Lightning Protection and Grounding Solutions for Wireless Networks June 2014 March 29, 2 / TMS Times standard PowerPoint Template / 6/25/2014 Few facts about the lightning event Typically, more than 2,000 thunderstorms are active throughout

slide-1
SLIDE 1

Lightning Protection and Grounding Solutions for Wireless Networks June 2014

slide-2
SLIDE 2

2 / TMS Times standard PowerPoint Template / 6/25/2014

March 29,

slide-3
SLIDE 3

3 / TMS Times standard PowerPoint Template / 6/25/2014

Few facts about the lightning event

Typically, more than 2,000 thunderstorms are active throughout the world at any given moment producing on the order of 100 flashes per second. As our society becomes more dependent upon computers and information/communications networks, protection from system disruptions becomes essentials. During fair weather, a potential difference of 200,000 to 500,000 Volts exists between the earth surface and ionosphere. In a lightning event this potential will be responsible for lightning discharge currents of up to 100,000 Ampere. The average length and duration of each lightning stroke vary, but typically average about 30 microseconds producing average peak power per stroke of about 1 (one) Trillion Watts. The temperature along the lightning channel (flash) during the electrical discharge is in the order of 20,000 degrees Celsius (three time the temperature of the surface of the Sun) Wireless networks rely on communication towers for its transmission of Radio Frequency putting them statistically in a very high exposure zone. Average communication site in Florida, during thunderstorm season, will be exposed to 18 to 20 lightning strikes a year.

slide-4
SLIDE 4

4 / TMS Times standard PowerPoint Template / 6/25/2014

ANA 747 triggered strike at Kanazawa

slide-5
SLIDE 5

5 / TMS Times standard PowerPoint Template / 6/25/2014

Aircraft launching step leader

slide-6
SLIDE 6

6 / TMS Times standard PowerPoint Template / 6/25/2014

Return Stroke

slide-7
SLIDE 7

7 / TMS Times standard PowerPoint Template / 6/25/2014

Annual Lightning Flash Rate

slide-8
SLIDE 8

8 / TMS Times standard PowerPoint Template / 6/25/2014

The Lightning Event

The lower part of a thundercloud is usually negatively charged. The upward area is usually positively charged. Lightning from the negatively charged area of the cloud generally carries a negative charge to Earth and is called a negative flash. A discharge from a positively-charged area to Earth produces a positive flash

slide-9
SLIDE 9

9 / TMS Times standard PowerPoint Template / 6/25/2014

Step Leader Length is Dependent on Cloud Charge Accumulation

Jumping Hemisphere 150 feet

Step Leader Distance

10 to 30kV/m E - Field

The Larger the Charge, the Larger the Step Typical Step 150ft. @ 50µS per Step ( 1µS jump, 49µS pause )

Jumping Hemisphere “Rolling Ball Theory”

slide-10
SLIDE 10

10 / TMS Times standard PowerPoint Template / 6/25/2014

Definition of pulse wave-shape

slide-11
SLIDE 11

11 / TMS Times standard PowerPoint Template / 6/25/2014

Six  distribution

Ref: W.C. Hart, E. W. Malone, Lightning and Lightning Protection, EEC Press, 1979

350kA

Maximum with 99.5% Confidence level AND

300kA

Maximum with 98% Confidence level

Measured Peak Lightning Current

slide-12
SLIDE 12

12 / TMS Times standard PowerPoint Template / 6/25/2014

Ref: W. C. Hart, E. W. Malone, Lightning and Lightning Protection, EEC Press, 1979

  • Max. 10-sec
  • Min. 0.7-sec

0 to peak current with 96% confidence level

Time

0 to peak current

Time to Peak Lightning Currents

slide-13
SLIDE 13

13 / TMS Times standard PowerPoint Template / 6/25/2014

  • Max. 1000A
  • Min. 30A
  • Max. 550m-sec
  • Min. 35m-sec

Ref: N. Clanos and E.T. Pierce, “A Ground Lightning Environment for Engineering Usage”, Contract L.S.-28170A-3, Stanford Research Institute, CA

Duration and Amplitude of Continuing Currents

slide-14
SLIDE 14

14 / TMS Times standard PowerPoint Template / 6/25/2014

Feeder current wave-shapes

Lightning current distribution on coaxial cable

Coaxial shield lightning current Center conductor lightning current

slide-15
SLIDE 15

15 / TMS Times standard PowerPoint Template / 6/25/2014

Grounding fundamentals for Lightning Protection

slide-16
SLIDE 16

16 / TMS Times standard PowerPoint Template / 6/25/2014

Any Conductor is an Inductor !

Communications Radio Tower Inductance

slide-17
SLIDE 17

17 / TMS Times standard PowerPoint Template / 6/25/2014

Tubular Plotted against the solid conductor

tower Inductance considerations – monopole tower

slide-18
SLIDE 18

18 / TMS Times standard PowerPoint Template / 6/25/2014

This distance is 6ft.

Inductance Inductance consideration – three leg tower

slide-19
SLIDE 19

19 / TMS Times standard PowerPoint Template / 6/25/2014

360kV Peak Distributed Voltage across mast Peak Voltage on Cable Shields ~ 28kV going to entrance panel 360kV would arise at the top of a 40µH mast with a relatively small 18 kA w/ a 2µS risetime strike . The voltage would be distributed down the mast to ground. If the cable shields were bonded to the mast at the 8 foot level, about 28kV would be riding on shields going to the entrance panel

Strike Voltage Distribution and cable shield potential at entry port

slide-20
SLIDE 20

20 / TMS Times standard PowerPoint Template / 6/25/2014

Lightning current sharing between tower and coaxial cables during the lightning event

100kA total discharge current 70kA propagating down the tower 30kA divides itself between distribution coax cables

slide-21
SLIDE 21

21 / TMS Times standard PowerPoint Template / 6/25/2014

Why Coaxial Cable Ground Kits are Essential

BTS Shelter

150ft / 360kV 75ft / 250kV 8ft / 28kV

Inductive voltage drop across entire 40uH tower with 2us rise time and peak current of 18kA E=-Ldi/dt

Magnetic field coupling into coaxial cable from current flow down the tower can cause a reverse emf on the coax, opposing downward current flow, and creating a differential voltage between tower and coax. Coax cable insulation could breakdown and allow an arc back to the tower. An additional ground kit at the tower center brings the shield back to tower potential reducing peak voltages and the probability of coax breakdown

slide-22
SLIDE 22

22 / TMS Times standard PowerPoint Template / 6/25/2014

Coupling Effects

Coaxial shield is ineffective at 20kHz to 100kHz fundamental frequencies

Coax

BACK EMF

Mag. Fields

Tower

Reverse EMF On Coax Tower Current Flow

slide-23
SLIDE 23

23 / TMS Times standard PowerPoint Template / 6/25/2014

Down conductors used for lightning protection must not have sharp bends.

Down Conductors

Lightning Strike Current

Back EMF from self inductive coupling Magnetic Field

N0!

slide-24
SLIDE 24

24 / TMS Times standard PowerPoint Template / 6/25/2014

Down Conductors

Proper bending requires a sufficient radius and no bends less than 90 degrees

Radius Current

YES!

slide-25
SLIDE 25

25 / TMS Times standard PowerPoint Template / 6/25/2014

Lightning Protection “Zone of Protection”

150’ Radius Striking Distance (100’ for flammable liquids)

Zone of Protection

Per ANSI/NFPA 780

slide-26
SLIDE 26

26 / TMS Times standard PowerPoint Template / 6/25/2014

Placement of Air Terminals

The Zone of Protection from lightning strikes can be defined using the rolling sphere model.

slide-27
SLIDE 27

27 / TMS Times standard PowerPoint Template / 6/25/2014

Radial and Ground Rod System

When rods are placed along radials with other rods, a capacitive plate is simulated for a more efficient transfer

  • f energy into the earth.

Radials with ground rods extending out from the tower base, form a fast transient low “resistance” ground system for a single point ground coaxial cable entry panel.

slide-28
SLIDE 28

28 / TMS Times standard PowerPoint Template / 6/25/2014

Sphere of Influence Step Potential

Ground d Rod Ground L d Level

Ground Electrode Soil compaction-displacement

Electron Transfer

slide-29
SLIDE 29

29 / TMS Times standard PowerPoint Template / 6/25/2014

Spheres of Influence

Readings Not Impacted by Spheres of Influence

20 25 15 10 05 00

Plateau System Resistance

Fall of Potential Test

Current Probe

50-100ft Spacing

slide-30
SLIDE 30

30 / TMS Times standard PowerPoint Template / 6/25/2014

– NFPA 70 NEC < 25 OHMS or two rods – IEEE Standard 142 Equipment Dependent – IEEE Standard 1100 < 5 OHMS – Motorola R-56 < 5 OHMS – Verizon Wireless 8501 < 5 OHMS – Bell Mobility Cellular < 5 OHMS – Essilor < 3 OHMS – GE Medical Systems < 2 OHMS Typical Grounding Requirements:

slide-31
SLIDE 31

31 / TMS Times standard PowerPoint Template / 6/25/2014

  • Grounding at bottom of the rack

creates a path for surge current to traverse the rack, upsetting or destroying equipment.

  • Proper grounding of the equipment
  • rack. If coax jumper cables enter at

the top, ground high. If they enter low, ground low. There will be minimal current flow through the rack.

Equipment Grounding with Coax Entering from a High Entry Panel

slide-32
SLIDE 32

32 / TMS Times standard PowerPoint Template / 6/25/2014

Rooftop Installations

Water /Sewer Ground Electrical Ground Ground Loop / Rods around building Ground Loop/Rods

GPS Antenna Cellular Antenna Coaxial Cables from antenna

Lightning Rods (6) Lightning Rod structural protection system down-conductors (4) Perimeter rooftop ground conductors for structural protection system with additional conductors bonding cellular antenna support Separate ground down–conductor for antenna structure and entry port bond

Coaxial Cable Entry panel

Antenna support - entry panel ground bond to building steel

Equipment ground preferences:

Marginal Bond to structural protection or separate down conductor Good Bond to structural protection and additional separate down conductor Better Single bond to structural steel Best Combine all three methods

Rooftop Ground Considerations

slide-33
SLIDE 33

33 / TMS Times standard PowerPoint Template / 6/25/2014

Tower Leg Grounding (UFER vs. AWG #2)

slide-34
SLIDE 34

34 / TMS Times standard PowerPoint Template / 6/25/2014

Tower Leg Grounding

slide-35
SLIDE 35

35 / TMS Times standard PowerPoint Template / 6/25/2014

UFER Ground Enhancement

slide-36
SLIDE 36

36 / TMS Times standard PowerPoint Template / 6/25/2014

Outside communication shelter copper theft fix

After the fix

slide-37
SLIDE 37

37 / TMS Times standard PowerPoint Template / 6/25/2014

Damage and Fix

External grounding after theft The high impedance fix

slide-38
SLIDE 38

38 / TMS Times standard PowerPoint Template / 6/25/2014

Improvement

slide-39
SLIDE 39

39 / TMS Times standard PowerPoint Template / 6/25/2014

Shelter exterior view

Nothing to steal here !!!!!

slide-40
SLIDE 40

40 / TMS Times standard PowerPoint Template / 6/25/2014

External view of traditional method and proposed solution

Traditional method consisting of:

  • High material and labor cost
  • Lack of provisions for other service entries
  • Theft exposure
  • Very high impedance return path to

ground

  • High preventative maintenance

Proposed method:

  • Addresses theft issue
  • Does not require external shield grounding kits
  • Makes provisions for Coax/EWG/Data/DC and fiber
  • Minimal labor cost
  • All prep work performed at the shelter manufacturer
slide-41
SLIDE 41

41 / TMS Times standard PowerPoint Template / 6/25/2014

Interior view of traditional method and proposed solution

Traditional method:

  • Requires separate Inside MGB (IMGB)
  • Trapeze or other method to ground SPDs
  • Performance affected by long ground wires
  • High impedance IMGB ground conductor
  • Single point ground by installation
  • High ground loop probability

Propose method:

  • All RF protectors bulkhead mounted for best surge performance
  • Assembly accommodates different wall thickness
  • Provisions for grounding of all protectors to the same SPG
  • Low impedance ground path for lightning current
  • Control of MGB potential rise due to low “L” of assembly
  • Accommodates for additional equipment mounting

RF Protectors Bulkhead mounted

2/0 Conductors to ground

slide-42
SLIDE 42

42 / TMS Times standard PowerPoint Template / 6/25/2014

Ground lead considerations for installation of RF protectors Applied surge wave-shape 6KV/3KA (8X20us)

Bulkhead mounted SPD without added ground “L” Surge return directly connected to protector ground

+25.6V, -9.2V +

  • Su rge
Gen er ator

DUT

Ce nte r Pin Chassis Ground Voltag e Measured at O-scope

+

  • Surge

Generator

DUT

Center Pin Voltag e Measured at O- sco pe

Ground Inductance

Effects of 1.5 ft ground lead inductance of #1 AWG Cu wire Voltage and energy throughput drastically increases

+544V, -176V

Note: The length of the grounding conductor connected to any lightning protection

device has a major effect on the protector performance as illustrated by the above test. Leadless/Bulkhead installation technique for RF lightning protection devices will eliminate this additive voltage and energy throughput to the protected equipment

slide-43
SLIDE 43

43 / TMS Times standard PowerPoint Template / 6/25/2014

Intelligently designed to effectively conduct lightning current to earth ground while balancing the need for security and economy

slide-44
SLIDE 44

44 / TMS Times standard PowerPoint Template / 6/25/2014

Feed-through LP-FT-DFDF LP-FT-NFNF Blank Plug LP-DP LP-NP Lightning Protectors

slide-45
SLIDE 45

45 / TMS Times standard PowerPoint Template / 6/25/2014

slide-46
SLIDE 46

46 / TMS Times standard PowerPoint Template / 6/25/2014

Smart-Panel feed-through adaptor

slide-47
SLIDE 47

47 / TMS Times standard PowerPoint Template / 6/25/2014

Feed-through BOM and drawing

slide-48
SLIDE 48

48 / TMS Times standard PowerPoint Template / 6/25/2014

  • 3/8” x 2” Tamper Resistant Galv Lag Screw
  • 3/8” Short Galv Lag Shield
  • 3/8” x 1-3/4” Tamper Resistant Bolt
  • 3/8” SS Flat Washer
  • 3/8” Lock Washer
  • 3/8” SS Hex Nut
  • Ground Lug 2/0 AWG
  • Tamper Resistant Wrench
  • Hole Cutout Template
  • Lightning Protectors

Based on Network Requirements

  • Feed Through Connectors:

LP-FT-DFDF (DIN Feed-Through) LP-FT-NFNF (N Feed-Through)

  • Blank Hole Plugs:

LP-DP (DIN Hole Plug) LP-NP (N Hole Plug) Material : 6061-T6 Master Ground Bar: C110 Copper Finish: Powder Coat Weight (lbs): 50 (12 Port) 58 (24 Port)

LP-SP-24N / LP-SP-24D LP-SP-12N / LP-SP-12D

Included installation hardware Available accessories

Specifications:

slide-49
SLIDE 49

49 / TMS Times standard PowerPoint Template / 6/25/2014

LP-SP-24N Installed view-metal building

slide-50
SLIDE 50

50 / TMS Times standard PowerPoint Template / 6/25/2014

Installed views

slide-51
SLIDE 51

51 / TMS Times standard PowerPoint Template / 6/25/2014

Mutual coupling and isolation considerations

Equipment Rack

2 ft. separation provides 120dB isolation for equipment at 20KA lightning current on down conducting plate

slide-52
SLIDE 52

52 / TMS Times standard PowerPoint Template / 6/25/2014

EMI coupling effects

slide-53
SLIDE 53

53 / TMS Times standard PowerPoint Template / 6/25/2014

Material Conductivity Comparison

slide-54
SLIDE 54

54 / TMS Times standard PowerPoint Template / 6/25/2014

Benefits of New Design Approach

  • Single point grounding accomplished by design.
  • 30 Degree RF feeder entries for easy access, better weatherization, and water drip curve.
  • Accommodates 12 or 24 RF feeder cables, wave guide, data, telemetry, DC & fiber entries .
  • Impedance and inductance controlled through geometry of design.
  • Provisions for installation of LP Devices to create true single point grounding.
  • Materials: Al 6061-T6 Standard, C110 copper optional.
  • No external coax ground kits required, eliminating potential water ingress.
  • Theft proof design.
  • Weatherized to IP-65.
  • Protector throughput voltage lower than other panel designs using long ground conductors.
  • Adjustable to shelter wall thickness.
  • Provisions for lightning strike counter and ground resistance monitor with remote alarms.
  • Allows installation of multiple lightning protectors on the same ground reference plane.
  • Easily connects to external lightning designed ground system. A low impedance, fast transient

response Radial and Ground Rod System is best.

slide-55
SLIDE 55

55 / TMS Times standard PowerPoint Template / 6/25/2014

Protector Grounding ???

slide-56
SLIDE 56

56 / TMS Times standard PowerPoint Template / 6/25/2014

Images of Lightning damaged RF protector

slide-57
SLIDE 57

57 / TMS Times standard PowerPoint Template / 6/25/2014

Reflected Power Issue

slide-58
SLIDE 58

58 / TMS Times standard PowerPoint Template / 6/25/2014

When everything else fails, there is always plastic tie!

slide-59
SLIDE 59

59 / TMS Times standard PowerPoint Template / 6/25/2014

RF protection circuit topologies

Gas Tube

Surge Protected

A dc blocked protector uses a gas tube connected from the center pin of the “surge” connector to the protector body and a discrete component capacitor in series from the top of the gas tube to the “protected” connector center pin. A dc blocked mechanical filter has a high current rated inductor connected from the center pin of the “surge” connector to the protector body. A conductor is continued from the top of the inductor to a mechanical capacitor in series to the center pin of the “protected” connector. The solid state dc pass/protect protector, with a dc blocking capacitor in the RF path from connector to connector, is bi-directional, and includes an RF isolated high current bi-polar diode. The diode is RF decoupled with an inductor from each connector center pin.

Bi-directional Surge Protected Bi-directional

A non-dc blocked protector (“straight-through”) will share the incoming current with a resistive component (RF coupling loop). The gas tube will turn on when the current through the resistive component in the equipment input rises enough to create a voltage drop reflected back to the protector’s gas tube.

Gas Tube

slide-60
SLIDE 60

60 / TMS Times standard PowerPoint Template / 6/25/2014

RF Protection Technologies Performance Overview

slide-61
SLIDE 61

61 / TMS Times standard PowerPoint Template / 6/25/2014

The preferred method for product recommendation is by obtaining the actual network operating data as

  • pposed to competitor part number as

cross-ref. There are many overlaps in competitive products which might otherwise disqualify our parts, even though our products could satisfy customer requirements.

slide-62
SLIDE 62

62 / TMS Times standard PowerPoint Template / 6/25/2014

LP-BTR-N Series DC blocked (20-1000MHz)

  • DC blocked design
  • Multi-strike capability
  • Broad band performance up to 1GHz
  • Exceptional RF characteristics
  • Universal bulkhead and flange mounting
  • Elongated Female connectors
  • Weatherization gasket included
  • Solid Brass design / White Bronze plating
  • Phosphor Bronze center pin construction
  • Silver plated center pin
  • Insertion Loss: < 0.1dB
  • Return Loss: <-26dB
  • VSWR: <1.1:1
  • Energy throughput: <200uJ
  • LP-BTR-NFF

N Female/Female

  • LP-BTR-NMP

N Male on Protected

  • LP-BTR-NMS

N Male on Surge

slide-63
SLIDE 63

63 / TMS Times standard PowerPoint Template / 6/25/2014

LP-BTR-N Series mechanical specifications

  • LP-BTR-NFF

N Female/Female

  • LP-BTR-NMP

N Male on Protected

  • LP-BTR-NMS

N Male on Surge

slide-64
SLIDE 64

64 / TMS Times standard PowerPoint Template / 6/25/2014

IP67 Weatherized LP-BTRW-N Series DC blocked (20-1000MHz)

  • DC blocked design
  • Multi-strike capability
  • Broad band performance up to 1GHz
  • Exceptional RF characteristics
  • Universal bulkhead and flange mounting
  • Elongated Female connectors
  • Weatherization gasket included
  • Solid Brass design / White Bronze plating
  • Phosphor Bronze center pin construction
  • Silver plated center pin
  • Insertion Loss: < 0.1dB
  • Return Loss: <-26dB
  • VSWR: <1.1:1
  • Energy throughput: <200uJ
  • IP67 Weatherized
  • LP-BTRW-NFF

N Female/Female

  • LP-BTRW-NMP

N Male on Protected

  • LP-BTRW-NMS

N Male on Surge

slide-65
SLIDE 65

65 / TMS Times standard PowerPoint Template / 6/25/2014

IP67 Weatherized LP-BTRW-N Series mechanical specifications

  • LP-BTRW-NFF

N Female/Female

  • LP-BTRW-NMP

N Male on Protected

  • LP-BTRW-NMS

N Male on Surge

  • All Units Weatherized to IP67
slide-66
SLIDE 66

66 / TMS Times standard PowerPoint Template / 6/25/2014

LP-HBX-N Series DC blocked (100-700MHz)

  • DC blocked design
  • Multi-strike capability
  • High power design 750W
  • Exceptional RF characteristics
  • Elongated Female connectors
  • IP 65 Weatherized
  • Insertion Loss: < 0.1dB
  • Return Loss: <-23dB
  • VSWR: <1.15:1
  • Voltage throughput: <5Vpk
  • Energy throughput: <1.4uJ
  • LP-HBX-NFF

N Female/Female

  • LP-HBX-NMS

N Male on surge side

  • LP-HBX-NMP

N Male on protected side

slide-67
SLIDE 67

67 / TMS Times standard PowerPoint Template / 6/25/2014

Surge Performance Data for LP-HBX Series at 6kV/3kA (1.2x50/8x20us) wave-shape

LP-HBX-NFF N Female/Female LP-HBX-NMS N Male on surge LP-HBX-NMP N Male on protected

Voltage throughput: <5Vpk Energy throughput: <1.4uJ

slide-68
SLIDE 68

68 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL-D series DC Blocked (680-2200MHz)

  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Maintenance free design
  • Maximum surge current: 50kA
  • Throughput voltage: 440mV
  • Throughput energy: 700pJ
  • PIM@ 900/1900/2100MHz: <-160dBc
  • Insertion Loss: < 0.1dB
  • Return Loss: <-26dB
  • LP-STRL-DFF

DIN Female/Female

  • LP-STRL-DMP

DIN Male on Protected

  • LP-STRL-DMS

DIN Male on Surge

slide-69
SLIDE 69

69 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL-D series mechanical specifications

  • LP-STRL-DFF

DIN Female/Female

  • LP-STRL-DMP DIN Male on Protected
  • LP-STRL-DMS DIN Male on Surge
slide-70
SLIDE 70

70 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL-N series DC Blocked (680-2200MHz)

  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Maintenance free design
  • Maximum surge current: 50kA
  • Throughput voltage: 440mV
  • Throughput energy: 700pJ
  • PIM@ 900/1900/2100MHz: <-160dBc
  • Insertion Loss: < 0.1dB
  • Return Loss: <-26dB
  • LP-STRL-NFF N Female/Female
  • LP-STRL-NMP N Male on Protected
  • LP-STRL-NMS N Male on Surge
slide-71
SLIDE 71

71 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL-N series mechanical specifications

  • LP-STRL-NFF N Female/Female
  • LP-STRL-NMP N Male on Protected
  • LP-STRL-NMS N Male on Surge
slide-72
SLIDE 72

72 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL Series Voltage Throughput

6kV/3kA 1.2x50us/8x20us wave-shape

440mV

slide-73
SLIDE 73

73 / TMS Times standard PowerPoint Template / 6/25/2014

LP-STRL Series Energy Throughput

000.0E+0 100.0E-12 200.0E-12 300.0E-12 400.0E-12 500.0E-12 600.0E-12 700.0E-12 800.0E-12 000.0E+0 50.0E-3 100.0E-3 150.0E-3 200.0E-3 250.0E-3 300.0E-3 350.0E-3 400.0E-3 450.0E-3 500.0E-3

  • 400.E-6
  • 360.E-6
  • 320.E-6
  • 280.E-6
  • 240.E-6
  • 200.E-6
  • 160.E-6
  • 120.E-6
  • 80.E-6
  • 40.E-6

200.E-9 40.E-6 80.E-6 120.E-6 160.E-6 200.E-6 240.E-6 280.E-6 320.E-6 360.E-6 Energy Let-thru (joules) Let-through (Voltage) Time

LP-STR and LP-STRL 6kV/3kA Energy & Voltage Plotted into 50 Ohms with 0.08VDC Offset when applicable

50 Ohm Voltage Voltage over DC (ABS) Energy Over DC Offset

slide-74
SLIDE 74

74 / TMS Times standard PowerPoint Template / 6/25/2014

QWS voltage and energy plotted into 50 Ohm load (8x20us)

slide-75
SLIDE 75

75 / TMS Times standard PowerPoint Template / 6/25/2014

Times-Protect PIM Test Data – LP-STRL Series / <-160dBc

slide-76
SLIDE 76

76 / TMS Times standard PowerPoint Template / 6/25/2014

“Other Brand” Ultra Low PIM protector / <-155dBc

slide-77
SLIDE 77

77 / TMS Times standard PowerPoint Template / 6/25/2014

DC Pass product family

  • Applications requiring power
  • Broadband design
  • Bi-directional operation
  • Multi strike capability
  • Fully weatherized to IP67
slide-78
SLIDE 78

78 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GTR-D Series DC pass (DC-2500MHz)

  • LP-GTR-DFF/23/35

DIN Female/Female

  • LP-GTR-DFM/23/35

DIN Female/Male

  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Bi-directional operation
  • 90Vdc turn on (50 Watts)
  • 230Vdc turn on (210 Watts)
  • 350Vdc turn on (550 Watts)
  • White Bronze plated body
  • Phosphor Bronze center pin
  • Silver plated center pin
  • Insertion Loss: < 0.2dB
  • Return Loss: <-26dB
slide-79
SLIDE 79

79 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GTR-N Series DC Pass (DC-3000MHz)

  • LP-GTR-NFF/23/35

N Female/Female

  • LP-GTR-NFM/23/35

N Female/Male

  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Bi-directional operation
  • 90Vdc turn on voltage (50 Watts)
  • 230Vdc turn on voltage (210 Watts)
  • White Bronze plated body
  • Phosphor Bronze center pin
  • Silver plated center pin
  • Insertion Loss: < 0.25dB
  • Return Loss: <-26dB
slide-80
SLIDE 80

80 / TMS Times standard PowerPoint Template / 6/25/2014

Universal mounting and grounding bracket LP-BFDN-CW

slide-81
SLIDE 81

81 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GTV-N Series DC Pass (DC-7000MHz)

  • LP-GTV-NFF

N Female/Female

  • LP-GTV-NFM

N Female/Male

  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Bi-directional operation
  • 180 Vdc turn on voltage (150 Watts)
  • White Bronze plated body
  • Phosphor Bronze center pin
  • Silver plated center pin
  • Insertion Loss: <20dB (DC-6.7GHz)
  • Insertion Loss: < 0.3dB (6.7-7.0GHz)
  • Return Loss: <20dB (DC-6.7GHz)
  • Return Loss: <17dB (6.7-7.0GHz)
slide-82
SLIDE 82

82 / TMS Times standard PowerPoint Template / 6/25/2014

LP-18-400-N series DC Pass (DC-6000MHz)

Cable Connector & Lightning Protector in One!

  • LP-18-400-NMH-X N type Male
  • LP-18-400-NF-X N type Female
  • Fully weatherized body to IP67
  • Broadband RF performance
  • Multi-strike capability
  • Bi-directional operation
  • 180 Vdc turn on voltage (150 Watts)
  • White Bronze plated body
  • Phosphor Bronze center pin
  • Silver plated center pin
  • Insertion Loss: < 0.15dB
  • Return Loss: <-23dB
slide-83
SLIDE 83

83 / TMS Times standard PowerPoint Template / 6/25/2014

6KV/3KA Gas Tube voltage and energy plotted into 50 Ohm load (8x20us)

slide-84
SLIDE 84

84 / TMS Times standard PowerPoint Template / 6/25/2014

Wireless Broadband and GPS designs

LP-WBX-N Series:

  • LP-WBX-NFF (Female-Female)
  • LP-WBX-NMP (Male on Protected)
  • LP-WBX-NMS (Male on Surge)

LP-GPX-05-N Series:

  • LP-GPX-05-NFF (Female-Female)
  • LP-GPX-05-NFM (Female-Male)
slide-85
SLIDE 85

85 / TMS Times standard PowerPoint Template / 6/25/2014

  • Fully weatherized body to IP65
  • Broadband RF performance
  • Multi-strike capability
  • Maintenance free design
  • Maximum surge current: 20kA
  • Throughput voltage: 2Vpk
  • Throughput energy: 150nJ
  • Insertion Loss: <-0.2dB
  • Return Loss: <-18dB
  • RF power: 50Watts
  • LP-WBX-NFF N Female/Female
  • LP-WBX-NMP N Male on Protected
  • LP-WBX-NMS N Male on Surge

LP-WBX-N series DC blocked (2000-6000)MHz

slide-86
SLIDE 86

86 / TMS Times standard PowerPoint Template / 6/25/2014

LP-WBX-NFF/NMP/NMS (2000-6000MHz) operation

slide-87
SLIDE 87

87 / TMS Times standard PowerPoint Template / 6/25/2014

LP-WBX-N Series S11 & S21 parameters

slide-88
SLIDE 88

88 / TMS Times standard PowerPoint Template / 6/25/2014

  • Fully weatherized body to IP65
  • L1, L2 & L3 RF performance
  • DC blocked RF path
  • Solid State DC protection circuit
  • Multi-strike capability
  • Maintenance free design
  • Maximum surge current: 10kA
  • User Voltage: 5Vdc
  • Throughput voltage: <12Vpk
  • Throughput energy: 150nJ
  • Insertion Loss: <-0.1dB
  • Return Loss: <-26dB
  • LP-GPX-05-NFF N Female/Female
  • LP-GPX-05-NFM N Female/Male
  • LP-GPX-05-SFF SMA Female/Female
  • LP-GPX-05-SFM SMA Female/Male
  • LP-GPX-05-TFF TNC Female/Female
  • LP-GPX-05-TFM TNC Female/Male

LP-GPX-05-N series DC pass (1000-2000)MHz

slide-89
SLIDE 89

89 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GPX-05-NFF & NFM (L1, L2 & L3) Bidirectional GPS Protector

slide-90
SLIDE 90

90 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GPX-05-SFF & LP-GPX-05-SFM Bidirectional L1, L2 & L3 Protector

LP-GPX-05-SFF LP-GPX-05-SFM

slide-91
SLIDE 91

91 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GPX-05-N & S Series S11 & S21 parameters

slide-92
SLIDE 92

92 / TMS Times standard PowerPoint Template / 6/25/2014

LP-GPX-05-N & S Series S22 & S21 parameters

slide-93
SLIDE 93

93 / TMS Times standard PowerPoint Template / 6/25/2014

Surge Performance Data for LP-GPX and LP-WBX Series at 6kV/3kA (1.2x50/8x20us) wave-shape

LP-GPX-05-NFF LP-GPX-05-NFM Bidirectional operation LP-WBX-NFF LP-WBX-NMP LP-WBX-NMS

User voltage: 5Vdc Voltage throughput: <12Vpk Energy throughput: <110uJ Voltage throughput: <2Vpk Energy throughput: <150nJ

slide-94
SLIDE 94

94 / TMS Times standard PowerPoint Template / 6/25/2014

LP-SPT (Surge Protector Tester)

LP-SPT Specifications:

Dimensions: 9.0” x 4.0” x 1.5” Weight: 1 pound Power: 9V battery, 2 each included Display: 3.5 digit LCD Test Output: 1000V / 1mA DUT interfaces: One type-N female, one type-N male Carrying Case: Rugged black nylon N–Alligator Clip Adaptor: Included

slide-95
SLIDE 95

95 / TMS Times standard PowerPoint Template / 6/25/2014

Product Type

“f”(MHz)

1500 3000 4500 6000

LP-STR-D & N Series LP-GTR-N Series

LOW PIM (800-2500MHz) DC blocked DIN & N type

  • Cellular Carriers

LP-GTR-D Series

(DC-3000MHz) DC pass N type (50/210/550 Watts) (DC-2500MHz) DC pass DIN type (50/210/550 Watts)

LP-STRL- D & N Series

LOW PIM (680-2200MHz) DC blocked DIN & N, type –LTE, 700MHz Public Safety Spectrum, Cellular Carriers

LP-WBX-N Series (2000-6000MHz) DC blocked LP-GPX-05 (1000-2000MHz) N, TNC & SMA type (5V) - L1, L2 & L3

Bidirectional GPS Protector

Product Selection Matrix

Broadband Wireless

Smart – Panel & Grounding Accessories LP-BTR-N (20-1000MHz) DC blocked N type – UHF/VHF applications – Indoor use

SCADA, LMR, Utilities, Public Safety, Oil, Gas

LP-BTRW-N

(20-1000MHz) DC blocked N type – UHF/VHF applications – IP67 Weatherized SCADA, LMR, Utilities, Public Safety, Oil, Gas 7000

LP-GTV-N Series (DC-7000MHz) DC pass N type Female /Female & Female /Male (150W) LP-18-400-N Series (DC-6000MHz) DC pass N type F&M with EZ-400 interface (150W)

slide-96
SLIDE 96

96 / TMS Times standard PowerPoint Template / 6/25/2014

Thank you and Questions ???
