HOLDING BACK THE FLOOD By Gabe Lederman, Mid-Atlantic Territory Manager, Wapro, LLC

HOLDING BACK THE FLOOD – Sponsored by NJAFM and Presented by Gabe Lederman Continuing Education Compliance Statement

This course is being offered as CPC credits to Certified Floodplain Managers and New Jersey Professional Engineers. To be compliant, certain procedures and record keeping are required by NJAFM. If you will be claiming the CPC credit, you must register your attendance on the NJAFM website and return the training evaluation form. Upon receipt of the training evaluation form, NJAFM will email you a certificate indicating the number of credit hours received for this instruction. A copy of the attendance record will be kept on file with these course credits. CPC credits are issued based upon the time of instruction. 50 minutes of instruction content equals 1 CPC credit. This course is scheduled to begin at 12:00 NOON and conclude no earlier than 1:00pm thus providing 1 CPC credit. PLEASE NOTE THAT THIS ON-LINE PRESENTATION IS BEING RECORDED AND WILL BECOME THE PROPERTY OF NJAFM. IF YOU AS A PARTICIPANT DO NOT DESIRE TO BE RECORDED, PLEASE DISCONTINUE FROM THE PRESENTATION. YOUR CONTINUED PARTICIPATION IN THIS EVENT PROVIDES YOUR INDIVIDUAL AUTHORIZATION TO NJAFM THAT YOU ACKNOWLEDGE AND CONSENT TO THE RECORDING OF THIS PRESENTATION AND CONTINUED USE BY NJAFM.

Speaker Biography Gabe Lederman Wapro, Inc. Mid-Atlantic Territory Manager Office phone number:732-586-7731 Office fax number: 609-208-0660 Email: gabe.lederman@wapro.com Presenter profile The Author, Gabe Lederman, has worked in the water segment for 19 years

• worldwide. He has been involved in projects in Delaware, Maryland, New

York, New Jersey, Pennsylvania, and throughout the Middle East primarily working with city councils to ensure their infrastructure is future-proof in terms of flood prevention caused by back flow in stormwater systems.

HOLDING BACK THE FLOOD

Wapro solutions protect against stormwater and backflow flooding. Protecting people and property

INTRODUCTION OF WAPRO AB In Line Storm Water Check Valves

WaStop In Line Check Valve

FUNCTION

• Low life cycle cost – pulsating flow ensures

pipes up-/downstream are kept clear of debris

• Superior construction materials such as

stainless steel 304 and 316, PVC, PP and PE

• Many dimensions
• Stainless steel 4” – 72” standard & non-

standard pipes

• PVC 3” – 8”
• Fast and easy installation
• Light Weight
• Lowest head loss amongst inline check valves
• Stops liquids, gases, odour, insects and small

animals from entering pipe system/housing

WASTOP: HEAD LOSS COMPARATIVE ASSESSMENT

WASTOP: WEIGHT COMPARATIVE ASSESSMENT

Valve Size (Inches) WaStop Weight (lbs) Checkmate Weight (lbs) % Difference 3 0,62 3,09 500% 4 1,54 3,31 214% 5 1,98 4,41 222% 6 5,20 8,82 169% 8 7,72 13,23 171% 8 10,14 17,64 174% 9 13,67 22,05 161% 10 22,05 37,48 170% 14 39,68 110,23 278% 16 52,91 114,64 217% 18 61,73 143,30 232% 20 63,93 224,87 352% 24 105,82 302,03 285% 30 165,35 500,45 303% 36 255,74 828,94 324% 42 310,85 1424,19 458% 48 639,34 1801,18 282% 60 1415,37 3315,75 234% 72 2028,25 6100,19 301%

PUMPING STATION – SIMRISHAMN, SWEDEN

STORMWATER OUTLET – HIGHLANDS BORO, NJ

STORMWATER OUTLET – LOMMA, SWEDEN

STORMWATER FLOODING STOPPED - COLUMBIA, SC USA

BRICK TOWNSHIP – NEW JERSEY, USA

2018 TOWNSHIP OF BRICK FLOODPLAIN MANAGEMENT PLAN ANNUAL PROGRESS REPORT as prepared by an independent engineering firm stated that “Outfalls in the Township continue to back up at high tide and during storms. To combat this issue, check valves have been installed on outfall pipes…additional installation of check valves are planned dependent on funding”

BRICK TOWNSHIP – NEW JERSEY, USA

The Brick Township engineer “relayed her approval of your product as we were working on the 2019 Floodplain Management Plan update for Brick…I’m happy to have your contact information on hand for clients who are looking for additional options for check valves. Keep up the good work!”

STARLAND BALLROOM PROTECTED – NEW JERSEY, USA

FLOOD MITIGATION - ST AUGUSTINE, FL

HMGP PHASE II PROJECT - OCEAN CITY, MARYLAND

TREATMENT PLANT FLOODING - DEPEW, NY

STORMWATER OUTFALLS – DAYTON, OHIO

VARIOUS INSTALLATIONS

Elliptical Flanged-Grouted Install Flex Coupling Install Angled Flanged w/ Bypass Bent Tab – RCP Install Vertical Flanged – Yard Drain Tab to Headwall Install WaStop installed in manhole Catch Basin installation

CUSTOMIZABLE SOLUTIONS

WaStop Wastewater | Stormwater | Odor protection

SHORT BODY VALVES FOR CATCH BASINS

SPECIAL FLANGE SHORT BODY REVERSE INSTALL

CUSTOMIZABLE SOLUTIONS

NJDOT Style A

QUAD VALVE TO FIT INTO A STRUCURE

MINIMIZED MAINTENENCE - KEREHANA BAY, NEW ZEELAND

CUSTOM ELLIPTICAL FLANGE – MONMOUTH BEACH, NJ

BRISBANE PROTECTED BY 2 X 72” WASTOPS

BRISBANE PROTECTED BY 2 X 72” WASTOPS

Thank you for attending our webinar.

For more information please visit our webiste – www.wapro.com Wastewater | Stormwater | Odor protection

COURSE EVALUATION HOLDING BACK THE FLOOD – Sponsored by NJAFM and Presented by Gabe Lederman

As a reminder, to claim the CPC credit, you must register your attendance on the NJAFM website and return the training evaluation form or email indicating you are self- certifying your participation. NJAFM will email you a certificate indicating the number of credit hours received for this instruction. A copy of the attendance record will be kept

• n file with these course credits.
