Innovation in Ultra-Efficient Air-Conditioning Crista Shopis Advanced Energy Conference October 13, 2011 The Challenge Air conditioning = 16% of energy use and large system load peaks. The Challenge Air Conditioning = Reducing Air

SLIDE 1

Crista Shopis Advanced Energy Conference October 13, 2011

Innovation in Ultra-Efficient Air-Conditioning

SLIDE 2

Air conditioning = 16% of energy use and large system load peaks. The Challenge

SLIDE 3

Air Conditioning = Reducing Air Temperature + Dehumidification

The Challenge

SLIDE 4

Source of the Idea: Cool Ground Temperatures

“Free” source of “coolth”
But: Well water temperatures

not cold enough to dehumidify directly

SLIDE 5

The Idea If we split an air stream, heat one of the two streams, and then pass both through a desiccant wheel, the heated and humidified air stream dewpoint will rise above the temperature

f ground water.

SLIDE 6

In Slow Motion

If we split an air stream, heat one of the two streams, and then pass both through a desiccant wheel, the heated and humidified air stream dewpoint will rise above the temperature of ground water.

COOLING COIL GEOTHERMAL COOLING COIL WATER MOISTURE CONDENSATE DESICCANT WHEEL HEAT SOURCE AIR FROM BUILDING AIR TO BUILDING

SLIDE 7

Psychrometric Chart

Enthalpy, Btu/lb(a) Saturation temperature, F Humidity ratio, lb/lb(a) Pressure: 14.6959 psi Dry bulb temperature, F 50 60 70 80 90 100 110 120 130 140 150 0.010 0.020 0.030

2 % 4 % 60%

20 30 40 50 60 70 40 50 60 70 50 60 70 80

1 2 3 4 5 8 6 9 7

SLIDE 8

Efficiency – Original Projection

COEFFICIENT OF PERFORMANCE (COP) 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Geothermal Desiccant Cooling (Natural Gas Fired) Ventilation Cycle Desiccant Cooling Absorption Cooling COP

SLIDE 9

Efficiency – Lab Results Efficiency: 1.85 COP Sensible Heat Ratio: 0.74

SLIDE 10

Other Findings Independent Temperature vs. Humidity controllability is

utstanding

Sensible Heat Ratio from 0 – 1.0 Typical air conditioner’s maximum Sensible Heat Ratio is about 0.75

SLIDE 11

The Vision: A simple four pipe fan coil Possible heat sources: Boiler Solar Waste heat 60°F cooling “sink”: Geothermal Lake Ocean Low-lift chiller Industrial dehumidifier

SLIDE 12

US Potential

SLIDE 13

Summary

A new cooling cycle
Efficiency over 1.8 COP,

likely higher

Heat-fired: Fossil-fuel,

solar, waste heat

Quiet (no compressor)
Outstanding humidity control
A possible path to zero-energy buildings

SLIDE 14

Support – Thank You

Taitem Engineering:
Idea
Prototype development
Continued technical and business

support

NYSERDA:
Feasibility Study
Demonstration project
Syracuse Center of Excellence
Technology Application and

Demonstration

SLIDE 15

…The future of air conditioning is here

Questions?
