Investing in CarMaker for Driver-In-The- Loop simulation

IPG Apply & Innovate September 2014 Chris Hoyle & Richard Hurdwell (RHE)

info@rfactor-pro.com

About rFpro

Driving simulators TerrainServer Digital Circuit Models

info@rfactor-pro.com

Driving simulator software

info@rfactor-pro.com

Digital Circuit Models

info@rfactor-pro.com

TerrainServer – real-time road surfaces

info@rfactor-pro.com

TURNOVER & APPLICATION GROWTH OF rFpro

Turnover UK£ Millions 3.5 2008

COMMISSIONED BY TOP F1 TEAM

2010

TRACK AND HIGHWAY LIDAR SCANNING SERVICE LAUNCHED

90%

MOTORSPORT

10%

AUTOMOTIVE

2009

rFpro BUSINESS APPLICATIONS

2011

TERRAINSERVER LAUNCHED

2014

COMPREHENSIVE DIGITALCIRCUIT MODEL LIBRARY OF OVER 50 TRACKS NOW AVAILABLE

2014

rFpro NOW USED IN OVER 25 SIMULATOR INSTALLATIONS WORLDWIDE INCLUDING OEMS AND TIER 1S IN THE USA, JAPAN AND EUROPE

80%

AUTOMOTIVE

20%

MOTOSPORT

2014

rFpro BUSINESS APPLICATIONS

LiDAR scanning image courtesy 3D Mapping, GmbH

info@rfactor-pro.com

rFpro CUSTOMERS

AVL ESTIMATES OVER 30 PERCENT COST SAVINGS DEVELOPING DRIVING ATTRIBUTES THROUGH FRONTLOADING THE ENGINEERING ACTIVITY ON A SIMULATOR

“ “

OEMs T1s Engineering services Simulator facilities

THE TRIAL OF RFPRO WAS SO PROMISING THAT WE IMMEDIATELY PUT IT TO USE IN PRODUCTION-INTENT APPLICATIONS, Head of Simulation, Ferrari

“ “

info@rfactor-pro.com

The engineering behind rFpro

The advantage of working in F1 for Vehicle Dynamics simulation studies with a human-in-the-loop

info@rfactor-pro.com

The engineering behind rFpro

Laptime Δ σ (sector Δ)

3D Stereo video vs mono Video Bandwidth 60 vs 120 Hz Video Video Latency (110-24ms) Optically corrected

info@rfactor-pro.com

The engineering behind rFpro

Measuring both absolute gain and variance

info@rfactor-pro.com

The engineering behind rFpro

Importance of Video latency – fastest signal to driver

info@rfactor-pro.com

The engineering behind rFpro

Measuring Importance of Video bandwidth

info@rfactor-pro.com

The engineering behind rFpro

Laptime Δ σ (sector Δ)

3D Stereo video vs mono Video Bandwidth 60 vs 120 Hz Video Video Latency (110-24ms) Optically corrected

info@rfactor-pro.com

Leverage your investment in CarMaker

Model based Development Hardware integration early in lifecycle Re-introduce the Human test driver – into the Model Based Development Process Test Vehicle Dynamics & ADAS with a human driver Before real hardware exists Ensure ADAS works despite human driver Reducing costs, shortening development cycles, improving quality and increasing the performance of a wide variety of automotive solutions

info@rfactor-pro.com

Calibrating CarMaker

• Driver-in-the-loop

Richard Hurdwell -

Concept chassis parameters with representative masses and powertrain

info@rfactor-pro.com

Initial calibration

• with IPG Driver

Steering Pad

info@rfactor-pro.com

CarMaker model Driver-In-TheLoop on THE rFpro VEHICLE DYNAMICS PROVING GROUND

A FICTITIOUS BUT ENTIRELY REPRESENTATIVE VDPG WITH ALL THE FEATURES OF A REAL FACILITY

CarMaker model links directly to rFpro Driver inputs via G27 / SensoWheel Torque feedback CM -> rFpro -> Handwheel Results: No perceptible phase delay between input, graphics or feedback Vehicle difficult to control in enthusiastic manoeuvres

info@rfactor-pro.com

Drivability Improvements

• Driver-in-the-loop at Proving Ground

Needed to Develop

• Yaw Damping
• Drivability in higher speed manoeuvres

By refining

• Elasto kinematics
• Roll damping
• Steering ratio & PAS
• Limited Slip Differential

info@rfactor-pro.com

Result:

• Much improved Drivability

Handling Track

Investing in CarMaker for Driver-In-The- Loop simulation

Thank you – Any Questions?

Chris Hoyle & Richard Hurdwell (RHE)
