Issues, Trends, and Challenges

EPRI Workshop – July 8, 2008 Mike Hightower Sandia National Laboratories

Presentation Overview Presentation Overview

• Energy–Water Connection and Interdependencies
• Energy-Water Report to Congress Highlights
• Energy–Water Regional Needs Workshops

– Regional and national issues and challenges – Summary of science and technology needs identified

• Potential impact of energy development and growth
• n national and regional water resources

Background info @ www.sandia.gov/energy-water

Energy and Water are … Interdependent

Water for Energy

and

Energy for Water

Energy and Water are … Interdependent

Water for Energy

and

Energy for Water

Energy and power production require water:

• Thermoelectric

cooling

• Hydropower
• Energy minerals

extraction/mining

• Fuel Production

(fossil fuels, H2 , biofuels)

• Emission control

Water production, processing, distribution, and end-use require energy:

• Pumping
• Conveyance

and Transport

• Treatment
• Use conditioning
• Surface and

Ground water

Water Withdrawal Trends by Sector Water Withdrawal Trends by Sector

[USGS, 2004]

Water Consumption by Sector Water Consumption by Sector

U.S. Freshwater Consumption, 100 Bgal/day

Livestock 3.3% Thermoelectric 3.3% Commercial 1.2% Domestic 7.1% Industrial 3.3% Mining 1.2% Irrigation 80.6%

Energy accounts for 27 percent of non-agricultural fresh water consumption

[USGS, 1998]

Growing Limitations on Fresh Surface and Ground Water Availability Growing Limitations on Fresh Surface and Ground Water Availability

• Little increase in surface water

storage capacity since 1980

• Concerns over climate impacts
• n surface water supplies
• Many major ground water

aquifers seeing reductions in water quality and yield

( Based on USGS WSP-2250 1984 and Alley 2007) (Shannon 2007)

Growing Use of Non-traditional Water Resources Growing Use of Non-traditional Water Resources

• Desal growing at 10% per year, waste water reuse at 15% per year
• Reuse not accounted for in USGS assessments
• Non-traditional water use is energy intensive

(From EPA 2004, Water Reuse 2007, Mickley 2003)

1 2 3 4 5 6 7 8 9 10

Kwh/m^3

Sea Water RO

Today The Future

Conventional Treatment Brackish RO Brackish NF

Power Requirements For Treating

(Einfeld 2007)

Most State Water Managers Expect Shortages Over The Next Decade Under Average Conditions Most State Water Managers Expect Shortages Over The Next Decade Under Average Conditions

TX CA MT AZ ID NV NM CO IL OR UT KS WY IA NE SD MN ND OK FL WI MO AL WA GA AR LA MI IN PA NY NC MS TN KY VA OH SC ME WV MI VTNH MD NJ MA CT DE RI

g

AK AK HI HI HI HI HI

shortage

Statewide Regional Local None No response or uncertain

Source: GAO 2003

Water challenges are nationwide Water challenges are nationwide

Projected Population Growth (2000-2020)

Source: Campbell (2000)

50%

%

30% 30% 40% 10% 10% 30% 15% 5% 15% 20% 35% 20%

EPRI 2003

2003 Heat Wave Impact on French Electric Power Generation 2003 Heat Wave Impact on French Electric Power Generation

• Loss of 7 to 15% of

nuclear generation capacity for 5 weeks

• Loss of 20% of hydro

generation capacity

• Large-scale load

shedding and shut off transmission to Italy

• Sharp increase of spot-

market prices: 1000 to 1500 $ / MWh for most critical days

Bort-les-Orgues Réservoir

Normal conditions in August August 27, 2003

Emerging Interest in Energy and Water Issues and Challenges Emerging Interest in Energy and Water Issues and Challenges

• State and national water and energy

groups

– 24 invited presentations in FY07 and 08 on energy and water challenges – Research and regulatory groups considering future energy and water needs

• Increased media interest

– NATURE, ECONOMIST – Technical magazines

• NSF/NRC interest in energy debate

and interdependencies research

• Growing international concerns and

challenges

– Europe, Australia, Asia, Canada

Cumberland River Basin Integrated Resources Planning Pilot Results Cumberland River Basin Integrated Resources Planning Pilot Results

" ) " ) " ) " ) " ) " ) " ) " ) " )

# #

• Integrated short-term (daily)

planning (TVA, SEPA, Corps)

• Interested in long-term

planning, but missions and activities are distinct

– Authority or incentives not aligned with energy-water efficiency

• Growing need for both water

and power

– Dam (rehabilitation and improvements) and drought impacts are major challenges to future water-energy planning

• Need better operational and

planning tools

Energy-Water Regional Needs Workshops Energy-Water Regional Needs Workshops

• Congressionally

funded and coordinated with DOE

• Coordinated by

Sandia with support from all the national laboratories

• Needs driven

research directions and solutions focus

Roadmap Regional Needs Workshops

Energy Water Roadmap Overview Energy Water Roadmap Overview

• Three regional needs assessment workshops: Nov 2005 through

mid-January 2006

– Kansas City, Baltimore, Salt Lake City – Almost 350 participants from 40 states involved – Focus on emerging user and stakeholder problems and challenges and science and technology role in effective solutions – captured high-level issues, needs, and directions

• Broad spectrum of regional, state, and local participation and

input

– Representatives from energy companies, electric utilities, water utilities, water managers, economic development groups, energy regulators, environmental groups, tribal nations, other water-use sectors

• Gaps and Technical Innovations Workshops to capture science

and technology research and development priorities

– Almost 150 researchers and technology developers involved

Better resources planning and management

• Integrated regional energy and water resource planning and decision

support tools

• Infrastructure and regulatory and policy changes for improved

energy/water efficiency

• Improved water supply and demand characterization, monitoring, and

modeling

Improved water and energy use efficiency

• Improved water efficiency in thermoelectric power generation
• Improved biofuels/biomass water use efficiency
• Reduced water intensity for emerging energy resources

Development of alternative water resources and supplies

• Oil and gas produced water treatment for use
• Energy efficiency and assessment of impaired water treatment and use

www.sandia.gov/energy-water

Summary of Major National Needs Summary of Major National Needs and Issues Identified in Regional and Issues Identified in Regional Workshops

Research and Development Program for Integrated Resources Management Research and Development Program for Integrated Resources Management

– Accelerate water resources forecasting and management – Evaluate impacts of climate variability and improve hydrological forecasting – Improve common decision support tools – Develop system analysis approaches for: Co-location of energy and water facilities, improved national transmission capabilities to support renewables, distributed generation of biofuels

Projected New Electric Power Generation Capacity through 2035 Projected New Electric Power Generation Capacity through 2035

• Coal

– 350, 400 MW steam turbine plants (140,000 MW)

• Natural Gas

– 150, 100 MW natural gas combined cycle (15,000 MW)

• Renewables

– 125, 200 MW wind or solar farms (25,000 MW)

• Nuclear

– 5, 1000 MW nuclear reactors (5,000 MW)

• Hydroelectric

– None (~40,000-60,000 MW available)

Water Use and Consumption for Electric Power Generation Water Use and Consumption for Electric Power Generation

Plant-type Cooling Process Water Use Intensity (gal/MWhe ) Steam Condensing Other Uses Withdrawal Consumption Consumption Fossil/ biomass steam turbine Open-loop 20,000–50,000 ~200-300 ~30 Closed-loop 300–600 300–480 Nuclear steam turbine Open-loop 25,000–60,000 ~400 ~30 Closed-loop 500–1,100 400–720 Natural Gas Combined- Cycle Open-loop 7,500–20,000 100 7–10 Closed-loop 230 180 Integrated Gasification Combined-Cycle Closed-loop 200 180 150 Carbon sequestration for fossil energy generation ~25% increase in water withdrawal and consumption Geothermal Steam Closed-loop 2000 1350 50 Concentrating Solar Closed-loop 750 740 10 Wind and Solar Photovoltaic N/A 1-2

Water Demands for Future Electric Power Development Water Demands for Future Electric Power Development

• Water demands could

almost triple from 1995 consumption for projected mix of plants and cooling

• Carbon emission

requirements will increase water consumption by an additional 1-2 Bgal/day

1 2 3 4 5 6 7 8 9 1995 2005 2015 2025 2035 Year Water Consumption ( billion gallons per day)

Source: NETL 2006

• Most growth in

water stressed regions

• Most new plants

expected to use evaporative cooling

Growth in Thermoelectric Growth in Thermoelectric Power Generation Power Generation

Source: NETL, 2004

Projected Thermoelectric Increases

(Capacity in 2025 vs 1995)

EMM Region 11 EMM Region 9 EMM Region 5 EMM Region 12 EMM Region 2 EMM Region 10 EMM Region 1 EMM Region 4 EMM Region 13 EMM Region 7 EMM Region 3 EMM Region 8 EMM Region 6 300 600 900 1,200 150 Miles

4

Estimated Capacity Change 1995-2025 (Gw) AEO Estimates

Legend

Major Lakes (National) regions4

Totcapchg

• 9.050000 - 0.000000

0.000001 - 11.630000 11.630001 - 26.920000 26.920001 - 44.560000 44.560001 - 133.230000 AK HI HI HI HI HI

Regional Variations in Water Laws and Nuclear Reactor Applications Regional Variations in Water Laws and Nuclear Reactor Applications

Appropriation States Riparian States Hybrid States

Alternative Cooling Issues and Challenges Alternative Cooling Issues and Challenges

• High capital cost and large

footprint

• Hot weather penalties

– Power capacity reduced during peak summer electricity demand – Grid stability concerns with many regional air cooled plants during summer months – Increased GHG emissions for most thermoelectric plants

• Wind effects reduce cooling

efficiency

• Not currently licensed for

nuclear power plants

Pilot Spray-enhanced Dry Cooling

Research Program for Electric Power Sector Research Program for Electric Power Sector

• Improve dry and hybrid

cooling system performance

• Improve ecological

performance of intake structures for hydro and

• nce-through cooling
• Improve materials and

cooling approaches compatible with use of degraded water

• Electric grid infrastructure

upgrades to improve low water use renewable technology integration

Hybrid Wet-Dry Cooling System

Water Demand/Impact of Transportation Fuels

Emerging Water Demands for Alternative Fuels Development Emerging Water Demands for Alternative Fuels Development

• Irrigation of

even small percentage of biofuel acreage will increase water consumption by an additional 3-5 Bgal/day

0.5 1 1.5 2 2.5 3 1 9 9 5 2 5 2 1 5 2 2 5 2 3 5 Year Water Consumption (billion gallons per day) Alt Fuels Biofuels Traditional Refining

Biomass and Water Use Impacts Will be Regional Biomass and Water Use Impacts Will be Regional

Oil Shale development will be regional and impact water availability and quality Oil Shale development will be regional and impact water availability and quality

• Reserves are in areas of

limited water resources

• Water needed for

retorting, steam flushing, and cooling up to 3 gallons per gallon of fuel

• Concerns over in situ

migration of retort by- products and impact on ground water quality

Research Program for Alternative Fuels Sector Research Program for Alternative Fuels Sector

• Reduce water use for

cooling in biofuels and alternative fuels production

• Reduce water use in

processing

• Develop low fresh water

use technologies such as algal biodiesel

• Assess non-traditional

water use for fuels applications

• Assess hydrologic impacts
• f large cellulose biofuels

scale-up and oil shale
