LED Industrial Considerations October 30 th 2015 Nate Dennis, LC Philips Lighting Company 207-838-0117 Agenda Order Presentation 1. Welcome Overview 2. About Philips and Goals 3. LED Technology Overview 4. Plant Evaluation Process 5.

slide-1
SLIDE 1

LED Industrial Considerations

October 30th 2015

Nate Dennis, LC Philips Lighting Company

207-838-0117

slide-2
SLIDE 2

Agenda

Order Presentation 1. Welcome Overview 2. About Philips and Goals 3. LED Technology Overview 4. Plant Evaluation Process 5. Outdoor Considerations 6. LED in your Facility 7. Controls 8. Wrap-Up and Questions

slide-3
SLIDE 3

Philips Lighting Company

Complete Solution Luminaires Philips Business Solutions Philips Design Solutions

slide-4
SLIDE 4

Philips Cares about Massachusetts!

slide-5
SLIDE 5

Philips Cares about Massachusetts!

slide-6
SLIDE 6

LED Adoption Occurring in Stages.

slide-7
SLIDE 7

LED Industrial Considerations

LED Technology

slide-8
SLIDE 8

4

What goes into an LED?

Level 4 Level 3 Level 2 Level 1

Thermal Management Optics– LED package /Array Driver Technology -

slide-9
SLIDE 9

Terms:LM-79, LM-80, TM-21

  • LM-79 - the Luminaire

– Absolute photometry – Lumen output – Luminous intensity – Colorimetry (CCT/CRI)

  • LM-80 – the LED

– Methodology for measuring lumen maintenance. – NOT life testing

  • TM-21 – Relates to how a MFG can project life to L70

– Limits test to 6 times the test period – Requires 6000 hours of testing – Relates to LM-80

slide-10
SLIDE 10

Terms: L70 and B50

  • L70 – Burn Hours until 70% Lumen Maintenance
  • B50 – Hours to 50% survivorship
  • L70/B50 – Hours to 50% and 70% light level (lumen maintenance)
  • Additional Government Standards:

– Energy Star – Design Lights Consortium (DLC)

slide-11
SLIDE 11

LED Improvements

  • 2013-2014 --- 20% Improvement in Light Output
  • 2014-2015 --- 10% Improvement in Light Output
  • 2013 - Lumens per Watt Exceeds best Fluorescent Lighting
  • 2014 – Color shifting technology to mimic Incandescent.
  • 2014 – Many color options of LED to meet the occupants space

requirements.

slide-12
SLIDE 12

LED Industrial Considerations

Evaluating Your Facility

slide-13
SLIDE 13

Business Case: Goals

slide-14
SLIDE 14

Lighting Audit

+ Can the current lighting be improved. + Can light be reduced? + What are light levels? + What is the burn hours? + What is your per watt cost? +What is a watt worth? + Good Lighting v. Cheapest Approach.

slide-15
SLIDE 15

General Evaluation

slide-16
SLIDE 16

Evaluating Payment Options

+ Leasing is a common alternative to utilizing capital investment to improve your facility. + Use energy savings as offset to other projects under consideration by your company. + On Bill Finance Options.

slide-17
SLIDE 17

Tax Centric Lighting Design

slide-18
SLIDE 18

LED Industrial Considerations

Outdoor Considerations

slide-19
SLIDE 19

Do You have poles that look like this?

slide-20
SLIDE 20

Photometric Performance

Backlight Uplight and Glare

BACKLIGHT Which creates light trespass

  • nto adjacent sites. The B rating takes

into account the amount of light in the BL, BM, BH and BVH zones, which are the OPPOSITE direction from the area intended to be lighted. UPLIGHT Which causes artificial sky glow. Eliminating uplight (UL and UH zones) ensures there is no wasted light and keeps our skies dark. Look for products with no uplight U0. GLARE Which can be annoying or visually disabling. The G rating accounts for the amount of light in the FH and FVH zones as well as the BH and BVH zones – also known as the glare zones.

BUG Rating

slide-21
SLIDE 21

Glare Excessive Light Noise Dark Skies Killer Not Code

slide-22
SLIDE 22

Fixture Head Reduction

Multiple Optics Options from a well designed Fixture

slide-23
SLIDE 23
slide-24
SLIDE 24

Competitor Analysis

Competitive Performance (House Side Shield - LED vs. LED)

The specially designed House Side Shield of the RoadFocus allows for better backlight control and sharper cutoff with less light loss compared to

  • ther products available
  • n the market, and its

tool-free field installation means less hassle.

Competitor

with House Side Shield

RoadFocus

with House Side Shield

Based on published competitor data.

slide-25
SLIDE 25
slide-26
SLIDE 26

26

15

PHILIPS LED OUTDOOR PRODUCT PORTFOLIO –

SITE LIGHTING

EcoForm AeroScape LytePro Plus PureForm SlenderForm

ClearScape LED

slide-27
SLIDE 27

LED Industrial Considerations

Plant, Office and Warehouse

slide-28
SLIDE 28

Plant and Warehouse

slide-29
SLIDE 29

Review Current Lighting Design – Then Improve it

slide-30
SLIDE 30

Challenges in the applications

Are any of these factors fixed or constantly changing ? Rack alignments Reflectance Spacing and height Storage material / machinery Daylight / Ambient light Stacking density

slide-31
SLIDE 31

19

Led Tubes – Called TLED

PHILIPS InstantFit

Fluorescent T8 Replacements

4’ 2100lm DIM 3’ 1200lm U-Bent 2100lm 4’ 1600lm 2’ 1050lm

Fluorescent “PL” Replacements

2’ PL-L 4’ 2100lm Glass

slide-32
SLIDE 32

LED High Bay

Key Features

  • Efficacies up to 120 lm/w
  • Multiple lumen packages up to 45,000 nominal

delivered lumens

  • Three sizes optimized to lumen packages
  • Multiple light distribution patterns
  • 4000K and 5000K color temperatures
  • 80+ CRI
  • 0-10V dimming drivers are standard
  • Available in all standard voltages 120V - 480V
  • Available for ambient temperatures up to 55C
  • Multiple mounting options
  • Optional motion detector
  • Optional integral emergency battery
  • DLC listed
slide-33
SLIDE 33

Conventional Comparison

Conventional System Conventional System Wattage FBX Potential Equivalent FBX System Wattage Energy Savings % Savings 100W PSMH 129W FBX08LL40 82W 47W 36.43% 150W PSMH 190W FBX12LL40 98W 92W 48.42% 250W PSMH 288W FBX16LL40 165W 123W 42.71% 400W PSMH 454W FBX24LL40 197W 257W 56.61% 750W PSMH 820W FBX45LL40 398W 422W 51.46% (4) 54W T5HO 236W FBX16LL40 165W 71W 30.08% (6) 32W T8 221W FBX16LL40 165W 56W 25.34% (6) 54W T5HO 354W FBX24LL40 197W 157W 44.35%

Compared to conventional systems, the FBX LED technology can save up to 56% of the energy required to light a space.

slide-34
SLIDE 34

Light Distributions

Each optic is designed for a specific purpose:

  • General distribution allows a

wash of light in any application

  • Narrow beam allows focused

light in higher ceiling areas

  • Medium beam is tailored for

mid mounting heights

  • Wide beam is perfect for low

bay areas or locations with wider fixture spacing

  • Aisle beam has an

asymmetric distribution for aisle or rack areas

slide-35
SLIDE 35

Options & Accessories

Multiple options and accessories are available to match the luminaire to the existing space requirements or to the desired design effect.

Wire Guard Chain Kit Pendant Hanger Emergency Option Motion Detector Cable Kit

slide-36
SLIDE 36

Fluxstream LED Strip Family – General Overview

  • Lengths: 4’ & 8’ Nominal
  • Flux:

3100lm & 3900/4100lm

  • Input Power: 31W/37W/40W
  • CCT:

3500K & 4000K

  • CRI:

80min

  • Dimming:

0-10v Analog Optional

  • Op Temps: -20°C to 25°C
  • cETLus listed for damp locations
  • Longevity: 100K hr L70 LED lumen maintenance
  • Warranty:

5 years

  • 0-10v analog dimming (DZT)
  • Continuous row mount coupler (LFCPL)
  • Remote mount emergency (consult factory)
  • Motion sensor (field install, voltage dedicated)
  • Wireguard (LF4WGW)
  • Suspension…
  • Aircraft cable – 6”-60” field adjustable, powered available
  • Chain – 5’ w/ V-hook (EE9HC)
  • Pendant stem – 12”-48” (SV5Fxx)
slide-37
SLIDE 37

OWL LED Wrap – Features

  • Lengths: 2’, 4’, & 8’ Nominal
  • Flux:

3000lm (2’) -14000lm (8’T)

  • Efficacy:

min 86lm/W (2’ 4000lm), others >93lm/W

  • CCT:

3500K & 4000K

  • CRI:

80min

  • Voltage: 120-277v (UNV) & 347v
  • Dimming:

0-10v Analog & 100/40 Step Dim

  • Op Temps:
  • 20°C to 25°C
  • ETL listed for damp locations
  • Longevity:

50K hr L70 LED lumen maintenance

  • Warranty:

5 years

37

$30 $50 $100 $50 $40-$80

slide-38
SLIDE 38

Product Details

Design

  • Attractive single lens

enclosure and architectural aesthetics.

  • Uniform glare-free lighting

without pixilation

  • 124LPW
  • Daylite, Dimming, Controls
  • 2.75” depth
slide-39
SLIDE 39

Product Details

Options

  • 3 sizes: 2x2,2x4 and(1X4 in Sept 2015)
  • T-Grid and Dry wall ceilings
  • Currently Static only. Air by Sept 2015.
  • 3500, 4000 and 5000K
  • CRI >80+
  • L70/50K as per TM21A. (L70/100K calculated under consideration)
  • 3000, 3800, 4500lm (2x2)
  • 3800, 4300, 4800, 5400, 7400lm (2x4)
  • 2600, 3000, 4000lm (1X4) – Sept Q4
  • Chicago plenum
  • 120/277V, 347V
  • Integrated battery packs
  • Integrated Daylight and Occupancy sensors
  • Space Wise under development. Expected to be available by

Sept 2015.

  • Standard dimming (0-10V)
  • DALI, Step-dim, Phase Dim, and Lutron Hi-Lume A and

EcoSystem drivers as options

Space Wise

Actilume Day and Occ Sensor

slide-40
SLIDE 40

Indoor Design of Space to Meet Requirements

slide-41
SLIDE 41

Plant, Office and Warehouse

slide-42
SLIDE 42

Controls: Application Modes

Warehouse mode Auto ON 100% ------> 2 min @100%------>2 min @Bgrnd----------------> OFF Warehouse comfort mode Auto ON 100% -------> 2 min @100%--------->Infinite @Bgrnd (No OFF)

slide-43
SLIDE 43

Controls: Application Modes Indoor Office

Configured on site to match occupant’s needs

Private Office Mode

On/Off sensor Daylight & manual dimming

Meeting Room Mode

Granular dimming Step-dim override (wall control)

Open Office Mode

Granular dimming Daylight dimming

Corridor Mode

Granular & Daylight Emergency Egress Mode

slide-44
SLIDE 44

Deep Energy Savings – Demonstrated 75% measured energy Savings

Wireless Integrated Control Technology was selected for evaluation under the GSA Green Proving Ground program at the Metcalfe Building in Chicago, with independent evaluation by Lawrence Berkeley National Laboratory.

slide-45
SLIDE 45

4 5

Thank You for your time today!

Nate Dennis, LC Philips Lighting nate.dennis@philips.com 207-838-0117
