H & M Te H & M Technology chnology Ve Ventures ntures LL LLP

Tr Trus ust t th the e Ex Expe perts rts

About H & M

• H & M Technology Ventures LLP, company promoted by two Industry HVAC Professionals, H P

Dudani and Manoj Khati. Both technocrats bring together six decades of diverse cross functional expertise.

• The vision is to partner with leading edge technology product company in HVAC & R area,

combining with local adaption with a customized solution and meet the requirements

• f our

customers.

• H & M business model is to foresee the unmet needs of the customers, get it delivered through an

ecosystem of certified capable contract manufacturers, duly trained in product quality & manufacturing process, enhancing their capability and matching our expectation standard. Further

• ur alliance and partnership with leaders in global technology have further enhanced our capability

in providing advance solution for diverse application.

Our Vision

We will be a GLOCAL company, with a culture of innovation. We will explore & bring technological products that add VALUE for our customers. We will harness & exploit the best ideas in our products & services, to be more effective, building diligently trust in H & M brand, in every business we do.

Board of Directors

H P Dudani is a Licentiate Mechanical Engineer from Mumbai University with 30 + years of experience in HVAC & R industry. During his long illustrious career, he worked across various functional domains

• f

Sales, Marketing, Business Development, Manufacturing, Research & Development, Product Management, Vendor Development, Procurement and Business Management functions. He held various senior management positions throughout a dynamic tenure to strengthen and expand company’s international operation in Middle East & Africa market for distribution of HVAC & Refrigeration products. Manoj Khati is Bachelor in Engineering, Post Graduate in Management Studies and with an advance study program in the field of strategy. Over the years, he has worked in the field of air management, clean room industry both in product & project segment. He is associated with technical society - ASHRAE, ISHRAE and AMCA.

Our Exclusive Brands

Our Products

❑ Air Management : ▪ H & M

Double Skin Air Handling Units

▪ H & M

Ventilation Units ( With Fan & Filter )

▪ H & M

Direct, Indirect, Hybrid Evaporative Adiabatic Cooling Air Handlers

▪ KINGAIR

Double Skin Hygiene & Cleanroom Air Handling Units

▪ MECO

Fan Coil Units

▪ HEATEX

Air to Air Heat Exchanger

▪ BARCOL-AIR

VAV Terminal Units

❑ Industrial : ▪ DONALDSON

Pharmaceutical Dust Collectors

▪ H & M

Drinking Water Coolers

▪ H & M

Fire Doors

THE EXPERT OF FAN COIL UNITS

About

• Taizhou MECO Refrigeration Equipment Co. Ltd, Established in year 2007, is a leading manufacturer of Fan

Coil Units. Located in Taizhou City, Zhejiang Province, China with an area of 13,000 sq. mtr. of Manufacturing, R & D and test facility.

• MECO is an OEM for more than 100 world famous central air conditioning brands word over. Under MECO

brand, It exports in more than 50 countries including Europe, South America, Middle East and South East Asia.

• MECO Strategy of “Differentiation, Continuous Improvement and Innovation Forever” with a constant focus on

“Product Quality” has led to establishing itself as a trusted supplier for many important projects..

FCU Range

FCU Range

FCU Range

FCU Options Available

• 2-Pipe / 4-Pipe Systems,
• 3 row / 4 row Cooling Coil
• LHS / RHS Coil connection
• Return Air from Side or Bottom
• Fan Motor with AC-3 Speed / DC-3 Speed / 0~10V DC motor
• Galva-Alu Cabinet
• Stainless Steel Drain Pan
• Electrical Heaters
• Drain pump
• 2/3-way Valve Package
• Manual / Digital Display Controller

Reference Projects

Olympic Stadium - Brazil Hilton Hotel - Venezuela Varna City Park - Bulgaria Istanbul New Airport Turkey Kings Hospital-Colombo

MODULAR AIR HANDLING UNITS WORLD’S A FAMILY, COMFORT QUALITY

About

AHU

AHU

Kingair AHU Casing Structure Patent Design

Standard AHU Design KINGAIR AHU Design

Kingair AHU Casing Structure Patent Design

Reference Projects

Reference Projects

AIR HANDLING UNITS ENGINEERED SOLUTION

AHU Range

• HMA series are available from 1000 cfm to 60000 cfm nominal air flow rate against total static

pressure up to 8” wg (2000 Pa).

• For special requirement, customized engineered solutions are available.
• HMA series can be offered in various types such horizontal floor mounted, vertical floor mounted,

ceiling suspended and customized two tier applications in draw through and blow through design.

Key Features

• Flexible, modular construction cabinet
• Customized design to suit application
• Compliance to CE & EN 1886
• Available with electrical heater
• Externally painted galvanized sheet and Internally

galvanized surface

• Optimum coil design through AHRI approved

selection software

• Double sloped drain pan
• Available in variable coil casing and drain pan

material

• High efficiency filtration material
• Energy recovery section (heat recovery wheel and

heat pipe)

• Suitable for high indoor air quality application
• AMCA-certified high efficiency fans
• Fan types available are with forward, backward,

aero-foil, plug fan and with EC fan design

• Motor compatible with frequency inverter (VFD)
• Low leakage class Face and by pass dampers
• Optimum size Mixing box section
• Available with electrical heater
• Sound attenuator/ silencer can be provided as

per NC Class

• Suitable UVC lamps provided based on need
• Suitable for low noise & vibrations areas
• Damper in low leakage class
• Accessible and ease in maintenance

Selection Software

Evaporative Adiabatic Cooling

Single Stage Direct 2 Stage Indirect Hybrid

AIR-TO-AIR HEAT EXCHANGERS

About

• Headquartered in Malmo, Sweden, specializes in Air-to-Air Heat Exchangers

designed to maximize heat transfer between air flows.

• Based on the fundamentals of heat transfer, fluid dynamics and more than 50 years
• f practical experience, Heatex´s products and designs are continuously evolving to

maintain our position on the cutting edge of energy management.

• HEATEX stand for the highest quality products that comes with long experience.
• AHU manufacturers worldwide use Heatex heat exchangers as key components in

HVAC systems for the transfer of heat or cooling and control of humidity between the supply and exhaust airstream.

Heatex Global Production

❑ Heat Recovery Wheel

• Sensible heat transfer only
• Aluminium matrix
• Epoxy-Coated Aluminium

❑ Energy Recovery Wheel

• Sensible and Latent Transfer
• Molecular Sieve Coated Aluminium
• Silica Gel coated Aluminium
• Hygromix (Molecular Sieve + Silica Gel Coated Aluminium)
• Hybrid (Aluminium Partially Coated with Silica Gel)

❑ Typical Temperature Efficiency up to 90 % ❑ Variable Well Height (1.4, 1.6, 1.8, 2.0, 2.2, 2.5mm) ❑ Compact Casing Design ❑ Air Flow : 200~190,000 m3/hr ❑ Size : 500 ~ 3800 mm Dia

OA EA SA RA

Rotary Heat Exchanger

❑ Standard Material

• Aluminium

❑ Other Material

• Epoxy coated Aluminium
• Stainless Steel

❑ Options

• Painted framework
• Closed Plate Cutting Edges

❑ Combined Module Size

• 200~3000 mm

❑ Typical Temperature Efficiency

• 65 % Single Pass
• 85 % Twin Pass

Plate Heat Exchanger

Model H, H2, P, Z (cross flow) Model T (twin cross flow) Model M (counter flow)

Conformity & Certifications

• Advanced design and calculation software tool.
• Available in online and offline versions at www.heatex.com.
• Eurovent Certified

Heatex Select

The National 9/11 Memorial New York, USA Public Hospital, Amiens France Baku International Airport, Azerbaijan, Baku Donatello Hotel Apts Dubai, UAE Galaxy SOHO Complex Beijing, China The Gate of the Orient Suzhou, China Hotel Gołębiewski Mikołajki, Poland Intercontinental Marseille, France Lotte World Tower Seoul, South Korea Lycée Marianne Montpellier, France Polar Ocean World Tianjin, China Toyosu Hospital Tokyo, Japan Yasuragi Spa and Hotel Stockholm, Sweden

Reference Projects

VARIABLE AIR VOLUME SYSTEM

About

• Specialists in Low Energy Air Conditioning Systems
• Established in 1982 as the European subsidiary of Barber Colman (USA) a

world leading Air Distribution and Controls Company

• Expanded operations worldwide : USA - Europe - Asia Pacific
• Work with customers to achieve the best engineered system solution for

each project

• Aim to achieve the ideal system with high efficiency..

World Class Labs

Product Range

• Variable Air Volume (VAV) Systems
• Induction Systems
• Chilled (Radiant) Ceiling Systems
• Chilled Beam Systems
• Air Distribution Systems

Product Range

Single / Double Skin Round Connection VAV Units Compact VAV Units Rectangular and Large Air Volume VAV Units

VAV Range

• Type : NA/NB/NC Round Inlet Terminals
• Volume Capacity– 50 to 4,500 m3/h
• Size- ∮100, 125,160, 200, 250, 315, 355, 400
• Type: NK/NL Rectangular Terminals
• Volume Capacity– 750 to 14,500 m3/h
• Size- W x H: 200 x 150 to 1000 x 600

❑ Barcol-Air patented design has 2 x 12 sensing points with signal averaging and amplification with proven accuracy of 2.5% even with irregular duct approach ❑ Controllers are normally factory calibrated with maximum and minimum and heat airflows for plug and play operation

Ind Room Supply Air

Heating Coil

DDC C LONworks or BACnet Compatible

Primary Supply Air from AHU

• ss Sensor for

dependent control

Induction Damper

Induction V A V induces room air into the V A V terminal to mix with the primary air before entering the room.

System Concept

❑ Inlet connector from 100mm to 400mm diameter ❑ Airflow from100 to 5,000m³/h ❑ Induction V A V addresses the limitations of conventional V A Vsystems:

• Reducing maximum airflows and AHU and ducting sizes.
• Overcomes poor air distribution at low primary air flows.
• Increases energy savings

Induction VAV System

Reference Projects

ABN-AMRO Bank Amsterdam Hoftoren office–Netherlands Nomura Bank – London Financial Building – Dubai KINGLAND Beijing Bahrain Financial Harbour

PHARMACEUTICAL DUST COLLECTORS

About

• Donaldson is a trusted supplier of industrial air filtration, providing effective

solutions for pharmaceutical, nutraceutical and cosmetic processing applications.

• Donaldson filtration expertise, wide breadth of product offerings, and

unrivaled product support help you optimize filtration performance and reduce long-term cost of operation low.

• Donaldson offer an extensive range of first-fit and aftermarket products and

services to assist in keeping your process running efficiently, from incoming materials all the way through to packaged goods.

Application

Down flow Dust Collector

WATER COLLER WE KEEP YOU COOL

Water Cooler

Key Features

• SS-304 food grade tank for hygienic drinking water
• Stainless steel outer body with SS-430 grade
• Back panel in galvanized powder coating for high

corrosion resistance

• Heavy duty brass fittings for better reliability
• Ergonomically designed for greater safety and
• perational convenience
• Blue fins on condenser coil for longer life
• Superior quality grooved copper tubes for Low power

consumption & better heat transfer

• PUF Insulation for longer hold time & power saving
• Hermetically sealed high efficiency reciprocating

compressor for faster cooling & power saving

• Eco – friendly R-134a refrigerant for environment

protection

• Wider operating voltage range
• Super tropicalized system design for high ambient
• Sturdy construction for longer product life
• Top lid cover with insulation to prevent heat loss
• Specially designed float valves made of brass &

food grade plastic, to withstand high inlet water head pressure

• Anti-splash drip tray

FIRE DOORS WE CREATE SAFE HABITAT

Fire Doors

Key Features

• High aesthetics, fully flush construction.
• Robust structure.
• Push bar for ease of access.
• Borosilicate, Toughened, Ultra clear transparent, Fire Resistance Vision Panel.
• Fire rated door accessories.
• Fire Protection Rating for 120 minutes.
• Air Tightness to avoid smoke to the safe side.
• Acoustics to reduce sound levels.
• Factory finished to highest quality standards.
• Vermin proof.

H & M Technology Ventures LLP 1103, Goldcroft, Hiranandani Estate, Thane 400607, Maharashtra, India Tel : +91 22 4923 3100 Contact Persons : H P Dudani Manoj Khati Director Director

Mobile : +91 98190 94260 Mobile : +91 99303 96969 hpdudani@hmtechnologyventures.com manojkhati@hmtechnologyventures.com

Contact us…

Tru Trust st the the Ex Exper perts ts
