IWL IN IA LTD

WHAT IS SEALANTS

WHY SEALANTS

Terminology – The Basics

BASE (Part –A) (High quality Polysulphide sealant) + Accelerator (Part – B) (Curing agent) ↓ IWL LIQUISEAL POLYSULPHIDE SEALANT (Flexible rubber like material)

Terminology – The Basics

Excellent adhesion ↓ Concrete, masonry, wood, glass, aluminum etc..,with the use of LIQUISEAL PS Primer. Capable of withstanding repeated extension, compression & Cyclic movements without loss of adhesion Resists deterioration by weathering, sunlight, ozone, water, salt,

• ils and fuels.

Mixing Process

Joint design

 joint - width: depth ratio 2:1  Total movement does not exceed the 25% MAF

 Wide 5 to 50 mm Depth - 5 mm for glass & metal

• 10 mm for porous surface
• 20 mm for joints exposed to traffic

and hydrostatic pressures

 Use backup material to adjust width depth ratio

 Masking tape on both side – uniform appearance

IWL - PRODUCTS

1.Liquiseal PS PRIMER – Adhesion promoters 2.LIQUISEAL PS PG - POURING GRADE ( Self leveling) 3.LIQUISEAL PS GG - GUN GRADE ( Non sag)

Liquiseal PS Primers

• Adhesion promoters
• Low viscous liquid
• Solvent with silane combination

Typical Properties

Viscosity (ford cup) : 10 – 12 seconds Specific gravity : 0.7 5– 0.85 Recommended coats : 02 Time interval : 15 minutes (minimum) Coverage : 6 – 7 sq.meter /1 liter

LIQUISEAL PS PG – BS 5212

• Two part system : (Part A &Part B)
• Ratio 92:08 (by weight)
• Color

Part A - off white Part B – brown

• Sp gravity 1.65 ± 0.02
• Pot life : 60 to 120 minutes (adjustable)
• Pourable sealants are low viscous
• Self leveling
• Mainly used for horizontal joint

Typical Properties

Tensile strength Kg/cm² : minimum 03. Elongation % : minimum 600. Shore A – Hardness : 08 – 14 Bonding with………… 1.Concrete to Concrete 2.Glass to Glass 3.Aluminium to Aluminium…Etc

PSPG Application Images

LIQUISEAL PS GG - BS 4254

• Two part system : (Part A &Part B)
• Ratio 92:08 (by weight)
• Color

Part A - off white Part B – brown

• Sp gravity 1.65 ± 0.1 (30°c)
• Pot life : 90 to 180 minutes (Adjustable)
• Gun grade sealants are high viscous
• Non sag nature convenient for both horizontal vertical joint

Typical Properties

Tensile strength Kg/cm² : minimum 05. Elongation % : minimum 500. Shore A – Hardness : 15 – 22 Bonding with 1.Concrete to Concrete 2.Glass to Glass 3.Aluminium to Aluminium…Etc

PS GG Application Images

Vertical Applications

Coverage

Calculate the sealant weight (in kgs) for a joint of particular length (in meters), The following formula can be used. Weight in kg = SG × W × D × L 1000 SG = Specific gravity of the sealant W = Width of joint (mm) D = Depth of joint (mm) L = Length of the joint (metre)

Where we Apply

 High – rise and low –rise commercial buildings  Window perimeters, Roofing terminations, Expansion joints and butt-Terminations.  Internal and external wall claddings ,Plaza decks  Water retaining structures – reservoirs ,dams ,canals ,etc…..  Airport pavement runways  Bridge & Highway joints  Commercial parking lots and flat work

COMPARISION

PARAMETERS POLYSULPHIDE POLYURETHANE SILICONE Fuel resistance

EXCELLENT GOOD POOR

Cost effect

ECONOMICAL HIGH HIGH

Workable Time

ADJUSTABLE SHORT SHORT

Moisture effect

NO YES YES

Shelf life

LONG SHORT SHORT

Packing & Productivity

PS PG & GG Packed in 4 Kg Tin Container & 4×4 corrugated box

Part A – 3.680 Kgs Part B - 0.320 Kgs Liquiseal PS primer 1KG /4 KG into 1litre/4Litre cans Shelf life - 12 months at 25°c RH 50% We have stocks up to 5 tones …….. 3 – 7days Priority

STANDARDS – PS PG & GG

• PS PG - BS 5212 : 1990
• PS GG – BS 4254 : 1983
• MAF ± 25 % As per – IRC 57

Certification by IRMRA –Thane

• PS PG & PSGG - IS 12118 − Certified by BIS
