1 ICAO Meteorological Information Exchange Model (IWXXM) Implementation Workshop (Paris, France, 5-6 November 2019) Vladimir Tsukanov, Aviamettelecom of Roshydromet Implementation of OPMET Data Exchange, using IWXXM 2 TAC - IWXXM Exchange

SLIDE 1

Vladimir Tsukanov, Aviamettelecom of Roshydromet

ICAO Meteorological Information Exchange Model (IWXXM) Implementation Workshop (Paris, France, 5-6 November 2019)

SLIDE 2

2 Implementation of OPMET Data Exchange, using IWXXM

Converter

ТАС to IWXXM

TAC - IWXXM Exchange

IWXXM Collection

Airports in the Russian Federation NOC Erevan NOC Minsk NOC Nur-Sultan NOC Bishkek NOC Dushanbe NOC Ashgabad AFS ICAO

TAC Bulletins

NOC Moscow MSS NOC Tashkent FSS RMDCN WMO

Gateway to AMHS

ROC ROC ROC RTH RTH RTH

SLIDE 3

3 Implementation of OPMET Data Exchange, using IWXXM

Gateway to AMHS in NOC Moscow

«Monitor-client-AMHS» User Agent with gateway option was developed by “Monitor Soft” Ltd company (Russian Federation)

SLIDE 4

4 Implementation of OPMET Data Exchange, using IWXXM

NOC Moscow converts OPMET data (METAR & TAF) from TAC to IWXXM from airports in 8 countries

Country Number of airports Armenia 2 Belarus 7 Kazakhstan 19 Kyrgyzstan 3 Russian Federation 71 Tajikistan 4 Turkmenistan 5 Uzbekistan 11 Total: 122

SLIDE 5

5 Implementation of OPMET Data Exchange using IWXXM

IWXXM converter implementation in NOC Moscow

Types of OPMET data Status METAR & TAF (TT=LA/LC/LT) Ok, IWXXM v. 2.1.1 SIGMET & AIRMET (TT=LS/LW)

January 2020

Other types of OPMET data (TT=LK/LP/LU/LV/LY)

November 2020

SLIDE 6

6 Implementation of OPMET Data Exchange using IWXXM

Web-service of the IWXXM (in manual mode)

http://meteocenter.ru/iwxxm

SLIDE 7

7 Implementation of OPMET Data Exchange using IWXXM
