Introduction

Contents:

• 1. Presentation
• 2. Installation
• 3. Control
• 4. Features
• 5. Links

Flower of your living room

• 1. Presentation – Style and design

STYLISH THINGS NEED A STYLISH SOLUTIONS

• 1. Presentation – Style and design

Solutions to your needs

Forget all the gray, or silver boxes. Each of the models AB IPBox is available in 8 color styles to nicely fill the space of your living room.

FLOWERS EDITION CLEAR EDITION

• 1. Presentation – Connectivity

AB IPBox 9900HD AB IPBox 99HD AB IPBox 55HD

• 1. Presentation – Connectivity

AB IPBox 9900HD AB IPBox 99HD AB IPBox 55HD

• 1. Prezentácia – Porovnávacia tabuľka

AB IPBox 9900 HD 99 HD 55 HD

• 1st. tuner

DVB-S2 fixed DVB-S2 fixed DVB-S2 fixed 2nd.tuner P&P optional DVB-S2, DVB-C, DVB-T P&P optional DVB-S2, DVB-C, DVB-T no CI 2x no no CardReader 2x 1x 1x ext./int. HDD eSATA/SATA SATA USB HDD bracket yes yes no USB 2.0 2x 1x 1x RS 232 yes yes no Display VFD VFD 4 Digit LED Scart 2x 1x 1x YPbPr yes no no RF Modulator yes no no Power Switch yes yes yes Flash 32MB 32MB 64MB DDRAM Memory 256MB 256MB 256MB S/PDIF yes yes yes Ethernet yes yes yes 0/12V out yes no no

• 2. Installation – Wizard

First use

When you first start the receiver the wizard guides you through the basic setup of your satellite equipment.

Video input selection.

• 2. Installation – Wizard

Setup Wizard

In the following steps the wizard carries out the basic setup of your receiver:

• A/V output
• Resolution setting
• Frequency setting
• Language selection
• Default setting of the receiver functionality
• Tuner/tuners setting
• Program setting
• Selection of satellites
• Parental Lock
• Network connection setting

• 2. Installation – Wizard

Completion Guide

After you finish the wizard the receiver switches to the channellist of installed programs. At this moment is the receiver already set up and ready for use:

List of programs installed in your receiver.

• 3. Control – Remote Control

Interesting buttons on the remote control

These buttons will enable you to control your digital satellite receiver in a more comfortable way.

Unrivaled button which is pressing you to a list of your recordings stored on the HDD. Alternative computer keyboards DEL Alternative computer keyboards BACKSPACE Re-download TV program (during outage audio/video signal)

• 3. Control – Remote Control

To select remote control

In addition to the standard remote control it is possible to make use of an exclusive model AB White Remote

• 4. Features – Software

Satellite receiver control and functions

Satellite receiver runs on its own open-source software based on Linux, deployed by AB IPBox. The software is intuitive and well known to users who have already worked with Linux receivers.

The main menu of the receiver.

• 4. Features – Interesting functions

Overview of interesting features

Detailed description of all functions of the satellite receiver can be found in the user manuals. These are some of the interesting functions or instructions you should know while handling your satellite box: a) Options PIP (Picture In Picture) features. b) Using the Time Shift (Pause Live broadcast). c) Recording two HD programs and watching a third SD program simultaneously. d) How to install additional plugins to your satellite receiver. e) How to easily update your receiver.

• 4. Features – Pip

a.) PIP (Picture In Picture)

This allows you to watch more television programs simultaneously.

Watching two TV programs. The small window of the program being watched can be moved to any position or resized (zoom in or out). The small window position can be adjusted in small steps so it is possible to place it anywhere.

It is possible to watch at the same time:

• two programs,
• the program being currently

broadcast as well as the program recorded on HDD,

• the program being currently

broadcast as well as another program with the TimeShift possibility.

• 4. Features – TimeShift

b.) TimeShift (Pause Live broadcast)

Using only one button you can stop the program being currently broadcast and play it with a time delay afterwards.

Stop the program being currently broadcast. Starting the program that has been stopped. Move forward in a recording. Move backward in a recording. In the large window there is an image being watched with the TimeShift feature, while the small window displays another program being currently broadcast.

• 4. Features – Recording

c.) Recording two HD programs simultaneously

An interesting feature is simultaneous recording of two HD (High Definition) programs and watching a third SD (Standard Definition) program at the same time.

Recording two HD channels (Filmbox HD and History HD) and watching the third program (Z1) simultaneously.

• 4. Features – Plugins

d.) Installation plugins

The receiver functions can be extended by using plugins. Plugins can be installed easily from the Internet as follows:

By pressing the button you will get to the MENU of the receiver where you select "Plugins". This will open the plugin manager. Plugin Browser.

• 4. Features – Update receiver

e.) A new software version installation

Installation is simple and consists of the following steps:

✔ Download new software version in RAR format of the manufacturer's website:

http://abipbox.com/tips-downloads

✔ Unzip files from archive and copy them to any flash disc (it doesn't need to be empty). ✔ Connect the flash disc to the receiver and start the receiver. ✔ During booting, as soon as the display shows "AB IPBOX", press ON/OFF button

(right on the box). Begin the installation process.

✔ Done. The installer takes care of the whole installation process itself.

• 5. Links

Where to learn more?

www.abipbox.com - Official website (technical data, new software, manuals, tips, support,...)

Reviews:

http://www.tele-satellite.com/TELE-satellite-1101/eng/abipbox.pdf http://abipbox.com/wp-content/uploads/SAT-kurier-10-2010-IPBox_9900HD_Plus.pdf http://abipbox.com/wp-content/uploads/SAT&DVB-T_01-2011-IPBox_9900HD_Plus.pdf http://abipbox.com/wp-content/uploads/SAT&DVB-T_12-2010-IPBox_9900HD_Plus.pdf
