slide-1
SLIDE 1

iRUI - The Rich Client and i iRUI - The Rich Client and i

Pluta Brothers Design, Inc. Joe Pluta

slide-2
SLIDE 2

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 2 joepluta@plutabrothers.com

Agenda

Who is PBD? Multi-Tiered Application Design The Tiers of a Rich Client The Messages Creating a Business Logic Library Function Creating a Client Connecting to ILE Code Advanced Concepts

slide-3
SLIDE 3

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 3 joepluta@plutabrothers.com

Who is PBD?

 In business since 1998

 Devoted to application modernization through industry standards

using IBM tooling  Products

 CPYSPLFPDF - The first commercial Java-based product for the i

family

 PSC/400 - The first tool to completely replace the display file with

servlets and JSPs  Services

 Training, mentoring, consulting  Specializing in proofs of concept

slide-4
SLIDE 4

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 4 joepluta@plutabrothers.com

Who is PBD?

 Started building open source and commercial solutions

for Java-based modernization in 1999

 Early adopter of Visual Age for Java, Eclipse, and

WDSC ("wrote the book" on the latter two)

 Started writing about EGL in 2005  Began pushing the multi-tiered EGL/RPG concept in

2006

 Advocate EGL as the primary interface to the i  Gave the first hands-on lab for EGL at an i-related

conference

slide-5
SLIDE 5

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 5 joepluta@plutabrothers.com

Who is PBD?

 Articles, sessions, labs  Wrote the business logic for the first public EGL

application, the scheduling application for the Rational Software Developer Conference

 This was a unique accomplishment, since it used the

Rich UI in conjunction with an i back end

 Working with a large i ISV to web enable their product

line using thin client EGL to access their existing back end logic

 Blog - "EGL and i" on EGL Cafe  Rich UI book coming out Real Soon Now

slide-6
SLIDE 6

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 6 joepluta@plutabrothers.com

Multi-Tiered Application Design

Multi-Tiered Applications Thick Client 5250 - The original multi-tier Thin Client (Browser Based) Multi-Tiered Rich Internet Applications

slide-7
SLIDE 7

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 7 joepluta@plutabrothers.com

Multi-Tiered Applications

User Interface Business Logic

slide-8
SLIDE 8

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 8 joepluta@plutabrothers.com

Thick Client Applications

PC Host

slide-9
SLIDE 9

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 9 joepluta@plutabrothers.com

5250-Based Applications

PC

5250 Emulation

i

Business Logic / Database

slide-10
SLIDE 10

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 10 joepluta@plutabrothers.com

Thin Client Applications (Browser-Based)

PC

Browser

i

Web Application Server Business Logic / Database

slide-11
SLIDE 11

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 11 joepluta@plutabrothers.com

Thin Client (JSF) in EGL

EGL Page Handler JSF Page EGL Library Function ILE Business Logic

slide-12
SLIDE 12

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 12 joepluta@plutabrothers.com

Multi-Tiered Rich Internet Applications

Browser

JavaScript Interpreter

i

Web Application Server DOM (Web Page) Business Logic / Database

slide-13
SLIDE 13

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 13 joepluta@plutabrothers.com

Rich Client with EGL

REST Service EGL Library Function ILE Business Logic The point here is that regardless of the interface, the business logic stays the

  • same. And with the concept of a dynamic array of records, even the EGL library

function can remain the same, leaving only the interface to change, which is the ultimate goal of a UI independent application development environment. Web Service EGL Rich UI Application

slide-14
SLIDE 14

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 14 joepluta@plutabrothers.com

Tiers of a Rich Client

Business Logic Service Layer Rich UI Tier Between these, you have messages

slide-15
SLIDE 15

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 15 joepluta@plutabrothers.com

Business Logic

Two components First is the library function within EGL

Note: not necessarily a call to ILE!

It could be a call to SQL It could be a call to another service

In the iRUI architecture, it is a call to an ILE program

The other component of the business logic for iRUI is the code in the ILE program

slide-16
SLIDE 16

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 16 joepluta@plutabrothers.com

Service Layer

Written entirely in EGL Runs in a web application server

WebSphere or Tomcat The web application server provides the infrastructure to support REST or SOAP services

The web application server can run on the i or not NOTE: The EGL portion of the business logic interface also runs in the web application server

slide-17
SLIDE 17

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 17 joepluta@plutabrothers.com

Rich UI Tier

JavaScript Runs in the browser on the end user PC Responds to events from the user (keystrokes, button clicks, mouse movement) Calls logic on the host via services (REST or SOAP)

slide-18
SLIDE 18

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 18 joepluta@plutabrothers.com

Business Logic Messaging

REST Service EGL Library Function ILE Business Logic Web Service EGL Rich UI Application SOAP/REST Flexible Records Fixed Records

slide-19
SLIDE 19

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 19 joepluta@plutabrothers.com

Fixed vs. Flexible

Not a whole lot of differences Fixed records have fixed length fields

Used when calling ILE Map directly to data structures

Flexible records do not (especially character fields)

Better between EGL layers

Used to hide the complexities of service call formatting Can be translated easily to either XML or JSON

slide-20
SLIDE 20

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 20 joepluta@plutabrothers.com

Simple vs. Composite

When talking to the host, use simple fixed records These are interchangeable with data structures When passing data between layers, however, you can use more complex data structures Let's take a look how this would map out

slide-21
SLIDE 21

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 21 joepluta@plutabrothers.com

record DSOrderHeader{} 10 OrderNumber string(10); 10 CustomerNumber decimal(6,0); 10 CustomerName string(50); 10 ShippingAddr string(50); 10 Tax money(9,2); 10 Freight money(9,2); 10 Total money(9,2); end record DSOrderLine{} 10 ItemNumber string(15); 10 Description string(30); 10 Quantity decimal(9,2); 10 Price money(9,2); 10 Extended money(11,2); end

I use the prefix DS on these records to indicate clearly that they are data structures (fixed), not flexible records.

slide-22
SLIDE 22

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 22 joepluta@plutabrothers.com

record OrderHeader{} OrderNumber string; CustomerNumber decimal(6,0); CustomerName string; ShippingAddr string; Tax money(9,2); Freight money(9,2); Total money(9,2); end record OrderLine{} ItemNumber string; Description string; Quantity decimal(9,2); Price money(9,2); Extended money(11,2); end record Order{} Header OrderHeader; Lines OrderLine[]; end

Note that in the flexible records strings have no lengths. Also, we see the concept of the Order, which is a composite.

slide-23
SLIDE 23

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 23 joepluta@plutabrothers.com

Messaging Design Points

The primary message format is flexible

Composite flexible records are used between EGL functions Fixed is used only in the lowest level of the library functions to interface with the ILE programs

The functions that call ILE are responsible for reformatting and packaging the simple records into composites

Support may be added for "simplified" flexible records

Flexible records are directly supported by the service generation pieces (SOAP and REST)

slide-24
SLIDE 24

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 24 joepluta@plutabrothers.com

Creating the Business Logic Function

Now that we've got the architecture in place, it's time to start cooking with gas First, create a dummy library function

slide-25
SLIDE 25

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 25 joepluta@plutabrothers.com

Creating the Business Logic Function

Add some logic to create a dummy record

function getOrderLocal(orderNumber string in, order Order out) returns (Error)

  • rder = new Order { Header = new OrderHeader {

OrderNumber = orderNumber, CustomerNumber = 789, CustomerName = "Pluta Brothers Design, Inc.", ShippingAddr = "542 E. Cunningham, Palatine, IL, 60074", Tax = 17.19, Freight = 14.95, Total = (17.19 + 14.95 + 4.32 + 23.95 + 9.45) }, Lines = [ new OrderLine { ItemNumber = "AS-1445", Description = "Squirt Guns", Quantity = 36, Price = .12, Extended = 4.32 }, new OrderLine { ItemNumber = "IIR-7728", Description = "Wading Pool", Quantity = 1, Price = 23.95, Extended = 23.95 }, new OrderLine { ItemNumber = "IIR-7243", Description = "Metal Ladder", Quantity = 1, Price = 9.45, Extended = 9.45 } ]}; return (null); end

slide-26
SLIDE 26

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 26 joepluta@plutabrothers.com

Thin Client is Now Enabled

From this point forward, you can start developing thin client (JSF) applications The flexible record definitions can be used to build the screen By creating a library function (and not a service), the business logic is now available to the thin client

At this point, it takes just a few minutes to throw together a JSF interface A few minutes more, you add AJAX support

slide-27
SLIDE 27

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 27 joepluta@plutabrothers.com

Create a Service

But we're here for the SOA piece, so let's get there First, create a service part

service OrderService function getOrder(orderNumber string in, order Order out) returns (Error) return ((OrderLib.getOrder(orderNumber, order))); end end

This is a proxy. Its purpose is to surface the library function as a service.

slide-28
SLIDE 28

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 28 joepluta@plutabrothers.com

And Now We Generate a Service

That's all it takes. Done.

slide-29
SLIDE 29

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 29 joepluta@plutabrothers.com

Creating the Rich UI

Rich UI is different than JSF For green screen veterans like me, it's different than just about anything we've ever done But it's not that bad; you build boxes

slide-30
SLIDE 30

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 30 joepluta@plutabrothers.com

Creating the Rich UI

Boxes are like grids - you specify the number of columns, and then put components in the box and they get laid out in the columns

Components can be simple things like labels and text fields Complex things like grids Even other boxes

You can also create custom widgets that have their

  • wn layout, and embed them
slide-31
SLIDE 31

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 31 joepluta@plutabrothers.com

The Order Widget

slide-32
SLIDE 32

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 32 joepluta@plutabrothers.com

The Order Widget

Three Boxes: Header Box Lines Box Totals Box

slide-33
SLIDE 33

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 33 joepluta@plutabrothers.com

Crafting the UI

  • rderBox Box {

columns = 1, paddingtop = 20, children = [ header, lines, totals] }; header Box = new Box { columns = 2, class = "header", children = [ new TextLabel { text = "Order Number", class = "prompt" }, new TextLabel { class = "value" }, new TextLabel { text = "Customer Number", class = "prompt" }, new TextLabel { class = "value" }, new TextLabel { text = "Customer Name", class = "prompt" }, new TextLabel { class = "value" } ] };

slide-34
SLIDE 34

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 34 joepluta@plutabrothers.com

Crafting the UI (cont'd)

lines Grid { behaviors = [ GridBehaviors.alternatingColor, formatCells ], headerBehaviors = [ GridBehaviors.grayCells ], columns = [ new GridColumn{name = "ItemNumber", width = 90, displayName = "Item Number"}, new GridColumn{name = "Description", width = 170 }, new GridColumn{name = "Quantity", width = 70 }, new GridColumn{name = "Price", width = 80 }, new GridColumn{name = "Extended", width = 80 } ], data = (new any[]) }; totals Box = new Box { columns = 2, class = "totals", children = [ new TextLabel { text = "Tax", class = "prompt", width = 430 }, new TextLabel { class = "rvalue", width=80 }, new TextLabel { text = "Shipping and Handling", class = "prompt" }, new TextLabel { class = "rvalue" }, new TextLabel { text = "Order Total", class = "prompt" }, new TextLabel { class = "rvalue" } ] };

slide-35
SLIDE 35

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 35 joepluta@plutabrothers.com

A Little Stylin'

<style type="text/css"> /* Standard overrides */ body { font-family: "Verdana"; } .prompt, .value, .rvalue { padding: 3px 10px 2px 10px } .header .prompt { text-align: left; background-color: blue; color: white; } .totals .prompt { text-align: right; } .rvalue, .right { text-align: right; } </style>

slide-36
SLIDE 36

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 36 joepluta@plutabrothers.com

And a Little Gridwork

// Handle column formatting function formatCells( grid Grid in, cell Widget in, row any in, rowNumber int in, column GridColumn in) // Set attributes based on column name case when (column.name == "Quantity") html HTML = cell.children[1]; cell.class = "EglRuiGridCell right"; tf TextField = new TextField { text = html.text, width = 50, class = "right",

  • nChange ::= updateQuantity };

tf.setAttribute("row", rowNumber); cell.children = [ tf ]; when (column.name == "Price" or column.name == "Extended") cell.class = "EglRuiGridCell right"; end end

slide-37
SLIDE 37

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 37 joepluta@plutabrothers.com

The Magic (Info)Bus

function setId(ibmSrc string in) id = ibmSrc; InfoBus.subscribe(id, listener); end function listener(eventName String in, eventData any in) ibm = eventData; case when (ibm.action == "SHOW") showOrder(ibm.data); end end function sendResponse(action string in, data any in) InfoBus.publish(ibm.src, new InfobusMessage { src = id, action = action, data = data }); end

slide-38
SLIDE 38

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 38 joepluta@plutabrothers.com

More on the Bus

MC Press Online just published an article today (Great timing, eh?) http://tinyurl.com/8jddd6 That's short for this: http://www.mcpressonline.com/programming/web- languages/rich-ui-unleashed.html

slide-39
SLIDE 39

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 39 joepluta@plutabrothers.com

Install the Service

Generate a WSDL in the EGL project Copy the WSDL into the RUI project Right-click on the WSDL and generate the client interface

slide-40
SLIDE 40

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 40 joepluta@plutabrothers.com

Invoking the Service

function showOrder(order string) InfoBus.publish(ibm.src, new InfobusMessage { action = "*STATUS", data = "Reading Order " :: order } ); OrderLib.getOrder(order, orderNotify); end // Remote functions function getOrderRemote(orderNumber string, orderNotify OrderNotify in)

  • ncb = orderNotify;
  • rderService OrderService { @WebBinding {

wsdlLocation="wsdl/OrderService.wsdl", wsdlPort = "OrderService", wsdlService = "OrderServiceService"}}; wOrder order; wError error; call orderService.getOrder(orderNumber, wOrder, wError returning to gORCallback; end function gORCallback(order Order in, error Error in)

  • ncb(order, error);

end

slide-41
SLIDE 41

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 41 joepluta@plutabrothers.com

Getting the Results

function orderNotify(orderIn Order in, error Error in) if (error != null and error.severity != 0) sendResponse("*STATUS", "Order Read Error[" :: error.severity :: "]:" :: error.message); else; (header.children[2] as TextLabel).text = order.Header.OrderNumber; (header.children[4] as TextLabel).text = order.Header.CustomerNumber; (header.children[6] as TextLabel).text = order.Header.CustomerName;

  • rderLines.data = order.Lines as any[];

(totals.children[2] as TextLabel).text = order.Header.Tax; (totals.children[4] as TextLabel).text = order.Header.Freight; (totals.children[6] as TextLabel).text = order.Header.Total; (shipping.children[2] as TextLabel).text = order.Header.ShippingAddr; (shipping.children[2] as TextLabel).text = MyAddress; sendResponse("SHOW", orderBox); end end

slide-42
SLIDE 42

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 42 joepluta@plutabrothers.com

Connecting Back to the i

function getOrderPgmCall(orderNumber string in, order Order out) returns (Error) control Control; line OrderLine; control.opcode = "H";

  • rder.Header.OrderNumber = orderNumber;

call "ORDSVR" (control, order.Header, line); // Fill header control.opcode = "D"; call "ORDSVR" (control, order.Header, line); // First line while (control.retcode == "0")

  • rder.Lines.appendElement(line);

call "ORDSVR" (control, order.Header, line); // Next line end end

slide-43
SLIDE 43

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 43 joepluta@plutabrothers.com

The RPG Code

FORDHDR IF E K DISK FORDDTL IF E K DISK DdsCONTROL E DS QUALIFIED DdsORDHDR E DS QUALIFIED DdsORDDTL E DS QUALIFIED DORDSVR PR D P1 likeds(dsCONTROL) D P2 likeds(dsORDHDR) D P3 likeds(dsORDDTL) DORDSVR PI D P1 likeds(dsCONTROL) D P2 likeds(sdORDHDR) D P3 likeds(dsORDDTL) /free select; when P1.opcode = 'H'; chain P2.OHNUM ORDHDR dsORDHDR; P1.retcode = %found(ORDHDR); setll P2.OHNUM ORDDTL; when P1.opcode = 'D'; reade P2.OHNUM ORDDTL dsORDDTL; P1.retcode = %eof(ORDDTL); endsl; /end-free

slide-44
SLIDE 44

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 44 joepluta@plutabrothers.com

Advanced Concepts

Encapsulation REST vs SOAP Extensions Debugging

slide-45
SLIDE 45

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 45 joepluta@plutabrothers.com

Encapsulation

function getOrder(orderNumber string in, order Order out) returns (Error) case (access) when (Utility.ACCESS_LOCAL) return (getOrderLocal(orderNumber, order)); when (Utility.ACCESS_SQL) return (getOrderSql(orderNumber, order)); when (Utility.ACCESS_PGMCALL) return (getOrderPgmCall(orderNumber, order));

  • therwise

return (Utility.Fatal("Invalid access " :: access)); end end

slide-46
SLIDE 46

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 46 joepluta@plutabrothers.com

REST vs. SOAP

ios com.pbd.svc.IOrderService { @RESTBinding {baseURI = "http://localhost:9081/iEGL/restservices/OrderService"}};

  • rder com.pbd.data.Order;

call ios.getOrder(orderNumber, order) returning to gORCallBack

  • nException ServiceLib.serviceExceptionHandler;
slide-47
SLIDE 47

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 47 joepluta@plutabrothers.com

Extensions

ExternalType Fmt type JavaScriptObject { relativePath = "com/pbd/util", javaScriptName = "Fmt" } function getNow() returns (string); end egl.defineClass('com.pbd.util', 'Fmt', // this class { "constructor" : function() { this.ms = new Date().getTime(); }, "getNow" : function( ) { function two(x) {return ((x>9)?"":"0")+x} function three(x) {return ((x>99)?"":"0")+((x>9)?"":"0")+x} var sec = Math.floor(this.ms/1000); var msec = this.ms % 1000; var min = Math.floor(sec/60); sec = sec % 60; var hr = Math.floor(min/60); min = min % 60; hr = (hr + 18) % 24; return (two(hr) + ":" + two(min) + ":" + two(sec) + "." + three(msec)); }});

slide-48
SLIDE 48

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 48 joepluta@plutabrothers.com

Debugging

EGL-level debugging Java debugging Console logging Web service explorer Chris Laffra's service monitor Service Entry Points (SEPs)

slide-49
SLIDE 49

Pluta Brothers Design, Inc. http://www.plutabrothers.com Page 49 joepluta@plutabrothers.com

Summary

Multi-tiered applications are complex beasts, usually requiring multiple languages and skill sets, not to mention tools EGL provides a consistent syntax, both in data representation and in program flow All components, both EGL and non-EGL, can be developed within the RDi-SOA workbench By providing end-to-end development capabilities, EGL is the only tool that can leverage the i out of the box to build powerful rich Internet applications
