SLIDE 1
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
2
Introduction
- A multitude of small details in columns, corners or
connections decide whether a building will survive
- r not
Hyde Systems for Earthquake Protection of Residential Buildings - - PowerPoint PPT Presentation
Hyde Systems for Earthquake Protection of Residential Buildings - - PowerPoint PPT Presentation
Hyde Systems for Earthquake Protection of Residential Buildings Uwe E. Dorka Stephan Gleim Introduction A multitude of small details in columns, corners or connections decide whether a building will survive or not Hyde Systems in
SLIDE 2
SLIDE 3
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
3
Introduction
- Quality control is overwhelmed by this
- requirement. Its like a game of chance, even for
the same type of building in the same location
SLIDE 4
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
4
Introduction
- Therefore, we need new
structural concepts adapted to earthquakes
- Buildings form mechanism
during earthquakes
- So why not introduce
efficient mechanisms up front and control them?
SLIDE 5
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
5
Efficient Structural Control systems for earthquake protection
SLIDE 6
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
6
A closer look at Hyde systems
- A typical residential building of the Balkan region
SLIDE 7
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
7
A closer look at Hyde systems
- subjected to a typical Balkan earthquake
SLIDE 8
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
8
A closer look at Hyde systems
- designed as a rigid body mechanism suitable for the application
- f Hydes
SLIDE 9
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
9
A closer look at Hyde systems
- requires only a simple structural model
SLIDE 10
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
10
A closer look at Hyde systems
- that has been verified with large-scale pseudo-dynamic tests at
JRC-Ispra
- n a !/2-scale steel frame with shear-panels
SLIDE 11
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
11
A closer look at Hyde systems
- and on a full-scale masonry in-filled
rc-frame with friction connections
SLIDE 12
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
12
A closer look at Hyde systems
- This model yields a Hyde
system design based on conventional linear limit states in the seismic link
SLIDE 13
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
13
A closer look at Hyde systems
- The comparison with a
conventional structure shows:
- Reduced stresses and
reduced deformations
SLIDE 14
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
14
Conclusions
- Conventional structures cannot be produced with the quality
required for earthquake safety of large numbers of buildings due to a multitude of critical details: Too much can and will go wrong
- Structural control systems are superior in performance,
reliability and price and have become a viable alternative
- Base Isolation, Tendon Systems, Pagoda Systems and Hyde
Systems use passive or semi-active control and may be used in new structures as well as in structural rehab
- The Hyde system is of particular advantage providing a better
performance and price for low to medium high residential or mixed residential-commercial buildings
- The Hyde system is the most economical concept to retrofit soft
storey buildings. Tenant activities are hardly affected.
SLIDE 15
Hyde Systems in Residential Buildings Uwe E. Dorka, Stephan Gleim
15
