Institute of Control and Industrial Informatics Faculty of Electrical Engineering and Information T echnology Slovak University of T echnology ICII ROBOTS ICII ROBOTS Ing. Frantiek Ducho Ing. Marian Kik Contents Contents

SLIDE 1

ICII ROBOTS ICII ROBOTS

Institute of Control and Industrial Informatics Faculty of Electrical Engineering and Information T echnology Slovak University of T echnology

Ing. František Duchoň
Ing. Marian Kľúčik

SLIDE 2

Contents Contents

Importance of mobile robotics Indoor mobile robot Outdoor mobile robot

SLIDE 3

Importance of mobile robotics Importance of mobile robotics

Mobile robots are used in:

1. harmful and dangerous environments
2. environment exploration
3. transportation tasks
4. property and people rescue
5. service robotics
6. space robotics

SLIDE 4

Indoor mobile robot Indoor mobile robot (IMR) (IMR)

SLIDE 5

Hardware of Indoor mobile Hardware of Indoor mobile robot robot

SLIDE 6

Sensors of Indoor mobile robot Sensors of Indoor mobile robot

1. 9 x Ultrasonic sensor MrRobot MUSTA 8-12V
2. 9 x Infra sensor
3. 1 x camera head
4. 1 x Ultrasonic Rangefinder

SLIDE 7

Sensors decomposition (IMR) Sensors decomposition (IMR)

SLIDE 8

Accumulator packs (IMR) Accumulator packs (IMR)

 20 NiMH Saft VH F 15Ah/1,2 cells (whole

packet: 24V/15Ah)

SLIDE 9

Stability for Indoor mobile robot Stability for Indoor mobile robot

SLIDE 10

Kinematics scheme of IMR Kinematics scheme of IMR

SLIDE 11

Processes (IMR) Processes (IMR)

SLIDE 12

Goals with IMR

Indoor mapping Reactive navigation Object recognition

People Furniture Other robots Goal objects

SLIDE 13

Local metric map (IMR) Local metric map (IMR) Ultrasonic sensor model (IMR) Ultrasonic sensor model (IMR)

SLIDE 14

Ultrasonic sensor model (IMR) Ultrasonic sensor model (IMR)

SLIDE 15

Reactive navigation (IMR) Reactive navigation (IMR)

SLIDE 16

Future? (IMR) Future? (IMR)

SLIDE 17

Outdoor mobile robot (OMR) Outdoor mobile robot (OMR)

SLIDE 18

Hardware of Outdoor mobile Hardware of Outdoor mobile robot robot

Drive system

two GDM100N2, differential drive
maximal velocity is 0,9 m/s
drive with 2 speeds
harmonic drive

Control system

basic control system hardware is industrial computer PC-UNO-2059

working with frequency 400MHz, with operating system Linux Debian, 1 GB RAM, RS232, RS422

main control system hardware:
small PC VIA EPIA PD15000, operating system Linux Debian
r
PC with Core 2 Duo,1GB 800 MHz RAM, with TVcard

also with Linux Debian

SLIDE 19

Sensors of Outdoor mobile Sensors of Outdoor mobile robot robot

1. 1 x Compass CMPS03
2. 1 x GPS Garmin 18-5Hz
3. Analog Devices:

Gyroscopes/Accelerometer/Inclinometer

4. 1 x Laser Scanner HOKUYO URG-04LX
5. 6 x Ultrasonic Range Finder MaxSonar EZ1
6. 2 x Ultrasonic Range Finder Devantech SFR

7. 1 x Camera Head

SLIDE 20

Accumulator packs (OMR) Accumulator packs (OMR)

1. Two interchangable packs
2. One pack has 22 1,2V cells
3. General capacity of one pack is 15 Ah
4. With one pack at velocity 0,5 m/s can the robot travel to

distance 2km

SLIDE 21

Laser scanner with camera view Laser scanner with camera view (OMR) (OMR)

SLIDE 22

Autonomous movement in park like

environment

Object detection
Object recognition
Path recognition
Obstacle avoiding
Performing autonomous tasks with arm

Goals with OMR Goals with OMR

SLIDE 23

Models of robots – Adams, MRS Models of robots – Adams, MRS
