Latest Results of the ILC Large TPC Prototype (LPTPC) G. De Lentdecker Universit Libre de Bruxelles Brussels, Belgium On behalf of the LCTPC Collaboration Overview Introduction Motivations, experiment and collider concepts TPC


slide-1
SLIDE 1

Latest Results of the ILC Large TPC Prototype (LPTPC)

  • G. De Lentdecker

Université Libre de Bruxelles Brussels, Belgium On behalf of the LCTPC Collaboration

slide-2
SLIDE 2

Overview

  • Introduction
  • Motivations, experiment and collider concepts
  • TPC
  • Micro Pattern Gaseous Detectors (MPGD)
  • The Large Prototype TPC (LPTPC)
  • Beam test setup in DESY
  • 3 detector technologies
  • Test-beam results
  • Future developments
  • Conclusions

2 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-3
SLIDE 3

Future e+e- Linear Colliders

  • Why ?
  • There are two paths for discovery:
  • Large Energy Range (Tevatron, LHC, HL-LHC,…)
  • Direct discovery of new particles
  • High Precision (LEP, ILC, CLIC,…)
  • Inferring new physics effects from high energy scales through precise

measurements at lower energy

  • Combining both strategies gives much more complete

understanding than either one alone

  • Let’s take a (random) example…

3 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-4
SLIDE 4

The Higgs

4

  • The LHC has just discovered a new particle with a mass

around 125-126 GeV/c2, consistent with the Brout-Englert- Higgs boson. But is it the SM Higgs boson ?

Relativistic Quantum Field theory Gauge Principle

Established by precision EWK studies

Symetry Breaking & Mass Generation We can now test it

2012/11/13

  • G. De Lentdecker - KEK seminar

Any deviation from the straight line would indicate BSM physics !

slide-5
SLIDE 5

Why precision ?

5

Assumed luminosities:

LHC = 14 TeV, 300fb-1 (*) HLC = ILC 250 GeV, 250fb-1 ILC = ILC 500 GeV, 500fb-1 ILCTeV = ILC 1 TeV, 1000fb-1

1 σ confidence intervals

  • M. Peskin arXiv:1207.2516v2 [hep-ph]

(*) 300fb-1 à ~ 2020 5% deviation band from SM prediction of the coupling

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-6
SLIDE 6

Experiment concept for ILC

  • “Visualize events as viewing Feynman diagrams”
  • We should be able to reconstruct any final state in term
  • f partons (quarks, leptons, gauge bosons)
  • Concept of particle flow (PF)
  • High granularity calorimetry: 1000 x LHC channels
  • High resolution tracking :
  • Hermiticity:

– Down to 10 mrad or lower – Everything incl. HCAL in Solenoid (B>3.5 T)

6

! 1 pt

" # $ $ % & ' ' =0.1( LHC

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-7
SLIDE 7

Bird’s Eye View of the ILC Accelerator

7

e+e- main linac Energy: 250 GeV + 250 GeV Length : 11km + 11km # of DRFS Klystron = 7280 # of Cryomodules = 1680 # of Cavities = 14560 Detectors Accelerator tunnel

Illustration by Rei Hori

2012/11/13

  • G. De Lentdecker - KEK seminar

Damping ring

slide-8
SLIDE 8

Detectors design

8

ILD SiD

  • Si vertex detector
  • Large TPC

(L=4.3m, Ø=3.6m)

  • Si envelope (in- & outside)
  • Precise calor. impact
  • Calorimeter
  • Muon chambers
  • All Si tracker

~10 discrete position measurements with σrφ~10 µm and a lever arm of ~1m in a 5T magnetic field

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-9
SLIDE 9

TPC principle

9 2012/11/13

  • G. De Lentdecker - KEK seminar

ionizing particle drifting e- Readout plane Projected trajectory

E B

slide-10
SLIDE 10

ILD TPC with MPGD

  • Micro Pattern Gas Detector (MPGD) instead of MWPC for the

electron amplification stage: Not limited by the ExB effects

10

MICROMEGAS OR GEM (Gas ElectronMultiplier)

  • 200 hits/track
  • δ1/pt ~ 9 10-5 /GeV/c (TPC only)
  • δ1/pt ~ 2 10-5 /GeV/c (Full Tracker)
  • σ (rφ) < 100 µm
  • Rad length: 0.04X0 – 0.25 X0
  • dE/dx resol ~ 5%

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-11
SLIDE 11

MICROMEGAS & GEM

11

~1 kV/cm

~50 µm ~50 kV/cm

MICROMEGAS GEM

2012/11/13

  • G. De Lentdecker - KEK seminar

~100 µm ~50 kV/cm

slide-12
SLIDE 12

The Large Prototype TPC (LPTPC)

  • Dimensions:
  • Length = 61cm
  • Diameter = 77cm
  • Endplate :
  • Aluminium
  • Can accommodate 7

detectors/dummy modules

  • GEM and Micromegas

modules have same shape à àinterchangeable

12

MICROMEGAS/Multi-GEM

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-13
SLIDE 13

The field cage

  • 13

.

HV : up to 20kV

Radiation Length: 1.31% of X 0

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-14
SLIDE 14

New endplate

14

New lighter endplate, space frame, completed end of March 2012:

2012/11/13

  • G. De Lentdecker - KEK seminar

Old endplate 16,9 % X0 New endplate 7,5 % X0

Endplate material budget:

  • readout : 5% X0
  • Cooling : 2% X0
  • Power cables :10% X0
  • Mechanical structure : 8% X0
slide-15
SLIDE 15

DESY set-up

  • LPTPC slided into a

superconducting solenoid of up to 1.25 T

  • 1 < p < 6 GeV/c e-

15

e- e-

Cosmic Trigger setup

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-16
SLIDE 16

DESY set-up developments

16

  • LCTPC Collaboration with EUDET

and AIDA :

2012/11/13

  • G. De Lentdecker - KEK seminar

3D moving table DESY – KEK collab PCMAG upgraded: new crycoolers and closed cooling cirtcuit (not shown here) Thanks to KEK-IPNS cryo. Group & KEK cryo. center + detector, electronics, developments …

slide-17
SLIDE 17

Tested MPGD technologies

  • 4 MPGD readout options are tested with the LPTPC:
  • Analog TPC (Subject to gas gain fluctuation in the gas amplification)
  • Multi layer GEM with standard pads

– The charge is spread on the pad plane by diffusion

  • MICROMEGAS with resistive-anode pads

– To spread the very narrow avalanche charge on the pad plane

  • Muli layer GEM with pixel readout

– To cope with high occupancy

  • Digital TPC (Free from gas gain fluct. Expect improvement on

position resolution by 20-30%)

  • Gridpix

– pixel device with implemented Micromegas mesh (Timepix of the pixel size of 55 µm) detecting individual primary electrons with 100% efficiency.

17 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-18
SLIDE 18

Multi layer GEM with standard pads

  • 2-3 layers of GEM provide sufficient gas

gain O(1000) for low noise electronics

  • The gap between the GEMs and the

E fields determine the charge spread à determine the point resolution

  • 2 types of GEM modules have been

successfully tested:

  • Asian GEM
  • Double thick (100µm) GEMs
  • Stretching to minimise dead

region on the sides.

  • DESY GEM
  • Triple CERN GEM

With thin (1mm) ceramic frame)

18 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-19
SLIDE 19

Asian GEM Set-up @ DESY

19

  • ALTRO chip (ALICE TPC Read Out) has 16 channels
  • Digitize and buffer the signal
  • Perform zero-suppression
  • 1 FEC has 8 ALTRO chips
  • For LCTPC, CERN designed a new preamp: PCA16
  • Tuneable gains, polarity, peaking/decay time,…

2012/11/13

  • G. De Lentdecker - KEK seminar

5152 pads of 1.2 x 5.4 mm2 (28 staggered rows)

slide-20
SLIDE 20

Some Double GEM Events

20 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-21
SLIDE 21

Spatial Resolution

21 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-22
SLIDE 22

Developments

  • Recent:
  • New segmented GEM foils (to reduce the discharge probability)
  • 3 modules will be tested at DESY in December 2012
  • Future (2013):
  • New readout electronics: the SALTRO16
  • Tested successfully on electronics testbench
  • Power pulsing demonstrated

– Power consumption reduced by a factor 60 with 5 Hz cycle

22 2012/11/13

  • G. De Lentdecker - KEK seminar

25 mm 32.5 mm

slide-23
SLIDE 23

MICROMEGAS with resistive anodes

  • Resistive coating on top of an

insulator: Continuous RC network which spreads the charge from σ (avalanche)~15µ to mm: matching pad width improves position sensitivity

  • PAD RESPONSE: Relative

fraction of ‘charge’ seen by the pad, vs x(pad)-x(track)

23

  • M. Dixit, A. Rankin, NIM A 566 (2006) 28

x(pad) – x(track) (mm) Z=20cm, 200 ns shaping

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-24
SLIDE 24

First MICROMEGAS tests

  • 3 bulk MICROMEGAS modules tested
  • Regular anodes
  • Resistive anodes (carbon loaded kapton)

with a resistivity ~ 5-6 MΩ/□

  • Resistive anodes (resistive ink) with a

resistivity ~ 1-2 MΩ/□

  • 1726 (24x72) pads of ~3x7 mm²
  • T2K AFTER-based electronics (72 ch./chip):
  • low-noise (700 e-) pre-amplifier-shaper
  • 100 ns to 2 µs tunable peaking time
  • full wave sampling by SCA

24 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-25
SLIDE 25

Some events

B=1T, T2K gas: Ar/CF4/iso-C4H10 (95:3:2)

25 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-26
SLIDE 26

Spatial resolution

26

  • Measured drift velocity (Edrift = 230 V/cm),

7.56 ± 0.02 cm/µs

  • Magboltz: 7.548 ± 0.003 cm/µs

for Ar/CF4/iso-C4H10/H2O (95:3:2:100ppm)

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-27
SLIDE 27

New Compact T2K electronics

  • New resistive anode with improved grounding
  • Compact T2K electronics directly mounted on the backside of the MICROMEGAS

module

27

Summer 2012: 6 modules mounted on LPTPC

2012/11/13

  • G. De Lentdecker - KEK seminar

Remove protection Remove the packaging Transfer power regulation and ADC to the mezzanine module card.

slide-28
SLIDE 28

First results

  • Also improvements in offline track reconstruction:
  • Uses now KalmanFilter (K. Fujii) in MarlinTPC (ILCSOFT) framework

28

  • nline
  • ffline

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-29
SLIDE 29

Study of the cracks

29

  • Having now almost the full LPTPC endplate equipped with

modules allow to study the features of the Large TPC prototype

Study the hit reconstruction efficiency at or near the crack: take data with beam, moving by steps of 2mm

Beam direction Outside crack In crack Upper crack Lower crack Pad-row number (3x24=72) Hits with ADC>150, event w/. 1 track

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-30
SLIDE 30

Scan around the cracks

30

Number of hits per track vs x

àEffect of cracks is felt in an area ~1cm around.

Number of hits per track vs x

More results to come soon (spatial resolution, etc.)

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-31
SLIDE 31

Field distortions

2012/11/13

  • G. De Lentdecker - KEK seminar

31

Residuals (mm) Pad row After software correction Need to control E field at the scale of O(100) µm

MMegas GEM

slide-32
SLIDE 32

Digital TPC with Gridpix

  • In Gridpix, the MICROMEGAS is built on the Timepix chip by a

wafer post-process providing the ideal alignment between the grid holes and the CMOS Timepix pixels.

  • Cell pitch: 55-60 µm
  • Si layer to protect
  • Gain 5k-10k

32 2012/11/13

  • G. De Lentdecker - KEK seminar

2 beta’s from 90 Sr in 0.2 T

slide-33
SLIDE 33

GridPix tested with LPTPC

  • The octopuce protoype, 8

GridPix’s on daughter board

  • Powerful tool to perform

fundamental studies for gaseous detectors:

  • Ionisation
  • Fano factor measurements
  • Avalanche fluctuations

33 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-34
SLIDE 34

GridPix tested with LPTPC

34

  • He/Iso 80/20
  • Vmesh = 400V
  • Time mode

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-35
SLIDE 35

Ion back flow

  • Simulation of positive ion back flow
  • Estimate the effect of the primary ions and the secondary ions

(from amplification) on the drifting electron trajectory with and without a gating device

  • Ion feedback ratio ~10-3

(measured with both devices)

  • Gain ~1000
  • Gate device probably needed
  • Wire gate
  • Very thin GEM gate

35 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-36
SLIDE 36

Future developments

  • Some already shown (Endplate, SALTRO)
  • Towards final electronics: GdSP
  • gaseous detector signal processing (or Go digital as Soon as Possible)
  • CERN-based collaboration lead by Paul Aspell, including Saclay: F.

Guilloux and E. Delagnes, continuing SALTRO evolution.

  • Common development for CMS GEM µ-chambers and LC TPC. Recently

considering ALICE upgrade (GEM TPC and µ chambers).

  • Main developments : 130 nm technology, 64 or 128 channels, low noise

and ultra-low consumption, many power domains to ease power switching

  • First Si test to be submitted in February 2013 (AIDA)
  • Goals for the FE: for 10 pF detector capacitance and 100 ns peaking time

ENC<900 e- and power < 1mW/ch (SALTRO~10mW/ch)

36

! !

2012/11/13

  • G. De Lentdecker - KEK seminar

Parameter VFAT2 (IBM 0.25) SALTRO (IBM 0.13) VFAT3 / GdSP (IBM 0.13) Linear range +- 12fC 150fC Max 200fC Input capacitance (pF) 20 0-20 5 – 10 – 30 – 60 Noise ~500e- 40-60e-/pF @ 25ns ~ 650e- 15e-/pF @ 120ns < SAltro /VFAT

slide-37
SLIDE 37

Conclusions

  • The LCTPC Collaboration has already achieved many

important milestones

  • Successfully tested the LPTPC with several MPGD devices and

readout electronics

  • The pad-readout MPGD TPCs satisfy the spatial resolution for

500 GeV ILC

  • Main electronics integration issues are now being adressed
  • Still a lo to do
  • Continue to reduce the material budget on the TPC endplate

(electronics mounting and cooling)

  • Come up with a design of gate device
  • Address engineering issues for stable and reliable operation

(distortions)

37 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-38
SLIDE 38

THANK YOU AND ESPECIALLY TO:

  • K. FUJII, T. MATSUDA,
  • D. ATTIE, P. COLAS

AND THE LCTPC COLLABORATION

38 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-39
SLIDE 39

Back-up slides

slide-40
SLIDE 40

Electron Linear Collider Projects

  • Compact Linear Collider:
  • ECM=1.0 - 3.0 TeV
  • L~1035 cm-2 s-1
  • 2-Beam accelerator scheme
  • Normal (warm) conducting accelerating cavities

– High accelerating gradients (100MV/m) and frequency (12 GHz)

  • 0,7 ns bunch spacing !
  • Expect CDR end of 2010, construction > 2017

40 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-41
SLIDE 41

41 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-42
SLIDE 42

42 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-43
SLIDE 43

Push-Pull options

43 43

detector B

may be accessible during run

accessible during run

Platform for electronic and services (~10*8*8m). Shielded (~0.5m of concrete) from five

  • sides. Moves with detector. Also

provide vibration isolation.

The concept is evolving and details being worked out detector A

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-44
SLIDE 44

From outside to inside

  • The muon system:
  • Instrumented iron return yoke
  • A few ns time resolution (Note: no trigger)
  • mm – cm spatial resolution range
  • RPCs with 3-4 cm wide strips

44 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-45
SLIDE 45

Imaging/Tracking calorimeter

  • The HCAL
  • High granularity Sampling calorimeter
  • Steel as absorber
  • Scintillator tiles (analog) VS. gaseous device (digital)
  • 3 x 3 cm2 VS. 1 x 1 cm2
  • SiPM VS. GlassRPC

45 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-46
SLIDE 46

From outside to inside II

  • The ECAL
  • High granularity, particle separation, compactness
  • => Sampling calorimeter (~30 layers)
  • Silicon diodes or scintillator separated by tungstene
  • Lateral cell size : 5 x 5 mm2
  • 100 Million of channels
  • FE electronics embedded in detection layer

46 Ø Small dead zone area Ø All modules are identical (Tungsten wrapped by Cfi) Ø The detector slabs would be tested before assembling 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-47
SLIDE 47

Pixel and Si detector

  • Main issue is the Material Budget !
  • Vertex detector
  • 3 double or 5 single pixel layers 15 < r < 60 mm
  • Should provide a point resolution ~ 3µm
  • Should intercept tracks with theta such that |cosθ| < 0.97
  • Size : 10x10 – 30x30 um2
  • Si Tracking detector
  • Around the TPC
  • Silicon Internal Tracker (SIT)
  • Silicon External Tracker (SET)
  • Forward Tracking Detector (FTD)
  • Endcap Tracking Detector (ETD)
  • Improve time and spatial resolution
  • Provide ECAL entry point

47 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-48
SLIDE 48

2012/11/13

  • G. De Lentdecker - KEK seminar

48

E B

slide-49
SLIDE 49

Space-frame endplate

2012/11/13

  • G. De Lentdecker - KEK seminar

49

calculated measured mass material deflection stress deflection kg %X0 µm MPa µm (100 N) (yield: 241) (100 N) LP1 18.87 16.9 29 1.5 33 LP2 Space-Frame 8.38 7.5 23 4.2 27

(strut or equivalent plate)

Lightened 8.93 8.0 68 3.2 Al-C hybrid Al 7.35 7.2 (68-168) (3.2-4.8)

(channeled plus fiber) C 1.29

Channeled Al 7.35 6.5 168 4.8

slide-50
SLIDE 50

Resistive anodes:

  • In TPC, the physics limit for the resolution comes from

transverse diffusion

Neff = effective no. of electrons contributing to position determination.

  • For best resolution, choose gas with smallest diffusion
  • BUT, with MPGD-TPC resolution is limited by pad width w.

The resolution gets worse for wide pads (~mm) in absence

  • f diffusion.

50

! x

2 " DTr 2 # z

Neff ! x

2 " w2

12 as z " 0 Solution: Resistive anodes

Resistive foil Glue pads

PCB

mesh

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-51
SLIDE 51

Resistive anodes

51

! 0

2 + CD 2

Ne z

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-52
SLIDE 52

DAQ

  • Triggers provided by scintillators (beam/cosmics)

52

Brussels contributions

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-53
SLIDE 53

Carbon Loaded Kapton VS. Resistive ink Carbon Loaded Kapton Resistive Ink

53 Γ = 7 mm δ = 10 mm Γ = 11 mm δ = 13 mm

à σz=5cm = 68 µm à σz=5cm = 130 µm !

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-54
SLIDE 54

54

MICROMEGAS + Silicon modules

  • Last november, the Vienna group installed Si modules around

the TPC

  • DAQ synchronisation based on Brussels DAQ board.

16/12/2009

IIHE, Internal seminar

54 2012/11/13

  • G. De Lentdecker - KEK seminar
slide-55
SLIDE 55

Double GEM structure

55

Optional: gating GEM

  • ALTRO (ALICE) Electronics + new PCA16 preamp. (tunable gain,
  • peak. and decay time, polarity,…), noise ~ 314 electrons

5152 pads of 1.2 x 5.4 mm2 (28 staggered rows)

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-56
SLIDE 56

56

3-GEM Structure & TimePix

Readout: 2 quadboards each with 4 TimePix chips of 256x256 ch (55µmx55µm)

3-GEM + CMOS pixel readout

14 mm

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-57
SLIDE 57

57

3-GEM Structure & TimePix

Largest amount of readout channels

  • n one anode for a TPC so far: # ch 500 k

10 cm T2K-Gas 40 cm T2K-Gas 50 cm T2K-Gas

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-58
SLIDE 58

2012/11/13

  • G. De Lentdecker - KEK seminar

58

! !

!""#$%&'($)*'+,*-./'!0+ 1$-'*/-)'2"%342)$%&',#-)/.

5*/67-#' 5*/67-#' 2"%)-2). 2"%)-2). 589',#-)/. +8!0+',$,/.

slide-59
SLIDE 59

59

Laser Calibration Setup

=> pattern seen with Micromegas Photoelectrons produced at cathode

  • UV light pulses sent via

fibres to top and bottom

  • f TPC endplate
  • Light distribution constant
  • ver central module
  • Position of reconstructed

hits to calculate distortions, diffusion, drift velocity…

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-60
SLIDE 60

60

TPC Performance

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-61
SLIDE 61

61

LP-TPC Endplate

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-62
SLIDE 62

B field

62

30 cm

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-63
SLIDE 63

63

Readout Electronics: AFTER

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-64
SLIDE 64

64

Jet Energy Resolution

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-65
SLIDE 65

65

Particle Flow

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-66
SLIDE 66

66

PF Calorimetry

2012/11/13

  • G. De Lentdecker - KEK seminar
slide-67
SLIDE 67

67

PF Algorithm

2012/11/13

  • G. De Lentdecker - KEK seminar
