Heavy goods vehicle charge in the Netherlands On the road to a reliable and user-friendly charging system HGVC in the context of 1 Infrastructure and Water Management 2 Introduction to HGVC in the Netherlands Program 3 Architecture of

slide-1
SLIDE 1

Heavy goods vehicle charge in the Netherlands

On the road to a reliable and user-friendly charging system

slide-2
SLIDE 2

Program

HGVC in the context of Infrastructure and Water Management Introduction to HGVC in the Netherlands Architecture of HGVC in the Netherlands Lunchbreak EETS and work packages tracks

1 2 3 4 5

slide-3
SLIDE 3

Code of conduct

  • Participation in the market interaction information meeting is not obligatory in order to

participate in future market consultations, accreditations or calls for tender.

  • Parties cannot derive any rights from their participation in this information meeting.

Regarding questions:

  • We aim to be as transparent as possible, to share information where available and final.
  • If decision-making is not yet clear or final, no anticipation is made.
  • Questions are answered as much as possible during the sessions, but you can also come

back to them later in writing.

  • Orally provided information (by VWH team members) has no status.
  • If relevant: make sure that a question is asked about it during a plenary session, or make

a comment, or submit the question or comment in writing. Orally provided information cannot be invoked later.

3

slide-4
SLIDE 4

André Belonje, director Finance

Introduction

HGVC in the context of Infrastructure and Water Management

slide-5
SLIDE 5
  • HGVC as soon as possible
  • Following neighbouring

countries

  • In consultation with the

sector

Coalition Agreement 2017

5

slide-6
SLIDE 6
  • Safe, robust and sustainable

traffic and transport system

  • Transition in mobility

Mobility Framework

6

slide-7
SLIDE 7
  • Safety
  • Climate
  • Robust Road Network

Challenges

7

slide-8
SLIDE 8
  • Mobility framework
  • Politics
  • Sustainability
  • Pay for use
  • Technology
  • Redistribution of the revenue

Context

8

slide-9
SLIDE 9

The Heavy Goods Vehicle Charge in two minutes

9

slide-10
SLIDE 10

Tomas de Laat, Program Manager HGVC

Heavy goods vehicle charge

Introduction in the Netherlands

slide-11
SLIDE 11

Introduce HGVC with a view to a level playing field:

  • foreign and Dutch HGV
  • abolish the tax on heavy

motor vehicles

  • reduce the motor vehicle tax
  • n heavy goods vehicles
  • revenues for innovation and

sustainability in the transport sector.

Introduction

11

slide-12
SLIDE 12

Policy framework

  • Vehicles
  • Exemptions
  • Tariff setting and

differentiation

  • Collection and supervision
  • Enforcement
  • Redistribution of the revenue
  • Effects of the HGVC
  • Road network

12

Main topics

slide-13
SLIDE 13

Phases and planning

13

slide-14
SLIDE 14
  • Multi-year revenue recycling

programme

  • The funds are available

after the introduction of the HGVC in 2023; pre- financing of measures is therefore not possible. Goals

  • Create a sustainable

transport system

  • Promote a smart and

innovative transport system

Redistribution of the revenue

slide-15
SLIDE 15
  • Transport sector
  • Road authorities
  • The public

Collaborations

15

slide-16
SLIDE 16
  • On the road to a reliable and

user-friendly charging system

  • Towards a successful route

to outsourcing

Why this meeting?

16

slide-17
SLIDE 17

Coffee break

slide-18
SLIDE 18

Hans Oortwijn – Enterprise Architect

Heavy Goods Vehicle Charge

The architecture

slide-19
SLIDE 19

The basics

TOLL CHARGER SERVICE PROVIDER USER

A Service Provider dominant scenario (based on GNSS)

GNSS Navigation DSRC On Board Unit Classification ANPR License Plate

slide-20
SLIDE 20

The EETS concept

20

TOLL CHARGER EETS SERVICE PROVIDERS

slide-21
SLIDE 21

TOLL CHARGER EETS SERVICE PROVIDERS

Main service provider

MAIN SERVICE PROVIDER

slide-22
SLIDE 22

Heavy goods vehicle charge

The architecture

Registration & collection

22

slide-23
SLIDE 23

Estimated numbers

665.000 Non-active foreign trucks / day (with OBU for the Netherlands) 25.000 Non-active dutch trucks / day (with OBU for the Netherlands) 100.000 Active dutch trucks / day (with OBU for the Netherlands) 60.000 Active foreign trucks / day (with OBU for the Netherlands) 850.000 On Board Units In the Dutch EETS Domain

slide-24
SLIDE 24

Overall view – the happy flow

01-DNH-1

T T

GSM

Service Providers Tollcharger

Vehicle Holder

Contract, Invoice & Payment Registration Data Contract & Payments GNSS (GPS Satellite Navigation) Declarations

slide-25
SLIDE 25

Registration & Collection

25

Ministerie van Infrastructuur en Waterstaat Toll Charger (Back Office) On Board Unit Service Provider (Back Office) User ISO 17575-3

  • Context data

ISO 17575-1

  • Charging data

ISO 12855

  • Toll Declarations
  • Billing Details
  • Payment Announcement
  • Trust objects
  • Contractual Info
  • Payment
  • General Questions
  • Public Information
  • Contract
  • Invoice
  • Customer Information
  • Payment
  • Questions

ISO 12855

  • Trust objects
  • Toll Context Data
  • Financial management
  • Revenue Assurance
  • Contract Management
  • Public Information
slide-26
SLIDE 26

Heavy goods vehicle charge

The architecture

Supervision & enforcement

26

slide-27
SLIDE 27

Enforcement numbers

27

70.000 Passages / Day through 30 moveable units 520.000 Passages / Day through 62 fixed gantries 180 million Passages / Year

slide-28
SLIDE 28

Overall view – monitoring & enforcement

28 Enforcement (Fixed, Moveable & Mobile)

Toll Charger Service Providers

Vehicle Holder

Sanction & Payment Control Data Enforcement Data Objection & Appeal

slide-29
SLIDE 29

Systems Architecture

Toll Charger

DigiNetwork Internet Road infra

Toll Service Providers

Mobile Toll Charger Monitoring , Enforcement & Control Center Toll Declarations, etc. Traffic Events On Board Equipment Roadside Equipment Back Offices Service Providers Back Office Roadside Equipment DSRC Toll Charger Fine Collection Toll Charger Levy Collection

Ꞓ

Contract

Ꞓ Ꞓ Ꞓ

Contract Payment Payment Payment Payment Fine ANPR GNSS ISO 12855 Objection & Appeal
slide-30
SLIDE 30

Systems Architecture

work & procurement packages

30

Toll Charger

DigiNetwork Internet Road infra

Toll Service Providers

Mobile Toll Charger Monitoring , Enforcement & Control Center Toll Declarations, etc. Traffic Events On Board Equipment Roadside Equipment Back Offices Service Providers Back Office Roadside Equipment DSRC Toll Charger Fine Collection Toll Charger Levy Collection

Ꞓ

Contract

Ꞓ Ꞓ Ꞓ

Contract Payment Payment Payment Payment Fine ANPR GNSS ISO 12855 Objection & Appeal

Work package 11 Work package 10 Work package 4 Work package 8 Work package 9 Work packages 2 & 3 Service providers (EETS providers & Main Service Provider) Observation Datacontrolcentre Tollcharger (Control & Enforcement) Systems of the Tollcharger Finance Public Fine Collection Work package 1 Domain Context data Internal interface – between work packages Work package 6 Information campaign Work package 7 Accreditation Service Providers Work package 5 VWH Information point Tollcharger (Physical Enforcement) Package 12 Gantries

slide-31
SLIDE 31

Systems Architecture

Control Centre – Details

Roadside Equipment BackOffice Service Provider On Board Unit Controlecentrum Supervision & Enforcement Datacollection & Registration Declarations Exception Lists White Lists Observations Declarations Exception List Observation Check Deviations (Analytics) Deviations Exemptions Rating Deviations (Case Management) Image (Optionel) Enforcement data Movements Traffic Event Signal List OBU Data International Vehicle registration Dutch Vehicle Registration Signal List Analyse / Investigation patterns) BackOffice Charge Declarations Payment Announcements Charge Contract Management Contract issues Labelling Fine Update Roadside Equipment Enforcement Register Imposing Fine Fine Collection (Administrative) Handling Objections & Appeals Fine Collection (Physical) Inspection ABC intervention state Observation Observation Registration signaal BackOffice Wegkantapparatuur ISO 12855 ISO 12813 ISO 14906 ISO 13141 € ISO 12855 Observation

Toll Charger

DigiNetwork Internet Road infra

Toll Service Providers

Mobile Toll Charger Monitoring , Enforcement & Control Center Toll Declarations, etc. Traffic Events On Board Equipment Roadside Equipment Back Offices Service Providers Back Office Roadside Equipment DSRC Toll Charger Fine Collection Toll Charger Levy Collection

Ꞓ

Contract

Ꞓ Ꞓ Ꞓ

Contract Payment Payment Payment Payment Fine ANPR GNSS ISO 12855 Objection & Appeal
slide-32
SLIDE 32

Overall View

32

Installation On Board Unit Entering Gross Vehicle Weight Rating, Euro Emission Norm etc.

01-DNH-1

Positioning

T T

On Board Unit recognizes road segment Enforcement (Fixed & Moveable) On Board Unit Calculation Levy Destination

GSM

Toll Charger Observation, Supervision Inspection, Enforcement (EETS) Service Providers Registration & Collection Tollcharger Financial, Accreditation Contractmanagement, Public Campaign

Vehicle Holder Sanction & Payment Contract, Invoice & Payment Registration Data Control Data Declarations Contract & Payments GNSS (GPS Satellite Navigation)

Transport sector Innovation & Sustainability

Revenue Recycling Enforcement Data Declarations

slide-33
SLIDE 33

Lunch break

Please hand in your questionnaires

33

slide-34
SLIDE 34

Questions & answers

34

›

Nikolai Jacobs, Manager Scheme Implementation

slide-35
SLIDE 35

Frédéric Koeman, Manager EETS involvement Rody van Vulpen, Procurement Specialist

EETS & Work packages

Introduction to the tracks

slide-36
SLIDE 36

“Following surrounding countries, a road user charge for heavy goods vehicles (“Maut”) will be introduced as soon as possible. The registration and payment system will be the same as in neighbouring countries, so that no extra equipment is necessary (…)”

Coalition agreement:

  • n-board equipment

36

slide-37
SLIDE 37

Facilitate EETS providers’ access to the market

  • Preferably simultaneously

and as from go-live Appoint a Main Service Provider

  • Coverage of 100% of users

by EETS providers at go-live is unrealistic

Strategy

37

slide-38
SLIDE 38
  • Facts and figures about the

Dutch market

  • Some elementary principles

underlying the EETS domain statement, with particular focus on the Dutch context

  • The road towards go-live

Plenary EETS-track:

38

slide-39
SLIDE 39
  • Products and services are procured from market parties so that

market and government function optimally alongside each other

  • Public domain, mostly enforcement tasks
  • Both for EETS parties and other market parties, competition rules

are complied with within the system

  • Equal treatment of parties who, in principle, are suitable for

carrying out the activities

  • Reduce administrative burdens for participants as much as possible

And…Introduction to the work packages in the procurement track

39

slide-40
SLIDE 40

The contracting authority will be further specified, maybe RWS, DG Mobility, RDW, ILT

Planning

40

EETS track

Plenary EETS session

Procurement track

General Information Session Introduction of work packages Market consultation(s) for selected packages 2019 2020

slide-41
SLIDE 41
  • Main Service Provider

(Hoofddienstaanbieder)

  • Observation (Waarneming)
  • Systems of the Toll Charger

(Systemen van de tolheffer)

Work packages

41

slide-42
SLIDE 42

Choose your track

See you at the reception at 16.30 hrs

42
