Hacking Cell Phone Embedded Systems Keegan Ryan RECON 2017 The Target The Target brendangates The Target Meriac (2010), Churchill Legacy ICLASS Introduced in 2007 Broken in 2010 Master key on every reader Security

slide-1
SLIDE 1

Hacking Cell Phone Embedded Systems

Keegan Ryan – RECON 2017

slide-2
SLIDE 2

The Target

slide-3
SLIDE 3

The Target

brendangates

slide-4
SLIDE 4

The Target

Meriac (2010), Churchill

slide-5
SLIDE 5

Legacy ICLASS

  • Introduced in 2007
  • Broken in 2010
  • Master key on every

reader

  • Security of card reader

broken

  • Protocol reverse

engineered

  • New version of iCLASS

released, but many still use Legacy iCLASS

  • Uses ISO15693

Meriac (2010), Inside Contactless (2004)

slide-6
SLIDE 6

Nexus S

  • Introduced in 2010
  • One of earliest to support NFC, including ISO15693
  • Android source code available
  • Cheap
slide-7
SLIDE 7

Nexus S

Android Application libnfc Library Kernel Driver NFC Controller

  • Try Android app first
  • Transceive raw bytes
  • CRC added automatically,

but we don’t want a CRC

  • Not added by libraries
  • Not added by kernel
  • Must be added by NFC

controller chip

slide-8
SLIDE 8

PN544

  • Separate from Nexus S CPU
  • Powered by host or external field
  • Supports ISO 15693, Mifare, FeliCa
  • Supports firmware upgrades
  • Uses 80C51MX Processor

NXP (2010), Wharton (1980)

DATA CODE

slide-9
SLIDE 9

Investigating the PN544

slide-10
SLIDE 10

Firmware Recovery

  • PHDNLD_CMD_READ
  • Pull from update file
  • Code signing
  • Protected with SHA1 and RSA-1024
  • Introduced after first devices shipped
  • Need a device never updated past Gingerbread

Libnfc-nxp

slide-11
SLIDE 11

FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-12
SLIDE 12

Reverse Engineering

There aren’t any. They don’t exist. No help.

  • Look for strings.
  • Look for CRC constants.
  • Look for usage of the XOR instruction.
  • Just start reversing until we find something

useful.

slide-13
SLIDE 13

FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-14
SLIDE 14

Reverse Engineering

  • Reverse commonly called functions
  • Find switch function
  • Find command switching
  • Trace known command IDs through code
slide-15
SLIDE 15

Reverse Engineering

Libnfc-nxp

slide-16
SLIDE 16

Problem:

FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-17
SLIDE 17

Problem: Missing Code

??? FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-18
SLIDE 18

Problem: Missing Code

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-19
SLIDE 19

Kernel Recovery

  • We understand and can modify FW_CODE
  • FW_CODE doesn’t have access to kernel
  • We can modify PATCH_CODE
  • Don’t know how to trigger PATCH_CODE
  • Want to maximize chances of executing our

code

slide-20
SLIDE 20

Kernel Recovery

PATCH_CODE

slide-21
SLIDE 21

Kernel Recovery

PATCH_CODE

slide-22
SLIDE 22

Kernel Recovery

slide-23
SLIDE 23

Problem: Missing Code

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-24
SLIDE 24

Problem: Missing Code

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-25
SLIDE 25

Reverse Engineering Kernel Reverse Engineering

Still aren’t any. Still don’t exist. No help.

  • Look for strings.
  • Look for CRC constants.
  • Look for usage of the XOR instruction.
  • CRC creation is done by hardware
  • Still not impossible, but we need a new approach
slide-26
SLIDE 26

Wireless Protocols

slide-27
SLIDE 27

SDR Setup

Antenna Upconverter Radio Signal Source

slide-28
SLIDE 28

SDR Setup

<s> 10 01 10 00 01 00 00 00…

slide-29
SLIDE 29

Transfer Speed

  • ISO15693 has two modes:
  • Slow (1.65 kbps)
  • Fast (26.48 kbps)
  • Nexus S uses slow mode
  • ICLASS only uses fast mode

Inside Contactless (2004)

slide-30
SLIDE 30

Problem: Transfer Speed

  • Capability probably

exists, but is unused.

  • Find transmission code
  • Loads settings from

EEPROM/CFG

  • Only uses one set of

values

  • Swap around values in

EEPROM/CFG

  • Fast mode!
slide-31
SLIDE 31

Mifare

Libnfc-nxp

slide-32
SLIDE 32

Problem: Checksum Generation

FW_CODE Command Handler RF Transmit MIFARE Setup (CRC) MIFARE Setup (No CRC) ISO15693 Setup (CRC) Android Find differences here Apply difference here

slide-33
SLIDE 33

Patching the Kernel

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-34
SLIDE 34

Exploitation

slide-35
SLIDE 35

Patching Checksum Generation

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-36
SLIDE 36
slide-37
SLIDE 37

Putting It All Together

KERNEL_CODE FW_CODE PATCH_TABLE PATCH_CODE EEPROM/CFG

slide-38
SLIDE 38

Demo

slide-39
SLIDE 39

Demo

slide-40
SLIDE 40

Future Research What can be done with a hacked NFC controller?

  • Surreptitiously read a badge
  • Information storage
  • Information exfiltration
slide-41
SLIDE 41

Future Research

  • What other embedded systems do we carry

everywhere?

  • Bluetooth
  • USB controller
  • Baseband radio
  • Camera
  • Fingerprint reader
  • What could you make these systems do?
slide-42
SLIDE 42

The End

Keegan Ryan Keegan.Ryan@nccgroup.trust @inf_0_

slide-43
SLIDE 43

Bypassing Firmware Signing?

doSecureDownload(); if (*flag == 0xa55a) doInsecureDownload(); else

slide-44
SLIDE 44

Bibliography

  • Brendangates. “Badge reader.” Licensed under a Creative Commons

Attribution 2.0 Generic (CC BY-NC-ND 2.0). Accessed 11 June 2017. https://www.flickr.com/photos/brendangates/2384518688. Churchill, Sam. “nfc.phone.” Licensed under a Creative Commons Attribution 2.0 Generic (CC BY 2.0). Accessed 11 June 2017. https://www.flickr.com/photos/samchurchill/5181496553 Inside Contactless. "Datasheet PicoPass 2KS." Rapport technique (2004). Libnfc-nxp Library. Accessed June 11, 2017. https://android.googlesource.com/platform/external/libnfc-nxp. Meriac, Milosch. "Heart of darkness-exploring the uncharted backwaters of hid iclass (TM) security." In 27th Chaos Communication Congress. 2010.

  • NXP. “NXP NFC controller PN544 for mobile phones and portable

equipment." On Line: http://www.nxp.com/documents/leaflet/75016890.pdf (2010). Wharton, John. "An Introduction to the Intel-MCS-51 Single-Chip Microcomputer Family." Intel Corporation (1980).
