In-Memory Data Parallel Processor Da Daichi Fu Fujiki Sc Scott - - PowerPoint PPT Presentation

In-Memory Data Parallel Processor

Da Daichi Fu Fujiki Sc Scott Ma Mahlke Re Reetuparna Da Das M-Bi Bits Research Group

2 CPU GPU

DATA-PARALLEL APPLICATIONS ARITHMETIC DATA COMMUNICATION

MANY CORE SIMD OoO MANY THREAD SIMT SIMD

“Data movement is what matters, not arithmetic”

– Bill Dally

1000x 40x

In-Memory Computing exposes parallelism while minimizing data movement cost

3 CPU GPU IN-MEMORY In-situ computing Massive parallelism

SIMD slots over dense memory arrays High bandwidth / Low data movement

In-Memory Computing – Reduces Data Movement

4 CPU GPU IN-MEMORY

– –

C11 C12 V1

I12= V1C12 DAC I11= V1C11

C21 C22

I22= V2C22 DAC

V2

I21= V2C21

I1=I11+I21 I2=I21+I22

In-situ computing Massive parallelism

5

CPU (2 sockets)

Intel Xeon E5-2597

GPU

NVIDIA TITAN Xp

ReRAM

Scaled from ISAAC*

Area (mm2) 912.24 471 494 TDP (W) 290 250 416 On-chip memory (MB) 78.96 9.14 8,590 SIMD slots 448 3,840 2,097,152 Freq (GHz) 3.6 1.585 0.02 SIMD Freq Product 3,227 6,086 41,953

In-Memory Computing – Exposes Parallelism

IN-MEMORY In-situ computing Massive parallelism

In-Memory Computing Today

6

C11 C12 V

1

I11= V1C11

DAC

C21 C22

I22= V2C22

DAC

V

2

C11 C12 V

1

DAC

C21 C22

DAC

V

2

I12= V1C12 I21= V2C21

I11 I12 I21 I22

I1 = I11+ I21 I2 = I12+ I22

Multiplication + Summation

ReRAM Dot-product Accelerator

• PRIME [Chi 2016, ISCA]
• ISAAC [Shafiee 2016, ISCA]
• Dot-Product Engine [Hu 2016, DAC]
• PipeLayer [Song 2017, HPCA]

IN-MEMORY

In-Memory Computing – No Demonstration of General Purpose Computing

No established programming model / execution model Limited computation primitives

How to program?

7

In-Memory Data Parallel Processor Overview

Microarchitecture ISA Execution Model Programming Model Compiler

HW SW

8

Memory ISA ADD MOVI DOT MOVG MUL SHIFT{L/R} SUB MASK MOV LUT MOVS REDUCE_SUM

Data Flow Graph

IB1 IB2

IMP Compiler ILP

IB1 IB2 IB1 IB2

Module DLP

Computation Primitives

CA CB A B

DAC DAC

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 9 Information stored in analog

(cell conductance C = 1/resistance)

A CA

Read Write

Computation Primitives

Vdd

CA CB

I = ( IA + IB )

Vdd/2

DAC DAC

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 10

(a) Addition

(b) Subtraction*

IA IA = (Vdd/2)CA

Ohm’s law [mult] Kirchhoff’s law [add]

IB

Vdd

* New primitive

Computation Primitives

(c) Dot-product

CA CC

DAC

CB CD

IDY= VYCD DAC

V I1=IAX+IBY I2=ICX+IDY

ICX= VXCC

VX

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 11

Y

IAX= VACA IBY= VYCB

C11 C12 V1

I11=(Vdd – V1)C11

V2

I12=(Vdd – V2) C12 DAC DAC DAC

(c) Element-wise multiplication 11

Vdd

Vdd - Multiplier Multiplicand ! " # $ % & = #! + %" $! + &" ! " (# %) = #! %"

B A A B ! + " +

X

• Y
• d

* New primitive *

Microarchitecture

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler

LUT ReRAM PU ReRAM PU

...

ReRAM PU

...

ReRAM PU Reg. File

Cluster

RRAM XB S+H DAC DAC ADC ADC S+A Reg

Processing Unit

Router = RowDecoder + Shift&Add Unit 12

Microarchitecture

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler

LUT ReRAM PU ReRAM PU

...

ReRAM PU

...

ReRAM PU Reg. File

Cluster

RRAM XB S+H DAC DAC ADC ADC S+A Reg

Processing Unit

Array Size 128 x 128 R/W Latency 50 ns Multi Level Cell 2 ADC Resolution 5 ADC Frequency 1.2 GSps DAC Resolution 2 LUT size 256 x 8 13

DAC DAC Shift and Hold DAC DAC DAC DAC DAC DAC

Sample and Hold

8 PUs/array 128 4B Regs/PU 512B x 8 Register File ALU ALU ALU ALU ALU ALU ALU ALU

ISA

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Opcode Format Cycles ADD <MASK> <DST> 3 DOT <MASK> <REG_MASK> <DST> 18 MUL <SRC> <SRC> <DST> 18 SUB <SRC> <SRC> <DST> 3 MOV <SRC> <DST> 3 MOVS <SRC> <DST> <MASK> 3 MOVI <SRC> <IMM> 1 MOVG <GADDR> <GADDR> Variable SHIFT{L/R} <SRC> <SRC> <IMM> 3 MASK <SRC> <SRC> <IMM> 3 LUT <SRC> <SRC> 4 REDUCE_SUM <SRC> <GADDR> Variable In-situ Computation Moves R/W Misc 14

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 15

Programming Model

Need a programming language that merges concepts of Data-Flow and SIMD for maximizing parallelism

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler

KEY OBSERVATION

Data-Flow

Explicit dataflow exposes Instruction Level Parallelism

SIMD

Data Level Parallelism

16 Side-effect Free

No dependence on shared memory primitives

Execution Model

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 17 Data Flow Graph

… …

Input Matrix A Input Matrix B

… …

Input Matrix A Input Matrix B

Execution Model

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 18 DLP Data Flow Graph

… …

Input Matrix A Input Matrix B Decomposed DFG ↕ Module Module Unroll innermost dimension

Modularized execution flow Applied to the innermost dimension

Execution Model

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Decomposed Data Flow Graph

IB1 IB2

Module 19 ILP Data Flow Graph

… …

Input Matrix A Input Matrix B

… …

Input Matrix A Input Matrix B IB IB

Instruction Block (IB) Partial execution sequence of a Module Mapped to a single array

Execution Model

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler ReRAM Array

IB1 IB2

Module 20

IB1 IB2 IB1 IB2

IB1 IB1 IB1 IB2 IB2 IB2 Module Modularized execution flow Applied to the innermost dimension IB IB Instruction Block (IB) Components of Module Mapped to a single array

Execution Model

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Data Flow Graphs

… …

IB1 IB2

Modules 21

IB1 IB2 IB1 IB2

ReRAM Array IB1 IB1 IB1 IB2 IB2 IB2 Input Matrix A Input Matrix B

… …

Module Modularized execution flow Applied to the innermost dimension IB IB Instruction Block (IB) Components of Module Mapped to a single array

…

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 22

Compilation Flow

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Python C++ Java Semantic Analysis Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen Target Machine Modeling IMP Compiler Tensor Flow DFG (Protocol Buffer) Backend 23

Compilation Flow

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Python C++ Java Semantic Analysis Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen Target Machine Modeling IMP Compiler Tensor Flow DFG (Protocol Buffer) Backend 24

Place holder Place holder

Add

Reduce

8 8

16

Optimization1 NodeMerging

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler

Place holder

5 6 3 2 … … 5 6 3 2 … …

Place holder Add + Reduce 16

+ + + +

Semantic Analysis

Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen 25

• Exploit multi-operand ADD/SUB
• Reduce redundant writebacks

NodeMerging

Place holder Place holder

Optimization2 IB Expansion

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler 5 3 6 2 … …

Place holder Place holder

Add

…

8 8 3 2 … …

Add

8 8

Add

Unpack Pack 3 2 5 6 + + + 5 6 +

Semantic Analysis

Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen 26

…

IB Expansion Expose more parallelism in a module to architecture.

Compilation Flow

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Python C++ Java Semantic Analysis Optimization NodeMerging IB Expansion Pipelining Target Machine Modeling IMP Compiler Tensor Flow DFG (Protocol Buffer) Backend Instruction Lowering IB Scheduling CodeGen 28

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler

Semantic Analysis

Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen Instruction Lowering

Instruction Lowering: Transform high level TF insts into memory ISA

29 Inst Lowering Add Mul LUT Add Sub Mul Div Sqrt Exp Sum Conv 2D Less

…

Memory ISA

…

Supported TF operation nodes

Division Algorithm

q = a / b 1. 12 = 345 6

(LUT)

2. 82 = 912 3. ;2 = 1 − 612 4. 8> = 82 + ;282 5. ;> = ;2

@

6. 8@ = 8> + ;>8>

High-level TF Node Newton-Raphson / Maclaurin Div

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling DFG IB Scheduling

Target # of IBs

= 1

IB1

Large Execution Time 30

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling DFG IB Scheduling

IB1 IB2 IB1 IB2

Good :) Bad :(

Target # of IBs

= 2 Large Execution Time Network Delay 31

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Bottom-Up Greedy Collect candidate assignments Make final assignments Minimize data transfer latency by taking both

• perand & successor

location into consideration Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling 32

[Ellis 1986]

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Bottom-Up Greedy Collect candidate assignments Make final assignments Minimize data transfer latency by taking both

• perand & successor

location into consideration Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling 33

[Ellis 1986]

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Bottom-Up Greedy Collect candidate assignments Make final assignments Minimize data transfer latency by taking both

• perand & successor

location into consideration Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling 1 1 34

[Ellis 1986]

IB1 IB2 Time

IB1 is chosen because …

Closer to operand locations

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Bottom-Up Greedy Collect candidate assignments Make final assignments Minimize data transfer latency by taking both

• perand & successor

location into consideration Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling 2 2 2 1 1 35

[Ellis 1986]

IB1 IB2 Time

IB2 is chosen because …

Earlier slots available

Compiler Backend

HW SW

Processor Architecture - ISA - Execution Model - Programming Model - Compiler Bottom-Up Greedy Collect candidate assignments Make final assignments Minimize data transfer latency by taking both

• perand & successor

location into consideration Optimization NodeMerging IB Expansion Pipelining Instruction Lowering IB Scheduling CodeGen

Semantic Analysis

IB Scheduling 2 2 2 1 1 1 1 36

[Ellis 1986]

IB1 IB2 Time

IB1 is chosen because …

Better overlap of comm. and computation

Evaluation Methodology

Benchmarks

• PARSEC 3.0

− Blackscholes, Canneal, Fluidanimate

• Rodinia

− Backprop, Hotspot, Kmeans, Streamcluster

CPU (2 sockets) GPU (1 card) IMP Processor Intel Xeon E5-2597 v3, 3.6GHz, 28 cores, 56 threads NVIDIA Titan Xp, 1.6GHz, 3840 cuda cores 20MHz ReRAM, 4096 Tiles, 64 ReRAM PU / Tile On-chip memory 78.96 MB 9.14 MB 8,590 MB Off-chip memory 64 GB DRAM 12 GB DRAM Profiler / Simulator (Performance) Intel VTune Amplifier NVPROF Cycle accurate simulator (Booksim Integrated) Profiler / Simulator (Power) Inter RAPL Interface NVIDIA System Management Interface Trace based simulation

Methodology

37

Offloaded Kernel / Application Speedup (CPU)

• Capacity limitation of IMP settles the upper-bound of performance improvement.

38 Offloaded Kernel Speedup Application Speedup

0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00

1 2 3 4 5 6 7 8 9 10

Normalized Execution Time

Series1 Series2 Series3 Series4

7.5x

1 10 100

1 2 3 4 5

Offloaded Kernel Speedup 41x

Kernel Speedup (GPU)

39

1 10 100 1,000 10,000 1 2 3 4 5 Kernel Speedup

763x

• GPU benchmarks are able to use higher DLP, dot product operations, and multi-row addition.

Summary

Microarchitecture ISA Execution Model Programming Model Compiler

HW SW

Contributions In-memory computing stack for general purpose programming

• Used Tensor Flow for the programming frontend
• Developed a compiler for in-memory computing on ReRAM
• Developed ISA and computation primitives

Results

763x speedup 440x energy efficiency .. over server class GPGPU 40

In-Memory Data Parallel Processor

Da Daichi Fu Fujiki Sc Scott Ma Mahlke Re Reetuparna Da Das M-Bi Bits Re Research Group

Thank you!
