Keynote Address Matthew Hussey

Associate Chief of the Office of Engineering and Technology Federal Communications Commission

What’s Going on at the FCC

Matthew Hussey, Associate Chief

Office of Engineering and Technology

Note: The views expressed in this presentation are those of the author and may not necessarily represent the views of the Federal Communications Commission

Source: Cisco VNI Mobile, 2017

Mobile Continues to Skyrocket

More Devices & Data = More Spectrum & Infrastructure

Source: http://blogs.cisco.com/wireless/enterprise-networks-and-the-drive-for-ipv6

Licensed Unlicensed

4

Pace of Advancing Technology

Strategy of Making More Spectrum Available

• Driver: Continued growth of mobile & other services
• Key Milestones:
• National Broadband Plan
• Middle Class Tax Relief

& Jobs Creation Act of 2012

• Presidential Memos
• NTIA Ten Year Plan
• PCAST Report
• Department of Defense Spectrum Strategy
• Strategy:
• Consider potential reallocations, but becoming more difficult
• Develop advanced spectrum sharing techniques
• Continue to advance efficient use of the spectrum (flexibility)

Broadcast TV Incentive Auction

How it Works

37 700 MHz UL 26 25 27 24 23 22 21 30 29 28 27 33 32 31 35 34

G F E D C G F E D C B A B A

36 11 7 3 84

• Reverse Auction
• Ended January 13, 2017 – Stage 4; 84 MHz clearing target
• Broadcaster clearing cost - ~ $10 Billion
• Broadcaster relocation funds – $1.75 Billion
• ~ $12 Billion needed to cover costs
• Forward Auction
• Concluded February 10, 2017
• $19.6 Billion in proceeds
• Assignment round began March 6, 2017
• Auction closing and channel reassignment PN will begin 39 month transition period

11 Megahertz “Duplex Gap” 6 megahertz WSD Unlicensed Microphones Uplink 1 MHz buffer Downlink Licensed Mics Paired Spectrum Blocks Repurposed

TV Study: Software Used to predict Coverage & Population Served Constraints on Repacking Stations ISIX: Controlling Interservice Interference Repacking Optimization Can’t assign same channel – too close OK to assign same channel – far apart Reorganize remaining stations in most efficient way that recovers the most spectrum at the least cost - - akin to repacking the closet

Technical Pillars of the Incentive Auction

Adopted final rules in 2012

• Fixed & Personal Portable devices
• Rely on geolocation database

Fifteen devices approved

• All fixed devices, designed for professional installation - location entered manually

Five databases approved IEEE 802.11af standard approved - Dec. 2013 Strong international interest

• Pilots in Philippines, South Africa, Namibia, Botswana and many others

Rules updated August 2015

• Implement Incentive Auction
• More flexible operation

NPRM adopted December 2015

• Require geo-location capability in fixed devices
• Validation checks for databases

Carlson Adaptrum Spectrum Bridge iconectiv Wireless Cameras Cover Park in Wilmington NC Meld

8

Unlicensed White Space Devices

The 5 GHz Band & Unlicensed Use

Wi-Fi Alliance: 7 for ’17 predictions:

• 1. Wi-Fi simplifies wireless networking.
• 2. High-performance Wi-Fi products with new

features and technologies will hit the shelves.

• 3. Wi-Fi Location will gain momentum.
• 4. Wi-Fi is a platform for IoT innovation.
• 5. Wi-Fi improves the AR/VR experience for the

masses.

• 6. Wi-Fi cements its place as a critical component

in communications infrastructure.

• 7. Cities and stadiums get major Wi-Fi upgrades.

More than 3 billion Wi-Fi device shipments expected in 2017 and more than 8 billion devices currently in use around the world.

Video Streaming Around Home

Wi-Fi Applications

IoT

And many, many more . . .

Offloading

5 GHz Background

• Middle Class Tax Relief & Jobs Creation Act of 2012:
• NTIA to study two bands at 5 GHz for unlicensed
• 5350 – 5470 MHz: allocated for federal (radars) & earth exploration satellites
• 5850 – 5925 MHz: allocated for non-federal use (Intelligent Transportation Services)
• FCC to initiate rule making
• NTIA study (Jan. 2013): More study needed
• FCC initiates rule making (Feb. 2013)
• IEEE Tiger Team Studies 5.9 GHz sharing (August 2013 –

March 2015):

• Two lead proposals considered
• Unable to achieve consensus on 5.9 GHz sharing

Expanding Unlicensed Spectrum Use in 5 GHz

• Much of the 5 GHz band is shared by unlicensed on a non-interference basis
• Some of this spectrum relies on dynamic frequency selection to avoid interfere with radars
• FCC Notice of Proposed Rule Making
• Proposed access to U-NII-2B and U-NII-4 for unlicensed
• Invited comment on possible sharing techniques
• No change to existing spectrum allocations - - existing allocations/services are protected against harmful interference

Previous Rules

A l l

• c

a t i

• n

s U n l i c e n s e d

Now 250 mW

IEEE Tiger Team Options

Dedicated Short Range Communications (DSRC) Channel Plan

• Option 1 Detect and avoid (Cisco): Unlicensed devices monitor the

10 megahertz-wide DSRC channels and vacate entire band if signal detected

• Option 2 Rechannelization (Qualcomm) : safety channels to top of the

band, widen lower channels & share only lower channels with Wi-Fi

Recent FCC Action on 5 GHz

• FCC Public Notice (June 2016)
• Refresh the record
• Invite comments on two options
• Invitation to submit prototype devices
• Outlined Three Phase Test Plan with DOT & NTIA
• Phase I - FCC Lab
• Phase II - DOT Basic Field Tests
• Phase III - Real-world Testing
• Provided draft test plan
• FCC has received several prototypes and is currently

testing them at the FCC lab in Columbia, MD

• Currently analyzing data and performing further test

3550 MHz 3700 MHz 3650

Navy Ship Radars Non-Federal FSS ES

Fixed Satellite Service Federal spectrum allocations

Federal Ground-Based Radar

3600

Citizens Broadband Radio Service

Spectrum Access System (SAS) manages Access to spectrum Conditional approval to7 SAS Administrators 6 ESC proposals - pending Multi-stakeholder group through Winnforum developing standards

Incumbent Access Priority Access General Authorized Access

Spectrum sharing across three tiers

3.5 GHz: Citizens Broadband Radio Service

• Core Principles of FCC Approach
• Identify substantial spectrum in MMW bands for new services
• Protect incumbent services against interference
• Flexible use: Enable market to determine highest valued use
• Overlay auctions where no existing assignments
• Provide spectrum for both licensed and unlicensed use
• Added 10.85 GHz of for mobile service
• Licensed: (3.85GHz): 27.5-28.35 GHz; 38.6-40 GHz; 37-38.6 GHz
• Unlicensed: (7GHz): 64-71 GHz
• Adopted licensing, operating & technical rules
• Considering add’l 15.8 GHz + above 95 GHz

– 24.25-24.45 GHz; 24.75-25.25 GHz; 31.8-33.4 GHz; 42-42.5 GHz; 47.2-50.2 GHz; 71-76 GHz; 81-86 GHz; bands above 95 GHz

Spectrum Frontiers & 5G

• Components of 5G are being identified and under discussion/development
• Throughput (>50x of 4G, or 5-10GBps) and latency (<1msec air latency) are often discussed
• The overall network architecture and end-user experience are being developed

What is 5G?

Overview of New Bands

28 GHz 37 GHz 39 GHz 64-71 GHz Frequency 27.5-28.35 GHz 37-38.6 GHz 38.6-40 GHz 64-71 GHz Bandwidth 850 MHz 1600 MHz 1400 MHz 7000 MHz Terrestrial Allocation Licensed for fixed

• perations, with about 75%
• f the population covered

by existing licenses; remaining licenses in inventory Yes (no current use) Licensed for fixed

• perations, with about

50% of the population covered by existing licenses; the remaining licenses are in inventory. Yes (no current use) Federal Allocation No Radio Astronomy / Space Research in 37-38 GHz @ 3 sites; Federal Fixed/Mobile in 37-38.6 GHz @ 14 locations Fixed Satellite Service / Mobile Satellite Service in 39.5-40 (military use

• nly)

Earth Exploration Satellite Fixed/Mobile/Satellite Satellite Allocation Yes Yes (no current use) Yes (no current use) Yes (no current use) Licensing Scheme Licensed Licensed Licensed Unlicensed

Factors to Enable Sharing

• High amount of spectrum

provides flexibility to avoid interference

• Relatively high path loss
• Adaptive antenna technology

(steered beams)

• Heterogeneous networks

Full Dimensional MIMO 5G Deployment Scenario

Recent Activity and Next Steps

• Strong support for FCC order
• Suppliers have developed equipment
• Carriers are conducting tests & planning trials
• Consider comments on Further NPRM
• Experimental licensing: Greater Flexibility
• Advanced Wireless Research Initiative:
• $400 million initiative led by the National Science Foundation (NSF) to

enable deployment and use of four city-scale testing platforms for advanced wireless research over next decade

• For details see https://nsf.gov/cise/advancedwireless/
