National Gallery of Art National Gallery Flood Prevention of Art Strategy After June 2006 Flood David Samec, P.E., CFM Chief of Facilities Management 1 Extent of Flooding Up the Hill Flood Flow Flood Flow NGA Located in Dashed Area

slide-1
SLIDE 1

National Gallery

  • f Art

1

Flood Prevention Strategy After June 2006 Flood

David Samec, P.E., CFM Chief of Facilities Management

National Gallery of Art

slide-2
SLIDE 2

Extent of Flooding “Up the Hill”

2

NGA Located in Dashed Area

Flood Flow Flood Flow

slide-3
SLIDE 3

NGA Flood Prevention Strategy Assess Areas of Highest Risk

3

1 6 3 2 4 5 7

slide-4
SLIDE 4

NGA Flood Prevention Strategy What to Use? (circa 2006)

4

Water-filled cofferdams Water-absorbing gel bags

slide-5
SLIDE 5

NGA Flood Prevention Strategy Caches and Pre-Positioning

5

slide-6
SLIDE 6

NGA Flood Prevention Strategy Caches and Pre-Positioning

6

slide-7
SLIDE 7

Aqua Dam Increased Facility Entrance Elevations as Required for a Flood Event

7

slide-8
SLIDE 8

8

Modular Flood Barriers Used by DC Metro 9th Street and Constitution Ave.

slide-9
SLIDE 9

9

NGA Flood Barrier Rehearsal 2017

  • One person

could put this together

slide-10
SLIDE 10

Vulnerabilities

10

  • If barriers fail, everything is vulnerable
  • Anything more than a 200-year storm event would cause catastrophic

flooding

  • Constant concern about Constitution Avenue Storm Sewer backup into

building floor drains
