HARPER CHALICE GROUP LIMITED 8 Binns Close Coventry CV4 9TB United Kingdom Telephone 02476 421300 Fax 02476 421 309 Email: sales@ harperchalice.co.uk www.harperchalice.co.uk HARPER CHALICE GROUP LIMITED We are the UKs leading manufacturer

slide-1
SLIDE 1

HARPER CHALICE GROUP LIMITED

8 Binns Close Coventry CV4 9TB United Kingdom Telephone 02476 421300 Fax 02476 421 309 Email: sales@ harperchalice.co.uk www.harperchalice.co.uk

slide-2
SLIDE 2

We are the UK’s leading manufacturer and supplier of specialist Electrified and Electronic Perimeter Intrusion Detection Systems. Our Brand names include: -

PulseSecure™ FenceSecure™ WallSecure™

We supply our products and systems worldwide with total manufacturers support at every stage from system surveys, design, installation training and commissioning.

HARPER CHALICE GROUP LIMITED

slide-3
SLIDE 3

Perim eter Defence

slide-4
SLIDE 4

FenceSecure™ & W allSecure™

Perimeter Intrusion Detection Systems

Perim eter Defence

Product overview presentation

slide-5
SLIDE 5

FenceSecure™ & W allSecure™

Perimeter Intrusion Detection Systems

slide-6
SLIDE 6

FenceSecure™

Fence Intrusion Detection System

 Suitable for use on most types of perimeter fences  Can be used in conjunction with fence or wall topping  Provides complete perimeter fence detection

slide-7
SLIDE 7

FenceSecure™

Fence Intrusion Detection System

  • Vibewire™ Piezoelectric sensor cable system
  • Single or Dual zone
  • Modular design
  • IP67 housing
  • Separate sensitivity settings for fence cut and climb
  • Alarm relay outputs
  • Optional monitoring & multiplex control systems
  • Up to 300 m zone lengths
  • Remote test and listen in facility
slide-8
SLIDE 8

How FenceSecure™ works

Vibewire piezoelectric sensor cable is acoustically coupled to the fence or fabric to be monitored against intrusion attempts. The Vibewire sensor cable picks up noises and vibrations that occur when a Would-be intruder attempts to cut ,climb, jack up or penetrate the protected barrier. The Vibewire and SA100 analysers are designed and installed to create detection zones for alarm monitoring and response. Each zone of Vibewire is connected to the SA100 analyser which analyses the signals received from the monitored fabric and discriminates between normal ambient noise and attack signals SA100 analyser features: - 15 sensitivity settings for detection 15 sensitivity settings for cut detection Operates from 12 or 24V DC Low current draw (less than 50mA per dual zones). Independent alarm relays for each zone and tamper Complete monitoring of the sensor cable. The analyser sensitivity is set up to match the fabric being protected for optimum detection and security. Vibewire can be used with zone lengths of up to 300m which is normally optimised at 100m for use with CCTV systems and alarm verification purposes There is an optional remote listen in facility for set up and alarm verification

slide-9
SLIDE 9

How FenceSecure™ works:

FenceSecure™ Vibewire sensor cable mounted on Chain link fence

Vibewire™ sensor cable is applied to the fence or fabric to be protected.

If an intruder attempts to cut climb or jack the protected fence to gain un authorised entry, the signals as detected by FenceSecure™ SA100 seismic analyser and a zone alarm is generated

FenceSecure™

Fence Intrusion Detection System

slide-10
SLIDE 10

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack The signal processing discrim inates betw een norm al background noises and disturbances and the vibrations and signals that occur during various m ethods of attack

Quiescent background noise Screen shot

slide-11
SLIDE 11

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack

Bolt cropper attack Screen shot

slide-12
SLIDE 12

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack

Climb detection Screen shot

slide-13
SLIDE 13

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack

Disc cutter Screen shot

slide-14
SLIDE 14

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack

Hack saw Screen shot

slide-15
SLIDE 15

How FenceSecure™ works:

FenceSecure™

Fence Intrusion Detection System

The SA1 0 0 analyser detects various form s of attack

Gross attack Screen shot

slide-16
SLIDE 16

Vibewire

Piezoelectric sensor cable

  • Uniform detection characteristics
  • High signal to noise ratio
  • Unobtrusive
  • Easy to install
  • Tough UV stabilised outer sheathing
  • Proven performance
  • Vibewire versions supplied in stainless steel sheath for “High Security”

Or difficult installations where extra physical protection is required

FenceSecure™

Fence Intrusion Detection System

slide-17
SLIDE 17

FenceSecure™

Fence Intrusion Detection System

Vibewire™ Piezoelectric sensor cable system

Model: Features/application: VW200 Standard sensor cable for use on chain link and welded mesh fences VW205 Premium sensor cable for use on Palisade, 358 weld mesh and “High Security” Fences VW210 Super sensor cable for use on special applications where maximum sensitivity and signal to noise is required

Note: VW200/SS – VW205SS – VW210SS are as above but supplied in a flexible stainless steel sheath.

slide-18
SLIDE 18

FenceSecure™ + WallSecure™

SA100 Seismic Fabric Mounted Detection Systems

A Complete range of installation components and accessories - It all fits together!

slide-19
SLIDE 19

Perimeter Intrusion Detection

Perimeter intrusion detection systems are zoned for interfacing with CCTV for alarm verification and response

Alarmed premises

Zone 1 Zone 2 Zone 3 Zone 4

FenceSecure™

Perimeter Intrusion Detection System

slide-20
SLIDE 20

FenceSecure™

Fence Intrusion Detection System

slide-21
SLIDE 21

FenceSecure™

Fence Intrusion Detection System FenceSecure

™

Fence Intrusion Detection System Vibewire mounted within flexible stainless steel conduit and secured with stainless steel ties to weld mesh fence

slide-22
SLIDE 22

FenceSecure™

Fence Intrusion Detection System

slide-23
SLIDE 23

Fence Intrusion Detection System Vibewire mounted within screw barrel conduit

FenceSecure™

slide-24
SLIDE 24

FenceSecure™

“High Security Fence Detection System” “High Security fence”

slide-25
SLIDE 25

FenceSecure™

Fence Intrusion Detection System

slide-26
SLIDE 26

Fence Intrusion Detection System gate loops.

FenceSecure™

slide-27
SLIDE 27

FenceSecure + PulseSecure

The winning combination…………..

slide-28
SLIDE 28

WallSecure

™

Wall and Roof Intrusion Detection System

slide-29
SLIDE 29

WallSecure

™

Wall and Roof Intrusion Detection System

slide-30
SLIDE 30

W allSecure

™

Wall and Roof Intrusion detection System for Bonded warehouse and secure storage

slide-31
SLIDE 31

WallSecure

™

Wall and Roof Intrusion Detection System

WallSecure™ Analyser Vibewire sensor cable mounted in conduit tube

slide-32
SLIDE 32

WallSecure

™

Wall and Roof Intrusion Detection System

End of line monitor Vibewire sensor cable mounted in conduit tube

slide-33
SLIDE 33

WallSecure

™

Wall and Roof Intrusion Detection System

WallSecure across boarded up doors and windows

slide-34
SLIDE 34

Your first line of Defence
