Industrial Computers

Made in Germany

• 50 employees
• 2.000 m² company floor area
• departments for software & hardware development
• production „Made in Germany“
• global sales network through partnerships

Graduate engineer (FH) Michael Böck

„Investing a great deal of passion, we develop, design and produce professional industrial computers entirely in Germany – since 1991.“

1991: founded by Graduate engineer (FH) Michael Böck 2000: Panel PC A15 is presented at the HMI 2002: certified to DIN EN 9001:2000 2004:

• pening showroom at tci

2005: PreVision Control 2006: ambiento presented at light+building 2008:

• pening ambiento.lounge

2009: self-development baseboard technology and widescreen touch panels 2013:

• pening VI-baseboard (Android)

2015:

• pening LDC, new development IB-Board, H19ST, G07T

2016: expansion of the series with H15ST and G10T 2018: certified to ISO 9001 launch SmartPLC, K19, IPC-TB-PREM, HDBaseT, E10A

Milestones

• plant and machine engineering
• building automation
• medical technology
• security technology
• server applications
• multimedia
• network technology

and internet

For Your Application

www.tci.de/0

 What is the best mounting option for your application?  What protection class has to be attained?  Which hardware configuration is needed?  Which individual demands must be fulfilled by the housing?  How should user input and operation be made?  What system is most suitable for your application?  How should the server connection be made?

Solution-Oriented Consulting

• also for Retrofitting
• PLC operating panel as the basis
• remote maintenance and data logging in the cloud
• cloud connectable in the German legal area
• existing equipment can be integrated into Industry 4.0 applications with

XS systems cost-efficiently

These Applications are Available:

• CodeSys WebVisu
• WAGO/Beckhoff via CGI.BIN
• S7-ISOTCP
• ModbusTCP
• OPC
• VNC

Industry 4.0

examines all relevant system parameters permanently and informs the user immediately if any risk of breakdown occurs.

Prevision Control

without: with:

Standard Modular Individual

Always Matching

Standard industrial computers are being extensively experienced in professional use. With proven technology, they score by their reliability and ruggedness in their industrial environment. To a certain extent, the systems are configurable - all at a reasonable price.

Industrial Computers

• Standard -

• with Integrated Touch Screen or for Rail Mounting
• programming via standard browser,

without external engineering tools

• PLC and HMI in one device
• remanent memory, protects the data in case of power failure
• fully functional PLC
• remote control, data logging and saving in the cloud
• completes the ecosystem of PLC operating panels (tci XS-technology)

PLC SmartPLC

E10A

• E10A-XI, 24V: UL certified
• widescreen touch panel for panel mounting
• PCT glass touch 10.1" with native resolution of

1024*600

• front IP54, back IP20
• optionally serial interfaces

Touch Panel for Panel Mounting

H-ST-Series

• completely closed
• available in different materials
• from 7 inch upwards, 16:9 / 4:3
• IP protection up to IP69k
• hygienic design

Touch Panel for Mounting Arm

Scalable Industrial PCs for 19“ Rack Mounting

• high-performance, customized,

industrial-suited

• customized variants
• robust protection of the components
• server application
• long-term availability

Rack PC

Box PC

Universally Useable Industrial PCs in Compact Construction

• high-performance in a minimum of space
• robust housing for industrial use
• free slots for plug-in boards

Digital Transmission of High-Resolution Signals

• by standard Ethernet cable CAT 5e up to 10 meters, with CAT 7 up

to 100 meters

• no separated KMV switch, no special cables
• for industry, building and infrastructure
• compact cables, which can be placed into the mounting arm

protectively

• directly integrated into different tci displays
• transmission of USB signals e.g. for keyboard and mouse

HDBaseT

Development of new devices by the combination of existing units. Standard systems can be extended for example by trackball or RFID. Customized front designs and modifications to your corporate design are also possible. Even in small quantities cost-effective solutions can be produced for your application.

Industrial Computers

• Modular -

• color according to customer specifications
• printed with customer logo
• closed standard support arm for

protected cable routing

• with keyboard and mouse tray optionally
• customized control elements (push buttons,

emergency stop button)

K-Series

• individual cabling outside the support arm

through rear connections

• by combining the Ex modules and the

H19-PC, this system was created for Ex areas

• integrated keyboard with trackball in

protection class IP 68

H19-ExReady

tci’s engineers develop customized industrial computers for your requirements. You get design, construction and manufacturing from a single source. Despite your flexibility in design and technology customized systems can be the economical solution– fitting perfectly to your application. Durable and reliable in highest tci quality.

Industrial Computers

• Individual -

• in semipublic sector – Bedside Terminal T-Systems
• from sketch through to large-scale production

Example: Hospital

• Point of Information (POI)

for the retail trade

• in use at Weltbild publishing company

and mediamark

Example: POI

• iTFT-Display for food industry
• high hygienic demands without gaps and joints
• optimized for the design of the

customer machines application

Example: Food Industry

• IPC as special system
• compact computer
• individual operating elements and display units

Example: Mechanical Engineering

Application Examples

Towards Feel-Good Climate via Touch Panel

C120 in Control Cabinet Front

• climatic chambers for PolyKlima
• monitoring and control:

temperature, light intensity, air humidity, gas saturation

Important Features

• mounting into switchboard IP65
• particularly robust quality
• resistive touch, can be operated

with gloves

Energy Management via Touch Panel

E10A for Data Analysis

• a lot of measuring points must be captured and

evaluated by detailed data analysis

Important Features

• continuous genuine glass front

in protection class IP54

• 10.1“ PCT glass touch
• safe AutomationBrowser

Panel PC on the High Seas

A15 at the Working Vessel

• display of operating conditions for monitoring
• forwarding to superordinate systems

Important Features

• robust housing for panel mounting
• extra low installation depth
• waterproof front in IP65

Precise Measurement and Documentation

K16-PC for Quality Assurance

• conversion from manual measurement to an automated solution
• completely closed panel PC
• high-performance
• robust industrial quality

Important Features

• 16“ TFT Panel-PC for

support arm or wall mounting

• Protection class scalable up to IP54

according to customer request

• individual housing color and logo

print are available even in small series

Service

Visit us at our showroom!

Showroom

• made in Germany
• quality management certified to DIN EN ISO 9001:2015
• consulting and support in Germany
• resource-friendly and sustainable production
• repair service for all systems sold

Support

Ludwig-Rinn-Straße 10-14 35452 Heuchelheim/Giessen Germany Phone: +49 641-9 62 84-0 Fax: +49 641-9 62 84-28 info@tci.de www.tci.de
