ISE 331 Fundamentals of Computer Security Authentication and Attacks

• User Authentication

Authentication process Means of authentication

• Passwords

Vulnerabilities of passwords Password Cracking Dictionary Attacks Thwarting dictionary attacks

Agenda

User Authentication

Authentication is the process of verifying an identity Authentication process (2 step)

• 1. Identification – User provides a claimed identity

to the system

• 2. Verification – System establishes the validity of

the claim

Authentication Process

Eg . Alice is user of system X and has the username Alice123 Alice’s password is a secret between Alice and the System. Identification – Alice provides Alice123 and password to logon into the system. Verification – Combination of Alice123 and password enables the system to verify that the user is indeed Alice.

Means of Authentication

There are four general means of authenticating user’s to the

• system. These can be used alone or in combination.

Something the individual knows Password, PIN, answers to prearranged questions Something the individual possesses (token) Memory card, Physical key Something the individual is (static biometrics) Fingerprints, Facial characteristics, Retinal and Iris patterns Something the individual does (dynamic biometrics) Voice, Signature, Typing Rythm

Passwords

฀ Passwords are the most widely used authentication mechanism in computers ฀ However they are prone to many vulnerabilities

• Offline Dictionary Attacks
• Specific Account Attack
• Workstation Hijacking
• Exploiting User mistakes

฀ An Attack is the act of exploiting the vulnerabilities for malicious intent

Vulnerabilities of Passwords

Dictionary Attacks

• Users have a tendency is to use passwords that are

easy to remember

• Dictionary is a collection of commonly used passwords

Example dictionary password 12345678 qwerty football 1234 baseball welcome

Vulnerabilities of Passwords

Specific Account Attack Attacker attempts to gain knowledge of a specific user and tries to guess the user’s password. Countermeasures:

• Prohibiting use of well-known user identifiers like name
• Using combination of character sets (combination of

special characters, numbers, letters)

• Regularly changing passwords

Vulnerabilities of Passwords

Workstation Hijacking Attacker waits until logged-in workstation is unattended. Countermeasures: Logout after use Automatically log out after certain period

Vulnerabilities of Passwords

Exploiting user mistakes Users may write their passwords somewhere Users may sometimes share their password with someone to allow one-time access Countermeasures: 2-step verification

• Eg. When logging into new device, google sends verification

code on your cellphone.

Vulnerabilities of Passwords

We discussed the following password vulnerabilities:

• Offline Dictionary Attacks
• Specific Account Attack
• Workstation Hijacking
• Exploiting User mistakes

Despite these vulnerabilities, passwords remain the most widely used authentication mechanism.

Password Cracking

Password cracking experiment ฀ Tried to crack a password file from a Unix system with 14000 encrypted passwords Initial Dictionary

• Combined words from various dictionaries (60,000

words)

• Transformations on the words
• Permutations of words from dictionaries
• Making some letters uppercase, reversing word,

changing o to zero Final dictionary contained 3 million words They were able to crack 25% of the passwords. Even one is enough to gain access into the system!

John-the-Ripper

• John the Ripper is a free password cracking software

tool developed in 1996.

• It can be run against various encrypted password

formats

• Such tools are used to check the strength of passwords
• Also, attackers can use them to crack passwords!

Cracking passwords is only getting easier

Increased Processing Capability A PC running a single AMD Radeon HD7920 GPU can try on an average 8.2X10^9 [order of billion] password combinations each second!

Cracking passwords is only getting easier

• The graph shows the percentage of passwords that have been recovered

as a function of the number of guesses. As can be seen, over 10% of the passwords are recovered after only 1010 guesses. After 1013 guesses, almost 40% of the passwords are recovered.

Password Cracking

• The key to password cracking:

฀ Large Dictionary File ฀ High Processing Power

• How to form a dictionary file?

Combine leaked password files

Vulnerabilities of Passwords

Dictionary Attacks

• Users tendency is to use passwords that are easy

to remember

• Dictionary is a collection of commonly used

passwords Example dictionary password 12345678 qwerty football 1234 baseball welcome

Hash values are used to store passwords

Actual password is never stored Passwords stored in the system are encrypted using some hashing algorithm (MD5, SHA-1) These are prone to dictionary attacks Attacker can easily calculate the hash values for the dictionary

Thwarting Dictionary Attack

• To reduce the possibility of dictionary

attacks, widely used password security technique is the use of hashed password and salt value.

• User selects a password. This is

combined with a fixed-length salt value (timestamp, pseudorandom number).

• The combination of password and salt

serve as an input to the hash function.

• The hashed password is then stored in

the password file, together with plaintext salt and corresponding user ID.

Thwarting Dictionary Attack

Dictionary Hash value password qwerty football 1234 welcome e10adc d8578e 37b4e2 81dc9 40be4 Password (not stored ) Salt (Stored) Hash value (Stored) qwerty football 1234 1 2 3 6dbd0 80acd 1c104

Benefits of using the salt ฀ Increases the difficulty of dictionary attacks ฀ The hash values do not match directly ฀ Now attacker needs to combine each word in the dictionary with each salt value

Thwarting Dictionary Attack

Benefits of using the salt ฀ Increases the difficulty of dictionary attacks. ฀ The hash values do not match directly ฀ Now attacker needs to combine each word in the dictionary with each salt value Slow Hash Functions ฀ MD5 crypt with 1000 iterations. ฀ The hash function is designed to be slow to make it difficult for dictionary attacks.
