SLIDE 1
Phase Two to include:
- Ground grid
Lake Trafford Substation Construction Phase Two Phase Two to - - PowerPoint PPT Presentation
Lake Trafford Substation Construction Phase Two Phase Two to - - PowerPoint PPT Presentation
Lake Trafford Substation Construction Phase Two Phase Two to include: Ground grid Ground Grid 12,500 of 4/0 copper 515 ground rods 1,407 exothermic welds Phase Two to include: Ground grid Cabling Cabling 272
SLIDE 2
SLIDE 3
Ground Grid
- 12,500’ of 4/0 copper
- 515 ground rods
- 1,407 exothermic welds
SLIDE 4
Phase Two to include:
- Ground grid
- Cabling
SLIDE 5
Cabling
- 272’ of Trenwa
- 3,400’ of 2” conduit
- Over 21,000’ control
cable
SLIDE 6
Phase Two to include:
- Ground grid
- Cabling
- Concrete
SLIDE 7
Caissons and Pads
- 43 caissons
- 714 cu. yds. of
concrete
- 7 pads
- 45 cu. yds. of
concrete
SLIDE 8
Phase Two to include:
- Ground grid
- Cabling
- Concrete
- High-side breakers and bus
SLIDE 9
138kv Breakers and Bus
- 4 - 138kv breakers
- 7 - 138kv disconnects
- 580’ of 4” Al bus
- 14 bus-support structures
SLIDE 10
Phase Two to include:
- Ground grid
- Cabling
- Concrete
- High-side breakers and bus
- 138kv capacitor bank
SLIDE 11
Capacitor Bank
SLIDE 12
Bid Results
PowerTown Line Construction Tampa, FL $309,478.69 McLaren Construction Company West Palm Beach, FL
- Elite Construction of Ocala
Ocala, FL
- Aubrey Silvey
Carrollton, GA
- Kent Power
Kent, MI
- Service Electric Company
Chattanooga, TN
SLIDE 13
PowerTown – LCEC Projects
- Neutral grounding reactor (NGR) foundations – 2014
- Carnestown circuit addition – 2013
- North Trail below grade – 2013
- Carnestown transformer changeout – 2011
- Del Prado expansion – 2010
SLIDE 14
Action Requested
We are requesting a motion to authorize the CEO to sign a contract with PowerTown Line Construction, LLC, for $309,478.69.
