. CLASS 3.1
TWO REPRESENTATIONS OF SQUARE WAVE
14
https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif
Time domain: waveform Frequency domain: spectrum
SLIDE 15
LINGUIST 197M, SPRING 2018. CLASS 3.1
HARMONIC AMPLITUDES
15
https://sites.google.com/a/georgiasouthern.edu/julia-inozemtseva/teaching-math-animations-and-pics? tmpl=%2Fsystem%2Fapp%2Ftemplates%2Fprint%2F&showPrintDialog=1#TOC-Fourier-Series
SLIDE 16
LINGUIST 197M, SPRING 2018. CLASS 3.1
BUILDING UP A TRIANGLE WAVE WITH SINES
16
https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif
SLIDE 17
LINGUIST 197M, SPRING 2018. CLASS 3.1
EXERCISE: CREATING TONE COMPLEXES
17
SLIDE 18
LINGUIST 197M, SPRING 2018. CLASS 3.1
EXERCISE: CREATING TONE COMPLEXES
18
Explore the missing fundamental effect!
SLIDE 19
LINGUIST 197M, SPRING 2018. CLASS 3.1
FUNDAMENTAL FREQUENCY
19
The fundamental frequency (f0) of a complex wave is defined as the frequency of the lowest frequency component wave. (simplified!) The fundamental frequency of the voice is the rate of vocal fold vibration at that timepoint.
Speech production/ articulation Acoustics
SLIDE 20
LINGUIST 197M, SPRING 2018. CLASS 3.1
SPECTRUM OF COMPLEX WAVEFORM
20
0.0 0.5 1.0 1.5 2.0 5 10 15 20 t wave.complex1 2 3 4 Amplitude (dB) 1 Frequency (Hz) Amplitude (dB) Time (s)
SLIDE 21
LINGUIST 197M, SPRING 2018. CLASS 3.1
SPECTRUM OF COMPLEX WAVEFORM
21
0.0 0.5 1.0 1.5 2.0 5 10 15 20 t wave.complex1 2 3 4 Amplitude (dB) 1 Frequency (Hz) Amplitude (dB) Time (s)
Waveform: x-axis is time Spectrum: x-axis is frequency
SLIDE 22
LINGUIST 197M, SPRING 2018. CLASS 3.1
IN PRAAT: FROM WAVEFORM…
22
SLIDE 23
LINGUIST 197M, SPRING 2018. CLASS 3.1
…TO SPECTRUM (SPECTRAL SLICE)
23
Why call these “spectral slices”? Because a spectrum is typically taken over some (small) window of time, over at least a few cycles of the waveform. So we take a spectrum over a “time slice”.
SLIDE 24
24
TONE LANGUAGES OF THE WORLD
http://wals.info/chapter/13 http://wals.info/feature/13A#2/5.5/141.8
SLIDE 25
25
CONTOUR TONES
SLIDE 26
LINGUIST 197M, SPRING 2018. CLASS 3.1
RUSS SCHUH (UCLA)
26
http://www.linguistics.ucla.edu/people/schuh/schuh.htm
SLIDE 27
LINGUIST 197M, SPRING 2018. CLASS 3.1
CANTONESE TONES
27
What do the funny symbols mean?
SLIDE 28
LINGUIST 197M, SPRING 2018. CLASS 3.1
INTERNATIONAL PHONETIC ALPHABET
28
https://www.internationalphoneticassociation.org/content/full-ipa-chart
SLIDE 29
LINGUIST 197M, SPRING 2018. CLASS 3.1
CANTONESE TONES: YOUR TURN!
29
Listen to and examine (in Praat) the Cantonese audio files linked below. Can you figure out which audio file corresponds to which tone category?
http://www.ling197m.krisyu.org/media/3/cant/
SLIDE 30
LINGUIST 197M, SPRING 2018. CLASS 3.1
MORE PRACTICE ON LISTENING TO TONES
30
http://www.linguistics.ucla.edu/people/hayes/103/TonePractice/
SLIDE 31
31
LEVEL TONES
SLIDE 32
LINGUIST 197M, SPRING 2018. CLASS 3.1
BOLE TONES (CHADIC LANGUAGE, NIGERIA)
32
SLIDE 33
LINGUIST 197M, SPRING 2018. CLASS 3.1
WHAT LEVEL TONES ACTUALLY “LOOK LIKE”
33
Time (s) 1.003 Pitch (Hz) 50 150 L L H L H L Time (s) 1.003
http://www.ling197m.krisyu.org/media/3/bole_m2_36_b5.wav
SLIDE 34
34
TALKING DRUMS
SLIDE 35
LINGUIST 197M, SPRING 2017. CLASS 3.1
35
http://www.youtube.com/watch?v=kpVS0-6yMlQ
SLIDE 36
LINGUIST 197M, SPRING 2018. CLASS 3.1
YORUBA TONES: DO RE MI
36
Listen to and examine (in Praat) the Yoruba audio files linked below.
http://www.ling197m.krisyu.org/media/3/yoruba/
SLIDE 37
LINGUIST 197M, SPRING 2017. CLASS 3.1
37
http://www.youtube.com/watch?v=kpVS0-6yMlQ
SLIDE 38
LINGUIST 197M, SPRING 2017. CLASS 3.1
38
