CALDERA HEATING GROUP

Founded in Bursa in 2009 for production

• f solid fuel boilers in a workshop of 500

square meters with 35 employees From 2011 to 2012, operated in NOSAB Industrial zone, in 2.700 covered production area with 70 employees

www.caldera.com.tr

CALDERA HEATING GROUP

And today, Caldera Heating has enlarged its organization with production of steel boilers, cast iron boilers, wood gasification boilers, biomass ( pellet ) boilers, as well as trade of new additional products such as hot water cylinders and radiators. Total covered area for production : 8.000 m2 Warehouse : 1.000 m2 Employees : 160

2013 turnover in excess of 12,5 million EURO

www.caldera.com.tr

CALDERA HEATING GROUP

www.caldera.com.tr

CALDERA HEATING GROUP

Laser cutting machine Laser cutting machine

Punch machine

Punch machine

www.caldera.com.tr

CALDERA HEATING GROUP

www.caldera.com.tr

CALDERA HEATING GROUP

www.caldera.com.tr

CALDERA HEATING GROUP

E x p o r t s t o o v e r 1 8 c o u n t r i e s

www.caldera.com.tr

PRODUCTS

• Steel Boilers For Solid Fuels ( Natural draught and fan assisted models)
• Wood gasification boilers with pyrolytic combustion principle
• Cast iron boilers for solid fuels
• Steel hot water boilers for gas, oil or dual fuel burners
• Biomass (pellet) boilers
• Cast Iron Radiator
• Towel radiators
• Floor standing hot water cylinders
• Wall hung hot water cylinders

Our Product Range

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Caltherm Series )

Caltherm S Caltherm B

• High efficiency steel boilers (Natural Draught)
• Up to 70 kW ( 17, 25, 35, 45, 55, 70 )
• Manual loading
• Three pass flue circulation
• Medium efficiency steel boilers (Natural Draught)
• Up to 45 kW ( 23, 28, 35, 45 )
• Manual loading
• Two pass flue circulation

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Caltherm Series )

Caltherm KF

Caltherm F

• High efficiency steel boilers (Fan asisted combustion)
• Up to 70 kW ( 25, 35, 45, 55, 70 )
• Manual loading
• Fan speed modulation
• Electronic control
• Sophisticated energy saving and safety features
• High efficiency steel boilers (Fan asisted combustion)
• Up to 70 kW ( 35, 45, 55, 70 )
• Manual loading
• Fan speed modulation
• Electronic control
• Ideal for small size coals and coal+dust mixtures by

particular secondary air distribution

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Caltherm Series )

Caltherm SF

Caltherm XF

• High efficiency steel boilers (Fan asisted combustion)
• Up to 290 kW ( 90, 115, 145, 175, 200, 230, 290 )
• Manual loading
• Elctronic control with fan speed modulation
• Sophisticated energy saving and safety features
• Auto ash-discharge mechanism
• High efficiency steel boilers (Fan asisted combustion)
• Up to 115 kW ( 30, 45, 70, 90, 115 )
• Automatic feeding
• Elctronic control with fan speed modulation
• Sophisticated energy saving and safety features

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Caltherm Series )

Caltherm XSF

• High efficiency steel boilers (Fan asisted combustion)
• Up to 290 kW ( 145, 175, 200, 230, 290 )
• Automatic feeding
• Elctronic control with fan speed modulation
• Sophisticated energy saving and safety features

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Caltherm Series )

Caltherm MSF

Caltherm MF

• High Range Manual Feeding Steel Boiler (Fan Assisted

Combustion)

• Up to 700 kW
• Electronically control with fan speed modulation
• Sophisticated energy saving and safety features
• High Range Automatic Feeding Boilers For Walnut-Coals

And Pirina (Fan Assisted Combustion)

• Up to 700 kW
• Electronically control with fan speed modulation
• Sophisticated energy saving and safety features

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Gasification Series )

Integra

Megatherm Plus

• High efficiency steel boilers (Fan asisted combustion)
• Up to 70 kW ( 18, 25, 32, 40, 50, 70 )
• Manual loading
• Exhaust fan speed modulation
• Electronic control
• Improved design with additional features
• High efficiency steel boilers (Fan asisted combustion)
• Up to 100 kW ( 25, 32, 40, 50, 70, 100 )
• Manual loading
• Exhaust fan speed modulation
• Electronic control
• High efficieny and low polluting emissions

www.caldera.com.tr

PRODUCTS ( Steel Solid Fuel Boilers – Gasification Series )

Pyrocal

• Up to 80 kW
• Manual loading
• Exhaust fan speed modulation
• Electronic control
• Improved design with additional features

www.caldera.com.tr Caltech 3

• Steel boilers for forced draught burners
• Up to 1200 kW
• Full three pass circulation
• Compact dimensions
• High efficiency
• Suitable for hot water and low temperature heating

installations

PRODUCTS ( Steel hot water boilers for gas, oil or dual fuel burners )

www.caldera.com.tr

PRODUCTS ( Steel Pellet Boilers – Biomass Series )

Bio-Pack

• Eco type compact steel pellet

boilers

• Up to 40 kW ( 18, 24, 32, 40 )
• Automatic ignition
• Exhaust fan speed modulation
• Flue thermostat / Room thermostat
• Back flame safety

 Automatic ignition  PID control, adjustable boiler outputs  Very compact dimensions to match any installation space  Fire protection system, safety against back burning  Exhaust fan speed modulation in respect with desired outlet water temperature and flue gas temperature  Exhuast fan speed control via encoder ensures a very safe operation  High heating surface with vertical flue circulation principle  High water efficiency (above 85%)  Low polluting emissions (less than eN 303/5 Class 4)  Burner made of special stainless steel sheetmetal with high heat resistance  Auto switch-off when there is no fuel  Room thermostat control option  Two models with different features and control options

www.caldera.com.tr

PRODUCTS ( Steel Pellet Boilers – Biomass Series )

Bio-Pack ES Bio-Pack EX

www.caldera.com.tr

Solitherm S

• High efficiency cast iron boilers for solid fuels (Natural

draught)

• Up to 56 kW
• Manual loading
• New and modern design
• Patented flue gas circulation principle

PRODUCTS ( Cast Iron Solid Fuel Boilers – Solitherm Series )

ST 3 S ST 4 S ST 5 S ST 6 S ST 7 S ST 8 S

Number of sections pcs.

3 4 5 6 7 8

(Coal) kW

17 27 34 41 48 56

(Wood) kW

15 23 30 36 43 51

Net Weight kg

253 288 323 358 428 428

Water Content lt

27 32 37 42 52 52 Height

mm

Width

mm

Depth

mm

220 320 420 520 620 720

Fuel loading clearance (upper door) mmxmm

• Max. Fuel loading height (for log wood)

mm

Temperature control range

ºC

Maximum operating temperature

ºC

Minimum return temperature

ºC

Maximum operating pressure bar Water flow/return connections (D) R Filling / draining connection R External dimensions Height (H) mm H1 mm H2 mm Width (W) mm W1 mm Length (L1) mm 562 662

762 862 962 1062

L2 mm 378 478

578 678 778 878

Flue outlet diameter (C) mm

½" 970

Model

Types Output 50 - 90

100

50 (recommended) 4 1 ½" Solitherm S 425 315 322 x 318 400 180 205 530 670 160

www.caldera.com.tr

Solitherm F

• High efficiency cast iron boilers for solid fuels (Fan asisted

combustion)

• Up to 70 kW
• Manual loading
• Electronic control with fan speed modulation
• Mew and modern design
• Patented flue gas circulation principle

PRODUCTS ( Cast Iron Solid Fuel Boilers – Solitherm Series )

ST 5 F ST 6 F ST 7 F ST 8 F ST 10 F

Number of sections pcs.

5 6 7 8 10

(Coal) kW

34 41 48 56 70

(Wood) kW

30 36 43 51 65

Net Weight kg

253 288 323 358 428

Water Content lt

27 32 37 42 52 Height

mm

Width

mm

Depth

mm

420 520 620 720 920

Fuel loading clearance (upper door) mmxmm

• Max. Fuel loading height (for log wood)

mm

Temperature control range

ºC

Maximum operating temperature

ºC

Minimum return temperature

ºC

Maximum operating pressure bar Water flow/return connections (D) R Filling / draining connection R External dimensions Height (H) mm H1 mm H2 mm Width (W) mm W1 mm Length (L1) mm

762 862 962 1062 1262

L2 mm

578 678 778 878 1078

Flue outlet diameter (C) mm Electrical supply V/Hz Power consumption

W 82 43

230/50

160 205 670 530 315 425

Model

970 180 Types Solitherm F

100

½" 4 1 ½" 50 (recommended) Output 50 - 90 322 x 318 400

www.caldera.com.tr Victoria

Name Type Height ( mm ) Height Centers ( mm ) Width ( mm ) Water Content ( l ) Weight ( kg ) Heating Surface ( m² ) Heat Output ( kcal/h )

Victoria 600 Feet 770 600 225 3,2 11,7 0,31 126 Victoria 600 Middle 710 600 225 3,2 10,6 0,31 126 Victoria 800 Feet 970 800 225 4,0 14,6 0,47 195 Victoria 800 Middle 910 800 225 4,0 13,5 0,47 195

• 2 height options
• Nostalgic outlook
• Long lasting usage
• Easy install
• Self-standing
• Homogenous heating
• Superior quality and guarantee
• Maximum efficiency
• High thermal power

PRODUCTS ( Cast Iron Radiators )

www.caldera.com.tr Caltherm White

• White and chrome color option
• Straight models
• High corrosion resistance
• Bathroom, kitchen and ideal for tight spaces
• Esthetic appearance, modern design

PRODUCTS ( Towel Radiators )

Caltherm Chrome

www.caldera.com.tr

Caltherm Hot Water Cylinders

Caltherm Thermo-Cylinders

• Enamelled hot water cylinders in floor standing

design

• Up to 1000 lt
• Single and double serpentine options
• High efficiency and high corrosion protection
• Enamelled hot water cylinders with electric

heater in wall hung design

• 60 and 80 lt
• Available for usage in combination with central

heating, solar panels and geothermal systems

PRODUCTS ( Hot Water Heaters )

www.caldera.com.tr

CERTIFICATES

www.caldera.com.tr
