SLIDE 1
Gyre Index and blue whiting: Environment and recruitment
Jan Arge Jacobsen & Hjálmar Hátún
Gyre Index and blue whiting: Environment and recruitment Jan Arge - - PowerPoint PPT Presentation
Gyre Index and blue whiting: Environment and recruitment Jan Arge - - PowerPoint PPT Presentation
Gyre Index and blue whiting: Environment and recruitment Jan Arge Jacobsen & Hjlmar Htn The basis currents and fronts! The Subpolar Gyre and the marine climate Subpolar Gyre Labrador Sea convection Subtropical Gyre (Hatun
SLIDE 2
SLIDE 3
SLIDE 4
SLIDE 5
SLIDE 6
Subtropical Gyre Subpolar Gyre Labrador Sea convection (Hatun et al., Science 2005)
The Subpolar Gyre and the marine climate
SLIDE 7
Source flows to the Rockall Region
SLIDE 8
Here we show that the spawning distribution of blue whiting is variable, regulated by the hydrography west of the British Isles. When the North Atlantic subpolar gyre is strong and spreads its cold, fresh water masses east over Rockall Plateau, the spawning is constrained along the European continental slope and in a southerly position near Porcupine Bank. When the gyre is weak and conditions are relatively saline and warm, the spawning distribution moves northwards along the slope and especially westwards covering Rockall Plateau ! (Canadian Journal of Fisheries and Aquatic Science, 2009)
SLIDE 9
R I
Salinity in the Irminger Current (obs.) Salinity at Rockall (obs.) Gyre index (GI)
Record high T and S
The Subpolar Gyre and the marine climate
Weak. Strong
SLIDE 10
Simulated temperature Cold Warm
The Subpolar Gyre and the marine climate
Large mid-1990s changes!
SLIDE 11
Blue whiting
Blue whiting: Spawning-feeding distributions/migrations
Spawning Mackerel Herring Feeding
SLIDE 12
Pre-1995
(cold and low-saline)
Blue whiting spawning distribution
Catches
Scotland
SLIDE 13
Catches
Post-1995
(warm and saline)
Scotland
Blue whiting spawning distribution
SLIDE 14
Blue whiting Migration
SLIDE 15
Cold years – Faroe-Shetland Ch.
SLIDE 16
Warm years – Iceland-Faroe region
Stronger prim. production and probably more food
SLIDE 17
Stor endringer i kolmule bestanden
A threefold blue whiting stock size increase
SST (in Rockall Area)
Stock size (<- shifted 3 years)
SLIDE 18
Warm (1998-2003) Cold (1990-1996)
Spatial Shift
(Blue whiting catches – all nations)
1997
Spawning distribution (Hátún et al. 2009b) Post-spawning migration (Hátún et al. 2009a)
SLIDE 19
Need to understand the processes
(Payne et al., 2011, in press) North Atlantic Sub-polar gyre
Recruitment
Gyre Index alone cannot explain recruitment
Atmospheric forcing
SLIDE 20
Wind stress curl
UK
Green-
land
Anticyclonic (Curl <0) Wind stress (ws) - arrows (NCAR/NCEP)
Curl (ws)
[N/m ]
2
Cyclonic (Curl >0)
SLIDE 21
WSC = 0 Subtropical Gyre Subpolar Gyre
SLIDE 22
Subpolar Gyre ”Inter-gyre region” ’Window’ WSC = 0 Subtropical Gyre
SLIDE 23
Subtropical Gyre Subpolar Gyre
Varying proportions “drifting” south-/northwards from Porcupine Bank due to environment?
SLIDE 24
Recruitment and wind stress curl
Spain
R
Recruitment vs. WSC
SLIDE 25
Recruitment and wind stress curl
SLIDE 26
Recruitment and wind stress curl, shifted on year ahead
Northward transport Improved Recruitment?
SLIDE 27
Blue whiting May 2011
10 20 30 40 50 60 5 10 15 20 25 30 10 15 20 25 30 35 40 2 4 6 8 10 12 15+
% %
Length in cm age i n years
Improved recruitment?
SLIDE 28
So is the recruitment predictable?
Not with certainty - But certainly not if the marine climate is ignored
SLIDE 29
