INDU-ZERO Ulla- Britt Krmer, Christian Struck, Gerard Salemink 23-05-2019 Content webinar Interreg NSR (North Sea Region) project Costs of renovations Renovation packages Reference dwellings Summary Next webinars Content

slide-1
SLIDE 1

INDU-ZERO

Ulla-Britt Krämer, Christian Struck, Gerard Salemink

23-05-2019

slide-2
SLIDE 2

Content webinar

  • Interreg NSR (North Sea Region) project
  • Costs of renovations
  • Renovation packages
  • Reference dwellings
  • Summary
  • Next webinars

Content

slide-3
SLIDE 3

The project

slide-4
SLIDE 4

The project

slide-5
SLIDE 5

The project

slide-6
SLIDE 6

The project

slide-7
SLIDE 7

The project

slide-8
SLIDE 8

The project

slide-9
SLIDE 9

The project

slide-10
SLIDE 10

The project

slide-11
SLIDE 11

The project

slide-12
SLIDE 12

The project

slide-13
SLIDE 13

Background

  • Interreg NSR (North Sea Region) project
  • Total budget 4,4 Million
  • Start project July 2018 - Duration 3 year unit July 2021
  • 15 project partners in total 30 persons
  • 6 countries from Northern Europe
  • 5 members advisory board

The project

slide-14
SLIDE 14

Partners and advisory board

The project

slide-15
SLIDE 15

Steps in the project

  • Assessment of the housing stock
  • Development of the renovation packages
  • Development of the production process and

factory

  • VR and AR development of the factory and houses
  • Showcases in 6 countries

The project

slide-16
SLIDE 16

Video

The project

slide-17
SLIDE 17

Costs of renovations

slide-18
SLIDE 18

Costs “traditional approach”

Costs of renovations

Costs groups Costs Percentage

  • f excl VAT

Preparation 1,6% Additional costs 5,4% Windows, doors + glass 15,7% Insulation 18,4% Sustainable energy 45,0% Building site costs 4,9% Subtotal € 75,000 Overheads (10 %) € 7,500 9,1%

  • Excl. of VAT

€ 82,500 100% VAT (21 %) € 17,325

  • incl. VAT

€ 101,475

Milieucentraal.nl
slide-19
SLIDE 19

Group of 5 people (3 from industry) Starting point:

  • Number of houses a year:

15,000

  • Fixed costs:

40,000 euro excl. VAT

Next step to reach the target price

Costs of renovtions

Other starting point

slide-20
SLIDE 20

INDU-ZERO Renovation packages

slide-21
SLIDE 21

Facades and roofs (incl. LCA)

Facades (Sandwichpanels with EPS) Roofs (Sandwich or Timberframe)

Renovation packages

slide-22
SLIDE 22

Renovation package re-design

Renovation packages

slide-23
SLIDE 23

Different claddings

Renovation packages

slide-24
SLIDE 24

INDU-ZERO Reference dwellings

slide-25
SLIDE 25

Reference dwellings

Appartement Semi-detached Terraced

3 arche types

slide-26
SLIDE 26

Building dwellings per type

Amount of detached, semi-detached, terraced dwellings and apartments (in millions) in the North Sea Region.

Reference dwellings

slide-27
SLIDE 27

Building/dwellings per period

Amount of dwellings (in millions) in the North Sea Regions categorized by period.

1950-1985

Reference dwellings

slide-28
SLIDE 28

Terraced dwelling (1965 -1974)

Examples of terraced dwellings built between 1965 and 1974.

Thermal Transmittance Thermal Transmittance Thermal Transmittance m2 m2 · K1 · W-1 W · m-2 · K-1 Floor 52,0 0,17 2,33 Roof 65,5 0,86 0,89 Façade - front 40,5 0,43 1,45 Glass (single) - front 4,3

  • 5,20

Glass (double) - front 21,3

  • 2,90

Façade - side 58,3 0,43 1,45 Glass (double) - side 1,8

  • 2,90

Characteristics (NL) Netto floor area 106 m2 Number of occupants 3 External wall cavity wall / window fills with sandwich panels Attic ventilated Ground floor construction concrete slabs Ventilation system window Heating / DHW system gas boiler

Reference dwellings

slide-29
SLIDE 29

Semi-detached dwelling (1965 – 1974 or ≤ 1964)

Figure 2: Examples of semi-detached dwellings built between 1965 and 1974.

Thermal Transmittance Thermal Transmittance Thermal Transmittance m2 m2 · K1 · W-1 W · m-2 · K-1 Floor 60,0 0,17 2,33 Roof - tilted 65,2 0,86 0,89 Roof - flat 14,0 0,86 0,89 Façade - front 104,7 0,43 1,45 Glass (single) - front 6,7

  • 5,20

Glass (double) - front 24,6

  • 2,90

Characteristics (NL) Netto floor area 123 m2 Number of occupants 3 External wall cavity wall / window fills with sandwich panels Attic ventilated Ground floor construction concrete slabs Ventilation system window Heating / DHW system gas boiler

Reference dwellings

slide-30
SLIDE 30

Appartement (shared entrance flats) (1965 – 1974)

Figure 3: Examples of apartments built between 1965 and 1974.

Area Thermal Transmittance Thermal Transmittance m2 m2 · K1 · W-1 W · m-2 · K-1 Floor 71,0 0,17 2,33 Roof 75,1 0,86 0,89 Façade - front 38,3 0,43 1,45 Glass (single) - front 1,3

  • 5,20

Glass (double) - front 16,8

  • 2,90

Façade - side 23,2 0,43 1,45 Glass (double) - side 1,4

  • 2,90

Characteristics (NL) Netto floor area 71 m2 Number of occupants 2,2 External wall sandwich panels Attic / Ground floor construction concrete slabs Ventilation system window Heating / DHW system gas boiler (local / central)

Reference dwellings

slide-31
SLIDE 31

Detailed energy simulation model / IDA-ICE & ESS models

Terraced dwellings / Reference building NL

Reference dwellings

slide-32
SLIDE 32

Summary

slide-33
SLIDE 33

Summary

  • Report housing stock available on website - ready
  • Development of the renovation packages - ongoing
  • Development of the production process and factory -
  • ngoing
  • VR and AR development of the factory and houses -
  • ngoing
  • Showcases in 6 countries - ongoing

https://northsearegion.eu/indu-zero/

Summary

slide-34
SLIDE 34

Next webinars

slide-35
SLIDE 35

Next webinars

  • 26th of June 2019 “5 challenges of housing

associations”

  • Autumn 2019 “Project status and production

process”

Next webinars
