2018.06 01 SMILE5 Introduction S E 5 02 Alpha Cloud M I L 03 - - PowerPoint PPT Presentation

2018.06

Alpha Cloud

02

Project References

04

S

M I L E 5

01

SMILE5 Introduction Company Introduction

03

S

M I L E 5

SMILE5 Introduction PART.1

Introduction

6.5kW ≥6000 2 MPPT IP65 Output Input Cycle Life Battery Chemistry MPPT Backup IP Certification Battery Capacity 5kW 5.7-34.4kWh VDE, SAA, TÜV , CE LiFePO4 UPS 2 Battery Modules 5 kW/11.5 kWh Cable Box Inverter

STORION-SMILE5 Residential Energy Storage System

Features

elf sufficient

S M

• dular battery I

ntelligent control L

• ng lifespan E

essential load protected 5 kW system Backup box functions to mange load devices Modular batteries like Tetris for easy add

• n/off of capacity and diversity.

This product is an off-grid integrated system that is connected to a PV generation system to ensure self-sufficiency for 24-hour power supply Easy installation – plug and play design 24/7 online monitoring Cloud based remote control enabled AlphaESS provides users with 5-year warranty and 10-year battery performance warranty. The only residential energy storage systems in the industry that have won both Reddot and iF Design award. The UPS function can protect the necessary loads for 24 hours without interruption

DC Mode AC Mode Hybrid Mode

Self-Sufficient

Solar Generation Load Consumption Generate - Use - Store Making your own generated solar energy available day and night.

DC Mode AC Mode Hybrid Mode

Modulated Battery

• 90% DOD, i.e. 5.3 kWh Usable
• 51.2V, 112Ah per Module
• BMS integrated in each module
• Max. 6 Modules in parallel / Max. 34.4 kWh
• 0.5C Maximum charge & discharge rate , i.e.
• approx. 3kw charge & discharge power each module.

5.7kWh Battery Module

DC Mode AC Mode Hybrid Mode

Intelligent Control

• Maximize PV self-consumption
• Export control from 0 to 5kW
• Remote batch control/micro-grid
• Programmable charge and discharge control
• Flexible battery reserve from 0 to100% for UPS
• Remotely control systems with Web & APP via Alpha Cloud
• Remotely upgrade EMS & BMS through USB or internet
• Remotely change parameter settings through web's management account
• To be combined with smart home devices and gain access to energy Internet

Intelligent Energy Management System

DC Mode AC Mode

Long Lifespan

Product Warranty Estimated Life Time Battery Performance Warranty Without Cycle-life Limitation

Long Life Time and Service

• Premium metal can battery cell
• Safest and longest life battery

chemistry LFP

• Multi-level software and hardware

protection

• Easy and flexible for installation and

maintenance

DC Mode AC Mode Hybrid Mode

Essential Load Protected

• Uninterrupted Power Supply

Your essential loads are protected at all time. No need to worry about power outage any more.

• Slim

Elegant & Slim design takes little space Flexibility in installation location

• IP65

Indoor & Outdoor where-ever you want to

• Plug & Play

Integrated cable box with all the DC and AC isolators wall-mounted, no additional isolators needed, cost saving and truly Plug & Play!

S

M I L E 5

Alpha Cloud PART.2

Info on electricity charge, discharge, power, capacity, area, self-consumption and self-sufficiency

• f

Alpha energy storage system in the whole world

End-users can monitor the system data in real-time such as power generation forecasting, load forecasting, intelligent charging and discharging and revenue overview.

Data analysis

System Power Analysis System Profit Analysis

S

M I L E 5

Company Intro & Product Range PART.3

100+ Patents 3 Tripled growth annually 6000+ Installed units 9 Nationalities 50% R&D experts 10000m2 Plant

City Building Commercial Energy Storage System

A B C D E

A B C D E Large Scale Industrial Energy Storage System Smart Homes Residential Energy Storage System Solar Power Station Electric Vehicle

AlphaESS scope of work

Residential Energy Storage Integrated system

B3

On/off grid integrated system Outdoor application design

24-hour monitoring

Flexible configuration High Efficiency 24 hr monitoring Flexible Configuration Easy installation and maintenance AC coupled Energy storage system

New G Generat ation 10 10kW residential al 3 3 phas ase P PV energy y storag age sys ystem

New Generation 3kW residential PV energy storage system

T10

Small and Medium sized commercial energy storage products

T 30 T 50 T 100

One set of rack contains 5-9 Lithium iron phosphate batteries, one HV900112 box can support up to 20 sets of racks with parallel connection, can cover battery demand range 28kWh-1MWh

50/100kW medium commercial storage system Adapts AC/DC coupling Self consumption, off grid application, diesel device

• n/off control, charging diesel

device, server monitoring and remote upgrade etc. AC coupling, supports 4-12 M48112-S batteries connection, system can cover 23-69kWh battery capacity 30kW small commercial energy storage system, All- in-one design, Android LCD display on cabinet door, real time monitoring Self consumption, pre-set charge & discharge, demand shift, AUX control, UPS, demand charge management etc.

Industrial/commercial energy storage System

On/off micro-grid compatible Modular design Demand charge 24/7 Monitoring with local interface Peak shaving and valley filling Alpha-CS large-scale lithium battery energy storage intelligent integrated system is based on lithium iron phosphate batteries and uses the container as the carrier. It can cover demand of power from 250kWh to 1.2MWh .

Real-time Monitoring All systems can be monitored by Web and iOS/Android APP. Safest Chemistry Li-phosphate for its excellent safety and long lifespan.

Project References

Residential Solution / SMILE5 Germany

Project Detail: Photovoltaic Capacity: 6 kWp System Specification: Storion-SMILE5 Battery Specification: SMILE5-BAT 11.5 kWh System Application: Self-consumption

Residential Solution / SMIL ILE5 Cook Island

Project Detail: Photovoltaic Capacity: 5 kWp System Specification: Storion SMILE5 Battery Specification: SMILE5-BAT 11.5 kWh System Application: Self-consumption + UPS

Resid idential l Solu lutio ion /SMILE5 New Zealand

Project Detail: Photovoltaic Capacity: 3 kWp System Specification: Storion Smile 5 Battery Specification: SMILE5-BAT 11.5 kWh System Application: Self-consumption + Load shifting

Commercial Solution / Cambodia

Project Detail: Photovoltaic Capacity: 500 kWp System Specification: T100 Battery Specification: 1MWh (176 units of M48112-S batteries) System Application: Factory micro-grid and peak shaving Demand side response Power regulation, frequency and voltage control, UPS
