SLIDE 1

NEW 2018 Debut

Introduction Aisin GHP F model

SLIDE 2

Index

1, Background to launch F model 2, Product line-up 3, Major mechanical change 4, Energy efficiency 5, Economical benefit

SLIDE 3

CONFIDENTIAL 秘

Background to launch F model

Compliance to European ECO design directive (Criteria of Energy efficiency introduced) →Higher criteria is applied from January 2018/2020.

End-user’s benefits to launch new F model

Background

■Specification: F model has higher energy efficiency and is complied with ECO design directive (complied with highest criteria starting from 2020) ■Cost: F model has more running merit through better energy efficiency.

SLIDE 4

CONFIDENTIAL 秘

Product line-up

Big family is replaced from E model to F model and small family remains in product line-up. We have 30HP in the product portfolio. 8HP 10HP 13HP 16HP 20HP 25HP 30HP

E E E E E E E E E F F F F Year 2018 Smally family Big family Year 2017

Replaced

New

Replaced Replaced

SLIDE 5

CONFIDENTIAL 秘

Major mechanical change (overview)

◆Fan motor

Output：810→750W Casing material：Iron→Plastic

◆Heat exchanger

Exchanger is expanded

Height：1,125→1,193mm Step：48→56steps Row：2→3rows

◆Refrigerants flow

Add the accumulator bypass valve and upsize the refrigerants piping

◆Engine oil

Less resistance inside engine with less viscosity oil (Saving fuel consumption)

◆Oil pan

Painting level-up to be capable for all the oils leaked (Environmentally friendly)

◆Compressor area

Add the stay mount of compressor intake piping (Sound improvement)

◆Fan shroud

Optimize the clearance（15→7mm） and save the electricity（30W less）

◆Radiator

Radiator size-up for heat exchanger

We made the design changes to improve the energy efficiency.

Efficiency improved Efficiency improved Efficiency improved Efficiency improved Efficiency improved

SLIDE 6

1,89 1,89 1,75 1,87 1,72 1,87

AI P Y AI P Y AI P Y AI P Y

2,39 1,93 2,44 1,90 2,42 1,94 2,17 1,91

AI P Y AI P Y AI P Y AI P Y

1,57 1,55 1,30 1,54 1,27 1,51

AI P Y AI P Y AI P Y AI P Y

1,48 1,36 1,55 1,33 1,54 1,30 1,52 1,33

AI P Y AI P Y AI P Y AI P Y

CONFIDENTIAL 秘

Energy efficiency (ECO design directive)

16HP 20HP 25HP 30HP

Cooling Heating

AWS DX

16HP 20HP 25HP 30HP

Aisin & Tecnocasa optimized the AWS software and improved the annual energy efficiency.
F models are all complied with ECO design directive and are superior to competitors.

(SPER)

AI & TC optimized the AWS software for the best energy efficiency

Criteria 1.25 Criteria 1.30 Criteria 1.54 Criteria 1.67

SLIDE 7

CONFIDENTIAL 秘

Other specification

■Unit dimension (installation space)

AI E model AI F model P Y

16 H P width（m）

1.66 1.66 1.65 1.69

length（m）

0.88 0.88 1.00 0.80

height（m）

2.08 2.25 2.26 2.17

space (m2)

1.46 1.46 1.65 1.35

20 H P width（m）

1.66 1.66 1.65 1.69

length（m）

0.88 0.88 1.00 0.80

height（m）

2.08 2.25 2.26 2.17

space (m2)

1.46 1.46 1.65 1.35

25 H P width（m）

1.66 1.66 2.03 2.10

length（m）

0.88 0.88 1.00 0.80

height（m）

2.08 2.25 2.26 2.17

space (m2)

1.46 1.46 2.03 1.68

30 H P width（m）

N/A 1.66 2.03 2.10

length（m）

N/A 0.88 1.00 0.80

height（m）

N/A 2.25 2.26 2.17

space (m2)

N/A 1.46 2.03 1.68 AI E model AI F model P Y

16HP

740 765 765 880

20HP

750 765 765 890

25HP

750 795 870 1,080

30HP

N/A 870 880 1,080 AI E model AI F model P Y

16HP

56 58 N/A 57

20HP

59 59 N/A 58

25HP

62 62 N/A 61

30HP

N/A 63 N/A 62 AI E model AI F model P Y

16HP

26 26 24 32

20HP

33 33 24 32

25HP

41 41 24 40

30HP

N/A 50 32 48

■Unit weight ■Sound pressure ■Connectable number of indoor units

(kg） (dB） (unit）

F models are good at both energy efficiency and compact design

SLIDE 8

CONFIDENTIAL 秘

Economical benefit

（EUR）

RUNNING COST RUNNING COST

16HP 20HP 25HP

（Year）（13Years） F model operates less energy consumption than E model. F model has more economical benefit. Gas price: €0.027/kWh EL price: €0.148/kWh Note: Eurostat Italy

30HP

2.224 1.784 2.658 2.146 3.331 2.721 3.252

440 512 610

E F diff E F diff E F diff E F diff

28.912 23.192 34.554 27.898 43.303 35.373 42.276

5.720 6.656 7.930

E F diff E F diff E F diff E F diff 139 112 28 133 107 26 133 109 24 108 1.807 1.450 358 1.728 1.395 333 1.732 1.415 317 1.409

【Per HP】（EUR）【Per HP】

SLIDE 9

CONFIDENTIAL 秘

Route map software (Sales tools)

Route map software has been developed. It encourages designers to draw Aisin GHP application. It is possible to make simple mapping. Use it as sales tools.

NEW Sales tool

SLIDE 10

Grazie per l'attenzione

SLIDE 11

GHP F – MODEL TECHNICAL INFO

SLIDE 12

GHP F – MODEL

Line-up

Direct expansion Air Water Sytem Air handling units ECO e LOW TEMP spec

SLIDE 13

Outdoor units 8 to 60 HP
Combination multi system
3 engines 3 compressors
Wide indoor unit selection
Enchanced performances

GHP F – MODEL

Line-up

SLIDE 14

GHP F – MODEL

Line-up

DX Systems

Up to 63 connectable indoor units Up to 160% connected capacity

SLIDE 15

GHP F – MODEL

Line-up

AHU systems

Model EASY13 EASY30 EASY60 EASY90 EASY120 Cooling (kW) 33,5 85 2X85 3X85 4X85 Heating (kW) 40 97,4 2X97,4 2X97,4 2X97,4 Circuits number 1 1 2 3 4

SLIDE 16

GHP F – MODEL

Line-up

Model 8HP 10HP 13HP 16HP 20HP 25HP 30HP 40HP 50HP 60HP Cooling (kW) 21,0 26,5 33,5 42,5 53,0 63,5 74,5 106 127 149 Heating (kW) 23,5 30,0 37,5 50,0 62,5 77,0 87,5 125 154 175 Recovery (kW) 8,0 10,0 13,5 19,5 23,5 30,5 44,5 47 61 89

Air-water systems

SLIDE 17

GHP F – MODEL

Line-up

Model ECO LOW TEMP 16HP 20HP 25HP 30HP 25HP 30HP Cooling (kW) 42,5 53,0 63,5 74,5 65,5 74,5 Heating (kW) 41,0 53,5 62,5 75,0 75,0 87,5 Recovery (kW) 19,5 23,5 30,5 44,5 36,5 44,5

Special units

SLIDE 18

30 HP Outdoor unit
Variable capacity scroll

compressors

New refrigerant circuit
Environment protection features
Management solutions tuned on

the installation needs

GHP F – MODEL

What’s new

SLIDE 19

GHP F – MODEL

What’s new

Same capacity with less
utdoor units
Increased layout flexibility

(90 m from first branch DX)

Dedicated gas engine
Optimised refrigerant gas

flow management 30 HP Outdoor unit

SLIDE 20

GHP F – MODEL

What’s new

Outdoor unit heat exchanger

New

Cool. Condens. Superc.

Cool.

Condens. Superc.

E model F model

60% bigger heat

transfer surface

Increased hight and
ne added row
Engine radiator

increased size

SLIDE 21

GHP F – MODEL

What’s new

4-way bypass

Nuovo

Less pressure drop in cooling
Improved layout of components
Higher overall efficiency

E model

SLIDE 22

GHP F – MODEL

What’s new

4-way bypass

Nuovo

F model

Less pressure drop in cooling
Improved layout of components
Higher overall efficiency

SLIDE 23

GHP F – MODEL

What’s new

Engine oil

Nuovo

Smoother operation
Engine min speed 500rpm
Oil leakage pan with integrated

safety switch included

F model E model

SLIDE 24

GHP F – MODEL

What’s new

Less noise

Nuovo

Reduced clearance btw. fan and

frame to minimise turbulence

New combustion engine dampers
Improved compressor intake piping

bracket to reduce vibrations

New casing

SLIDE 25

TOYOTA reliability
Eco-sustanable

GHP F – MODEL

Innovation and experience

Strong partnership when developing new products
Most efficient and top performant
Tailored technical soluntions for many different type of

customers

SLIDE 26

AWS F MODEL

SLIDE 27

AWS F model

Development

AWS E model Stand Alone System:

It manages the proper GHP
peration
It can provide information to
ther system
It has to be integrated by a

Yoshi management system or a third party one

SLIDE 28

AWS F model

Development

AWS E model

These management systems

are able to control:

Circulation pump
Boiler and/or chiller
Temperature and/or pressure

sensor

…

SLIDE 29

AWS F model

Development

This method allows:

To promote dedicated control system
To not limit the available logic functions
To not oblige to buy a specific logic

controller

SLIDE 30

AWS F model

Development

Possible problems:

GHP efficency lower than expected one

due to improper third party management

Running cost higher than expected one

due to improper third party management

Inadeguate comfort due to improper third

party management

High cost

SLIDE 31

AWS F model

Development

AWS F model

It can be still installed as a stand alone system:
Backward compatibility
Deep system integration for each possible layout
It can be the centre of a fully integrated smart system:
Using standard base hydraulic layout
Choosing the needed Yoshi components

SLIDE 32

AWS F model

Modular System

AWS F model = Modular system made up by components:

Linked and smart
With standard features
Designed for specific
perations
Combinable with no restriction

SLIDE 33

AWS F model

Modular System

Included features:

Group control for AWS
WebServer
DataLogger
High efficency pump Wilo

Yonos Maxo (AWS J excluded)

Pumps and valves

management

SLIDE 34

AWS F model

Modular System

Available optionals:

Mod.1 – Capacity integration
Mod. 2 – DHW production
Mod. 3 – Energy meter reading
Mod. 4 – Secondary circuit
Temperature probes
Keyboard
Gateway
Pumps

SLIDE 35

AWS F model

Modular System – AWS

Networked AWS F model:

Are controlled and managed by
nly one HMI
Share the load selecting the

proper working GHP number e

Control the capacity produced

by each GHP

SLIDE 36

AWS F model

Modular System – PUMPS

AWS F model:

Control their own pump
Control On-Off valves and

primary loop pump

SLIDE 37

AWS F model

Modular System – PUMPS

AWS is equipped with a

circulation pump of the latest generation (Yonos Maxo)

High static pressure specification

is available

Strong partnership with Wilo.

Tecnocasa offers carefully selected pumps compatible with Yoshi products

SLIDE 38

AWS F model

Modular System – PROBES

AWS F model + Outside temperature probe:

Climatic compensation curves

are available

AWS operation is avoided

when not necessary (excessive

utside temperature in Winter)

Tw Ta

SLIDE 39

AWS F model

Modular System – PROBES

AWS F model + Optional probe:

Improved circulation pump
peration (even if one pump

supplies several AWS)

Electrical consumption

reduction

Improved circulation pump

realiability

SLIDE 40

AWS F model

Modular System – EX. MODULES

AWS F model + Expansion Module 1:

Included backup system

management as gas boiler and/or air to water EHP

SLIDE 41

AWS F model

AWS F model + Expansion Module 2:

WKIT management
DHW gas boiler management
DHW circulation pump
DHW mixing valve

Coming Soon

Modular System – EX. MODULES

SLIDE 42

AWS F model

AWS F model + Expansion Module 3:

Metering system management
Consumption data are recorded
Consumption data can be

downloaded remotely

Coming Soon

Modular System – EX. MODULES

SLIDE 43

AWS F model

AWS F model + Expansion Module 4:

Secondary circuit pumps

management by timer or manual ON/OFF

Coming Soon

Modular System – EX. MODULES

SLIDE 44

AWS F model

Modular System - HMI

AWS F model + Keyboard:

All the components (AWS + Ex.

MOD + Probes) can be controlled and managed by a single HMI

Coming

Soon

SLIDE 45

AWS F model

Modular System - Connectivity

AWS F model improved included connectivity:

Gateway ModBus RTU
Gateway ModBus IP
Data Logger with WEB access
WebServer – Each AWS

system components can be controlled and managed by remote.

SLIDE 46

AWS F model

Modular System - Connectivity

Additional communication gateway can be added:

ModBus ASCII (RS232)
BacNet MSTP (RS485)
Lon

Coming Soon

SLIDE 47

AHU KIT

SLIDE 48

Kit AHU

Main Features

EVKIT 224 – 560

Compatible with other DX

units

Compatible with standard

controllers

Constant coil

temperature: 45°C Winter 7°C Summer

SLIDE 49

Kit AHU

Main Features

AHU KIT EASY 8 – 120 HP

Up to 4 GHP
No design air volume and

intake air temperature limitation

Very usefull in large

volume application

AHU KIT Controllo UTA

SLIDE 50

Kit AHU

Main Features

AHU KIT EASY 8 – 120 HP

Specific software

strictly connected with AWS tecnology

Analogue input for

capacity management

It must be controlled by

AHU master controller

AHU KIT AHU Master Controller

SLIDE 51

Gas Engine Heat Pump

Research & development

Clean Energy for the Future Clean Energy for a new sustainable, efficient, renewable climate

Sensibility to environmental issues New national and European scenarios Innovative solutions for a largest number of users

SLIDE 52

... with high annual energy efficiency, optimized both for the winter and summer season

Gas Engine Heat Pump

A new heat pump...

A++

... with high energy performance at standard rated conditions

SLIDE 53

... that produces renewable heat

Gas Engine Heat Pump

A new heat pump...

... to be considered as Total Energy System: the residual heat is completely recovered

SLIDE 54

... reliable, based on a greater circularity of resources

Gas Engine Heat Pump

A new heat pump...

... innovative, developed to meet the needs of each user

SLIDE 55

Gas Engine Heat Pump

A new heat pump...

... sustainable, with zero emissions

f PM 10 and a production of low-

carbon heating & cooling energy ... quality, a solution at the new national and european efficiency strict limits

SLIDE 56

Gas Engine Heat Pump

Clean Energy for the future

Research and analysis Development and test Production

SLIDE 57

Gas Engine Heat Pump

Clean Energy for the future

SUSTAINABLE EFFICIENT RENEWABLE INNOVATIVE

SLIDE 58

Gas Engine Heat Pump

Seasonal Efficiency

30% 40% 26% 4% 25% 50% 75% 100% Time Part Load

During normal operation, a heat pump runs primarily at partial load High seasonal efficiency allows to reduce primary energy consumption, minimizing running costs

SLIDE 59

Gas Engine Heat Pump

Energy Label A++

Engine

GEHP Heat/Cool Energy Air Gas Engine Heat

GUE Heat/Cool Energy = Gas PER Heat/Cool Energy + Engine Heat Recovery = Gas

SLIDE 60

Gas Engine Heat Pump

Energy Label A++

The new GEHP promote the development of buildings in ENERGY CLASS A++ ECO Design National efficiency limit A+ A++

SLIDE 61

Gas Engine Heat Pump

Energy Label A++

ECO Design National efficiency limit

8 10 13 16 20 25 30

A++ A+

8 10 13 16 20 25 30

A++ A+ Air to Air Air to Water

SLIDE 62

Gas Engine Heat Pump

Total Energy System

The recovery of the residual heat, allows to provide end users a surplus of energy for free Given a total efficiency that can be higher than 280%, the new Gas Engine Heat Pumps can be considered Total Energy System

SLIDE 63

Gas Engine Heat Pump

Renewable Energy

Engine

GEHP

≈ 65% of thermal energy produced by a GEHP it is Renewable

Air Thermal Energy

The new Heat Pumps promotes the decarbonization of Heating & Cooling sector through Renewable Energy

SLIDE 64

Gas Engine Heat Pump

Energy Efficiency

The energy needed to heat a NZEB is Efficient and Renewable The new Gas Engine Heat Pumps allow the design of nearly zero energy buildings and the refurbishment of existing ones, reducing energetic and economic consumption

SLIDE 65

Gas Engine Heat Pump

Renewable, efficient, sustainable

promotes efficient buildings promotes thermal renewable energies complys with the requirements of the ECODesign Directive

The high quality of new AISIN Engine Heat Pump

SLIDE 66

Gas Engine Heat Pump

ECO Innovation

In 2017, in 15 main European cities the annual average emissions of PM10 exceeded the safety limit value of 20 μg/mc

40% CO2

0 PM10

Nation City Annual avarage PM10 Italy Torino 39 Italy Milan 37 Spain Sevilla 29 France Marceille 29 France Nice 29 Italy Rome 28 France Paris 28 Germany Stuttgart 24 Spain Barcelona 24 Germany Dourtmund 24 Germany Berlin 24 United Kingdom Glasgow 23 Fance Bordeaux 22 United Kingdom London 22 United Kingdom Leeds 22

SLIDE 67

Gas Engine Heat Pump

ECO Innovation

A simple and not frequent ordinary maintenance reduces the environmental impact and the annual costs Gas engine heat pumps are sustainable Oil change every 30,000 hours Few operations

f maintenance

SLIDE 68

Gas Engine Heat Pump

Sustainable and Renewable future

The new biofuel: BIOMETHANE

Biomethane is RENEWABLE Biomethane is SUSTAINABLE Biomethane is FLEXIBLE Biomethane is PROGRAMMABLE

SLIDE 69

Gas Engine Heat Pump

Sustainable and Renewable future

Gas Engine Heat Pump powered with biomethane will be the best technology solution for Heating & Cooling sector Fully RENEWABLE ZERO emissions

SLIDE 70

Gas Engine Heat Pump

DX System

Gas Engine Heat Pump Air to Air Energy Performances

SLIDE 71

Gas Engine Heat Pump

DX System

20 40 60 80 100 16 HP 20 HP 25 HP 30 HP 20 40 60 80 100 16 HP 20 HP 25 HP 30 HP

Heating Capacity Cooling Capacity

= = = = = =

SLIDE 72

Gas Engine Heat Pump

DX System

0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP 0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP

PER - Heating Efficiency PER - Cooling Efficiency

2%

+4% +4% +15% +2% +2%

SLIDE 73

Gas Engine Heat Pump

DX System

0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP 0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP

SPERh – Seasonal Heating Efficiency

+23% +29% +28%

1,20

+26%

1,57 1,67 SPERc – Seasonal Cooling Efficiency

+52% +55% +54% +38%

1,30

dal 2018 dal 2021 dal 2018 dal 2021

SLIDE 74

Gas Engine Heat Pump

AWS System

Gas Engine Heat Pump Air to Water Energy Performances

SLIDE 75

Gas Engine Heat Pump

AWS System

20 40 60 80 100 16 HP 20 HP 25 HP 30 HP 20 40 60 80 100 16 HP 20 HP 25 HP 30 HP

Heating Capacity Cooling Capacity

+5% +4% +2,5% +2,5% +2% =

SLIDE 76

Gas Engine Heat Pump

AWS System

0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP 0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP

PER - Heating Efficiency PER - Cooling Efficiency

+1% +4% +2% +15% +2% +2%

SLIDE 77

Gas Engine Heat Pump

AWS System

0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP 0,5 1 1,5 2 2,5 16 HP 20 HP 25 HP 30 HP

SPERh – Seasonal Heating Efficiency

+26% +24% +23%

1,25

+21%

1,44 1,54 SPERc – Seasonal Cooling Efficiency

+31% +31% +30% +30% dal 2017 dal 2018 dal 2021

SLIDE 78

Gas Engine Heat Pump

AWS System - ECO

0,5 1 1,5 2 16 HP 20 HP 25 HP 30 HP +8% +9% +13% +5%

GUE - Heating Efficiency

The special version ECO aims to maximum efficiency to fulfil requirements in areas where subsidies and green energy promotion programs are in place.

SLIDE 79

Gas Engine Heat Pump

AWS System - ECO

AWS ECO the best solution for the environment

Up to 180%

More Efficiency Reduced consumption

SLIDE 80

Gas Engine Heat Pump

AWS System – LOW TEMP

0,5 1 1,5 16 HP 20 HP 25 HP 30 HP +13% +3%

GUE - Heating Efficiency

The special version LOW TEMP offers the highest performances at low outside temperature

Non disponibile Non disponibile

SLIDE 81

Gas Engine Heat Pump

AWS System – LOW TEMP

GUE - Heating Efficiency

AWS LOW TEMP can be used in combination to back up or integration generators, which are not able to supply renewable energy Powerful and efficient at low temperature

7

2 7

SLIDE 82

Thank you for your attention
