Iowa Cabins Task Force November 16, 2018 Com ompany B y Backgrou ound Founded in 1983 100,000 sq. ft. state-of-the-art facility Key market Log cabins & homes under 2,500 sq. ft. Camping cabins, Deluxe cabins,

slide-1
SLIDE 1

Iowa Cabins Task Force November 16, 2018

slide-2
SLIDE 2

Com

  • mpany B

y Backgrou

  • und
  • Founded in 1983
  • 100,000 sq. ft. state-of-the-art facility
  • Key market
  • Log cabins & homes under 2,500 sq. ft.
  • Camping cabins, Deluxe cabins, Vacation homes, Bathhouses, Bunkhouses, Trading Post

(stores), offices, etc.

  • Sold over 3,300 kits
  • In all 50 USA states & 7 foreign countries
slide-3
SLIDE 3

Partne nershi hip P Phi hilosophy hy

  • We understand the building process
  • Planning, appropriation of funds,

contracting and site development all take time

  • We partner with our clients to:
  • Build sustainable structures
  • Structures that match their needs
  • Structures that are code compliant
  • We assist in every aspect of the process

including helping market the cabins when completed

  • We partner Cedar Forest

Products for local sale support

  • Site Visits
  • Installation relationships
  • Our Team consist of
  • Project consultants
  • Technical Support staff
  • Designers
  • Production and administrative staff to

ensure the highest quality product and service in the industry

slide-4
SLIDE 4

Ev EverLast TM

TM LOGS

GS

slide-5
SLIDE 5

What’s included in our Kits

slide-6
SLIDE 6

Buyer Responsibility

The items listed below are intended to be provided by the buyer. Conestoga can provide if requested for an additional charge. A quote can be provided.

  • Foundation
  • Exterior Stairs
  • Furniture and equipment not purchased

through Conestoga

  • Plumbing for kitchen and bathroom(s)
  • All trim not associated with windows and

doors

  • Electrical connection to devices and breaker

box with main power supply

  • Surface preparations, including but not limited

to sanding, staining and painting

  • Perforations through roofing
  • Debris and trash removal
  • Offloading of delivery truck(s), if not being

assembled by Conestoga

  • Any modifications to original building contract

unless authorized in writing by Conestoga

slide-7
SLIDE 7

Design Process

Services provided by Conestoga Log Cabins & Homes

slide-8
SLIDE 8

Step 1) Sketch and draft floor plan

A draft floor plan is created from the napkin sketch and any layout changes are made

slide-9
SLIDE 9

Step 1) Sketch and draft floor plan

A draft floor plan is created from the napkin sketch and any layout changes are made

slide-10
SLIDE 10

Step 2) Create 3D model

A detailed 3-dimensional model is created enabling the designer to ensure all aspects of the design are accounted for, including furniture and appliances as necessary

slide-11
SLIDE 11

3D Mo de l

slide-12
SLIDE 12

Step 3) Create Plans

A set of construction plans is created from the 3D model.

slide-13
SLIDE 13

Step 3) Create Plans

A set of construction plans is created from the 3D model

slide-14
SLIDE 14

Step 4) Shop Data

Because all necessary cuts and drills appear in the 3D model, the log and beam information can be sent directly to our shop floor to be produced at a one- sixteenth inch precision

slide-15
SLIDE 15

Step 5) Creating shop paperwork and ‘notchers’

Along with the electronic data, drawings are created for the shop employees to verify dimensions on the physical parts. This paperwork includes a set of ‘notchers’ which also play a role in cabin assembly.

slide-16
SLIDE 16

These plans identify the location of each log. Each log has its own unique number that corresponds to the plans.

Notcher Plans

slide-17
SLIDE 17

Conestoga’s Notchers Explained

slide-18
SLIDE 18

Conestoga’s Notchers Explained

Each different log gets a unique number. All logs are tagged with their number allowing for easy log verification.

slide-19
SLIDE 19

Conestoga’s Notchers Explained

Electrical drills are each dimensioned from the nearest notch or the beginning of the log, allowing the builder to easily calculate lengths required for wire runs.

slide-20
SLIDE 20

Conestoga’s Notchers Explained

Openings and log lengths are clearly dimensioned to verify accuracy in both production and assembly.

slide-21
SLIDE 21

Plans & s & Kit S Simplify A Asse ssembly

How simple is it? Even the Boy Scouts can do it!

slide-22
SLIDE 22
slide-23
SLIDE 23

Building ng & & Ene nergy C y Cod

  • des

Building Codes

  • IRC 2015 or IBC 2015
  • Local code requirements
  • Wind-load (Florida Keys)
  • Snow-load (High Sierra)
  • Costal Building Hardware & Windows

Energy Codes

  • REScheck
  • COMcheck
  • IECC (Intl’ Energy Conservation Code)
  • No air-leaks, they will hold pressure
  • No settling like typical log structure
slide-24
SLIDE 24

Mo Moulder

Used for precise molding

  • f tongue & groove and

engineered log profile, D- Log or Flat-Log.

slide-25
SLIDE 25

Notcher er

A computerized process that ensures accurate log cuts, electrical wire traces, electrical boxes mortised. All window and door openings are prefab cut, no cutting required. Leave your chainsaw at home!

slide-26
SLIDE 26

Notcher er

Notches ensure secure fit

  • f nested logs.

EMSEALTM , a vacuum foam tape, is applied to the tongue of the log to seal from moisture and air leaks.

slide-27
SLIDE 27

Notcher er

Pre-drilled nail holes in logs for ease and accuracy of log fastening.

slide-28
SLIDE 28

Hundeg egger er

This machine is used for special cuts for peaks, beams, octagon windows, etc.

slide-29
SLIDE 29

Completed K Kit its for Ship ippin ing

slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39
slide-40
SLIDE 40

Log Structure Maintenance

Exterior treatment Interior treatment

Woodguard is applied at time building is finished. Reapply at 2 years and then every 5 years. ZipGuard is applied to interior surfaces to protect the wood. Wood can be stained prior to application.

slide-41
SLIDE 41

State Park Partners

slide-42
SLIDE 42
slide-43
SLIDE 43

Your Partner in Park Cabin Upgrades and Development of Quality Rentals
