ON TOP OF THE W ORLD NORTH ADVANCED W ASTEW ATER TREATMENT FACI LI TY Springs Com m ittee Presentation Decem ber 1 1 , 2 0 1 9 Site Map 2 Proposed Facility I m provem ents WWTF Improvements Construction of new 2.5 MGD advanced
SLIDE 2
SLIDE 3
3
Proposed Facility I m provem ents
- WWTF Improvements
- Construction of new 2.5
MGD advanced wastewater treatment facility and decommission of existing 1.25 MGD conventional treatment plant
- Biosolid treatment and
thickening with elimination
- f biosolids land application
site
- Reclaimed water
transmission system high service pump station
SLIDE 4
4
Proposed Facility I m provem ents
- Wastewater Transmission System
Improvements
- Triplex master lift station with
- dor control
- 15,000 feet of 20-inch force
main
- Reclaimed Water Transmission
System Improvements
- 5 million gallon ground storage
tank
- 7700 feet of 24-inch
transmission main
- 300 feet of 16-inch transmission
main for tie-in
SLIDE 5
5
Environm ent Statistics
Significant Nutrient Reduction
Year Total Plant Flow ( MGD) W W TF Effluent Load Reduction ( lbs/ year) Biosolids Load Reduction ( lbs/ year) Total Load Reduction ( lbs/ year) 2 0 1 9 ( Current Flow s) 0.650 1,636 7,326 8,962 2 0 2 6 ( Projected Flow s) 1.150 2,895 12,962 15,856 2 0 3 8 Projected ( 2 0 years from BMAP) 1.850 4,656 20,851 25,508 2 0 4 8 Projected ( New Plant Capacity) 2.500 6,292 28,177 34,470
SLIDE 6
6
- ~ 8 Miles to Rainbow
Springs Headw aters
- High Recharge Area
Environm ent Statistics
SLIDE 7
7
Schedule
Project Schedule 2 0 2 1 2 0 2 2 2 0 2 3 2 0 2 4
PHASE 1 Engineering PHASE 2 Bidding and Construction
January 2021 June 2022 July 2022 September 2024
