The Center for
 Brains, Minds and Machines

tomaso poggio CBMM McGovern Institute, BCS, LCSL, CSAIL MIT

I-tutorial

Learning of Invariant Representations in Sensory Cortex

2

1.Intro and background 2.Mathematics of invariance 3.Biophysical mechanisms for tuning and pooling 4.Retina and V1: eccentricity dependent RFs; V2 and V4: pooling, crowding and clutter 5.IT: Class-specific approximate invariance and remarks

I-theory

Learning of Invariant Representations in Sensory Cortex

3

Class 24 Mon Dec 1 Learning Invariant Representations: Retina and V1: eccentricity dependent RFs; V2 and V4: pooling, crowding and clutter

4

Summary of previous class

Hebb synapses imply that the tuning of the neuron converges to the top eigenvector of the covariance matrix of the “frames” of the movie of objects transforming. The convergence follows the Oja flow Different cells are exposed (during development) to translations in different directions.

Unsupervised ¡tuning ¡(during ¡development) ¡ and ¡eigenvectors ¡of ¡covariance ¡matrix

Linking ¡Conjecture

• Predicts Gabor-like tuning of simple cells in

V1

• Qualitatively predicts tuning in V2/V4
• Predicts/justifies mirror-symmetric tuning
• f cells in face patch AL

The ventral stream hierarchy: V1, V2, V4, IT A gradual increase in the
 receptive field size, in the complexity of the preferred stimulus, in tolerance to position and scale changes

Kobatake & Tanaka, 1994

Properties of the Ventral Stream

8

End Summary

Note: ¡we ¡focus ¡on ¡the ¡ sampling ¡layout ¡of ¡the ¡ retinal ¡ganglion ¡cells ¡ (RGCs) ¡-­‑ ¡the ¡outputs ¡of ¡ the ¡retina.

(Also: ¡focusing ¡on ¡the ¡Parvo ¡ pathway, ¡ignoring ¡Magno.)

Receptive field size vs. eccentricity - HW

Hubel and Wiesel, 1971

Scatter of receptive field sizes in V1

Schiller, P ., Finlay, B., Volman S. Quantitative Studies of Single Cells Properties in monkey striate cortex, 1976

Retina and V1: eccentricity dependent RFs

• Inverted truncated pyramid
• Fovea and foveola
• Scale and position invariance

to have invariant representation

Usual recipe:

• memorize a set of images/objects called templates and for

each template memorize observed transformations

• to generate an invariant signature
• compute dot products of transformations with image
• compute histogram of the resulting values

13

s-x space: definitions

15

Geometry of scaling

16

The magic window for pooling over scale and x-y shifts

17

Sampling in the window

18

Sampling in the window

19

Magic window in V1

25’ !!! total 40x40 units 5 degree! total 40x40 units

Anstis, 1974

“Prediction” of Anstis observation

V2 and V4: pooling, crowding and clutter

• Why multilayer pooling
• Decimating the array
• Bouma’s law

22

Empfeh len
 11






We All Live In A Yellow Subroutine

Hierarchies of magic HW modules: key property is covariance

l=4 l=3 l=2 l=1

HW module

24

• Compositionality: signatures for wholes and for parts of

different size at different locations

• Minimizing clutter effects
• Invariance for certain non-global affine transformations
• Retina to V1 map

Why V1, V2, V4, IT?

V2 and V4: pooling, crowding and clutter

• Why multilayer pooling
• Decimating the array
• Bouma’s law

¡ ¡Top ¡module

∑ = signature⋅vector ⋅

Associative memory

28

V1 and V2…

(from ¡Freeman ¡& ¡Simoncelli ¡2011)

Magic theory “predicts” eccentricity dependence of M in V1, V2, V4, IT

30

Predictions

• Very small foveola ~25’
• Scale invariance more important than position invariance
• Uniform scale invariance at “all” eccentricities
• Shift invariance proportional to spatial frequency
• Bouma’s law for crowding d= b x
• Role of V2 (b=0.5)

Hierarchical network

l=4 l=3 l=2 l=1

HW module

Predictions

• Very small foveola ~25’
• Scale invariance more important than position invariance
• Uniform scale invariance at “all” eccentricities
• Shift invariance proportional to spatial frequency
• Crowding in the fovea d=2’40” in fovea
• Bouma’s law for peripheral crowding d= b x (role of V2 b=0.5)

The predictions are:

• a. Consider a small target, such as a 5’ width letter, placed in the center of

the fovea, activating the smallest simple cells at the bottom of the inverted

• pyramid. The smallest critical distance to avoid interference should be the size of

a complex cell at the smallest scale, that is d=1’ 20” in V1 and d=2’40” in V2. If the letter is made larger, then the activation of the simple cells shifts to a larger scale and thus does the critical spacing which is proportional to the size of the

• target. It is remarkable that both these predictions match quite well Figure 10 in

Levi and Carney, 2011.

• b. Usually the target is just large enough to be visible at that eccentricity

(positive say). The critical separation for avoiding crowding outside the foveola is 12) d ~ b x since the RF size of the complex cells increases linearly with eccentricity, with depending on the cortical area responsible for the recognition signal. Thus the theory ``predicts'' Bouma's law , (Bouma, 1970) of crowding!

Predictions on crowding

35

36

37

38

Collaborators (MIT-IIT, LCSL) in recent work

• F. Anselmi, J. Mutch , J. Leibo, L. Rosasco, A. Tacchetti, Q. Liao

+ + Evangelopoulos, Zhang, Voinea Also: ¡ ¡L. ¡Isik, ¡S. ¡Ullman, ¡S. ¡Smale, ¡ ¡C. ¡Tan, ¡M. ¡Riesenhuber, ¡T. ¡Serre, ¡G. ¡Kreiman, ¡S. ¡Chikkerur, ¡

• A. ¡Wibisono, ¡J. ¡Bouvrie, ¡M. ¡Kouh, ¡ ¡ ¡J. ¡DiCarlo, ¡ ¡C. ¡Cadieu, ¡S. ¡Bileschi, ¡ ¡L. ¡Wolf, ¡ ¡
• D. ¡Ferster, ¡I. ¡Lampl, ¡N. ¡Logothe[s, ¡H. ¡Buelthoff

40
