Heraklion 2019 Conference Heraklion - 26-29 June 2019 Waste-To-Energy with carbon capture via Molten Carbonate Fuel Cells Session XVII: Waste-to-Energy, 28 June 2019 S. Consonni a,b , F . Vigan a,b , M. Spinelli a L. Mastropasqua b , S.


slide-1
SLIDE 1

Heraklion 2019 Conference

Heraklion - 26-29 June 2019

Waste-To-Energy with carbon capture via Molten Carbonate Fuel Cells

Session XVII: Waste-to-Energy, 28 June 2019

  • S. Consonnia,b, F

. Viganòa,b, M. Spinellia

  • L. Mastropasquab, S. Campanarib

a LEAP s.c.ar.l., Piacenza b Department of Energy, Politecnico di Milano

slide-2
SLIDE 2
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Motivation

Terminology: Waste- To-Energy (WTE) ↔ Energy from Waste (EfW)

1) Energy recovery is an essential ingredient of sustainable waste management 2) EfW with grate combustors and steam Rankine cycle dominates the production of electricity and heat from waste 3) Net Life-Cycle fossil CO2 emissions from EfW plants are low – even negative in several instances - but the goals set by the Paris agreement call for further efgorts 4) Reducing direct CO2 emissions from EfW plants can further improve their environmental compatibility and improve their acceptance by the public opinion 5) Post-combustion CO2 capture appears the most suitable technology to reduce direct CO2 emissions from EfW plants 6) This work aims at assessing the performances achievable by post-combustion capture via Molten Carbonate Fuel Cells (MCFC)

2

slide-3
SLIDE 3
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

EfW plant

3

slide-4
SLIDE 4
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

EfW plant

4

Nominal thermal capacity, MWLHV 200.0

  • No. of parallel lines

3 Design LHV, MJ/kg 10.34* Waste throughput, t/h 69.6 Treatment capacity (@ 8,000 h/y), kt/y 557.0 Steam pressure, bar(a) 50.0 Steam temperature, °C 440 Nominal steam production, t/h 233.9 Nominal condensing pressure, bar(a) 0.05 Nominal gross power, MWE 63.0 Nominal net power, MWE 56.1 “Only electricity” mode Gross el. efg., %LHV 31.5 Net el. efg., %LHV 28.1 Estimated R1 index 0.75 Expected emission levels* CO, mg/mN

3

5.0 SO2, mg/mN

3

0.5 NOX, mg/mN

3

35.0 HCl, mg/mN

3

2.0 HF, mg/mN

3

0.1 PM, mg/mN

3

0.3

* Reference waste taken from Consonni & Viganò, WM 2011. * Dry gas @ 11% O2 content

  • Grate combustor with integrated boiler.
  • Dry Air Pollution Control (APC) system with use of NaHCO3.
  • Low temperature (~180 °C) “tail end” SCR with NH3 solution.
slide-5
SLIDE 5
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Molten Carbonate Fuel Cell

5

ELECTROLYTE

CO2+O2 input to cathode

(e.g. fmue gases)

ANODE (-) CATHODE (+)

CO2-lean stream Fuel to anode CO2 + H2O + unreacted fuel (CO + H2)

T emperature range: 600-650°C

  • Steam reforming
  • Water gas

shift

  • Overall REDOX

LOA D Overall exothermic

(in this application)

slide-6
SLIDE 6
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

↑ High effjciency (>50% LHV) ↑ Suitable for CCS applications in power and industrial plants ↑ Operating temp. (650°C) favors internal reforming  cheap catalyst ↑ Internal reforming increases fuel fmexibility (variety of hydrocarbons) ↑ Low NOX (electro-reduction) and SO2/H2S (must be removed upstream)

Basic features of the MCFC

6

In a MCFC carbonate ions (CO3

=) permeate through a Li-K solid

matrix electrolyte supported by porous aluminate (LiAlO2) for stability and strength increase. H2 is fed to the anode (Ni), O2 and CO2 to the cathode (NiO) ↓ Low materials durability (corrosion) and low tolerance to contaminants ↓ Costs and durability

slide-7
SLIDE 7
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Commercial MCFC

7

Carbon input Carbon

  • utput

CO2 loop

Plant confjguration of system

  • fgered by Fuel Cell Energy (FCE)
slide-8
SLIDE 8
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

From commercial MCFC to carbon capture

8 *Flows not to scale

slide-9
SLIDE 9
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

9

From commercial MCFC to carbon capture

*Flows not to scale Plant generating CO2 CO2 Processing Unit (CPU)

slide-10
SLIDE 10
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

10

CO2 Capture by MCFCs

slide-11
SLIDE 11
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Plant confjguration

11

EfW Plant EfW Plant

CO2 Processing Unit (CPU) CO2 Processing Unit (CPU)

Natural gas & steam Unconverted fuel CO2 to storage CO2-poor gases CO2-rich gases Air Waste EfW power

  • utput

CPU Power input EfW fmue gases MCFC power

  • utput

Flue gas pre-heating

CO2

MCFC

slide-12
SLIDE 12
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Flue gas preheating ahead of MCFC

12

___Option 2 - COMPACT HEAT EXCHANGER____________________________________

Features:  Stamped and folded metal foil  Chessboard arrangement - Square matrix  Counter-fmow confjguration INDUSTRIAL REFERENCE: Heat exchanger type like Solar Mercury 50 GT’s recuperator

___Option 1 – LJUNGSTROM REGENERATOR_____________________________________ Hot fmow Cold fmow L=Length D

e

D

i

slide-13
SLIDE 13
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

CO2 Processing Unit (CPU)

13 T=-29°C p=25 bar T=30°C p=110 bar xCO2 = 98-99% T=-50°C p=20 bar T=30°C p=26 bar xCO2 = 80-85% T=75°C p=1 bar xCO2 = 40-45%

slide-14
SLIDE 14
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Assumptions

14

MCFC operating conditions Current density 1500 A/m2 Voltage 0.65-0.72 V Fuel utilization factor 75% Steam to carbon ratio 2 Inlet temperature (pre-reformer layer) 450°C Inlet temperature (anode) 600°C Inlet temperature (cathode) 575°C Outlet temperature (anode and cathode) 645°C Pressure losses on anode / cathode sides 3 kPa /2kPa Heat losses (% input thermal power) 1% DC/AC electrical efficiency 97% Minimum CO2 molar fraction at cathode outlet 1% Minimum O2 molar fraction at cathode outlet [%] 2.5% EfW Effluents properties Flow rate Temperature Pressure Composition, %vol kg/s °C bar Ar CO2 O2 N2 H2O 137.9 61.3 1.01 0.8 8.86 7 67.1 16.24 EfW Operating conditions Primary energy input, MWLHV 200 Net electric power, MWe 54.9

slide-15
SLIDE 15
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

RESULTS

  • Ref. EfW

EfW+1 MCFC EfW+2 MCFC EfW gross electric power*, MW 63.0 64.1 64.1 EfW net electric power*, MW 56.1 54.9 54.9 MCFC gross electric power, MW

  • 47

50.2 CO2 capture and other auxiliary consumptions, MW

  • 14.4
  • 12.8

Overall net electric power, MW 56.1 87.5 92.3 Natural gas consumption, MWLHV

  • 79.5

79.4 1st law energy efficiency, %LHV 28.1 31.3 33.0 NG marginal efficiency, %LHV

  • 39.5

47.1 Biogenic CO2 released by waste combustion+, kg/s 9.7 9.7 9.7 Captured CO2, kg/s

  • 21.6

21.7 Emitted CO2, kg/s 19.1 1.90 1.9 Fossil CO2 emission, kg/s 9.4

  • 7.8
  • 7.8

Avoided fossil CO2 emission§, kg/s

  • 10.8

11.2 Primary energy consumption for CO2 capture§, MWLHV

  • 27.2

19.1 SPECCA§, MJLHV/kgCO2

  • 2.52

1.70

* Including extra power production due to heat recovery from additional flue gas cooling and extra consumption due to the increased head of the ID fan.

+ By assuming 51% of carbon in the waste is biogenic. § By assuming reference efficiency for electricity from NG of 60%LHV.

Results

15

slide-16
SLIDE 16
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Carbon balance – single stack

16

slide-17
SLIDE 17
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Conclusions / perspectives

17

1) The use of MCFCs as post-combustion capture technology for EfW plants can yield interesting outcomes in terms of both carbon capture and performances 2) For a large scale EfW plant, fossil CO2 emissions become negative, making the EfW+MCFC plant a CARBON SINK rather than a carbon emitter 3) For the case study considered here - EfW with combustion power 200 MWLHV - net power production increases by 55-65%, at the expense of a natural gas consumption for the MCFC of about 80 MWLHV, i.e. about 40% of the energy input from waste 4) Crucial issue to be verifjed for technical feasibility is the capability to achieve EfW fmue gas purity compatible with the requirements of the fuel cell 5) Additional crucial issue to be verifjed for industrial feasibility is capital and operating costs

slide-18
SLIDE 18
  • S. Consonni – WTE with carbon capture via MCFC - Heraklion, 28 June 2019

Thank you

Thank you for your attention !

18
