Laurel Woods Elementary School Construction Document Report

Bruce Gist Director, School Construction February 25, 2014

Project Updates

• Design features and requirements were fully

refined after all stakeholders were engaged

• The new pre-kindergarten room was enlarged

and adjacent toilet facilities were renovated

• An add-alternate was designed to add a

serving line to the kitchen

Project Updates (cont)

• Light tubes were added to 4 classrooms

adjacent to new classroom addition for daylighting

• The dumpster enclosure was relocated away

from the building to improve sightlines

• Existing and new electrical systems were

modified due to MEMA mandates

Proposed Site Plan

Laurel Woods Elementary School - CD Report

Existing Building Plan

Laurel Woods Elementary School - CD Report

Proposed Building Plan

Laurel Woods Elementary School - CD Report

Enlarged Plan at Classroom Addition

Laurel Woods Elementary School - CD Report

First Floor Second Floor

Enlarged Plan at Art Room to Pre-K Renovation

Laurel Woods Elementary School - CD Report

Enlarged Plan at Cafetorium Addition and Add-Alternate Number 3

Laurel Woods Elementary School - CD Report

T

• tal Project Budget

Base construction estimate $6,343,590 (includes 6% construction Contingency $360,292) Architect Engineering Fee $465,633 Construction Management Fee $648,000 Related Costs $302,150 Project Contingency $302,150 Equipment $50,000 Total Project Estimate ` $8,111,523 Project T

• tal Budget (includes updated FY15 CIP request)

$8,062,000 Alternate #1: PE Activity Room $373,591 Alternate #2: DDC HVAC Control Package $387,397 Alternate #3: Kitchen Modifications $35,168

Summary

• Project bid opening in May 2014
• Completion August 2015
• Request approval of construction documents

and allow staff to proceed to bid
